2001 NISSAN ALMERA TINO charging

Wiring Diagram—CHARGE—NLSC0010MODELS WITH FUSE AND FUSIBLE LINK BOX E43NLSC0010S04
YEL858B
CHARGING SYSTEM
Wiring Diagram—CHARGE—
SC-25

MODELS WITH FUSE AND FUSIBLE LINK BOX E90NLSC0010S05
YEL388C
CHARGING SYSTEM
Wiring Diagram—CHARGE—(Cont’d)
SC-26

Trouble DiagnosesNLSC0011Before conducting an alternator test, make sure that the battery is fully charged. A 30-volt voltmeter and suit-
able test probes are necessary for the test. The alternator can be checked easily by referring to the Inspec-
tion Table.
+Before starting, inspect the fusible link.
+Use fully charged battery.
WITH IC REGULATORNLSC0011S01
SEL338V
NOTE:
+If the inspection result is OK even though the charging system is malfunctioning, check the B terminal
connection. (Check the tightening torque.)
+When field circuit is open, check condition of rotor coil, rotor slip ring and brush. If necessary, replace faulty
parts with new ones.
MALFUNCTION INDICATORNLSC0011S02The IC regulator warning function activates to illuminate“CHARGE”warning lamp, if any of the following
symptoms occur while alternator is operating:
+Excessive voltage is produced.
+No voltage is produced.
CHARGING SYSTEM
Trouble Diagnoses
SC-27

ConstructionNLSC0012
MEL141LA
MEL497L
CHARGING SYSTEM
Construction
SC-28

NEL733
YEL427B
CHARGING SYSTEM
Construction (Cont’d)
SC-29

NEL732
Removal and InstallationNLSC0013REMOVAL (SR ENGINE)NLSC0013S041. Disconnect alternator connector, the terminal and A/C com-
pressor.
2. Loosen alternator upper (lock) bolt and the adjusting bolt.
3. Remove engine under cover RH.
4. Remove A/C compressor bolts×4.
5. Remove alternator mounting bracket bolt×1 and the nuts×2.
6. Loosen alternator lower bolt (long bolt).
7. Remove alternator upper bolt.
8. Move alternator towerd vehicle front.
9. Remove alternator mounting bracket bolt×1.
10. Remove alternator with mounting bracket.
MEL145L
REMOVAL (QG ENGINE)NLSC0013S011. Loosen drive belt idler pulley.
2. Remove drive belt idler pulley (include tightening screw).
3. Remove alternator harness.
4. Remove alternator upper bolt and lower bolt.
5. Remove alternator.
NEL645
REMOVAL (YD ENGINE)NLSC0013S031. Remove alternator harness.
2. Loosen alternator upper nut and lower bolt.
3. Loosen drive belt.
4. Remove alternator bracket bolts (two).
5. Remove alternator upper nut and lower bolt.
6. Remove alternator.
INSTALLATIONNLSC0013S02To install, reverse the removal procedure.
CHARGING SYSTEM
Removal and Installation
SC-30

SEL032Z
DisassemblyNLSC0021REAR COVERNLSC0021S01CAUTION:
Rear cover may be hard to remove because a ring is used to
lock outer race of rear bearing. To facilitate removal of rear
cover, heat just bearing box section with a 200W soldering
iron.
Do not use a heat gun, as it can damage diode assembly.
REAR BEARINGNLSC0021S02CAUTION:
+Do not reuse rear bearing after removal. Replace with a
new one.
+Do not lubricate rear bearing outer race.
SEL033Z
InspectionNLSC0022ROTOR CHECKNLSC0022S011. Resistance test
Resistance: Refer to SDS (SC-34).
+Not within the specified values ... Replace rotor.
2. Insulator test
+Continuity exists ... Replace rotor.
3. Check slip ring for wear.
Slip ring minimum outer diameter:
Refer to SDS (SC-34).
+Not within the specified values ... Replace rotor.
CHARGING SYSTEM
Disassembly
SC-31

SEL034Z
BRUSH CHECKNLSC0022S021. Check smooth movement of brush.
+Not smooth ... Check brush holder and clean.
2. Check brush for wear.
+Replace brush if it is worn down to the limit line.
SEL037Z
STATOR CHECKNLSC0022S031. Continuity test
+No continuity ... Replace stator.
2. Ground test
+Continuity exists ... Replace stator.
SEL044Z
AssemblyNLSC0023RING FITTING IN REAR BEARINGNLSC0023S01+Fix ring into groove in rear bearing so that it is as close to the
adjacent area as possible.
CAUTION:
Do not reuse rear bearing after removal.
CHARGING SYSTEM
Inspection (Cont’d)
SC-32
