2000 Lexus LS400 lexus LS400 2000 Engine / LEXUS 2000 LS400 OWNER'S MANUAL (OM50533U)

GAUGES, METERS AND SERVICE REMINDER INDICATORS
64(a) If parking brake
is off, stop
immediately and
contact Lexus
dealer.
(b) Fasten driver's seat belt.

(Indicator and buzzer)
(c) Fasten front passenger's
seat belt.
(Under the center vent)
(d) Take vehicle to Lexus dealer
immediately.
(e) Stop and check. (f) Take vehicle to
Lexus dealer.
(g) Take vehicle to Lexus dealer.
(h) Close all doors.
(i) Low fuel level Fill up tank. warning light
(j) Key reminder buzzer Remove key.
oror
or

GAUGES, METERS AND SERVICE REMINDER INDICATORS
65
(a) Brake System Warning Light
This light comes on in the following cases when the
ignition key is turned on.
When the parking brake is applied ...
 When the brake fluid level is low ...
Have your vehicle checked at your Lexus dealer in
the following cases:
The light does not come on even if the parking brake is
applied with the ignition ªONº.
CAUTION
If the light does not go out even after the parking brake
is released during the engine running, immediately stop
your vehicle at a safe place and contact your Lexus
dealer. In this case, the brakes may not work properly
and your stopping distance will be longer. Depress the
brake pedal firmly.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
66
(b) Driver's Seat Belt Reminder Lightand Buzzer
This light and buzzer remind you to buckle up the driver's
seat belt.
Once the ignition key is turned to ºONº or ºSTARTº, the
reminder light flashes and buzzer sounds if the driver's
seat belt is not fastened. Unless the driver fastens the
belt, the light stays flashing and the buzzer stops after
about 4 to 8 seconds.
(c) Front Passenger's Seat Belt Reminder Light
This light reminds you to buckle up the front passenger's
seat belt.
Once the ignition key is turned to ºONº or ºSTARTº, the
reminder light flashes if a passenger sits in the front
passenger seat and does not fasten the seat belt.
Unless the front passenger fastens the belt, the light
stays flashing.
If luggage load is placed on the front passenger seat,
depending on its weight and how it is placed on the seat,
built±in sensors in the seat cushion may detect the
pressure, causing the reminder light to come on.
(d) SRS Warning Light
The indicators come on when the ignition key is
turned to the ºACCº or ºONº position. It goes off
after about 6 seconds. This means the SRS airbags
and front seat belt pretensioners are operating
properly.
The SRS warning light system monitors the airbag
sensor assemblies, inflators, seat belt pretensioners,
warning light, interconnecting wiring and power sources.
If either of the following conditions occurs, this indicates
a malfunction somewhere in the parts monitored by the
warning light system. Contact your Lexus dealer as
soon as possible to service the vehicle.
 When the ignition key is turned to the ªACCº or ªONº
position, the light does not come on, remains on or
flashes.
 The light comes on or starts flashing while driving.
If the light stays on, it indicates that the driver and front
passenger airbags fail. If the light flashes, the side
airbags and/or seat belt pretensioners fail.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
67
(e) Discharge Warning Light
This light warns that the battery is being discharged.
If it comes on while you are driving, stop the vehicle, turn
off the engine, and check for the cause. Look first at the
engine drive belt.
If it is loose or broken, the generator will not charge
the battery properly.
 If the belt is O.K., there is a problem somewhere in the
charging system.
The engine ignition will continue to operate, however,
until the battery is discharged. Turn off the air
conditioning, blower, radio, etc., and drive directly to the
nearest Lexus dealer or repair shop.
NOTICE
Do not continue driving if the engine drive belt is broken or loose.
(f) Malfunction Indicator Lamp
This lamp comes on in the following cases.
a. The fuel tank is completely empty. (See ºFuel gaugeº
on page 57 for instructions.)
b. The fuel tank cap is not tightened securely. (See
ºFuel tank capº on page 114 for instructions.)
c. There is a problem somewhere in your engine
electrical system, automatic transmission electrical
system or electronic throttle control system.
If it comes on while you are driving in case ªc.º, have your
vehicle checked/repaired by your Lexus dealer as soon
as possible.
If this lamp comes on and the engine speed does not
increase with the accelerator pedal depressed down to
about the middle position, there may be a problem
somewhere in your electronic throttle control system.
At this time, if you depress the accelerator pedal more
firmly and slowly, you can drive your vehicle at low
speeds. Have your Lexus checked by your Lexus dealer
as soon as possible.
Even if the abnormality of the electronic throttle control
system is corrected during low speed driving, the system
may not be recovered until the engine is stopped and the
ignition key is turned to ªACCº or ªLOCKº position.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
68
(g) ºABSº Warning Light
The light comes on with the ignition key turned to ªONº.
If the anti±lock brake system and the brake assist
system work properly, the light goes out after a few
seconds. Thereafter, if either of the systems
malfunctions, the light comes on.
When the ªABSº warning light is on (and the brake
system warning light is off), the anti±lock brake system,
the brake assist system, the traction control system
and/or the vehicle skid control system do/does not
operate, but the brake system still operates
conventionally.
When the ªABSº warning light is on (and the brake
system warning light is off), the anti±lock brake system
does not operate so that the wheels could lock up during
a sudden braking or braking on slippery road surfaces.
If the following conditions occur, this indicates a
malfunction somewhere in the parts monitored by
the warning light system. Contact your Lexus
dealer as soon as possible to service the vehicle.
 The light does not come on with the ignition key
turned to ªONº, or remains on.
 The light comes on while driving.
If the light lit during driving goes out and does not come
on again, it is a normal operation.
(h) Open Door Warning Light
This light remains on until all the doors are completely
closed.
(i) Low Fuel Level Warning Light
This light comes on when the fuel level in the tank
becomes nearly empty. F ill the tank as soon as possible.
On inclines or curves, due to the movement of fuel in the
tank, the low fuel level warning light may come on earlier
than usual.
(j) Key Reminder Buzzer
This buzzer reminds you to remove the key when you
open the driver's door with the ignition key in the ºACCº
or ºLOCKº position.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
69
How to check all the service reminder
indicators
(except the low fuel level warning light):
1. Apply the parking brake.
2. Open the door.
The following service reminder indicator should come
on. It goes off when you close the door completely.
3. Turn the ignition key to ºACCº.
The following service reminder indicator should come
on. It goes off after 6 seconds.
4. Turn the ignition key to ºONº.
The following service reminder indicators should come
on.

or
or

or
The following service reminder indicators go off after 3
seconds.

or
If any service reminder indicator or warning buzzer does
not function, either the bulb is burned out or circuit is in
need of repair. Have it checked by your Lexus dealer as
soon as possible.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
70
MULTI INFORMATION DISPLAY
13L042±1
The multi information display provides cruise
information on your vehicle's driving condition and
warning messages if your vehicle has trouble.
During ordinary driving, cruise information is
shown in the display. However, if any problem
occurs in your vehicle, a warning message appears
in place of cruise information. To change to the
cruise information display, push the ºFUNCTIONº
button.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
71
(a) Cruise information
13L049±1
The following information is shown with the ignition
switch turned on. Each time you push the ºMODEº
button, the displayed information is changed.
Available driving distance
 Average fuel consumption
 Current fuel consumption
 Average fuel consumption after being refueled
 Driving distance after being refueled
 Elapsed time
 Average vehicle speed
The displayed values of cruise information indicate the
general driving condition, so those may not show
precise and actual condition. Available driving distance
