Page 3671 of 4323

BO4S6±01
H24329
37 (380, 27)
37 (380, 27)
37 (380, 27)
37 (380, 27)
37 (380, 27)
42 (430, 32) Seatback Cover
Seat Cushion
Cover
Seat Cushion
PadArmrest CapArmrest Spacer
Armrest
Lock Plate
Spacer
Armrest
AssemblyHeadrest
Headrest Support Seatback Pad
Lumbar Support
Adjuster
Seat Frame Assembly Seat Position Sensor
Protector
Seat Position
Sensor
Seat Cushion
Inner Shield
Seat Cushion
Lower ShieldFront Seat Inner BeltRH Reclining
Adjuster Inside
CoverRH Seatback
ShieldVertical Adjuster
Bracket Inner Cover
Vertical Adjuster
Bracket Outer Cover
LH Reclining
Adjuster Inside Cover
Reclining Knob
Slide Knob
Seat Cushion Outer ShieldLumbar Switch Power Seat SwitchLH Seatback Shield
Hog RingSeat Track
Cover
Seat Track
CoverBushing
Hog Ring
Non±reusable part: Specified torque
N´m (kgf´cm, ft´lbf)
w/ Side airbag:
5.5 (56, 49 in.´lbf)
w/ Seat heater:
w/ Seat heater:
Seat Cushion Heater Assembly
Seatback
Heater Assembly
Occupant Classification ECUPassenger's seat:
Driver's seat:
Driver's seat:
BO±110
± BODYFRONT SEAT (Power Adjuster Type)
3663 Author: Date:
2005 SEQUOIA (RM1146U)
FRONT SEAT (Power Adjuster Type)
COMPONENTS
HINT:
The procedures listed below are for the LH side.
Page 3677 of 4323
H24327
BO±116
± BODYFRONT SEAT (Power Adjuster Type)
3669 Author: Date:
2005 SEQUOIA (RM1146U)
16. REMOVE RH AND LH SEATBACK SHIELDS
(a) Remove the 2 screws and RH seatback shield.
(b) Perform the same procedure on the other side.
17. REMOVE VERTICAL ADJUSTER BRACKET INNER
AND OUTER COVERS
(a) Remove the screw and vertical adjuster bracket inner
cover.
(b) Perform the same procedure on the other side.
18. Driver 's seat:
REMOVE SEAT POSITION SENSOR
(See page RS±104)
Page 3678 of 4323

BO4SA±01
H24327
H24326
H24325
± BODYFRONT SEAT (Power Adjuster Type)
BO±117
3670 Author: Date:
2005 SEQUOIA (RM1146U)
REASSEMBLY
CAUTION:
Wear safety gloves, because the sharp edges and surfaces
of the seat frame may cause injury to the hands.
HINT:
The procedures listed below are for the LH side.
A bolt without a torque specification is shown in the stan-
dard bolt chart (see page SS±2).
1. Driver 's seat:
INSTALL SEAT POSITION SENSOR
(SEE PAGE RS±108)
2. INSTALL VERTICAL ADJUSTER BRACKET INNER
AND OUTER COVERS
(a) Install the vertical adjuster bracket inner cover with the
screw.
(b) Perform the same procedure on the other side.
3. INSTALL RH AND LH SEATBACK SHIELDS
(a) Install the RH seatback shield with the 2 screws.
(b) Perform the same procedure on the other side.
4. INSTALL RH AND LH RECLINING ADJUSTER INSIDE
COVERS
(a) Connect the wire harness clamp.
(b) Install the RH reclining adjuster inside cover with the
screw.
(c) Perform the same procedure on the other side.
5. INSTALL LUMBAR SUPPORT ADJUSTER
(a) Install a new bushing to the lumbar support adjuster.
(b) Install the lumbar support adjuster with the 2 screws.
Page 3685 of 4323

BO4SB±01
H24345
RH Lower Reclining
Adjuster Inside Cover
Seat Cushion
Outer Shield
Vertical Adjuster Handle Cap Reclining Adjuster Release Handle Seat Cushion
Inner ShieldRH Upper Reclining
Adjuster Inside Cover
RH Seat Cushion
Lower Shield
LH Lower Reclining
Adjuster Inside CoverLH Upper Reclining
Adjuster Inside CoverLH Seat Cushion
Lower Shield
Vertical Adjuster Handle
Non±reusable part: Specified torque
N´m (kgf´cm, ft´lbf)
Driver's seat:
Driver's seat:
37 (380, 27)
37 (380, 27)37 (380, 27)
37 (380, 27)
42 (430, 32) Seatback Cover
Seat Cushion
Cover
Seat Cushion
PadArmrest CapArmrest SpacerArmrest
Lock Plate
Spacer
Armrest AssemblyHeadrest
Headrest Support Seatback Pad
Seat Frame Assembly
Seat Position Sensor
Protector
Seat Position Sensor
Front Seat
Inner Belt Hog RingSeat Track Cover
Seat Track Cover
Hog Ring
37 (380, 27)
Occupant Classification ECUPassenger's seat:
w/ Side airbag:
5.5 (56, 49 in.´lbf)
BO±124
± BODYFRONT SEAT (Manual Adjuster Type)
3677 Author: Date:
2005 SEQUOIA (RM1146U)
FRONT SEAT (Manual Adjuster Type)
COMPONENTS
HINT:
The procedures listed below are for the LH side.
Page 3690 of 4323
H24343
H24341
± BODYFRONT SEAT (Manual Adjuster Type)
BO±129
3682 Author: Date:
2005 SEQUOIA (RM1146U)
13. REMOVE RH AND LH LOWER RECLINING ADJUSTER
INSIDE COVERS
(a) Remove the screw and LH lower reclining adjuster inside
cover.
(b) Perform the same procedure on the other side.
14. REMOVE RH AND LH SEAT CUSHION LOWER
SHIELDS
(a) Using a screwdriver, disengage the claw and remove the
LH seat cushion lower shield.
HINT:
Tape the screwdriver tip before use.
(b) Perform the same procedure on the other side.
15. Driver 's seat:
REMOVE SEAT POSITION SENSOR
(See page RS±104)
Page 3691 of 4323

