SEL048Z
SEL049Z
REAR COVER INSTALLATIONNLSC0023S021. Fit brush assembly, diode assembly, regulator assembly and
stator.
2. Push brushes up with fingers and install them to rotor.
Take care not to damage slip ring sliding surface.
CHARGING SYSTEM
Assembly (Cont’d)
SC-33
