1999 MERCEDES-BENZ C-280 Owners Manual

Program Mode Selector Switch
The transmission is provided with a selector switch for Standard "S" and Winter/Wet
(snow and ice) "W" program modes.



Important !
Always be certain of the program mode se lected since the vehicle driving characteristics change with the selection of
the program mode.


S Standard mode
Press switch on symbol "S". Use this mode for a ll regular driving. The vehicle starts out in 1st gear.
W Winter/Wet (snow and ice) mode Press switch on symbol "W". The vehicle starts out in 2nd gear, except
lever in 1st gear, or with accelerator pedal in kick-dow n position. The "W" mode helps to imp upshifts occur at lower
vehicle and engine speeds than in the "S" program mode.


Caution !
Never change the program mode? when the selector lever is out of position "P". It could result in a change of driving
characteristics for which you may not be prepared.

Emergency Operation (Limp Home Mode)
If vehicle acceleration worsens, or the transmission no longe r shifts, the transmission is most likely operating in Limp
Home Mode which engages when there is a malfunction at the transmission. This condition may be accompanied by
the "CHECK ENGINE" malfunction indicator lamp in the instrument cluster coming on.
In this mode only the 2nd gear or reverse gear can be activated.

To engage 2nd gear or reverse:
1 . Stop the vehicle.
2 . Move selector lever to position "P".
3 . Turn off the engine.
4 . Wait 10 seconds.
5 . Restart the engine.
6 . Move selector lever to position "D" (for 2nd gear), or move selector lever to position "R" (for reverse gear).

Have the transmission checked at your authorized Mercedes-Benz dealer as soon as possible.


ProCarManuals.com

Cruise Control



Cruise Control
Any given speed above approximately 22 mph (35 km/h) can be maintained with the cruise control by operating the
lever.
1. Accelerate and set:
Lift lever briefly to set speed. Hold lever up to accelerate.
2. Decelerate and set:
Depress lever briefly to set sp eed. Hold lever down to decelerate.
Normally the vehicle is accelerated to the desired speed with the accelerator. Speed is set by briefly pushing
the lever to position 1 or 2. The accelerator can be released. The speed can be increased (e.g. for passing)
by using the accelerator. As soon as the accelerator is released, the previously set speed will be resumed
automatically. If a set speed is to be increased or decreased slightly, e.g. to adapt to the traffic flow, hold lever in
position 1 or 2 until the desired speed is reached, or br iefly tip the control lever in the appropriate direction for
increases or decreases in 0.6 mph (1 km/h) increment s. When the lever is released, the newly set speed remains.
3. Canceling
To cancel the cruise control, briefly push lever to position 3.
When you step on the brake or the vehicle speed drops below approx. 22 rnph (35 km/h), for example when driving
upgrade, the cruise control will be canceled. If the cruise control cancels by itself and remains inoperative until the
engine is restarted, have the syst em checked at your authorized Mercedes -Benz dealer as soon as possible.
4. Resume
If the lever is briefly pushed to position 4 when drivi ng at a speed exceeding approx. 22 mph (35 km/h), the vehicle
resumes the speed which was set prior to the cancella tion of the cruise control. The last memorized speed is
canceled when the key in the steering lock is turned to position 1 or 0.



Note:
If the engine does not brake the vehicle sufficiently while dr iving on a downgrade, the speed you set on the cruise
control may be exceeded and you may have to step on the brake pedal to slow down.
As soon as the grade eases, the cruise controlled speed w ill again be maintained as long as the brakes were not
previously applied, or the lever may be used to resume the previously set speed if the brakes were applied.


Caution !
Moving gear selector lever to position "N" switches the cruise control off.

Warning !
Only use the cruise control if the traffic and weather conditions make it advisable to travel at a steady speed.
• The use of cruise control can be dangerous on winding roads or in heavy traffic because conditions do not
allow safe driving at a steady speed.
• The use of cruise control can be dangerous on slippery roads. Rapid changes in tire adhesion can result
in wheel spin and loss of control.
The "Resume" function should only be operated if the driv er is fully aware of the previously set speed and
wishes to resume this particular preset speed.


ProCarManuals.com

Charge Indicator Lamp
Should the charge indicator lamp fail to come on prior to starting when the electronic key is in steering lock position 2
or should it fail to go out after starting or during operati on, this indicates a fault which must be repaired at an
authorized Mercedes-Benz dealer immediately.
If the charge indicator lamp comes on while the engine is ru nning, this may indicate that the poly-V-belt has broken.
Should this condition occur, the poly-V-bel t must be replaced before continuing to operate the vehicle. Otherwise, the
engine will overheat due to an inoperative water pump which may result in damage to the engine.
Do not continue to drive the vehicle with the charge indicator lamp illuminated. Doing so could result in serious engine
damage that is not covered by the Mercedes-Benz Limited Warranty.

Low Engine Oil Level Warning Lamp
With the electronic key in steering lock position 2, the o il level warning lamp comes on. It should go out immediately
when the engine is running.
If the warning lamp does not go out after starting the engi ne, or comes on with the engine running and at operating
temperature, the engine oil level has dropped to approximately the minimum mark on the dipstick.
When this occurs, the warning lamp will first come on intermittently and then stay on if the oil level drops further.
If no oil leaks are noted, continue to drive to the nearest service station where the engine oil should be topped to the
"full" mark on the dipstick with an approved oil.
The low engine oil level warning light should not be ignored. Extended driving with the light illuminated could result in
serious engine damage that is not covered by the Mercedes -Benz Limited Warranty. In addition to the warning lamp,
the engine oil level should be periodically checked with the di pstick (or via the odometer display - Model 280 only), for
example during a fuel stop, or before a long trip (see Index)


ProCarManuals.com

Engine Oil Consumption
Engine oil consumption checks should only be made after the break-in period. During the break-in period, higher oil
consumption may be noticed and is normal. Frequent driving at high engine speeds results in increased consumption.