BO4SE±01
H24343
H24342
H24395
BO±130
± BODYFRONT SEAT (Manual Adjuster Type)
3683 Author: Date:
2005 SEQUOIA (RM1146U)
REASSEMBLY
CAUTION:
Wear safety gloves, because the sharp edges and surfaces
of the seat frame may cause injury to the hands.
HINT:
The procedures listed below are for the LH side.
A bolt without a torque specification is shown in the stan-
dard bolt chart (see page SS±2).
1. Driver 's seat:
INSTALL SEAT POSITION SENSOR
(SEE PAGE RS±108)
2. INSTALL RH AND LH SEAT CUSHION LOWER
SHIELDS
3. INSTALL RH AND LH LOWER RECLINING ADJUSTER
INSIDE COVERS
(a) Install the LH lower reclining adjuster inside cover with the
screw.
(b) Perform the same procedure on the other side.
4. INSTALL RH AND LH UPPER RECLINING ADJUSTER
INSIDE COVERS
(a) Install the LH upper reclining adjuster inside cover with
the screw.
(b) Perform the same procedure on the other side.
5. INSTALL SEAT CUSHION COVER
Install the seat cushion cover to the seat cushion pad with the
hog rings.
HINT:
When installing the hog rings, take as much care as possible to
prevent wrinkles.
6. INSTALL SEAT CUSHION COVER AND PAD
(a) Install the seat cushion cover with seat cushion pad, and
latch the seat cushion cover hooks.
Page 3744 of 4323

± AIR CONDITIONINGAIR CONDITIONING SYSTEM
AC±9
3736 Author: Date:
2005 SEQUOIA (RM1146U)
3. INSPECT IDLE±UP SPEED
(a) Warm up the engine.
(b) Inspect idle±up speed when the following conditions are
established.
Warm up engine
Blower speed control switch at ºHIº position
A/C switch ON
Temperature control dial at ºCOOLº position
Magnetic clutch conditionIdle±up speed
Magnetic clutch not engaged700 ± 50 rpm
Magnetic clutch engaged780 ± 50 rpm
If idle speed is not as specified, check the Idle control system.
4. INSPECT FOR LEAKAGE OF REFRIGERANT
(a) Perform under the following conditions:
Stop the engine.
Secure good ventilation (If not, the gas leak detec-
tor may react to volatile gases witch are not refriger-
ant, such as evaporated gasoline and exhaust gas.)
Repeat the test 2 or 3 times.
Make sure that there is some refrigerant remaining
in the refrigeration system.
When the compressor is OFF: approx. 392 to 588
kPa (4 to 6 kgf/ cm
2, 57 to 85 psi)
(b) Bring the gas leak detector close to the drain hose before
performing the test.
HINT:
After the blower motor stopped, leave the cooling unit for
more than 15 minutes.
Bring the gas leak detector sensor under the drain hose.
When bringing the gas leak detector close to the drain
hose, make sure that the gas leak detector does not react
to the volatile gases.
If such reaction is unavoidable, the vehicle must be lifted up.
(c) If gas leak is not detected on the drain hose, remove the
blower motor linear controller from the cooling unit. Then
insert the gas leak detector sensor into the unit and per-
form the test.
(d) Disconnect the connector and leave the pressure switch
for approx. 20 minutes. Then bring the gas leak detector
close to the pressure switch and perform the test.
(e) Bring the gas leak detector close to the refrigerant lines
and perform the test.
Page 3748 of 4323
AC1JW±06
I21418
R/B No. 2
Heater Main Relay
(Marking: HTR)
Compressor
Condenser
Receiver Pressure Switch
Integration Panel Assembly
A/C ECU
A/C Switch
Air Inlet Selector
Heater Unit
Heater Radiator
Air Mix Servomotor
Air Outlet Servomotor
Cooling Unit
Blower Motor Linear
Controller
Evaporator
Expansion Valve
ThermistorBlower Unit
Blower Motor
Air Inlet Servomotor
Water Valve
Rear Heater
Control Assembly
Condenser Fan
Ambient
Temperature
Sensor
Solar Sensor
Room
Temperature
Sensor
Rear Room Temperature Sensor
± AIR CONDITIONINGAIR CONDITIONING SYSTEM
AC±13
3740 Author: Date:
2005 SEQUOIA (RM1146U)
LOCATION
