2003 MERCEDES-BENZ E500 Owner's Manual

97 Controls in detail
Locking and unlocking
Closing from outside
1Trunk closing switch
Press the closing switch briefly.
The trunk lid closes automatically.
When closing, if the trunk lid comes into
contact with an object (e.g. luggage that
has been piled too high) in the upper mo-
tion sequence, the closing procedure is
stopped and the trunk re-opens slightly.
Trunk lid emergency release
The emergency release button is located
on the inside of the trunk lid.
1Emergency release button
Briefly press the emergency release
button.
The trunk unlocks and the trunk lid
opens.
Warning!
G
Monitor the closing procedure carefully to
ensure that no one is in danger of being in-
jured. To prevent possible personal injury,
always keep hands and fingers away from
the trunk opening when closing the trunk.
Be especially careful when small children
are around. To stop the closing procedure,
press the remote control switch for the
trunk lid or the
Š
key on the remote con-
trol.
!Do not place the key in the open trunk.
You may lock yourself out.
Vehicles with KEYLESS-GO*:
To prevent a possible inadvertent lock-
out, the trunk lid will open automatical-
ly if a SmartKey with KEYLESS-GO is
recognized in the area of the rear shelf
or inside the trunk.
!The emergency release button unlocks
and opens the trunk while the vehicle is
standing or driving.

98 Controls in detailLocking and unlockingIllumination of the emergency release but-
ton:

The button will blink for 30 minutes af-
ter opening the trunk.


The button will blink for 60 minutes af-
ter closing the trunk.
Separately locking the trunk
The lock is located next to the recessed
handle.
1Unlocked
2Locked

Close the trunk lid (
page 96).

Pull the mechanical key out of the
SmartKey (
page 329).

Insert the mechanical key in the trunk
lid lock.

Turn the key completely to the right to
position2.
The trunk remains locked even when the
vehicle is centrally unlocked.
!The emergency release button does
not open the trunk lid if the vehicle bat-
tery is discharged or disconnected.iIf the emergency release button is
pressed and the vehicle was centrally
locked, the exterior lamps will flash and
the alarm will sound.
To cancel the alarm, insert the key in
the starter switch or press buttonŒ
or ‹ on the key.
iTo deny any unauthorized person ac-
cess to the trunk, lock it separately
with the mechanical key. Leave only
the SmartKey without its mechanical
key inside the vehicle.
iYou can only cancel the separate trunk
locking mode by means of the mechan-
ical key.

99 Controls in detail
Locking and unlocking
Separately unlocking the trunk
Pull the mechanical key out of the
SmartKey (
page 329).

Insert the mechanical key in the trunk
lid lock.

Turn the key completely to the left to
position1, see above.
You can now open the trunk (
page 96).
Automatic central locking
The doors and the trunk automatically lock
when the ignition is switched on and the
wheels are turning at vehicle speeds of ap-
proximately 9 mph (15 km/h) or more.
You can open a locked door from the in-
side. Open door only when conditions are
safe to do so.
You can deactivate the automatic locking
mode over the control system
(
page 142).
iUnlocking the trunk with the mechani-
cal key will trigger the anti-theft alarm
system. To cancel the alarm, do one of
the following:

Press button Œor ‹on the
SmartKey.


Insert the SmartKey in the starter
switch.
iThe doors unlock automatically after an
accident if the force of the impact ex-
ceeds a preset threshold.
The vehicle automatically locks when
the ignition is switched on and the
wheels are turning at vehicle speeds of
approximately 9 mph (15 km/h) or
more. You could therefore lock yourself
out when the vehicle

is pushed


is on a test stand

100 Controls in detailLocking and unlockingLocking and unlocking from the inside
You can lock or unlock the doors and the
trunk from inside using the central locking
switch. This can be useful, for example, if
you want to lock the vehicle before starting
to drive.
The fuel filler flap cannot be locked or un-
locked with the central locking switch.The switch is located in the center console.
Central locking switch1Locking
2Indicator lamp
3UnlockingLocking

Press upper half1 of the central lock-
ing switch.
If both front doors are closed, the vehi-
cle locks.
Unlocking

Press lower half2 of the central lock-
ing switch.
The vehicle unlocks.
Warning!
G
When leaving the vehicle, always remove the
key from the starter switch, take it with you
and lock the vehicle. Do not leave children
unattended in the vehicle, or with access to
an unlocked vehicle. Unsupervised use of
vehicle equipment may cause serious per-
sonal injury.

