2003 NISSAN MAXIMA navigation

Thank you for purchasing a NISSAN automo-
bile. This user’s manual is for the navigation
system only .
Please read this manual carefully to ensure safe
operation of the navigation system.

Please read your vehicle’s owner’s manual
first.

Do not remove this manual from the vehicle
when selling this vehicle. The next user of
this navigation system may need the
manual.

Because of possible specification changes,
parts of this manual may not apply to your
vehicle.

All information, specifications and illustra-
tions in this manual are those in effect at the
time of printing. NISSAN reserves the right
to change specifications or design at any
time without notice.

HOW TO USE THIS
MANU AL
This manual uses special words and icons, or-
ganized by function. Please refer to the follow-
ing items and familiarize yourself with them.
The display and control panel are combined for
Pathfinder model navigation system.
FOR SAFE OPERATION
WARNING
This is used to indicate the presence
of a hazard that could cause death or
serious personal injury . T o avoid or
reduce the risk, the procedures must
be followed precisely .
CAUTION
This is used to indicate the presence
of a hazard that could cause minor or
moderate personal injury or damage
to your vehicle. T o avoid or reduce
the risk, the procedures must be fol-
lowed carefully .
NOTE:
This indicates an item to help you under-
stand the maximum performance of your
vehicle. If ignored, it may lead to a
breakdown or poor performance.
REFERENCE SYMBOLS
INFO:
This indicates information necessary for effi-
cient use of your vehicle or accessories.DESTbutton
This is a button on the control panel.
Viewkey
This is a select key on the screen. By se-
lecting this key you can proceed to the
next function.
SAFETY NOTE
This system is primarily designed to help you
reach your destination, and also performs other
functions as outlined in this manual. However ,
you, the driver , must use the system safely and
properly . Information concerning road condi-
tions, traffic signs and the availability of ser-
vices may not always be up-to-date.The sys-
tem is not a substitute for safe, proper ,
and legal driving.
Before using the navigation system, please
read the following safety information. Always
use the system as outlined in this manual.
INTRODUCTION
1-2

2 HOW DOES THE NISSAN NAVIGATION SYSTEM WORK?
Wha t is a naviga tion system?..................... 2-2
About the naviga tion system ................ 2-2
Wha t is GPS (Global Positioning
System)? .................................................... 2-2
Accuracy of positioning.......................... 2-2
Positioning adjustment........................... 2-3
Receiving signals from GPS sa tellites ... 2-3
Displa y of GPS informa tion ................... 2-3
Det ailed map coverage areas (MCA) for the
naviga tion system ....................................... 2-4

WHA T IS A NA VIGA TION
SYSTEM?
ABOUT THE NAVIGATION SYS-
TEM
This navigation system combines the data ob-
tained from the vehicle (by gyro sensor) and
from GPS (Global Positioning System) satel-
lites to calculate the current location of the ve-
hicle. This position is then displayed on the
screen, allowing route guidance to a destina-
tion.
WHA T IS GPS (GLOBAL PO-
SITIONING SYSTEM)?
GPS is a system developed and operated by the
U.S. government, covering the entire globe.
This navigation system receives three or more
different radio signals from NAVST AR (GPS
satellites), orbiting the earth 13,049 miles
(21,000 km) above ground. The data from dif-
ferent sets of signals will be trigonometrically
calculated to obtain the position of the vehicle.INFO:
The tracking center in the US, controls signals
transmitted from GPS satellites. This control
sometimes results in reduced accuracy or no
signal received at all.
ACCURACY OF POSITIONING
The color of the GPS Indicatoron the up-
per left corner of the screen indicates position-
ing as follows:

Green: When positioning is possible and
accurate

Y ellow: When positioning is possible but
not accurate

Gray: When positioning is not possible
INV0255
HOW DOES THE NISSAN NAVIGATION SYSTEM WORK?
2-2

INFO:
For approximately 3 or 4 minutes after system
startup, the GPS indicator
remains gray ,
even if accurate positioning is possible.
POSITIONING ADJUSTMENT
When the system judges that the vehicle po-
sition information is not accurate based on ve-
hicle speed and gyro sensor data calculations,
the system will adjust the vehicle position in-
formation using GPS signals.
RECEIVING SIGNALS FROM
GPS SATELLITES
Sometimes, satellite reception is weak. The fol-
lowing are places where signals tend to be
weak:

Inside tunnels and parking lots in buildings

Areas with numerous tall buildings

Under multi-layered highways

In a dense forestVehicles in these areas may not receive GPS
signals (Indicator color: gray).
INFO:
The antenna for GPS is located in the instru-
ment panel inside the vehicle.Do not place
any object, especially mobile phones or
transceivers, on the instrument panel.
Because the strength of the GPS signals is ap-
proximately one billionth of that of TV waves;
phones and transceivers will decrease the
strength or may totally disrupt the signals.
DISPLAY OF GPS INFORMA-
TION
This system displays GPS information.
Please refer to “GPS information display” on
page 11-12.NOTE:
The navigation system does not take
driving in carpool lanes into consider-
ation for the guidance.
HOW DOES THE NISSAN NAVIGATION SYSTEM WORK?
2-3

DET AILED MAP CO VERAGE
AREAS (MCA) FOR THE
NA VIGA TION SYSTEM
This system is primarily designed to help you
reach your destination, and also performs other
functions as outlined in this manual. However ,
you, the driver , must use the system safely and
properly . Information concerning road condi-
tions, traffic signs and the availability of ser-
vices may not always be up-to-date. The sys-
tem is not a substitute for safe, proper , and le-
gal driving.
Map data includes major metropolitan areas in
the United States.
Map data consists of map CD-ROM MCA1 to
MCA9. For information about map CD-ROMs,
contact a NISSAN dealer .
Map data includes 2 types of areas: “Detailed
coverage areas” providing all detailed road
data and other areas showing main roads only .The route calculation may not be made on the
border of the map coverage area and the other
areas.
When driving from one map coverage area
(MCA) into another: No map information is
displayed on the screen when the vehicle is
driven past the mapping border into the new
area. Only the vehicle position icon is dis-
played on the screen. The screen will become
gray indicating that you are outside the MCA
covered by the mapping CD. Replace the cur-
rent map CDwith the new map CDthat con-
tains the information for the new area in which
you are driving. Map information will then be
displayed on the screen for the new area.
NOTE:
Waypoints and destinations cannot be
set for positions outside of a map cov-
erage area. Once the new Map CD is in-
stalled, you will need to reprogram the
waypoints and final destination.
HOW DOES THE NISSAN NAVIGATION SYSTEM WORK?
2-4

Map Coverage Area (MCA) 1
INI0040
HOW DOES THE NISSAN NAVIGATION SYSTEM WORK?
2-5

Map Coverage Area (MCA) 2
INI0041
HOW DOES THE NISSAN NAVIGATION SYSTEM WORK?
2-6
