1999 NISSAN PRIMERA p0325

5 CHECK INTERMITTENT INCIDENT
Perform ªTROUBLE DIAGNOSIS FOR INTERMITTENT INCIDENTº, EC-QG-102.
©INSPECTION END
Component InspectionNCEC0212KNOCK SENSORNCEC0212S01IUse an ohmmeter which can measure more than 10 MW.
1. Disconnect knock sensor harness connector.
2. Check resistance between terminal 2 and ground.
Resistance: 500 - 620 kW[at 25ÉC (77ÉF)]
CAUTION:
Discard any knock sensors that have been dropped or physi-
cally damaged. Use only new ones.
SEF057X
DTC P0325 KNOCK SENSOR (KS)QG16I18DE
Diagnostic Procedure (Cont'd)
EC-231

DTC Confirmation Procedure ..................................175
Wiring Diagram ........................................................177
Diagnostic Procedure ..............................................178
Component Inspection .............................................179
DTC P0137 HEATED OXYGEN SENSOR 2(REAR)
(MIN. VOLTAGE MONITORING).................................180
Component Description ...........................................180
CONSULT-II Reference Value in Data Monitor
Mode ........................................................................180
ECM Terminals and Reference Value .....................180
On Board Diagnosis Logic.......................................180
DTC Confirmation Procedure ..................................181
Overall Function Check ...........................................182
Wiring Diagram ........................................................183
Diagnostic Procedure ..............................................184
Component Inspection .............................................186
DTC P0138 HEATED OXYGEN SENSOR 2(REAR)
(MAX. VOLTAGE MONITORING)...............................187
Component Description ...........................................187
CONSULT-II Reference Value in Data Monitor
Mode ........................................................................187
ECM Terminals and Reference Value .....................187
On Board Diagnosis Logic.......................................187
DTC Confirmation Procedure ..................................188
Overall Function Check ...........................................189
Wiring Diagram ........................................................190
Diagnostic Procedure ..............................................191
Component Inspection .............................................193
DTC P0139 HEATED OXYGEN SENSOR 2(REAR)
(RESPONSE MONITORING).......................................194
Component Description ...........................................194
CONSULT-II Reference Value in Data Monitor
Mode ........................................................................194
ECM Terminals and Reference Value .....................194
On Board Diagnosis Logic.......................................194
DTC Confirmation Procedure ..................................195
Overall Function Check ...........................................196
Wiring Diagram ........................................................197
Diagnostic Procedure ..............................................198
Component Inspection .............................................200
DTC P0140 HEATED OXYGEN SENSOR 2(REAR)
(HIGH VOLTAGE)........................................................201
Component Description ...........................................201
CONSULT-II Reference Value in Data Monitor
Mode ........................................................................201
ECM Terminals and Reference Value .....................201
On Board Diagnosis Logic.......................................201
DTC Confirmation Procedure ..................................202
Overall Function Check ...........................................202
Wiring Diagram ........................................................203
Diagnostic Procedure ..............................................204
Component Inspection .............................................205DTC P0141 HEATED OXYGEN SENSOR 2
(REAR) HEATER.........................................................207
Description ...............................................................207
CONSULT-II Reference Value in Data Monitor
Mode ........................................................................207
ECM Terminals and Reference Value .....................207
On Board Diagnosis Logic.......................................207
DTC Confirmation Procedure ..................................208
Wiring Diagram ........................................................209
Diagnostic Procedure ..............................................210
Component Inspection ............................................. 211
DTC P0171 FUEL INJECTION SYSTEM
FUNCTION (LEAN SIDE)............................................212
On Board Diagnosis Logic.......................................212
DTC Confirmation Procedure ..................................212
Wiring Diagram ........................................................213
Diagnostic Procedure ..............................................214
DTC P0172 FUEL INJECTION SYSTEM
FUNCTION (RICH SIDE).............................................218
On Board Diagnosis Logic.......................................218
DTC Confirmation Procedure ..................................218
Wiring Diagram ........................................................220
Diagnostic Procedure ..............................................221
DTC P0300 - P0304 NO.4-1CYLINDER
MISFIRE, MULTIPLE CYLINDER MISFIRE...............224
On Board Diagnosis Logic.......................................224
DTC Confirmation Procedure ..................................224
Diagnostic Procedure ..............................................225
Component Inspection .............................................229
DTC P0325 KNOCK SENSOR (KS)...........................230
Component Description ...........................................230
ECM Terminals and Reference Value .....................230
On Board Diagnosis Logic.......................................230
DTC Confirmation Procedure ..................................230
Wiring Diagram ........................................................231
Diagnostic Procedure ..............................................232
Component Inspection .............................................233
DTC P0335 CRANKSHAFT POSITION SENSOR
(CKPS) (OBD)..............................................................234
Component Description ...........................................234
ECM Terminals and Reference Value .....................234
On Board Diagnosis Logic.......................................234
DTC Confirmation Procedure ..................................235
Wiring Diagram ........................................................236
Diagnostic Procedure ..............................................237
Component Inspection .............................................238
DTC P0340 CAMSHAFT POSITION SENSOR
(CMPS).........................................................................239
Component Description ...........................................239
ECM Terminals and Reference Value .....................239
On Board Diagnosis Logic.......................................240
DTC Confirmation Procedure ..................................240
CONTENTS(Cont'd)
EC-3

