2002 MERCEDES-BENZ G500 Owner's Manual

366 Fuels, coolants, lubricants etc.
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
the engine temperature will increase due to the lower
heat transfer capability of the solution. Therefore, do not
use more than this amount of anticorrosion / antifreeze.
If the coolant level is low, water and MB anticorrosion/
antifreeze should be used to bring it up to the proper
level (have cooling system checked for signs of leakage).
The water in the cooling system must meet minimum
requirements, which are usually satisfied by normal
drinking water. If your are not sure about the water
quality, consult your authorized Mercedes-Benz Light
Truck Center.
Anticorrosion/antifreeze
Your vehicle contains a number of aluminum parts. The
use of aluminum components in motor vehicle engines
necessitates that anticorrosion / antifreeze coolant used
in such engines be specifically formulated to protect the
aluminum parts. (Failure to use such anticorrosion/
antifreeze coolant will result in a significantly
shortened service life.)
Therefore the following product is strongly
recommended for use in your vehicle: Mercedes-Benz
Anticorrosion / antifreeze agent.Before the start of the winter season (or once a year in
the hot southern regions), you should have the
anticorrosion / antifreeze concentration checked. The
coolant is also regularly checked each time you bring
your vehicle to your authorized Mercedes-Benz Light
Truck Center for service.
Anticorrosion / antifreeze quantity
Approx. freeze protection
– 35
°F
(– 37°C)– 49
°F
(– 45°C)
5.5 US qt
(5.2 l)6.2 US qt
(5.8 l)
J_G463.book Seite 366 Mittwoch, 19. September 2001 8:06 08

367 Consumer information
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index Consumer information
This has been prepared as required of all manufactures
of passenger cars under Title 49, Code of U.S. Federal
Regulations, Part 575 pursuant to the “National Traffic
and Motor Vehicle Safety Act of 1966”.
Uniform tire quality grading
Quality grades can be found where applicable on the
tire sidewall between tread shoulder and maximum
section width. For example:
All passenger vehicle tires must conform to federal
safety requirements in addition to these grades.Treadwear
The treadwear grade is a comparative rating based on
the wear rate of the tire when tested under controlled
conditions on a specified government test course. For
example, a tire graded 150 would wear one and one-half
(1
1/2) times as well on the government course as a tire
graded 100. The relative performance of tires depends
upon the actual conditions of their use, however, and
may depart significantly from the norm due to
variations in driving habits, service practices and
differences in road characteristics and climate.
Traction
The traction grades, from highest to lowest are AA, A, B,
and C. Those grades represent the tire’s ability to stop
on wet pavement as measured under controlled
conditions on specified government test surfaces of
asphalt and concrete. A tire marked C may have poor
traction performance. Tread wear 200 Traction AA Temperature A
Wa r n i n g !
The traction grade assigned to this tire is based on
straight ahead braking traction tests, and does not
include acceleration, cornering, hydroplaning, or
peak traction characteristics.
J_G463.book Seite 367 Mittwoch, 19. September 2001 8:06 08

368 Consumer information
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Tempera t u re
The temperature grades are A (the highest), B, and C,
representing the tire’s resistance to the generation of
heat and its ability to dissipate heat when tested under
controlled conditions on a specified indoor laboratory
test wheel. Sustained high temperature can cause the
material of the tire to degenerate and reduce tire life,
and excessive temperature can lead to sudden tire
failure. The grade C corresponds to a level of
performance which all passenger vehicle tires must
meet under the Federal Motor Vehicle Safety Standard
No. 109. Grades B and A represent higher levels of
performance on the laboratory test wheel than the
minimum required by law.
Wa r n i n g !
The temperature grade for this tire is established
for a tire that is properly inflated and not
overloaded. Excessive speed, underinflation, or
excessive loading, either separately or in
combination, can cause excessive heat build up
and possible tire failure.
J_G463.book Seite 368 Mittwoch, 19. September 2001 8:06 08

