ANTENNA MODULE C1 (BUILT-UP-EXPORT)-2WAY
CAV CIRCUIT FUNCTION
1 F85 16VT/WT FUSED IGNITION SWITCH OUTPUT (RUN--ACC)
2- -
ANTENNA MODULE C2 (BUILT-UP-EXPORT)-2WAY
CAV CIRCUIT FUNCTION
1 X30 BK RADIO ANTENNA CORE
2 X31 BK RADIO ANTENNA SHIELD
ASH RECEIVER LAMP-2WAY
CAV CIRCUIT FUNCTION
1 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
2 Z158 20BK/GY GROUND
BACK-UP LAMP SWITCH (M/T) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 F15 18DB/WT FUSED IGNITION SWITCH OUTPUT (RUN)
2 L10 18BR/LG BACK-UP LAMP FEED
BATTERY TEMPERATURE SENSOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K118 18PK/YL BATTERY TEMPERATURE SENSOR SIGNAL
2 K4 18BK/LB SENSOR GROUND
8Wa - 80 - 8 8W-80 CONNECTOR PIN-OUTSKJ

BOOST PRESSURE SENSOR (DIESEL)-4WAY
CAV CIRCUIT FUNCTION
1 K4 18BK/LB SENSOR GROUND
2 K21 18BK/RD INTAKE AIR TEMPERATURE SENSOR SIGNAL
3 K6 18VT/WT SENSOR REFERENCE VOLTAGE B
4 K37 20DB/YL BOOST PRESSURE SENSOR SIGNAL
BRAKE LAMP SWITCH - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 F32 18PK/DB FUSED B(+)
2 L50 18WT/TN (GAS) BRAKE LAMP SWITCH OUTPUT
2 L50 18WT/TN (DIESEL) PRIMARY BRAKE SWITCH SIGNAL
3 V30 18DB/RD SPEED CONTROL BRAKE SWITCH OUTPUT
4 V32 18YL/RD SPEED CONTROL SUPPLY
5 Z3 18BK/OR GROUND
6 K29 18WT/PK (GAS) BRAKE SWITCH SENSE
6 K29 18WT/PK (DIESEL) SECONDARY BRAKE SWITCH SIGNAL
BRAKE PRESSURE SWITCH (ABS) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 F22 18DB/PK FUSED IGNITION SWITCH OUTPUT (RUN)
2 S43 18LB/YL FLUID PRESSURE SWITCH SIGNAL
C100 (RHD) - GRAY (INSTRUMENT PANEL SIDE)
CAV CIRCUIT
1 L43 18VT
2 F1 20DB
3 M1 18PK
4 B22 18LG/YL
5 L44 18VT/RD
6 V16 18VT/YL
7 V55 16TN/RD
8 G32 20DB/OR
9 D20 20LG
10 D25 18YL/VT/BR
11 V14 18RD/VT
12 L13 18BR/YL
13 G70 20BR/TN
14 G11 20WT/BK
15 K4 20BK/LB
16 L50 18WT/TN
17 L62 18BR/RD
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-11

G 202 - BLACK 14 WAY
CAV CIRCUIT FUNCTION
4- -
5- -
6 Z105 20BK/LG GROUND
7 Z231 16BK/WT GROUND
8 Z103 16BK/OR GROUND
9 Z131 10BK/GY GROUND
10 Z300 16BK GROUND
11 Z232 16BK/LB GROUND
12 - -
13 Z158 20BK/GY GROUND
14 Z110 20BK/TN (EXCEPT BASE) GROUND
GENERATOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 A71 18DG/RD (DIESEL) FUSED AUTO SHUT DOWN RELAY OUTPUT
1 K20 18DG (GAS) GENERATOR FIELD DRIVER
2 K20 18DG (DIESEL) GENERATOR FIELD CONTROL
2 K125 18WT/DB (GAS) GENERATOR SOURCE
GLOW PLUG ASSEMBLY (DIESEL) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K154 10GY GLOW PLUG RELAY NO. 1 OUTPUT
2 K104 10RD/WT GLOW PLUG RELAY NO. 2 OUTPUT
HAZARD SWITCH/COMBINATION FLASHER - WHITE 10 WAY
CAV CIRCUIT FUNCTION
1 A15 18PK/OR FUSED B(+)
2 Z3 18BK/OR GROUND
3 L62 18BR/RD RIGHT TURN SIGNAL
4 L91 20DB/PK HAZARD LAMP CONTROL
5 L305 20LB/WT LEFT TURN SWITCH SENSE
6- -
7 L63 18DG/RD LEFT TURN SIGNAL
8 F15 18DB/WT FUSED IGNITION SWITCH OUTPUT (RUN)
9 L302 20LB/YL RIGHT TURN SWITCH SENSE
10 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
8Wa - 80 - 62 8W-80 CONNECTOR PIN-OUTSKJ