Alphabetical & P No. Index for DTCNCEC0001ALPHABETICAL INDEX FOR DTCNCEC0001S01
Items
(CONSULT-II screen terms)DTC*6
Reference page
CONSULT-II
GST*2ECM*1
Unable to access ECM Ð Ð EC-SR-93
AIR TEMP SEN/CIRC *7 P0110 0110 EC-SR-127
A/T DIAG COMM LINE *7 P1605 1605 EC-SR-295
ATF TEMP SEN/CIRC *7 P0710 0710 Refer to AT section.
CAM POS SEN/CIRC P0340 0340 EC-SR-239
CLOSED TP SW/CIRC *7 P0510 0510 EC-SR-271
COOLANT T SEN/CIRC P0115 0115 EC-SR-132
CPS/CIRC (OBD) COG *7 P1336 1336 EC-SR-290
CPS/CIRCUIT (OBD) *7 P0335 0335 EC-SR-234
CYL 1 MISFIRE *7 P0301 0301 EC-SR-224
CYL 2 MISFIRE *7 P0302 0302 EC-SR-224
CYL 3 MISFIRE *7 P0303 0303 EC-SR-224
CYL 4 MISFIRE *7 P0304 0304 EC-SR-224
ECM *7 P0605 0605 EC-SR-277
ENGINE SPEED SIG *7 P0725 0725 Refer to AT section.
LINE PRESS SE *7 P1791 1791 Refer to AT section.
HO2S1 HTR (B1) P0135 0135 EC-SR-175
HO2S1 (B1) P0130 0130 EC-SR-144
HO2S1 (B1) *7 P0131 0131 EC-SR-150
HO2S1 (B1) *7 P0132 0132 EC-SR-156
HO2S1 (B1) *7 P0133 0133 EC-SR-162
HO2S1 (B1) *7 P0134 0134 EC-SR-170
FUEL SYS -LEAN/BK1 *7 P0171 0171 EC-SR-212
FUEL SYS -RICH/BK1 *7 P0172 0172 EC-SR-218
IACV/AAC VLV/CIRC *7 P0505 0505 EC-SR-263
IN PY SPD SEN/CIRC *7 P0715 0715 Refer to AT section.
KNOCK SEN/CIRC -B1 P0325 0325 EC-SR-230
L/PRESS SOL/CIRC *7 P0745 0745 Refer to AT section.
MAF SEN/CIRCUIT *3 P0100 0100 EC-SR-120
MULTI CYL MISFIRE *7 P0300 0300 EC-SR-224
NATS MALFUNCTION P1610 - P1615 1610 - 1615 Refer to EL section.
NO SELF DIAGNOSTIC FAILURE INDICATED P0000 0000 Ð
NO SELF DIAGNOSTIC FAILURE INDICATED No DTC Flashing*5 EC-SR-59
ENG OVER TEMP P1217 1217 EC-SR-279
P-N POS SW/CIRCUIT *7 P1706 1706 EC-SR-298
TROUBLE DIAGNOSIS Ð INDEXSR20DE
Alphabetical & P No. Index for DTC
EC-6

