Page 129 of 256

F-250 Regular Cab Pickup
Engine Rear axle
ratioMaximum GCWR -
kg (lbs.)Maximum
trailer weight -
kg (lbs.)
6.8L (without
fifth wheel)4.30 9072 (20000) 5670 (12500)
6.8L (with fifth
wheel)4.30 9072 (20000) 6260 (13800)
4x4 with automatictransmission
5.4L 3.73 6123 (13500) 3402 (7500)
5.4L 4.10 6804 (15000) 4082 (9000)
6.8L 3.73 7711 (17000) 4944 (10900)
6.8L (without
fifth wheel)4.30 9072 (20000) 5670 (12500)
6.8L (with fifth
wheel)4.30 9072 (20000) 6305 (13900)
F-250 SuperCab Pickup
Engine Rear axle
ratioMaximum GCWR -
kg (lbs.)Maximum
trailer weight -
kg (lbs.)
4x2 with manual transmission
5.4L 3.73 6123 (13500) 3402 (7500)
5.4L 4.10 6804 (15000) 4082 (9000)
6.8L 3.73 7484 (16500) 4717 (10400)
6.8L (without
fifth wheel)4.30 9072 (20000) 5670 (12500)
6.8L (with fifth
wheel)4.30 9072 (20000) 6305 (13900)
4x2 with automatictransmission
5.4L 3.73 6123 (13500) 3402 (7500)
5.4L 4.10 6804 (15000) 4082 (9000)
6.8L 3.73 7711 (17000) 4944 (10900)
6.8L (without
fifth wheel)4.30 9072 (20000) 5670 (12500)
Driving
129
Page 130 of 256

F-250 SuperCab Pickup
Engine Rear axle
ratioMaximum GCWR -
kg (lbs.)Maximum
trailer weight -
kg (lbs.)
6.8L (with fifth
wheel)4.30 9072 (20000) 6305 (13900)
4x4 with manual transmission
5.4L 3.73 6123 (13500) 3221 (7100)
5.4L 4.10 6804 (15000) 3901 (8600)
6.8L 3.73 7484 (16500) 4491 (9900)
6.8L (without
fifth wheel)4.30 9072 (20000) 5670 (12500)
6.8L (with fifth
wheel)4.30 9072 (20000) 6078 (13400)
4x4 with automatictransmission
5.4L 3.73 6123 (13500) 3221 (7100)
5.4L 4.10 6804 (15000) 3901 (8600)
6.8L 3.73 7711 (17000) 4763 (10500)
6.8L (without
fifth wheel)4.30 9072 (20000) 5670 (12500)
6.8L (with fifth
wheel)4.30 9072 (20000) 6123 (13500)
F-250 Crew Cab Pickup
Engine Rear axle
ratioMaximum GCWR -
kg (lbs.)Maximum
trailer weight -
kg (lbs.)
4x2 with manual transmission
5.4L 3.73 6123 (13500) 3266 (7200)
5.4L 4.10 6804 (15000) 3992 (8800)
6.8L 3.73 7484 (16500) 4581 (10100)
6.8L (without
fifth wheel)4.30 9072 (20000) 5670 (12500)
6.8L (with fifth
wheel)4.30 9072 (20000) 6169 (13600)
Driving
130
Page 131 of 256

F-250 Crew Cab Pickup
Engine Rear axle
ratioMaximum GCWR -
kg (lbs.)Maximum
trailer weight -
kg (lbs.)
4x2 with automatictransmission
5.4L 3.73 6123 (13500) 3311 (7300)
5.4L 4.10 6804 (15000) 3992 (8800)
6.8L 3.73 7711 (17000) 4853 (10700)
6.8L (without
fifth wheel)4.30 9072 (20000) 5670 (12500)
6.8L (with fifth
wheel)4.30 9072 (20000) 6214 (13700)
4x4 with manual transmission
5.4L 3.73 6123 (13500) 3130 (6900)
5.4L 4.10 6804 (15000) 3810 (8400)
6.8L 3.73 7484 (16500) 4400 (9700)
6.8L (without
fifth wheel)4.30 9072 (20000) 5670 (12500)
6.8L (with fifth
wheel)4.30 9072 (20000) 5987 (13200)
4x4 with automatictransmission
5.4L 3.73 6123 (13500) 3130 (6900)
5.4L 4.10 6804 (15000) 3810 (8400)
6.8L 3.73 7711 (17000) 4672 (10300)
6.8L (without
fifth wheel)4.30 9072 (20000) 5670 (12500)
6.8L (with fifth
wheel)4.30 9072 (20000) 6033 (13300)
F-350 Regular Cab Single Rear Wheel Pickup
Engine Rear axle
ratioMaximum GCWR -
kg (lbs.)Maximum
trailer weight -
kg (lbs.)
4x2 with manual transmission
5.4L 3.73 6123 (13500) 3538 (7800)
Driving
131
Page 132 of 256

