2003 NISSAN MAXIMA display

CHANGING THE DISPLA Y
DIRECTION (IN PLANVIEW
DISPLA Y)
How to use the keys on the screen
Press the MAP button on the map screen to
display the
key .
Select the
Heading key (key) to alter-
nate the map displays between the North up
and the current forward direction up.
In case of
Settingkey
1. Change to the current vehicle location
screen.
2. Select the
Setting key .INV0495
INV0496INV0497
HOW DO I ADJUST THE DISPLAY?
11-6

3. Select theSystem Setting key on the
[SETTINGS] screen.4. Select theHeading key on the [SYSTEM
SETTINGS] screen.
The [HEADING] screen will be displayed.5. Select theHeading Up key or the
North Up key .
The map is displayed as follows:
Heading Up : The map shows the current
forward direction up.
North Up : The map shows North up.
INFO:

When the key is selected, the green indi-
cator light will light up.

When the Map button is pressed after the
INV0259INV0433INV0434
HOW DO I ADJUST THE DISPLAY?
11-7

display setting, the [CURRENT LOCA TION]
screen will appear .
When the
Previous key is selected, the
previous screen will reappear .
SCROLLING THE MAP
Y ou can manually scroll the map to check the
places of your choice.
1. Operating the joystick.
The map scrolls to the same direction as the
joystick.INFO:
While the vehicle is traveling, a single opera-
tion will move a fixed amount of the screen.
2. Press the MAP button to go back and
show the current vehicle position.
INFO:
Y ou can also select the
Previous key to go
back.
DISPLA YING THE COM-
PLETE ROUTE TO THE DES-
TINA TION
Y ou can request to display the complete sug-
gested route to the destination.
1. T ouch the screen.
Keys will be displayed on the screen.
INV0435
INV0436
INV0437
HOW DO I ADJUST THE DISPLAY?
11-8

2. Select theRoute Info key .
3. Select the
Complete Route key .The complete suggested route to the destina-
tion will be displayed.
DISPLA YING TURN LIST
Y ou can display the list of guide points to the
destination during route calculation.
1. T ouch the screen.
INV0438INV0439
INV0437
HOW DO I ADJUST THE DISPLAY?
11-9

2. Select theRoute Info key .
3. Select the
T urn List key .A list of destinations, waypoints and guide
points will be displayed. Guidance will be
made at each guide point about which direction
to turn.
The distance between the guide points and the
required time will also be displayed.
It may take time to prepare the turn list. In such
cases, the
T urn List key will be highlighted
and you can not select it until calculation is
completed.
INFO:

In the turn list, turning points more than 60
miles (100 km) away from the current ve-
hicle location will not be displayed.

When calculated routes include a freeway ,
information about freeway entrances and
exits will also be displayed.
REQUESTING THE SIMULA-
TION DRIVE TO THE DESTI-
NA TION
Y ou can simulate driving the entire suggested
route to the destination on the screen.
1. T ouch the screen.
Keys will be displayed on the screen.
2. Select the
Route Info key .
INV0440
INV0441
INV0437
HOW DO I ADJUST THE DISPLAY?
11-10

3. Select theRoute Simulation key .
The screen will display a simulated drive withvoice guidance on the suggested route to the
destination.
4. Press the MAP button to go back to the
map display .
INFO:
If you select the
Pause key , simulation is in-
terrupted. If you select the key again, the simu-
lation will restart.
DISPLAYING THE TRACK
Y ou can have the system track the road you
have taken, and display it with indication mark
().
1. Change to the current vehicle location
screen.
2. Select the
Setting key .3. Select the
System Setting key on the
[SETTINGS] screen.
INV0442
INV0443
INV0259
HOW DO I ADJUST THE DISPLAY?
11-11

4. Select theT racking key .
5. Select the
On key .6. Press the MAP button.
The location of the vehicle will be displayed.
INFO:

Y ou can select the
On key to display the
indicator (), and the
Off key to get rid
of it.

The locus indicator () may be spaced dif-
ferently , according to the scale of the map.

If you re-set the current vehicle location, the
indicator () will be cleared.
GPS INFORMA TION DIS-
PLA Y
The following GPS information will be dis-
played on the screen: latitude, longitude, alti-
tude, signal reception, and satellite locations.
1. Change to the current vehicle location
screen.
2. Select the
Setting key .
3. Select the
System Setting key on the
[SETTINGS] screen.
INV0444
INV0445
INV0446
INV0259
HOW DO I ADJUST THE DISPLAY?
11-12

4. Select theGPS Information key .
GPS information will be displayed.INFO:

The satellite with a strong enough signal
will be indicated in green.

The display will read, [3-dimensional po-
sitioning], [2-dimensional positioning], or
[positioning impossible], depending on the
signal strength. (Altitude will not be dis-
played in 2-dimensional positioning.)

When the MAP button is pressed, the
[CURRENT LOCA TION] screen will appear .
When the
Previous key is touched, the[SYSTEM SETTING] screen will appear .
UPDATING THE CURRENT VE-
HICLE LOCATION AND THE
DIRECTION
If the vehicle icon does not indicate the correct
location or the direction does not match the ac-
tual road, you can adjust them on the map
screen.
1. Change to the current vehicle location
screen.
2. Select the
Setting key .
INV0447INV0448