DTC*6
Items
(CONSULT-II screen terms)Reference page
CONSULT-II
GST*2ECM*1
P0137 0137 HO2S2 (B1) *7 EC-SR-180
P0138 0138 HO2S2 (B1) *7 EC-SR-187
P0139 0139 HO2S2 (B1) *7 EC-SR-194
P0140 0140 HO2S2 (B1) *7 EC-SR-201
P0141 0141 HO2S2 HTR (B1) *7 EC-SR-207
P0171 0171 FUEL SYS -LEAN/BK1 *7 EC-SR-212
P0172 0172 FUEL SYS -RICH/BK1 *7 EC-SR-218
P0300 0300 MULTI CYL MISFIRE *7 EC-SR-224
P0301 0301 CYL 1 MISFIRE *7 EC-SR-224
P0302 0302 CYL 2 MISFIRE *7 EC-SR-224
P0303 0303 CYL 3 MISFIRE *7 EC-SR-224
P0304 0304 CYL 4 MISFIRE *7 EC-SR-224
P0325 0325 KNOCK SEN/CIRC -B1 EC-SR-230
P0335 0335 CPS/CIRCUIT (POS) *7 EC-SR-234
P0340 0340 CAM POS SEN/CIRC EC-SR-239
P0420 0420 TW CATALYST SYS -B1 *7 EC-SR-246
P0443 0443 PURG VOLUME CONT/V *7 EC-SR-250
P0500 0500 VEH SPEED SEN/CIRC *4 EC-SR-255
P0505 0505 IACV/AAC VLV/CIRC *7 EC-SR-263
P0510 0510 CLOSED TP SW/CIRC *7 EC-SR-271
P0605 0605 ECM *7 EC-SR-277
P0705 0705 PNP SW/CIRC *7 Refer to AT section.
P0710 0710 ATF TEMP SEN/CIRC *7 Refer to AT section.
P0715 0715 IN PY SPD SEN/CIRC *7 Refer to AT section.
P0720 0720 VEH SPD SEN/CIR AT *4 *7 Refer to AT section.
P0725 0725 ENGINE SPEED SIG *7 Refer to AT section.
P0740 0740 TCC SOLENOID/CIRC *7 Refer to AT section.
P0745 0745 L/PRESS SOL/CIRC *7 Refer to AT section.
P1217 1217 ENG OVER TEMP EC-SR-279
P1336 1336 CPS/CIRC (OBD) COG *7 EC-SR-290
TROUBLE DIAGNOSIS Ð INDEXSR20DE
Alphabetical & P No. Index for DTC (Cont'd)
EC-8

Items
(CONSULT-II screen terms)DTC*4
SRT codeTest value/Test
limit
(GST only)1st trip DTC*4Reference
page CONSULT-II
GST*2ECM*1
CYL 1 MISFIRE *5 P0301 0301 Ð Ð X EC-SR-224
CYL 2 MISFIRE *5 P0302 0302 Ð Ð X EC-SR-224
CYL 3 MISFIRE *5 P0303 0303 Ð Ð X EC-SR-224
CYL 4 MISFIRE *5 P0304 0304 Ð Ð X EC-SR-224
KNOCK SEN/CIRC-B1 P0325 0325 Ð Ð Ð EC-SR-230
CPS/CIRCUIT (OBD) *5 P0335 0335 Ð Ð X EC-SR-234
CAM POS SEN/CIRC P0340 0340 Ð Ð X EC-SR-239
TW CATALYST SYS-B1 *5 P0420 0420 X X X*3 EC-SR-246
PURG VOLUME CONT/V *5 P0443 0443 Ð Ð X EC-SR-250
VEH SPEED SEN/CIRC P0500 0500 Ð Ð X EC-SR-255
IACV/AAC VLV/CIRC *5 P0505 0505 Ð Ð X EC-SR-263
CLOSED TP SW/CIRC *5 *6 P0510 0510 Ð Ð X EC-SR-271
ECM *5 P0605 0605 Ð Ð X EC-SR-277
PNP SW/CIRC *5 P0705 0705 Ð Ð X AT section
ATF TEMP SEN/CIRC *5 P0710 0710 Ð Ð X AT section
IN PY SPD SEN/CIRC *5 P0715 0715 Ð Ð X AT section
VEH SPD SEN/CIR AT *5 P0720 0720 Ð Ð X AT section
ENGINE SPEED SIG *5 P0725 0725 Ð Ð X AT section
TCC SOLENOID/CIRC *5 P0740 0740 Ð Ð X AT section
L/PRESS SOL/CIRC *5 P0745 0745 Ð Ð X AT section
ENG OVER TEMP P1217 1217 Ð Ð X EC-SR-279
CPS/CIRC (OBD) COG *5 P1336 1336 Ð Ð X EC-SR-290
A/T DIAG COMM LINE *5 P1605 1605 Ð Ð X EC-SR-295
TP SEN/CIRC A/T *5 P1705 1705 Ð Ð X AT section
P-N POS SW/CIRCUIT *5 P1706 1706 Ð Ð X EC-SR-298
STEP MOTOR CIRC *5 P1777 1777 Ð Ð X AT section
STEP MOTOR FNC *5 P1778 1778 Ð Ð X AT section
LINE PRESSURE SEN *5 P1791 1791 Ð Ð X AT section
*1: In Diagnostic Test Mode II (Self-diagnostic results). These numbers are controlled by NISSAN.
*2: These numbers are prescribed by ISO 15031-6.
*3: These are not displayed with GST.
*4: 1st trip DTC No. is the same as DTC No.
*5: Not available for ªEastern Europe modelsº.
*6: CVT models only
ON BOARD DIAGNOSTIC SYSTEM DESCRIPTIONSR20DE
Emission-related Diagnostic Information (Cont'd)
EC-55