F-350 Regular Cab Single Rear Wheel Pickup
Engine Rear axle
ratioMaximum GCWR -
kg (lbs.)Maximum
trailer weight -
kg (lbs.)
5.4L 4.10 6804 (15000) 4218 (9300)
6.8L 3.73 7484 (16500) 4853 (10700)
6.8L (without
fifth wheel)4.30 9072 (20000) 5670 (12500)
6.8L (with fifth
wheel)4.30 9072 (20000) 6441 (14200)
4x2 with automatictransmission
5.4L 3.73 6123 (13500) 3583 (7900)
5.4L 4.10 6804 (15000) 4218 (9300)
6.8L 3.73 7711 (17000) 5080 (11200)
6.8L (without
fifth wheel)4.30 9072 (20000) 5670 (12500)
6.8L (with fifth
wheel)4.30 9072 (20000) 6441 (14200)
4x4 with manual transmission
5.4L 3.73 6123 (13500) 3357 (7400)
5.4L 4.10 6804 (15000) 4037 (8900)
6.8L 3.73 7484 (16500) 4672 (10300)
6.8L (without
fifth wheel)4.30 9072 (20000) 5670 (12500)
6.8L (with fifth
wheel)4.30 9072 (20000) 6260 (13800)
4x4 with automatictransmission
5.4L 3.73 6123 (13500) 3402 (7500)
5.4L 4.10 6804 (15000) 4082 (9000)
6.8L 3.73 7711 (17000) 4899 (10800)
6.8L (without
fifth wheel)4.30 9072 (20000) 5670 (12500)
6.8L (with fifth
wheel)4.30 9072 (20000) 6260 (13800)
Driving
132
Page 133 of 256

F-350 Regular Cab Dual Rear Wheel Pickup
Engine Rear axle
ratioMaximum GCWR -
kg (lbs.)Maximum
trailer weight -
kg (lbs.)
4x2 with manual transmission
5.4L 3.73 6123 (13500) 3447 (7600)
5.4L 4.10 6804 (15000) 4128 (9100)
6.8L 3.73 7484 (16500) 4672 (10300)
6.8L (without
fifth wheel)4.30 9072 (20000) 5670 (12500)
6.8L (with fifth
wheel)4.30 9072 (20000) 6260 (13800)
4x2 with automatictransmission
5.4L 3.73 6123 (13500) 3447 (7600)
5.4L 4.10 6804 (15000) 4128 (9100)
6.8L 3.73 7711 (17000) 4944 (10900)
6.8L (without
fifth wheel)4.30 9072 (20000) 5670 (12500)
6.8L (with fifth
wheel)4.30 9072 (20000) 6305 (13900)
4x4 with manual transmission
5.4L 3.73 6123 (13500) 3221 (7100)
5.4L 4.10 6804 (15000) 3901 (8600)
6.8L 3.73 7484 (16500) 4491 (9900)
6.8L (without
fifth wheel)4.30 9072 (20000) 5670 (12500)
6.8L (with fifth
wheel)4.30 9072 (20000) 6078 (13400)
4x4 with automatictransmission
5.4L 3.73 6123 (13500) 3266 (7200)
5.4L 4.10 6804 (15000) 3946 (8700)
6.8L 3.73 7711 (17000) 4763 (10500)
6.8L (without
fifth wheel)4.30 9072 (20000) 5670 (12500)
Driving
133
Page 134 of 256

