2003 NISSAN MAXIMA display

2. Select theSetting key .
The [SETTINGS] screen will be displayed.
3. Select the
Edit Address Book key .4. Choose a stored location where you want to
set the icon.5. Select the
Landmark Icon key .
6. Choose an icon.
INV0363
INV0371INV0372
INV0373
HOW DO I USE THE ADDRESS BOOK FEATURE?
7-7

The left one on the key is a planview icon and
the right one on the key is a BirdviewTMicon.
The icon of the stored location will be set.
INFO:

T o go back to the screen displaying the cur-
rent vehicle position, press the
MAP button.

If you select the
Previous key , the screen
will go back to the one in procedure 5.

If you alter the icon of the stored location,the icon on the map will also change.
INV0374
HOW DO I USE THE ADDRESS BOOK FEATURE?
7-8

ADJUSTING THE STORED AD-
DRESS BOOK ENTRIES
Y ou can easily adjust the point of the stored
location by the joystick.
1. Change to the current vehicle location
screen.
2. Select the
Setting key .
The [SETTINGS] screen will be displayed.
3. Select the
Edit Address Book key .4. Choose the
Map key next to the stored
location you want to adjust.5. Use the joystick to set the new location.
6. Select the
Adjust key .
INV0363
INV0376INV0377
INV0378
HOW DO I USE THE ADDRESS BOOK FEATURE?
7-10

The location is updated, and the screen goes
back to the one in step 5 after the update mes-
sage is shown.
INFO:
T o go back to the screen displaying the current
vehicle position, press the MAP button.
DELETING STORED LOCA-
TIONS
Y ou can delete from memory the stored loca-
tions you no longer need.
1. Change to the current vehicle location
screen.
2. Select the
Setting key .
The [SETTINGS] screen will be displayed.3. Select the
Edit Address Book key .
4. Select the location you want to delete.5. Select theDelete key .
6. The system will ask for a confirmation. If
INV0363
INV0379
INV0380
INV0381
HOW DO I USE THE ADDRESS BOOK FEATURE?
7-11

correct, touch theY es key . The location
will be deleted, and the screen goes back
to the one in step 4 after the deletion mes-
sage is shown.
INFO:
T o go back to the screen displaying the current
vehicle position, press the MAP button.
HOW DO I USE THE ADDRESS BOOK FEATURE?
7-12

A VOID AREA
SETTING AVOID AREAS
Setting avoid areas will give you a route around
certain areas.
INFO:
If the vehicle icon is in the avoid area, route
calculation cannot be completed.
1. Change to the current vehicle location
screen.
2. Select the
Setting key .3. Select the
System Setting key . 4. The display shows the [SYSTEM SET -
TINGS] screen.
Select the
Avoid Area Setting key .
INV0259INV0382
HOW DO I USE THE AVOID AREA FEATURE?
8-2

5. The display shows the [AVOIDAREA SET -
TING] screen.
Select a key which is not set as an avoid area.
INFO:
It is possible to set up to 10 areas.6. The display shows categories which can be
used to set an avoid area.
For example, use the
Map key to set an avoid
area.
Select the
Map key .
INFO:
For setting with other categories, please refer
to “Seven categories” on page 5-2.7. The display shows the map which centers
the area to be set as an avoid area.
Use the ZM+ or ZM− button to adjust the
map reduction scale.
INV0383INV0384INV0386
HOW DO I USE THE AVOID AREA FEATURE?
8-3

8. Use the joystick to adjust the location.
INFO:
Area size: Max.5x5miles (8x8km)9. The display shows the keys on the right of
the screen.
Select the
Set key .
INFO:

If you want to avoid the freeway in that area,
select the
key to turn on the green in-
dicator on the key . (Indicator ON: avoid,
OFF: do not avoid)

When altering the size of the avoid area,
touch the
Area key . The area size is al-
tered by three scales.
The avoid area is set, and the grid will be
displayed on the screen.
INFO:
The grid color will be displayed in green or
blue.
(Avoid Freeway ON: green, OFF: blue)
If the route guidance is set, the display shows
the [DEST . SETTING] screen.
INV0493INV0388INV0389
HOW DO I USE THE AVOID AREA FEATURE?
8-4