IDLE AIR CONTROL MOTOR - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 K59 18VT/BK IDLE AIR CONTROL MOTOR NO. 4 DRIVER
2 K40 18BR/WT IDLE AIR CONTROL MOTOR NO. 1 DRIVER
3 K60 18YL/BK IDLE AIR CONTROL MOTOR NO. 2 DRIVER
4 K39 18GY/RD IDLE AIR CONTROL MOTOR NO. 3 DRIVER
IGNITION SWITCH - BLACK 10 WAY
CAV CIRCUIT FUNCTION
1 A1 12RD FUSED (+)
2 A21 12RD/DB IGNITION SWITCH OUTPUT (RUN-START)
3 F81 12TN IGNITION SWITCH OUTPUT (RUN-ACC)
4 A25 12DB FUSED B(+)
5 G26 20LB KEY-IN IGNITION SWITCH SENSE
6 A41 12YL IGNITION SWITCH OUTPUT (START)
7 A31 12BK/WT IGNITION SWITCH OUTPUT (RUN-ACC)
8 A22 12BK/OR IGNITION SWITCH OUTPUT (RUN)
9 A2 12PK/BK FUSED B (+)
10 Z232 16BK/LB GROUND
INPUT SPEED SENSOR (3.7L) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 T52 18RD/BK INPUT SPEED SENSOR SIGNAL
2 T13 18DB/BK SPEED SENSOR GROUND
INSTRUMENT CLUSTER - BLACK 20 WAY
CAV CIRCUIT FUNCTION
1 Z105 20BK/LG GROUND
2- -
3 Y98 20GY/DB INSTRUMENT CLUSTER WAKE UP SIGNAL
4- -
5 G18 20PK/BK LOW COOLANT FLUID LEVEL SENSE
6 L63 20DG/RD LEFT TURN SIGNAL
7 G9 20GY/BK PARK BRAKE SWITCH SENSE
8 G69 20BK/OR VTSS INDICATOR DRIVER
9- -
10 M1 20PK FUSED B(+)
11 L78 20DG/YL FUSED PARK LAMP RELAY OUTPUT
12 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
13 - -
14 D25 20YL/VT/RD PCI BUS
15 - -
8Wa - 80 - 64 8W-80 CONNECTOR PIN-OUTSKJ