DTC Inspection Priority ChartNCEC0039If some DTCs are displayed at the same time, perform inspections one by one based on the following prior-
ity chart.
Priority Detected items (DTC)
1IP0100 Mass air flow sensor
IP0110 Intake air temperature sensor
IP0115 Engine coolant temperature sensor
IP0120 Throttle position sensor
IP0325 Knock sensor
IP0340 Camshaft position sensor
IP0500 Vehicle speed sensor
IP0605 ECM
IP0335, P1336 Crankshaft position sensor (OBD)
IP1605 A/T diagnosis communication line
IP1706 Park/Neutral position switch
2IP0130 - P0134 Heated oxygen sensor 1 (front)
IP0135 Heated oxygen sensor 1 (front) heater
IP0137 - P0140 Heated oxygen sensor 2 (rear)
IP0141 Heated oxygen sensor 2 (rear) heater
IP0443 EVAP canister purge volume control solenoid valve
IP0510 Closed throttle position switch
IP0705 - P0725, P0740 - P1791 CVT related sensors, solenoid valves and switches
IP1217 Overheat (Cooling system)
3IP0171, P0172 Fuel injection system function
IP0300 - P0304 Misfire
IP0420 Three way catalyst function
IP0505 IACV-AAC valve
IP1778 CVT step motor function
TROUBLE DIAGNOSIS Ð GENERAL DESCRIPTIONSR20DE
DTC Inspection Priority Chart
EC-92

Component DescriptionNCEC0206The knock sensor is attached to the cylinder block. It senses
engine knocking using a piezoelectric element. A knocking vibration
from the cylinder block is sensed as vibrational pressure. This
pressure is converted into a voltage signal and sent to the ECM.
Freeze frame data will not be stored in the ECM for the knock
sensor. The MI will not light for knock sensor malfunction. The
knock sensor has one trip detection logic.
ECM Terminals and Reference ValueNCEC0207Specification data are reference values and are measured between each terminal and 48 (ECM ground).
TERMI-
NAL
NO.WIRE
COLORITEM CONDITION DATA (DC Voltage)
81 W Knock sensor[Engine is running]
IIdle speed2.0 - 3.0V
On Board Diagnosis LogicNCEC0208
DTC No. Malfunction is detected when ... Check Items (Possible Cause)
P0325
0325IAn excessively low or high voltage from the knock sen-
sor is sent to ECM.IHarness or connectors
(The knock sensor circuit is open or shorted.)
IKnock sensor
DTC Confirmation ProcedureNCEC0209NOTE:
If ªDTC Confirmation Procedureº has been previously conducted,
always turn ignition switch ªOFFº and wait at least 9 seconds
before conducting the next test.
TESTING CONDITION:
Before performing the following procedure, confirm that bat-
tery voltage is more than 10V at idle.
With CONSULT-II
1) Turn ignition switch ªONº and select ªDATA MONITORº mode
with CONSULT-II.
2) Start engine and run it for at least 5 seconds at idle speed.
3) If DTC is detected, go to ªDiagnostic Procedureº, EC-SR-232.
With GST
Follow the procedure ªWith CONSULT-IIº above.
SEF598K
NEF068A
DTC P0325 KNOCK SENSOR (KS)SR20DE
Component Description
EC-230

Wiring DiagramNCEC0210
YEC089A
DTC P0325 KNOCK SENSOR (KS)SR20DE
Wiring Diagram
EC-231
