2003 MERCEDES-BENZ E500 Owner's Manual

225 Controls in detail
Loading
Cargo tie-down rings*
Four rings1 are located in the cargo com-
partment.
Carefully secure cargo by applying
even load on all rings with rope of suffi-
cient strength to hold down the cargo.
Always follow loading instructions
(page 224).Rear seat
There is a cargo tie-down ring located on
each side of the footwell under the rear
seat.

226 Controls in detailUseful features
Useful featuresInterior storage spaces Parcel net in front passenger footwell
A small convenience parcel net is located
in the front passenger footwell. It is for
small and light items, such as road maps,
mail, etc.Glove box
1Glove box lid release
2Compartment for mobile phone/glass-
es
Opening the glove box

Push lid release1.
The glove box lid opens downward.
Closing the glove box

Push lid up to close.
Warning!
G
To help avoid personal injury during a colli-
sion or sudden maneuver, exercise care
when stowing objects in the vehicle. Put lug-
gage or cargo in the trunk if possible. Do not
pile luggage or cargo higher than the seat
backs. Do not place anything on the shelf
below the rear window.
Luggage nets cannot secure hard or heavy
objects.
Keep compartment lids closed. This will help
to prevent stored objects from being thrown
about and injuring vehicle occupants during
an accident.
Warning!
G
The parcel net is intended for storing
light-weight items only.
Heavy objects, objects with sharp edges or
fragile objects may not be transported in the
parcel net.
The parcel net cannot protect transported
goods in the event of an accident.

227 Controls in detail
Useful features
Storage compartment in the center
console
1Opening/closing button
Press button1 to open.The control panel swings out upward
and the storage compartment extends
out.

Press button1 to close.
Storage compartment in front of the
armrestOpening

Briefly press the marking in the back of
the cover.
The cover opens.
Cup holder in the center console

Briefly press marking on the cup hold-
er.
The cup holder extends automatically.
iPrior to closing the glove box, close the
compartment for glasses first.iThe storage compartment in the center
console cannot be opened if the cas-
sette tray is open.
iNever place any medications in the
storage compartment. If there is a pow-
er failure, the storage compartment
cannot be opened.

228 Controls in detailUseful features1Left cup holder
2Right cup holderStorage space under armrest
1Storage compartment
2Storage tray
Opening storage tray

Pull handle2.
Opening storage compartment

Pull handle1.
iThe cup holder can be removed for
cleaning. Clean the cup holder only
with clear, lukewarm water.
Make sure to insert the cup holder in
the guides when reinstalling it.
Warning!
G
When not in use, keep the cup holder closed
while traveling. Place only containers that fit
into the cup holder to prevent spills. Use lids
on open containers and do not fill containers
to a height where the contents, especially
hot liquids, could spill during vehicle maneu-
vers.

229 Controls in detail
Useful features
Front center console storage compart-
ment ventilation
The front center console storage compart-
ment under the armrest has its own air out-
let. The air temperature is about the same
as that of the dashboard air outlets.
The lever is located in the front center out-
let.
1Lever
To open air outlet slide the lever up.

To close air outlet slide the lever down.Storage compartment in the rear cen-
ter console

Briefly press the top of the compart-
ment.
It extends automatically.
iThe compartment can get very warm
due to its confined space. When storing
heat sensitive objects (e.g. groceries)
in the compartment, close the air outlet
while heating the passenger compart-
ment

230 Controls in detailUseful featuresRuffled storage bags
Ruffled storage bags are located on the
back of the front seats.Storage compartment in the rear arm-
rest

Press the handle upward and fold the
armrest up.Rear cup holder

Briefly press the front of the center
armrest.
The cup holder extends automatically.
Warning!
G
Do not transport hard objects in the storage
bags.
Warning!
G
When not in use, keep the cup holder closed
while traveling. Place only containers that fit
into the cup holder to prevent spills. Use lids
on open containers and do not fill containers
to a height where the contents, especially
hot liquids, could spill during vehicle maneu-
vers.

231 Controls in detail
Useful features
Ashtrays
Center console ashtray
Opening ashtray
Briefly press the marking on the bot-
tom of cover1.
The ashtray opens automatically.Removing ashtray insert

Secure vehicle from movement by set-
ting the parking brake. Move the selec-
tor lever to positionN.
Now you have more room to take out
the insert.

Push sliding button2 to the right and
hold.

Grip and remove insert from ashtray
frame.
Reinstalling ashtray insert

Install insert by pushing it back into
frame until it engages again.Rear seat ashtray
Opening ashtray

Briefly press the top of the ashtray.
The ashtray opens.
Warning!
G
Remove front ashtray only with vehicle
standing still. Set the parking brake to se-
cure vehicle from movement. Move gear se-
lector lever to positionN. With gear selector
lever in positionN turn off the engine.

232 Controls in detailUseful featuresCigarette lighter
The cigarette lighter is located in the cen-
ter console compartment in front of the
armrest (
page 26).
1Cigarette lighter

Turn key in the starter switch to
position1 or2.

Push in cigarette lighter1.
The lighter will pop out automatically
when hot.
12-V socket*
The socket is located in the rear of the cen-
ter console storage compartment.
The socket can be used for accessories up
to a maximum of 180 W.
Warning!
G
Never touch the heating element or sides of
the lighter; they are extremely hot. Hold the
knob only.
When leaving the vehicle always remove the
key from the starter switch, and lock your
vehicle. Do not leave children unattended in
the vehicle, or with access to an unlocked
vehicle. Unsupervised use of vehicle equip-
ment may cause serious personal injury.iThe lighter socket can be used to ac-
commodate electrical accessories up
to a maximum 85 W.