JUNCTION BLOCK BODY CONTROL MODULE-JB - 26 WAY
CAV CIRCUIT FUNCTION
21 V14 FRONT WIPER ON/OFF RELAY CONTROL
22 P30 TAILGATE LOCK DRIVER
23 P36 DOOR LOCK SWITCH MUX
24 M2 COURTESY LAMP DRIVER
25 Z131 GROUND
26 M20 COURTESY LAMP LOAD SHED
JUNCTION BLOCK C1 - GRAY 42 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3 A21 12RD/DB IGNITION SWITCH OUTPUT (RUN-START)
4 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
5 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
6- -
7 X3 20BK/RD HORN RELAY CONTROL
8 L78 20DG/YL (EXCEPT BUILT-UP-EX-
PORT)FUSED PARK LAMP RELAY OUTPUT
8 L78 18DG/YL (BUILT-UP-EXPORT) FUSED PARK LAMP RELAY OUTPUT
9 F1 20DB (PREMIUM) FUSED IGNITION SWITCH OUTPUT (RUN-START)
10 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
11 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
12 M1 20PK FUSED B(+)
13 F33 20PK/RD FUSED B(+)
14 - -
15 M1 20PK FUSED B(+)
16 L50 18WT/TN BRAKE LAMP SWITCH OUTPUT
17 Z300 16BK GROUND
18 - -
19 - -
20 Z131 10BK/GY GROUND
21 L309 20LG/WT HIGH BEAM RELAY CONTROL
22 F14 18LG/YL FUSED IGNITION SWITCH OUTPUT (RUN-START)
23 M2 20YL COURTESY LAMP DRIVER
24 M2 20YL COURTESY LAMP DRIVER
25 F33 20PK/RD (PREMIUM) FUSED B(+)
26 F88 20BR/RD FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
27 M1 20PK FUSED B(+)
28 V23 20BR/PK FUSED IGNITION SWITCH OUTPUT (RUN)
29 V23 20BR/PK FUSED IGNITION SWITCH OUTPUT (RUN)
30 - -
31 F87 20TN/BK FUSED IGNITION SWITCH OUTPUT (RUN-START)
32 - -
33 F38 16RD/WT FUSED B(+)
34 C16 20LB/YL FUSED DEFOGGER RELAY OUTPUT
35 F30 16RD FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
36 - -
37 F32 18PK/DB FUSED B(+)
38 F15 18DB/WT FUSED IGNITION SWITCH OUTPUT (RUN)
39 F23 18DB/YL FUSED IGNITION SWITCH OUTPUT (RUN)
40 A31 12BK/WT IGNITION SWITCH OUTPUT (RUN-ACC)
41 A15 18PK/OR FUSED B(+)
42 A22 12BK/OR IGNITION SWITCH OUTPUT (RUN)
8Wa - 80 - 66 8W-80 CONNECTOR PIN-OUTSKJ

JUNCTION BLOCK C2 - GREEN 42 WAY
CAV CIRCUIT FUNCTION
1 F37 14RD/LB (MIDLINE/HIGHLINE) FUSED B(+)
2- -
3 C15 12BK/WT DEFOGGER RELAY OUTPUT
4 F89 18OR/RD FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
5 P37 20LG (EXCEPT BASE) DOOR LOCK SWITCH GROUND
6 P33 18OR/BK (EXCEPT BASE) DOOR LOCK RELAY OUTPUT
7 F22 18DB/PK FUSED IGNITION SWITCH OUTPUT (RUN)
8 P34 18PK/BK (EXCEPT BASE) DRIVER DOOR UNLOCK RELAY OUTPUT
9 P35 18OR/VT (EXCEPT BASE) PASSENGER DOOR UNLOCK RELAY OUTPUT
10 P36 20PK/VT (EXCEPT BASE) DOOR LOCK SWITCH MUX
11 P37 20LG (EXCEPT BASE) DOOR LOCK SWITCH GROUND
12 M20 20BR COURTESY LAMP LOAD SHED
13 L50 18WT/TN BRAKE LAMP SWITCH OUTPUT
14 P36 20PK/VT (EXCEPT BASE) DOOR LOCK SWITCH MUX
15 P30 16OR/WT TAILGATE LOCK DRIVER
16 F70 18PK/BK FUSED B(+)
17 L77 18BK/YL FUSED LEFT INBOARD TAIL LAMP
18 M1 20PK FUSED B(+)
19 M1 20PK FUSED B(+)
20 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
21 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
22 - -
23 V23 20BR/PK (HIGHLINE) FUSED IGNITION SWITCH OUTPUT (RUN)
24 V23 20BR/PK (EXCEPT BASE) FUSED IGNITION SWITCH OUTPUT (RUN)
25 V23 20BR/PK (MIDLINE/HIGHLINE) FUSED IGNITION SWITCH OUTPUT (RUN)
26 L78 18DG/YL FUSED PARK LAMP RELAY OUTPUT
27 - -
28 A6 16RD/BK (PREMIUM GAS) FUSED B(+)
29 - -
30 M2 18YL COURTESY LAMP DRIVER
31 C16 18LB/YL (EXCEPT BASE) FUSED DEFOGGER RELAY OUTPUT
32 F14 18LG/YL FUSED IGNITION SWITCH OUTPUT (RUN-START)
33 F14 18LG/YL FUSED IGNITION SWITCH OUTPUT (RUN-START)
34 L38 18BR/WT (HIGHLINE) REAR FOG LAMP RELAY OUTPUT
35 P31 16PK/WT TAILGATE UNLOCK DRIVER
36 - -
37 F60 16DG/RD (PREMIUM) FUSED B(+)
38 F87 20WT/BK FUSED IGNITION SWITCH OUTPUT (RUN-START)
39 C16 18LB/YL (EXCEPT BASE) FUSED DEFOGGER RELAY OUTPUT
40 F85 16VT/WT (MIDLINE/HIGHLINE) FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
41 F41 16PK/VT FUSED B(+)
42 A3 16RD/WT (HIGHLINE) FUSED B(+)
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-67

