1999 TOYOTA CAMRY width

H06696
SST
H00401Weight
x y
y
R04211
Inner Diam.
Tires
(3 or More)Width
± SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
RS±23
2168 Author: Date:
(e) Install the SST.
CAUTION:
Place the disc wheel on the level ground.
(1) Connect the connector of SST to the steering wheel
pad connector.
SST 09082±00700
NOTICE:
To avoid damaging the SST connector and wire harness,
do not lock the secondary lock of the twin lock. Also, se-
cure some slack for the SST wire harness inside the disc
wheel.
(2) Move the SST to at least 10 m (33 ft) away from the
steering wheel pad tied down on the disc wheel.
(f) Cover the steering wheel pad with a cardboard box or
tires.

Covering method using a cardboard box:
Cover the steering wheel pad with the cardboard
box and weight the cardboard box down in 4 places
with at least 190 N (20 kg, 44 lb).
Size of cardboard box:
Must exceed the following dimensions:
x= 460 mm (18.11 in.)
When dimension of the cardboard box exceeds the di-
ameter of the disc wheel with tire to which the steer-
ing wheel pad is tied
x= 460 mm (18.11 in.) + width of tire
y= 650 mm (25.59 in.)
NOTICE:
If a cardboard box smaller than the specified size is used,
the cardboard box will be broken by the shock from the air-
bag deployment.

Covering method using tires:
Place at least 3 tires without disc wheel on top of the
disc wheel with tire to which the steering wheel pad
is tied.
Tire size: Must exceed the following dimensions±
Width: 185 mm (7.87 in.)
Inner diameter: 360 mm (14.17 in.)

W03519
L
M
W03652
2 times or more
R08582
Width
Inner
Diam. RS±34
± SUPPLEMENTAL RESTRAINT SYSTEMFRONT PASSENGER AIRBAG ASSEMBLY
2179 Author: Date:
CAUTION:
If the front passenger airbag assembly is tied down with
too thin wire harness, it may snap. This is highly danger-
ous. Always use a wire harness which is at least 1.25 mm
2
(0.0019 in.2).
HINT:
To calculate the square of the stripped wire harness section:
Square = 3.14 X (Diameter)
2 divided by 4
(1) Install the 2 bolts with washers in the 2 bolt holes in
the front passenger airbag assembly,
Bolt:
L: 35.0 mm (1.387 in.)
M: 6.0 mm (0.236 in.)
Pitch: 1.0 mm (0.039 in.)
NOTICE:

Tighten the bolts by hand until the bolts become diffi-
cult to turn.

Do not tighten the bolts too much.
(2) Using 3 wire harness, wind the wire harness at least
2 times each around the bolts installed on the front
passenger airbag assembly.
(3) Position the front passenger airbag assembly in-
side the tire with the airbag deployment side facing
inside.
Tire size: Must exceed the following dimensions±
Width: 185 mm (7.28 in.)
Inner diameter: 360 mm (14.17 in.)
CAUTION:

Make sure that the wire harness is tight. It is very dan-
gerous if looseness in the wire harness results in the
front passenger airbag assembly coming free due to
the shock from the airbag deploying.

Always tie down the front passenger airbag assembly
with the airbag deployment side facing inside.
NOTICE:
The tire will be marked by the airbag deployment, so use a
redundant tire.

H01333
H01334
H08326
Inner
Diam.Width
AB0158
SSTBattery
± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (TMC Made)
RS±45
2190 Author: Date:
(1) Install the 2 nuts to the side airbag assembly.
(2) Wind the wire harness around the stud bolts of the
side airbag assembly as shown in the illustration.
(3) Position the side airbag assembly inside the tire
with the airbag deployment direction facing inside.
Tire size : Must exceed the following dimensions:±
Width 185 mm (7.28 in.)
Inner diameter 360 mm (14.17 in.)
CAUTION:

Make sure the wire harness is tight. It is very danger-
ous when a loose wire harness results in the side air-
bag assembly coming free due to the shock from the
airbag deploying.

