Page 103 of 1897
Q10172
Front
Q10064
Rear
Q04659
Q04660
Q10036
AX-40
- AUTOMATIC TRANSAXLEAUTOMATIC TRANSAXLE UNIT
1330 Author: Date:
2001 AVALON (RM808U)
(b) Remove the 6 bolts, 4 nuts, 4 lower brace and front frame
assembly.
Torque:
19 mm head bolt: 181 N´m (1,850 kgf´cm, 134 ft´lbf)
14 mm head bolt: 32 N´m (330 kgf´cm, 24 ft´lbf)
Nut: 36 N´m (370 kgf´cm, 27 ft´lbf)
34. SUPPORT TRANSAXLE WITH A JACK
35. REMOVE TORQUE CONVERTER CLUTCH MOUNT-
ING BOLT
(a) Remove the 2 bolts and hole cover.
(b) Turn the crankshaft to gain access to each bolt, remove
the 6 bolts while holding the crankshaft pulley bolt with a
wrench.
Torque: 41 N´m (420 kgf´cm, 30 ft´lbf)
HINT:
At the time of installation, please refer to the following item.
First install black colored bolt and then the 5 other bolts.
36. REMOVE EXHAUST MANIFOLD PLATE
Remove the bolt, nut and exhaust manifold plate.
Torque: 34 N´m (350 kgf´cm, 25 ft´lbf)
Page 104 of 1897
Z14284
Left and lower
- AUTOMATIC TRANSAXLEAUTOMATIC TRANSAXLE UNIT
AX-41
1331 Author: Date:
2001 AVALON (RM808U)
37. REMOVE 3 LOWER TRANSAXLE- TO- ENGINE
BOLTS
Torque: 48 N´m (490 kgf´cm, 35 ft´lbf)
38. REMOVE TRANSAXLE ASSEMBLY
Separate the transaxle from the engine, and lower the trans-
axle.
Page 105 of 1897
Q05726
AX03O-04
Q04733
O-Ring
- AUTOMATIC TRANSAXLEDIRECT CLUTCH SPEED SENSOR
AX-3
1293 Author: Date:
2001 AVALON (RM808U)
DIRECT CLUTCH SPEED SENSOR
ON-VEHICLE REPAIR
1. REMOVE AIR CLEANER ASSEMBLY
2. DISCONNECT DIRECT CLUTCH SPEED SENSOR
CONNECTOR
3. REMOVE DIRECT CLUTCH SPEED SENSOR
(a) Remove the bolt and direct clutch speed sensor.
(b) Remove the O-ring from the direct clutch speed sensor.
4. INSTALL DIRECT CLUTCH SPEED SENSOR
(a) Coat a new O-ring with ATF and install it to the direct
clutch speed sensor.
(b) Install the direct clutch speed sensor with the bolt.
Torque: 11 N´m (110 kgf´cm, 8 ft´lbf)
5. CONNECT DIRECT CLUTCH SPEED SENSOR CON-
NECTOR
6. INSTALL AIR CLEANER ASSEMBLY
Page 107 of 1897
AX0KB-01
D07772
Radio Assembly with Heater Control & Accessory Assembly Except Taiwan Spec.:
Lower Instrument Panel
Sub-assembly
Lower No. 4 Instrument
Panel Sub-assembly
Hood Lock
Release Lever
Radio Tuner Opening
Covers with Heater
Console & Accessory
Assembly Taiwan Spec.:Taiwan Spec.:
Center Instrument Cluster Finish Panel
Sub-assemblyNo. 2 Instrument Panel
Under Cover Sub-assembly
Front Ash Receptacle Assembly
Upper Console Panel
Sub-assembly
Console Box Plate
Front Console Box
Assembly
Upper Rear Console
Panel Sub-assembly
Clip
Shift Control
Cable
Floor Shift Lever Assembly
12 (120,9)
Rear Console Box Assembly
RH Cowl Side Trim
RH Scuff Plate
N´m (kgf´cm, ft´lbf) : Specified torqueRH Cowl Side Trim
RH Scuff Plate
AX-20
- AUTOMATIC TRANSAXLEFLOOR SHIFT ASSEMBLY
1310 Author: Date:
2001 AVALON (RM808U)
FLOOR SHIFT ASSEMBLY
COMPONENTS
Page 117 of 1897
- AUTOMATIC TRANSAXLEFLOOR SHIFT ASSEMBLY
AX-31
1321 Author: Date:
2001 AVALON (RM808U)
(c) Install the 2 shift lever sub-assembly set screws.
Torque: 2.2 N´m (22 kgf´cm, 19 in.´lbf)
(d) Raise the shift lever knob cover.
14. CONNECT O/D MAIN SWITCH TERMINAL
(a) Connect the terminals of the O/D main switch.
(b) Connect the O/D main switch connector to the shift lever
plate.
Page 119 of 1897
D07219
- AUTOMATIC TRANSAXLEFLOOR SHIFT ASSEMBLY
AX-23
1313 Author: Date:
2001 AVALON (RM808U)
(c) Remove the 2 bolts from the brace.
(d) Remove the 4 bolts and floor shift assembly.
Torque: 12 N´m (120kgf´cm, 9 ft´lbf)
Page 120 of 1897
AX0KB-01
D07772
Radio Assembly with Heater Control & Accessory Assembly Except Taiwan Spec.:
Lower Instrument Panel
Sub-assembly
Lower No. 4 Instrument
Panel Sub-assembly
Hood Lock
Release Lever
Radio Tuner Opening
Covers with Heater
Console & Accessory
Assembly Taiwan Spec.:Taiwan Spec.:
Center Instrument Cluster Finish Panel
Sub-assemblyNo. 2 Instrument Panel
Under Cover Sub-assembly
Front Ash Receptacle Assembly
Upper Console Panel
Sub-assembly
Console Box Plate
Front Console Box
Assembly
Upper Rear Console
Panel Sub-assembly
Clip
Shift Control
Cable
Floor Shift Lever Assembly
12 (120,9)
Rear Console Box Assembly
RH Cowl Side Trim
RH Scuff Plate
N´m (kgf´cm, ft´lbf) : Specified torqueRH Cowl Side Trim
RH Scuff Plate
AX-20
- AUTOMATIC TRANSAXLEFLOOR SHIFT ASSEMBLY
1310 Author: Date:
2001 AVALON (RM808U)
FLOOR SHIFT ASSEMBLY
COMPONENTS
Page 130 of 1897
- AUTOMATIC TRANSAXLEFLOOR SHIFT ASSEMBLY
AX-31
1321 Author: Date:
2001 AVALON (RM808U)
(c) Install the 2 shift lever sub-assembly set screws.
Torque: 2.2 N´m (22 kgf´cm, 19 in.´lbf)
(d) Raise the shift lever knob cover.
14. CONNECT O/D MAIN SWITCH TERMINAL
(a) Connect the terminals of the O/D main switch.
(b) Connect the O/D main switch connector to the shift lever
plate.