101 Controls in detail
Locking and unlocking
Locking the vehicle from the trunk*
Vehicles with trunk lid opening/closing
system* and KEYLESS-GO* can be central-
ly locked using a switch in the trunk lid.
1Central locking
Press button 1.
The vehicle is centrally locked.
iYou can open a locked door from the
inside. Open door only when conditions
are safe to do so.
If the vehicle was previously centrally
locked using the SmartKey, it will not
unlock using the central locking switch.
If the vehicle was previously locked
with the central locking switch

while in the selective remote con-
trol mode, only the door opened
from the inside is unlocked.


while in the global remote control
mode, the complete vehicle is un-
locked when a door is opened from
the inside.

102 Controls in detailSeats
SeatsInformation on seat adjustment can be
found in the "Getting started" section
(page 35).
Easy-entry/exit feature*
With the easy-entry/exit feature activated,
the steering wheel tilts upwards and the
driver’s seat moves to the rear.
This allows easier entry into and exit from
the vehicle when the driver’s door is
opened. However, the engine must be
turned off.
When the SmartKey is inserted in the start-
er switch and the driver’s door is closed,
the steering wheel and the driver’s seat re-
turn to their last set positions.You can activate the following functions:


Steering column:
Only the steering column is adjusted.


Steering column and seat:
The steering column and the seat are
adjusted.
The easy-entry/exit feature can be
switched on or off in the individual setting
menu
Convenience
- Easy-entry feature
activate
(page 143).
Warning!
G
You must ensure that no one can become
trapped or injured by the moving steering
wheel and driver’s seat when the
easy-entry / exit feature is activated, the
driver’s door is being opened and the engine
is turned off or the SmartKey removed from
the starter switch. Do not leave children un-
attended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause serious personal
injury.
iTo cancel seat/steering wheel move-
ment, do one of the following:

Press seat adjustment switch
(page 28).


Move steering column stalk
(page 38).


Press the memory switch
(page 28).

103 Controls in detailSeats
Head restraints
Information on head restraint adjustment
can be found in the "Getting started" sec-
tion (
page 36).Front seat head restraints
Removing front head restraints

Press switch1 upwards and hold until
the head restraint is fully extended.

Pull out head restraint.
Installing front head restraints:

Press switch1 upwards and hold for
about five seconds.

Push the head restraint down until it
engages.

Adjust head restraint to desired posi-
tion (
page 36).Rear seat head restraints
Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust head restraint to support the back of
the head approximately at ear level.
Do not drive the vehicle without the seat
head restraints. Head restraints are intend-
ed to help reduce injuries during an acci-
dent.iTilt the backrest to the rear for easier
removal and installation of the head re-
straints.
Warning!
G
For safety reasons, always drive with the
rear head restraints in the upright position
when the rear seats are occupied.
Keep the area around head restraints clear
of articles (e.g. clothing) to not obstruct the
folding operation of the head restraints.

104 Controls in detailSeatsFolding rear head restraints back
Make sure the starter switch is in
position1 or2.

Push switch1.
The rear head restraints will fold back-
ward.Placing rear head restraints upright

Pull the rear head restraint forward un-
til it locks into position.
Multicontour seat*
The multicontour seat has a movable seat
cushion and inflatable air cushions built
into the backrest to provide additional lum-
bar and side support.
The seat cushion movement, backrest
cushion height and curvature can be con-
tinuously varied with regulators on the
right side of the seat after turning the
SmartKey in the starter switch to
position2.