369 Index
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex
Index
AA few words about differentials and
differential locks ....................................................... 251
ABS (Antilock brake system) .......................................239
LOW RANGE – ABS .................................................. 240
Air conditioner refrigerant ........................................... 363
Airbags .............................................................................. 66
Anticorrosion/antifreeze ................... 223, 306, 362, 366
Antiglare night position ................................................. 79
ANTILOCK BRAKE SYSTEM
Malfunction and warning message ........................ 275
Antilock brake system (ABS) .......................................239
LOW RANGE – ABS .................................................. 240
Antitheft alarm system ................................................... 42
Aquaplaning ...................................................................220
Ashtray
Center console, front ................................................ 168
Rear passenger compartment ................................. 169
Audio systems .................................................................. 96
CD Player ...................................................................... 97
Radio ............................................................................. 96Automatic central locking .............................................. 41
Automatic climate control
Adjustable air outlets,
rear passenger compartment ............................. 150
Automatic transmission ............................................... 207
Emergency Operation ............................................... 214
Fluid level .................................................................. 305
Selector lever position .............................................. 210
Transmission selector lever,
manually unlocking ............................................ 327
BBabySmart
TM airbag deactivation system ..................... 63
BAS (Brake assist system) ........................................... 237
Battery ............................................................................. 319
Battery recycling ...................................................... 320
Block heater ................................................................... 225
Brake assist system (BAS) ........................................... 237
Brake fluid ..............................................................217, 363
Capacity ..................................................................... 362
Brakes .................................................... 215, 217, 362, 363
Brush guard .................................................................... 182
J_G463.book Seite 369 Mittwoch, 19. September 2001 8:06 08

370 Index
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex
CCapacities
Fuels, coolants, lubricants etc. ............................... 361
Cargo area ....................................................................... 174
Loading instructions ................................................ 178
Cargo area cover blind .................................................. 180
Cargo compartment lamps ........................................... 159
Cargo tie-down rings ..................................................... 174
Catalytic converter ........................................................ 202
CD player
See Audio systems ...................................................... 96
CD-changer ..................................................................... 296
Cellular telephone ......................................................... 184
Center console .................................................................. 20
Central locking switch .................................................... 40
Central locking system ................................................... 29
Automatic central locking ......................................... 41
Central locking switch ............................................... 40
Choosing global or selective mode ........................... 31
General notes ............................................................... 28
Locking and unlocking
driver’s door manually .......................................... 36
Locking and unlocking
the tailgate manually ............................................. 38Locking and unlocking
with remote control ............................................... 31
Locking the tailgate separately ................................. 39
Mechanical keys ..........................................................33
Obtaining replacement keys .....................................27
Summer opening/convenience feature ...................32
Vehicle keys ................................................................. 26
Changing wheels ............................................................ 314
Check regularly and before a long trip ....................... 261
Checking engine oil level
Via oil dipstick .......................................................... 304
Child restraint ........................................................... 56, 73
Cleaning and care of the vehicle ................................ 350
Climate control ............................................................... 140
Adjustable air outlets,
rear passenger compartment ............................. 150
Air recirculation ........................................................ 146
Basic setting ............................................................... 144
Defrosting ................................................................... 145
Display and controls ................................................. 142
Dust filter ................................................................... 143
Economy mode .......................................................... 147
Residual engine heat utilization ............................. 148
Special settings ......................................................... 144
Windows fogged up on the inside .......................... 145
Windows fogged up on the outside ........................ 146
J_G463.book Seite 370 Mittwoch, 19. September 2001 8:06 08

371 Index
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex COMAND, radio and telephone ................................... 190
Combination switch ...................................................... 134
Consumer information .................................................. 367
Control and operation of radio transmitters ............. 190
Coolant level
Adding ........................................................................306
Checking .................................................................... 306
Coolant temperature gauge .......................................... 123
Coolants ........................................................................... 365
Anticorrosion/antifreeze quantity ......................... 365
Cover blind, cargo area ................................................. 180
Cover, spare wheel ......................................................... 312
Cruise control .................................................................234
Cup holder
In passenger footwell ............................................... 167
Next to the armrest ................................................... 166
Rear passenger footwell ........................................... 167
DDeep water
Driving instructions ................................................. 224
Differential locks ............................................................253
Differential locks, disengage ........................................256
Differential locks, engage ............................................. 254Door control panel ........................................................... 22
Door entry lamps ........................................................... 157
Doors ..................................................................................34
Drinking and driving ..................................................... 216
Drive sensibly - save fuel .............................................. 216
Driving instructions ...................................................... 216
Driving off ....................................................................... 218
EEasy-entry/exit feature ...................................................44
Electrical outlet ..............................................................301
Electronic Brake Booster (EBB) ................................... 242
Electronic key ................................................................... 27
Electronic main key
Changing batteries .................................................. 343
Synchronizing remote control ............................... 345
Electronic stability program (ESP) ............................. 243
Control switch .......................................................... 245
Synchronizing .......................................................... 244
Electronic traction system (4-ETS) .............................. 241
Emergency call
See Tele Aid ............................................................... 192
Emergency tensioning retractor (ETR) .........................65
Emergency unlocking in case of accident ................... 41
J_G463.book Seite 371 Mittwoch, 19. September 2001 8:06 08

