Changes display brightness.
7. OFF button
T urns off the display .
8. AUTO button; refer to page 12-3.
Displays automatic temperature control.
9. ECON button; refer to page 12-4.
The air conditioner does not activate. When
you need to heat only , use the ECON button.
10. T emperature set knob; refer to page 12-3.
Changes the temperature setup.
11.
button; refer to page 12-4.
Recirculates air within vehicle.
12.
button; refer to page 12-5.
Controls air flow.
13.
button; refer to page 12-5.
Activates the defroster .14. OFF button
Cancels the display relative to air conditioner
or turns the automatic temperature control off.
HOW TO USE THE
JOYSTICK/TOUCH SCREEN
The system’s basic operation is to select
(touch) the keys displayed on the screen.
The joystick is used to make selections.
T ouch the key on the screen with your finger .
NOTE:
T o select the key displayed on the
screen, touch it lightly .
T ouching the screen with hard objects
such as your finger nails or a pen will
damage or adversely affect the system.
Please refer to “How to handle the dis-
play” on page 11-20.
HOW TO USE THE KEYS THAT
APPEAR ON THE DISPLAY
When the buttons on the control panel are
pressed, the display shows keys which are
used for various settings. The keys that appear
on the display when each button is pressed are
explained in this section, while the detailed op-
erations of keys are explained in each section.
Keys that appear when the
MAPbutton is pressed
INV0484
HOW DO I OPERATE THE NISSAN NAVIGATION SYSTEM?
4-3
NOTES ON ROUTE GUIDANCE
The route selected by the system may not
be the shortest, nor are other circumstances
such as traffic jams considered.
Because of the inevitable difference in road
conditions and circumstances between the
time you use this system and the time the
information was produced from the CD,
there may be discrepancies in roads and
regulations. In such cases, follow the actual
information available.
During route calculation, the map will not
scroll, however the vehicle icon will move
with the actual vehicle’s movement.
During route calculation, buttons such as
MAP , DEST , ZM− and ZM+ and
the joystick will be disabled.
In some cases, after the calculation is com-
plete, it may take some time to get the cal-
culated route on the display .Waypoints that have been passed will not
be covered by the re-routing calculation.
If you scroll the map while the suggested
route is being drawn, it may take more time
to finish drawing.
If waypoints are set, the system is calculat-
ing multiple routes between waypoints si-
multaneously , and the following may result.
— If one section (or more) of the routes be-
tween the waypoints is not found, none of
the route will be displayed.
— The route may not connect completely at
some waypoints.
— The route may require a U-turn close to
some waypoints.
Route calculation may not be completed in
the following cases.
— If there is no main road within 3.1 miles (5
km) from the vehicle, a message saying so
will appear on the screen. T ry requestingroute calculation when the vehicle is closer
to the main road.
— If there is no main road within 3.1 miles (5
km) from the destination or waypoint, a
message saying so will appear on the
screen. T ry setting the location closer to the
main road.
— If the vehicle is too close to the destination
or if there are no branches of the roads to
the destination. A message saying so will
appear on the screen.
— If it is deemed impossible to reach the des-
tination or waypoints because of traffic
regulations, etc.
— If there is only an extremely complicated
route to reach the destination or waypoints.
— If the destination, current vehicle position
or waypoint is within the
avoid area.
— If the setting of
avoid areascovers the
routes to the destination, route calculation
HOW DO I OPERATE THE NISSAN NAVIGATION SYSTEM?
4-14
SCREEN INFORMA TION —
PLANVIEW DISPLA Y
Direction key:
This indicates and sets the direction of the map
on the display .
Please refer to “Changing the display direc-
tion” on page 11-6.
Map scale:
This display indicates the scale on the current
map.
V ehicle icon:
This icon indicates your vehicle and the direc-
tion of travel.
GPS indicator:
This will tell you the strength of the GPS signal
received.
Please refer to “Accuracy of positioning” on
page 2-2.
:
This will indicate the approximate distance of
route and traveling time to the destination. This
indicator will appear when you set the desti-
nation with the route guidance ON.
:
When the route guidance is OFF or when routecalculation is not started after you set the des-
tination, it will show the direction and approxi-
mate straight distance to the destination.
SCREEN INFORMA TION —
BIRD VIEWTMDISPLA Y
Map scale:
This display indicates the scale on the current
map.
By using the ZM− ZM+ buttons, you can
change the scale of the map.
INV0419
INV0422
HOW DO I ADJUST THE DISPLAY?
11-2