Always tie down the side airbag assembly with the
airbag door facing inside.
NOTICE:
The tire will be marked by the airbag deployment, so when
disposing of the airbag use a redundant tire.
(d) Check functioning of the SST. (See page RS±18)
SST 09082±00700

SS0AD±03
SS±6
± SERVICE SPECIFICATIONSENGINE MECHANICAL (5S±FE)
169 Author: Date:
ENGINE MECHANICAL (5S±FE)
SERVICE DATA
Compression
pressureat 250 rpm STD
Minimum
Difference of pressure between each cylinder1,226 kPa (12.5 kgf/cm2, 178 psi) or more
981 kPa (10.0 kgf/cm2, 142 psi)
98 kPa (1.0 kgf/cm2, 14 psi) or less
Valve
clearanceat cold Intake
Exhaust
Adjusting shim (for repair part) Mark 2.500
Mark 2.550
Mark 2.600
Mark 2.650
Mark 2.700
Mark 2.750
Mark 2.800
Mark 2.850
Mark 2.900
Mark 2.950
Mark 3.000
Mark 3.050
Mark 3.100
Mark 3.150
Mark 3.200
Mark 3.250
Mark 3.3000.19 ± 0.29 mm (0.007 ± 0.011 in.)
0.28 ± 0.38 mm (0.011 ± 0.015 in.)
2.500 mm (0.0984 in.)
2.550 mm (0.1004 in.)
2.600 mm (0.1024 in.)
2.650 mm (0.1043 in.)
2.700 mm (0.1063 in.)
2.750 mm (0.1083 in.)
2.800 mm (0.1102 in.)
2.850 mm (0.1122 in.)
2.900 mm (0.1142 in.)
2.950 mm (0.1161 in.)
3.000 mm (0.1181 in.)
3.050 mm (0.1201 in.)
3.100 mm (0.1220 in.)
3.150 mm (0.1240 in.)
3.200 mm (0.1260 in.)
3.250 mm (0.1280 in.)
3.300 mm (0.1299 in.)
Ignition timingw/ Terminals TE1 and E1 connected of DLC18 ± 12° BTDC @ idle
Idle speed±700 ± 50 rpm
Idler pulley
tension springFree length
Installed load at 50.5 mm (1.988 in.)42.0 mm (1.654 in.)
32 ± 37 N (3.25 ± 3.75 kgf, 7.2 ± 8.3 lbf)
Cylinder headWarpage
Cylinder block side Maximum
Manifold sideMaximum
Valve seat
Refacing angle
Contacting angle
Contacting width
0.05 mm (0.0020 in.)
0.08 mm (0.0031 in.)
30°, 45°, 75°
45°
1.0 ± 1.4 mm (0.039 ± 0.055 in.)
Valve guide
bushingInside diameter
Outside diameter (for repair part) STD
O/S 0.056.010 ± 6.030 mm (0.2366 ± 0.2374 in.)
11.048 ± 11.059 mm (0.4331 ± 0.4342 in.)
11.050 ± 11.077 mm (0.4350 ± 0.4361 in.)
ValveValve overall length STD Intake
Exhaust
Minimum Intake
Exhaust
Vale face angle
Stem diameterIntake
Eh t
97.40 ± 97.80 mm (3.8346 ± 3.8504 in.)
98.25 ± 98.65 mm (3.8681 ± 3.8839 in.)
97.1 mm (3.823 in.)
98.0 mm (3.858 in.)
44.5°
5.970 ± 5.985 mm (0.2350 ± 0.2356 in.)
5 965 5 980 (0 2348 0 2354 i )Exhaust
Stem oil clearance STD Intake
Exhaust
Maximum Intake
Exhaust
Margin thickness STD
Minimum5.965 ± 5.980 mm (0.2348 ± 0.2354 in.)
0.025 ± 0.060 mm (0.0010 ± 0.0024 in.)
0.030 ± 0.065 mm (0.0012 ± 0.0026 in.)
0.08 mm (0.0031 in.)
0.10 mm (0.0039 in.)
0.8 ± 1.2 mm (0.031 ± 0.047 in.)
0.5 mm (0.020 in.)
Valve springDeviation Maximum
Free length
Installed tension at 34.7 mm (1.366 in.)2.0 mm (0.079 in.)
40.95 ± 42.80 mm (1.6122 ± 1.6850 in.)
164 ± 189 N (16.7 ± 19.3 kgf, 36.8 ± 42.5 lbf)

