2002 BUICK PARK AVENUE Owner's Manual

3-6
NOTICE:
Don't use a razor blade or something else sharp
on the inside of the rear window. If you do, you
could cut or damage the warming grid or the
integrated rear window antenna, and the repairs
wouldn't be covered by your warranty.
Passenger Climate Control
The front seat passenger can control the air temperature
in his or her seating area. This can be set up to 5
F
(3
C) cooler or warmer than the primary setting. You
can activate this feature by sliding the lever located on
the right side of the instrument panel toward WARM
or COOL.
If the passenger climate control has been turned on, it
can be turned off by pressing the OFF button on the
climate control system faceplate once. Pressing the OFF
button a second time will turn off the main system.
Personal Choice Comfort Controls
(If Equipped)
This feature enables up to two drivers to store and recall
comfort control settings for the temperature, fan speed
and the direction of the air flow.
The memory buttons (1 or 2) for this feature are located
on the driver's door panel and correspond to the
numbers (1 or 2) found on the back of each remote
keyless entry transmitter.
To recall comfort settings, press the unlock button on the
remote keyless entry transmitter and put the ignition in
ACCESSORY or RUN. The climate control setting last
chosen by the identified driver (1 or 2) will be recalled.

3-7
To program a personal choice comfort control setting,
do the following:
1. Choose a climate control setting for the driver and
if desired, for the passenger. See ªDual Automatic
ComforTemp
Climate Controlº and ªPassenger
Climate Controlº earlier in this section.
2. Locate the memory buttons on the driver's door panel.
3. Press a memory button (1 or 2) until you hear two
beeps. The beeps confirm that your selection has
been saved and can now be recalled.
Follow these steps each time you want to change the
stored settings. For more information on the memory
feature, see ªMemory Seat and Mirrorsº in the Index.
Ventilation System
For mild outside temperatures when little heating or
cooling is needed, use VENT in manual mode to direct
outside air through your vehicle. Air will flow through
any of the outlets depending on outside temperatures
and climate control settings.
Your vehicle's flow
-through ventilation system supplies
outside air into the vehicle when it's moving. When the
vehicle is not moving, you can get outside air to flow
through your vehicle by pressing VENT and then using
the AIR FLOW button to select a mode and the FAN
button to select a fan speed.
Change the direction of
airflow by adjusting the
louvered vents.
You have rear passenger
ComforTemp outlets that
you can use to change the
direction of the airflow to
the rear seating area. The
temperature is controlled by
the front passenger.

3-8
Ventilation Tips

Keep the hood and front air inlet free of ice, snow or
any other obstruction such as leaves. The heater and
defroster will work better, reducing the chance of
fogging your windows.

Keep the air path under the front seats clear of
objects. This helps air to circulate throughout
your vehicle.
Steering Wheel Controls for
Climate Control
You can control the
temperature inside of your
vehicle using the button
located on your steering
wheel. Press the TEMP
up arrow to increase the
temperature and the TEMP
down arrow to decrease
the temperature.
Audio Systems
Your audio system has been designed to operate easily
and give years of listening pleasure. You will get the
most enjoyment out of it if you acquaint yourself with it
first. Find out what your audio system can do and how
to operate all of its controls to be sure you're getting the
most out of the advanced engineering that went into it.
Your vehicle has a feature called Retained Accessory
Power (RAP). With RAP, you can play your audio
system even after the ignition is turned off. See
ªRetained Accessory Powerº in the Index.
Setting the Clock
Press and hold the HRS button until the correct hour
appears. Press and hold the MIN button until the correct
minute appears.
You may set the clock with the ignition off if you
press RECALL first and follow the same procedure
described above.

3-9 AM-FM Stereo with Cassette Tape Player
and Automatic Tone Control (If Equipped)
Playing the Radio
ON/OFF: Push this knob to turn the system on and off.
VOLUME: Turn the knob clockwise to increase volume.
Turn it counterclockwise to decrease the volume.RECALL: Press this button to display the station being
played or to display the clock. To change what is
normally shown on the display (station or time), press
this button until you see the display you want, then hold
the button until the display flashes. If you press the
button when the ignition is off, the clock will show for a
few seconds.
Finding a Station
AM
-FM: Press this button to switch between AM,
FM1 and FM2. The display shows your selection.
 TUNE
: Press the up or down arrow to choose
radio stations.
 SEEK
: Press the up or down arrow to go to the
next or previous station and stay there. The radio will
seek to stations with a strong signal only. The sound will
mute while seeking.
To scan stations, press and hold one of the SEEK arrows
for two seconds and SCAN will appear on the display.
The radio will go to a station, play for a few seconds,
then go on to the next station. Press one of the SEEK
arrows again to stop scanning. The radio will scan to
stations with a strong signal only. The sound will mute
while scanning.

3-10
P SCAN (Preset Scan): Press this button to listen to
each of your preset stations for a few seconds. The radio
will go to the first preset station, play for a few seconds,
then go on to the next preset station. Press P SCAN
again to stop scanning. The radio will scan preset
stations with a strong signal only. The sound will mute
while scanning.
AUTO (Automatic) SET: Press this button and the
system will seek and set the 12 strongest FM or the
6 strongest AM stations on your preset pushbuttons
(depending on which band (AM or FM) you are
listening to). AUTO SET will flash while seeking
and will remain on until this function is complete.
To return to the stations you manually set, press
AUTO SET again.
Setting Preset Stations
The six numbered pushbuttons let you return to
your favorite stations. You can set up to 18 stations
(six AM, six FM1 and six FM2) by performing the
following steps:
1. Turn the radio on.
2. Press AM
-FM to select the band.
3. Tune in the desired station.
4. Press TONE to select the setting you prefer.5. Press and hold one of the six numbered pushbuttons.
The sound will mute. When it returns, release the
pushbutton. Whenever you press that numbered
pushbutton, the station you set will return and the
tone you selected will be automatically selected for
that button.
6. Repeat the steps for each pushbutton.
Setting the Tone (Bass/Treble)
BASS: Press this knob lightly so it extends. Turn the
knob to increase or decrease bass.
TREB (Treble): Press this knob lightly so it extends.
Turn the knob to increase or decrease treble. If a station
is weak or noisy, you may want to decrease the treble.
Push these knobs back into their stored positions when
you're not using them.
TONE: This feature allows you to choose preset bass
and treble equalization settings designed for
country/western, jazz, talk, pop and classical stations.
CLASS will appear on the display when you first
press TONE.