F-350 Regular Cab Dual Rear Wheel Pickup
Engine Rear axle
ratioMaximum GCWR -
kg (lbs.)Maximum
trailer weight -
kg (lbs.)
6.8L (with fifth
wheel)4.30 9072 (20000) 5897 (13000)
F-350 SuperCab Single Rear Wheel Pickup
Engine Rear axle
ratioMaximum GCWR -
kg (lbs.)Maximum
trailer weight -
kg (lbs.)
4x2 with manual transmission
5.4L 3.73 6123 (13500) 3402 (7500)
5.4L 4.10 6804 (15000) 4082 (9000)
6.8L 3.73 7484 (16500) 4672 (10300)
6.8L (without
fifth wheel)4.30 9072 (20000) 5670 (12500)
6.8L (with fifth
wheel)4.30 9072 (20000) 6260 (13800)
4x2 with automatictransmission
5.4L 3.73 6123 (13500) 3402 (7500)
5.4L 4.10 6804 (15000) 4082 (9000)
6.8L 3.73 7711 (17000) 4763 (10500)
6.8L (without
fifth wheel)4.30 9072 (20000) 5670 (12500)
6.8L (with fifth
wheel)4.30 9072 (20000) 6305 (13900)
4x4 with manual transmission
5.4L 3.73 6123 (13500) 3221 (7100)
5.4L 4.10 6804 (15000) 3901 (8600)
6.8L 3.73 7484 (16500) 4491 (9900)
6.8L (without
fifth wheel)4.30 9072 (20000) 5670 (12500)
6.8L (with fifth
wheel)4.30 9072 (20000) 6078 (13400)
Driving
134
Page 135 of 256

F-350 SuperCab Single Rear Wheel Pickup
Engine Rear axle
ratioMaximum GCWR -
kg (lbs.)Maximum
trailer weight -
kg (lbs.)
4x4 with automatictransmission
5.4L 3.73 6123 (13500) 3221 (7100)
5.4L 4.10 6804 (15000) 3901 (8600)
6.8L 3.73 7711 (17000) 4763 (10500)
6.8L (without
fifth wheel)4.30 9072 (20000) 5670 (12500)
6.8L (with fifth
wheel)4.30 9072 (20000) 6123 (13500)
F-350 SuperCab Dual Rear Wheel Pickup
Engine Rear axle
ratioMaximum GCWR -
kg (lbs.)Maximum
trailer weight -
kg (lbs.)
4x2 with manual transmission
5.4L 3.73 6123 (13500) 3266 (7200)
5.4L 4.10 6804 (15000) 3946 (8700)
6.8L 3.73 7484 (16500) 4536 (10000)
6.8L (without
fifth wheel)4.30 9072 (20000) 5670 (12500)
6.8L (with fifth
wheel)4.30 9072 (20000) 6123 (13500)
4x2 with automatictransmission
5.4L 3.73 6123 (13500) 3266 (7200)
5.4L 4.10 6804 (15000) 3946 (8700)
6.8L 3.73 7711 (17000) 4763 (10500)
6.8L (without
fifth wheel)4.30 9072 (20000) 5670 (12500)
6.8L (with fifth
wheel)4.30 9072 (20000) 6123 (13500)
4x4 with manual transmission
5.4L 3.73 6123 (13500) 3130 (6900)
Driving
135
Page 136 of 256

F-350 SuperCab Dual Rear Wheel Pickup
Engine Rear axle
ratioMaximum GCWR -
kg (lbs.)Maximum
trailer weight -
kg (lbs.)
5.4L 4.10 6804 (15000) 3810 (8400)
6.8L 3.73 7484 (16500) 4400 (9700)
6.8L (without
fifth wheel)4.30 9072 (20000) 5670 (12500)
6.8L (with fifth
wheel)4.30 9072 (20000) 5987 (13200)
4x4 with automatictransmission
5.4L 3.73 6123 (13500) 3130 (6900)
5.4L 4.10 6804 (15000) 3901 (8600)
6.8L 3.73 7711 (17000) 4627 (10200)
6.8L (without
fifth wheel)4.30 9072 (20000) 5670 (12500)
6.8L (with fifth
wheel)4.30 9072 (20000) 5987 (13200)
F-350 Crew Cab Single Rear Wheel Pickup
Engine Rear axle
ratioMaximum GCWR -
kg (lbs.)Maximum
trailer weight -
kg (lbs.)
4x2 with manual transmission
5.4L 3.73 6123 (13500) 3266 (7200)
5.4L 4.10 6804 (15000) 3946 (8700)
6.8L 3.73 7484 (16500) 4581 (10100)
6.8L (without
fifth wheel)4.30 9072 (20000) 5670 (12500)
6.8L (with fifth
wheel)4.30 9072 (20000) 6169 (13600)
4x2 with automatictransmission
5.4L 3.73 6123 (13500) 3311 (7300)
5.4L 4.10 6804 (15000) 3992 (8800)
6.8L 3.73 7711 (17000) 4808 (10600)
Driving
136