LEFT INSTRUMENT PANEL SPEAKER - WHITE 2 WAY
CAV CIRCUIT FUNCTION
1 X53 18DG (BASE) LEFT FRONT SPEAKER (+)
1 X83 18YL/RD (PREMIUM) AMPLIFIED HIGH LEFT FRONT SPEAKER (+)
2 X55 18BR/RD (BASE) LEFT FRONT SPEAKER (-)
2 X81 18YL/BK (PREMIUM) AMPLIFIED HIGH LEFT FRONT SPEAKER (-)
LEFT LEVELING MOTOR (BUILT-UP-EXPORT) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 Z141 18BK GROUND
2 L13 18BR/YL HEADLAMP ADJUST SIGNAL
3 L77 18BK/YL FUSED PARK LAMP RELAY OUTPUT
LEFT POSITION LAMP (BUILT-UP-EXPORT) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 L77 18BK/YL FUSED PARK LAMP RELAY OUTPUT
2 Z141 18BK GROUND
LEFT POWER MIRROR (EXCEPT BASE) - WHITE 8 WAY
CAV CIRCUIT FUNCTION
1 P71 20YL/DG LEFT MIRROR UP DRIVER
2 P76 20OR/YL MIRROR COMMON DRIVER
3 P75 20LB/WT LEFT MIRROR LEFT DRIVER
4- -
5 C16 20LB/YL FUSED DEFOGGER RELAY OUTPUT
6 Z350 20BK/LG GROUND
7 P99 20GY (WITH FOLD) FOLDING MIRROR FEED
8 P110 20YL (WITH FOLD) FOLDING MIRROR RETURN
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-73

MULTI-FUNCTION SWITCH C1 - GRAY 10 WAY
CAV CIRCUIT FUNCTION
1 E21 20OR/RD PANEL LAMPS DIMMER SWITCH MUX
2 L27 20WT/TN (EXCEPT BASE) FRONT FOG LAMP SWITCH SENSE
3- -
4 L80 20WT/DG HEADLAMP SWITCH RETURN
5 L307 20LG/OR HEADLAMP SWITCH MUX
6 L305 20LB/WT LEFT TURN SWITCH SENSE
7 L309 20LG/WT HIGH BEAM RELAY CONTROL
8 Z12 18BK/TN GROUND
9 L324 20WT/LG HIGH BEAM SWITCH SENSE
10 L302 20LB/YL RIGHT TURN SWITCH SENSE
MULTI-FUNCTION SWITCH C2 - GRAY 8 WAY
CAV CIRCUIT FUNCTION
1 V21 20DB/RD REAR WIPER ON DRIVER
2 V22 20BR/YL REAR WIPER INTERMITTENT DRIVER
3 V20 18BK/WT WASHER MOTOR SENSE
4 V52 20DG/RD FRONT WIPER SWITCH MUX
5 F88 20BR/RD FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
6- -
7 V10 18BR WASHER PUMP DRIVER
8- -
OUTPUT SPEED SENSOR (3.7L) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 T14 18LG/WT OUTPUT SPEED SENSOR SIGNAL
2 T13 18DB/BK SPEED SENSOR GROUND
OVERHEAD MAP/READING LAMP (EXCEPT BASE) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 M1 20PK FUSED B(+)
2 M2 20YL REAR COURTESY LAMP CONTROL
3 M20 20BR COURTESY LAMPS LOAD SHEED
8Wa - 80 - 78 8W-80 CONNECTOR PIN-OUTSKJ