SS076±02
± SERVICE SPECIFICATIONSENGINE MECHANICAL (1MZ±FE)
SS±11
174 Author: Date:
ENGINE MECHANICAL (1MZ±FE)
SERVICE DATA
Compression
pressureat 250 rpm STD
Minimum
Difference of pressure between each cylinder1,500 kPa (15.3 kgf/cm2, 218 psi)
1,000 kPa (10.2 kgf/cm2, 145 psi)
100 kPa (1.0 kgf/cm2, 15 psi) or less
Valve
clearanceat cold Intake
Exhaust
Adjusting shim for repair part Mark 2.500
Mark 2.550
Mark 2.600
Mark 2.650
Mark 2.700
Mark 2.750
Mark 2.800
Mark 2.850
Mark 2.900
Mark 2.950
Mark 3.000
Mark 3.050
Mark 3.100
Mark 3.150
Mark 3.200
Mark 3.250
Mark 3.3000.15 ± 0.25 mm (0.006 ± 0.010 in.)
0.25 ± 0.35 mm (0.010 ± 0.014 in.)
2.500 mm (0.0984 in.)
2.550 mm (0.1004 in.)
2.600 mm (0.1024 in.)
2.650 mm (0.1043 in.)
2.700 mm (0.1063 in.)
2.750 mm (0.1083 in.)
2.800 mm (0.1102 in.)
2.850 mm (0.1122 in.)
2.900 mm (0.1142 in.)
2.950 mm (0.1161 in.)
3.000 mm (0.1181 in.)
3.050 mm (0.1201 in.)
3.100 mm (0.1220 in.)
3.150 mm (0.1240 in.)
3.200 mm (0.1260 in.)
3.250 mm (0.1280 in.)
3.300 mm (0.1299 in.)
Ignition timingw/ Terminals TE1 and E1 connected of DLC18 ± 12° BTDC @ idle
Idle speed±700 ± 50 rpm
Timing belt
tensionerProtrusion from housing side10.0 ± 10.8 mm (0.394 ± 0.425 in.)
Cylinder headWarpage Maximum
Valve seat
Refacing angle
Contacting angle
Contacting width
Valve guide bushing bore diameter STD
O/S 0.05
12 pointed head cylinder head bolt diameter
at tension portion STD
Minimum0.10 mm (0.039 in.)
30°, 45°, 75°
45°
1.0 ± 1.4 mm (0.039 ± 0.055 in.)
10.295 ± 10.313 mm (0.4053 ± 0.4080 in.)
10.345 ± 10.363 mm (0.4073 ± 0.4080 in.)
8.95 ± 9.05 mm (0.3524 ± 0.3563 in.)
8.75 mm (0.3445 in.)
Valve guide
bushingInside diameter
Outside diameter for repair part STD
O/S 0.055.510 ± 5.530 mm (0.2169 ± 0.2177 in.)
10.333 ± 10.344 mm (0.4068 ± 0.4072 in.)
10.383 ± 10.394 mm (0.4088 ± 0.4092 in.)
ValveValve overall length STD Intake
Exhaust
Minimum Intake
Exhaust
Valve face angle
Stem diameterIntake
Exhaust
Stem oil clearance STD Intake
Exhaust
Maximum Intake
Exhaust
Margin thickness STD
Maximum95.45 mm (3.5779 in.)
95.40 mm (3.7559 in.)
94.95 mm (3.7382 in.)
94.90 mm (3.7362 in.)
44.5°
5.470 ± 5.485 mm (0.2154 ± 0.2159 in.)
5.465 ± 5.480 mm (0.2152 ± 0.2157 in.)
0.025 ± 0.060 mm (0.0010 ± 0.0024 in.)
0.030 ± 0.065 mm (0.0012 ± 0.0026 in.)
0.08 mm (0.0031 in.)
0.10 mm (0.0039 in.)
1.0 mm (0.039 in.)
0.5 mm (0.020 in.)