3-11
Each time you press the TONE button, this feature will
switch to one of these program types.
To return the bass and treble to the manual mode, either
press TONE, BASS or TREB until MANUAL appears.
See ªSetting Preset Stationsº listed previously to
program the auto tone feature.
Adjusting the Speakers (Balance/Fade)
BAL (Balance): Press this knob lightly so it extends.
Turn the knob to move the sound to the left or right
speakers. The middle position balances the sound
between the speakers.
FADE: Press this knob lightly so it extends. Turn
the knob to move the sound to the front or rear
speakers. The middle position balances the sound
between the speakers.
Push these knobs back into their stored positions when
you're not using them.
Playing a Cassette Tape
The longer side with the tape visible should face to the
right. If the ignition and the radio are on, the tape can be
inserted and will begin playing. If you hear nothing or
hear a garbled sound, the tape may not be in squarely.
Press EJECT to remove the tape and start over.While the tape is playing, use the VOLUME, SEEK,
FADE, BAL, BASS and TREB controls just as you
do for the radio. Other controls may have different
functions when a tape is inserted. The display will show
an arrow to show which side of the tape is playing.
If you want to insert a tape when the ignition or radio is
off, first press EJECT or RECALL. Cassette tape
adapter kits for portable compact disc players will work
in your cassette tape player.
Your tape bias is set automatically.
If an error appears on the display, see ªCassette Tape
Messagesº later in this section.
1 PREV (Previous): Press this pushbutton to search for
the previous selection on the tape. Your tape must have at
least three seconds of silence between each selection for
previous to work. The sound will mute while seeking.
2 NEXT: Press this pushbutton to search for the next
selection on the tape. Your tape must have at least three
seconds of silence between each selection for next to
work. The sound will mute while seeking.
3


(Reverse): Press this pushbutton to reverse the
tape rapidly. Press it again to return to playing speed.
The radio will play while the tape reverses.

3-12
4

(Forward): Press this pushbutton to advance
quickly to another part of the tape. Press it again to
return to playing speed. The radio will play while the
tape advances.
5 SIDE: Press this pushbutton to change the side of the
tape that is playing.
6
(Dolby): Press this pushbutton to reduce
background noise. The double
-D symbol will appear on
the display.
Dolby Noise Reduction is manufactured under a license
from Dolby Laboratories Licensing Corporation. Dolby
and the double
-D symbol are trademarks of Dolby
Laboratories Licensing Corporation.
AM
-FM: Press this button to listen to the radio when a
cassette tape is playing.
SOURCE: Press this button to play a tape when
listening to the radio. TAPE PLAY with an arrow will
appear on the display when the tape is active.
 SEEK : Press the up or down arrow to go to
the next or previous selection on the tape. Your tape
must have at least three seconds of silence between
each selection for seek to work. The sound will mute
while seeking.
EJECT: Press this button to eject a tape. Eject may be
activated with the radio off.Cassette Tape Messages
E (Error): If this message and a number appears while
trying to play a cassette tape, it could be for one of the
following reasons:
E10: The tape is tight and the player can't turn the
tape hubs. Remove the tape. Hold the tape with the
open end down and try to turn the right hub
counterclockwise with a pencil. Turn the tape over
and repeat. If the hubs do not turn easily, your tape
may be damaged and should not be used in the
player. Try a new tape to make sure your player is
working properly.
E11: The tape is broken. Try a new tape.
CLN (Clean): If this message appears on the display,
the cassette tape player needs to be cleaned. It will still
play tapes, but you should clean it as soon as possible to
prevent damage to the tapes and player. See ªCare of
Your Cassette Tape Playerº in the Index.
If any error occurs repeatedly or if an error can't be
corrected, contact your dealer. If your radio displays an
error number, write it down and provide it to your dealer
when reporting the problem.

3-13 AM-FM Stereo with Cassette Tape and
Compact Disc Player with Automatic Tone
Control (If Equipped)
Playing the Radio
ON/OFF: Push this knob to turn the system on and off.
VOLUME: Turn this knob clockwise to increase
volume. Turn it counterclockwise to decrease volume.RECALL: Press this button to display the station being
played or to display the clock. To change what is
normally shown on the display (station or time), press
this button until you see the display you want, then hold
this button until the display flashes. Press this button
when the ignition is off to display the clock.
Finding a Station
AM
-FM: Press this button to switch between AM, FM1
and FM2. The display shows your selection.
 TUNE
: Press the up or down arrow to choose
radio stations.
 SEEK
: Press the up or down arrow to go to the
next or previous station and stay there. The radio will
seek to stations with a strong signal only. The sound will
mute while seeking.
To scan, press one of the SEEK arrows for two seconds
and SCAN will appear on the display. The radio will go
to a station, play for a few seconds, then go on to the
next station. Press one of the SEEK arrows again to stop
scanning. The radio will scan to stations with a strong
signal only. The sound will mute while scanning.