372 Index
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex
Emission control ............................................................203
Emission control label .................................................. 357
Engine compartment .....................................................302
Engine oil additives ....................................................... 363
Engine oil consumption ................................................305
Engine oil level
Checking .................................................................... 304
Engine oil level indicator .............................................. 127
Engine oils ...................................................................... 363
Capacities ................................................................... 361
Enlarged cargo area ....................................................... 174
ESP (Electronic stability program) .............................. 243
Control switch ...........................................................245
Synchronizing ...........................................................244
ETR (Emergency tensioning retractor) ......................... 65
ETS (4-ETS) ..................................................................... 241
Exterior lamp switch ..................................................... 129
Daytime running lamp mode .................................. 131
Exterior lamps ................................................................ 328
Bulbs for low and high beam .................................. 331
Bulbs for parking and standing lamp .................... 331
Fog lamp, front ..........................................................332
Front and rear side marker lamps ......................... 337
Headlamp assembly ................................................. 329Headlamps .........................................................329, 352
High mounted stop lamp ......................................... 342
License plate lamps ................................................. 340
Rear fog lamp/Backup lamp .................................... 341
Replacing bulbs ........................................................ 328
Taillamp assemblies ................................................ 339
Turn signal lamp, front ........................................... 334
Turn signal lamp, side ............................................. 335
Exterior mirror adjustment ............................................80
Exterior mirror,
front passenger side, parking position .................... 82
Exterior rear view mirrors .............................................. 80
FFirst aid kit, vehicle tools and jack ............................ 296
Flexible service system (FSS) ...................................... 124
Floor mat ......................................................................... 170
Fog lamp, front .............................................................. 332
Folding backrest forward .............................................. 172
Folding seat bench ......................................................... 172
Four wheel electronic traction system (4-ETS) ......... 241
Front seat adjustment ..................................................... 45
Synchronizing head restraints and
seat adjustment fore, aft ....................................... 47
J_G463.book Seite 372 Mittwoch, 19. September 2001 8:06 08

373 Index
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex Fuel
Gasoline additives ....................................................365
Premium unleaded gasoline ................. 259, 362, 364
Fuel filler flap, manual release ...................................347
Fuel requirements ......................................................... 364
Fuel reserve warning ....................................................268
Fuels, coolants, lubricants etc. - Capacities .............. 361
Fuse box in battery box ................................................300
Fuse box in front passenger footwell ......................... 298
Fuse box in middle tunnel ........................................... 299
Fuse box in the passenger compartment ................... 297
Fuses, electrical ............................................................. 297
GGarage door opener ....................................................... 185
Gasoline
Additives .................................................................... 365
Fuel requirements ....................................................364
Premium unleaded ................................................... 364
Glove box ......................................................................... 163
HHazard warning flasher switch ................................... 139
Head restraints
Rear ............................................................................. 173
Removal ...................................................................... 173
Head restraints, front seats
Removal and installation ........................................... 51
Headlamp assembly
Halogen ...................................................................... 329
Headlamp cleaning system ........................................... 133
Headlamp mode (HEADLAMPS) .................................. 130
Heated seats, front ........................................................... 52
Heated seats, rear ............................................................ 54
High and low beam, bulb .............................................. 331
Hood ................................................................................ 302IIdentification labels ...................................................... 357
Illuminated vanity mirrors ........................................... 161
Indicator lamps in the instrument cluster ...................86
J_G463.book Seite 373 Mittwoch, 19. September 2001 8:06 08