SS076±02
± SERVICE SPECIFICATIONSENGINE MECHANICAL (1MZ±FE)
SS±11
174 Author: Date:
ENGINE MECHANICAL (1MZ±FE)
SERVICE DATA
Compression
pressureat 250 rpm STD
Minimum
Difference of pressure between each cylinder1,500 kPa (15.3 kgf/cm2, 218 psi)
1,000 kPa (10.2 kgf/cm2, 145 psi)
100 kPa (1.0 kgf/cm2, 15 psi) or less
Valve
clearanceat cold Intake
Exhaust
Adjusting shim for repair part Mark 2.500
Mark 2.550
Mark 2.600
Mark 2.650
Mark 2.700
Mark 2.750
Mark 2.800
Mark 2.850
Mark 2.900
Mark 2.950
Mark 3.000
Mark 3.050
Mark 3.100
Mark 3.150
Mark 3.200
Mark 3.250
Mark 3.3000.15 ± 0.25 mm (0.006 ± 0.010 in.)
0.25 ± 0.35 mm (0.010 ± 0.014 in.)
2.500 mm (0.0984 in.)
2.550 mm (0.1004 in.)
2.600 mm (0.1024 in.)
2.650 mm (0.1043 in.)
2.700 mm (0.1063 in.)
2.750 mm (0.1083 in.)
2.800 mm (0.1102 in.)
2.850 mm (0.1122 in.)
2.900 mm (0.1142 in.)
2.950 mm (0.1161 in.)
3.000 mm (0.1181 in.)
3.050 mm (0.1201 in.)
3.100 mm (0.1220 in.)
3.150 mm (0.1240 in.)
3.200 mm (0.1260 in.)
3.250 mm (0.1280 in.)
3.300 mm (0.1299 in.)
Ignition timingw/ Terminals TE1 and E1 connected of DLC18 ± 12° BTDC @ idle
Idle speed±700 ± 50 rpm
Timing belt
tensionerProtrusion from housing side10.0 ± 10.8 mm (0.394 ± 0.425 in.)
Cylinder headWarpage Maximum
Valve seat
Refacing angle
Contacting angle
Contacting width
Valve guide bushing bore diameter STD
O/S 0.05
12 pointed head cylinder head bolt diameter
at tension portion STD
Minimum0.10 mm (0.039 in.)
30°, 45°, 75°
45°
1.0 ± 1.4 mm (0.039 ± 0.055 in.)
10.295 ± 10.313 mm (0.4053 ± 0.4080 in.)
10.345 ± 10.363 mm (0.4073 ± 0.4080 in.)
8.95 ± 9.05 mm (0.3524 ± 0.3563 in.)
8.75 mm (0.3445 in.)
Valve guide
bushingInside diameter
Outside diameter for repair part STD
O/S 0.055.510 ± 5.530 mm (0.2169 ± 0.2177 in.)
10.333 ± 10.344 mm (0.4068 ± 0.4072 in.)
10.383 ± 10.394 mm (0.4088 ± 0.4092 in.)
ValveValve overall length STD Intake
Exhaust
Minimum Intake
Exhaust
Valve face angle
Stem diameterIntake
Exhaust
Stem oil clearance STD Intake
Exhaust
Maximum Intake
Exhaust
Margin thickness STD
Maximum95.45 mm (3.5779 in.)
95.40 mm (3.7559 in.)
94.95 mm (3.7382 in.)
94.90 mm (3.7362 in.)
44.5°
5.470 ± 5.485 mm (0.2154 ± 0.2159 in.)
5.465 ± 5.480 mm (0.2152 ± 0.2157 in.)
0.025 ± 0.060 mm (0.0010 ± 0.0024 in.)
0.030 ± 0.065 mm (0.0012 ± 0.0026 in.)
0.08 mm (0.0031 in.)
0.10 mm (0.0039 in.)
1.0 mm (0.039 in.)
0.5 mm (0.020 in.)

SS09Q±01
± SERVICE SPECIFICATIONSCLUTCH
SS±43
206 Author: Date:
CLUTCH
SERVICE DATA
Pedal height from asphalt sheet 1MZ±FE161.8 ± 171.8 mm (6.370 ± 6.764 in.)
Pedal height from asphalt sheet 5S±FE156.8 ± 166.8 mm (6.173 ± 6.567 in.)
Push rod play at pedal top1.0 ± 5.0 mm (0.039 ± 0.197 in.)
Pedal freeplay5.0 ± 15.0 mm (0.197 ± 0.591 in.)
Clutch start switch ON±OFF Stroke5.0 ± 0.5 mm (0.197 ± 0.020 in.)
Clutch release point from pedal full stroke end position25 mm (0.98 in.) or more
Disc rivet head depth Min.0.3 mm (0.012 in.)
Disc runout Max.0.8 mm (0.031 in.)
Flywheel runoutMax.0.1 mm (0.004 in.)
Diaphragm spring finger wear Max. depth0.6 mm (0.024 in.)
Diaphragm spring finger wear Max. width5.0 mm (0.197 in.)
Diaphragm spring tip non±alignmentMax.0.5 mm (0.020 in.)