Fuel Reserve and Fuel Cap Placement Warning Lamp
With the electronic key in steering lock position 2, the fuel reserve warning lamp comes on. It should go out
immediately when the engine is running.
If the warning lamp does not go out after starting the engine, or if it comes on while driving, it indicates that the fuel
level is down to the reserve quantity of approximately 2.1 gal (8 liters).
The warning lamp blinks when the fuel c ap is not closed, or a fuel system leak has been detected. Retighten cap and
see if lamp goes out.
If the warning lamp continues to blink after closing the fuel cap correctly, hav e the fuel system checked at your
authorized Mercedes-Benz dealer as soon as possible.
Leaving the engine running and the fuel cap open can cause the "Check Engine" lamp to illuminate).


Tachometer
Red marking on tachometer: Excessive engine speed. Avoid th is engine speed, as it may result in serious engine
damage that is not covered by the Mercedes-Benz Limited Warranty. For engine protection, the fuel supply is
interrupted if the engine is operated within the red marking.


Seat Belt Warning Lamp
With the electronic key in steering lock position 2, the warning lamp comes on, and a warning sounds for a short time
if the drivers seat belt is not fastened. After starting the engine, the warning lamp blinks for a brief period to remind
the driver and passengers to fasten seat belts.


ProCarManuals.com

Outside Temperature Indicator
The temperature sensor is located in the front bumper area. Due to its location, the sensor can be affected by road or
engine heat during idling or slow driving. This means that the accuracy of the displayed temperature can only be
verified by comparison to a thermometer placed next, to the sensor, not by comparison to external displays (e.g. bank
signs etc.).
Adaptation to ambient temperature takes place in steps and depends on the prevailing driving conditions (stop-and-
go or moderate, constant driving) and amount of temperature change.

Warning !
The outside temperature indicator is not designed to serve as an Ice-Warning Device and is therefore un-
suitable for that purpose. Indicated temperatures just above the freezing point do not guarantee that the road
surface is free of ice.


Coolant Temperature Gauge
If the antifreeze mixture is effective to -22°F (-30°C), the boiling point of the c oolant in the pressurized cooling system
of your vehicle is approx. 266°F (130°C). During severe operating conditions and stop-and-go city traffic, the coolant
temperature may rise close to the red marking. The engine should not be operated with the coolant temperature in
the red zone. Doing so may cause serious engine damage wh ich is not covered by the Mercedes-Benz Limited
Warranty.

Warning !
• Driving when your engine is badly overheated can cause some fluids which may
have Beaked into the engine compartment to catch fire. You could be seriously
burned.
• Steam from an overheated engine can cause serious burns and can occur just by
opening the engine hood. Stay away from the engine if you see or hear steam
coming from it.
Turn off the engine, get out of the car and do not stand near the car until it cools down.


ProCarManuals.com

Low Engine Coolant Level Warning Lamp
With the electronic key in steering lock position 2, the warning lamp comes on.
It should go out when the engine is running. If the warning lamp does not go out after starting the
engine, or if it comes on while driving, then the coolant level has dropped below the required level. If
no leaks are noticeable and the engine temperature does not increase, continue to drive to the
nearest service station and have coolant added to the coolant system (see Index).
The low engine coolant level warning light should not be ignored. Extended driving with the light
illuminated may cause serious engine damage not co vered by the Mercedes-Benz Limited Warranty.
In cases of major or frequent minor coolant lo ss, have the cooling system checked at your
authorized Mercedes-Benz dealer as soon as possible.

Note:
Do not drive without coolant in the cooling sy stem. The engine will overheat causing major engine
damage. Monitor the coolant temperature gauge while driving.

Warning !

Do not spill antifreeze on hot engine parts. Antifreeze contains ethylene glycol which may
burn if it comes into contact with hot engine parts. You can be seriously burned.


Low Windshield and Headlamp Washer System Fluid Level Warning Lamp
With the electronic key in steering lock position 2, the warning lamp comes on. It should go out when
the engine is running. If the warning lamp does not go out after starting the engine, or if it comes on
while driving, the level of the reservoir has droppe d to approx.1/4 of the total volume. The reservoir
should be refilled with MB Windshield Washer Concentrate "S" and water (or commercially available
premixed windshield washer solvent/antifreeze, depending on ambient temperature - see Index) at
the next opportunity. The reservoir for the windshie ld and headlamp washer systems is located in
the engine compartment.


ProCarManuals.com

Exterior Lamp Failure Indicator Lamp
With the electronic key in steering lock position 2, an indicator lamp comes on. It should go out when the engine is
running. If the warning lamp does not go out after starting the engine, or if it comes on while driving, this lamp
indicates a failure in the parking lamp, taillamp, stop lamp, or low beam headlamp. If an exterior lamp fails, the
indicator lamp will come on only when that lamp is switched on. If a brake lamp fails, the lamp failure indicator will
come on when applying the brake and st ay on until the engine is turned off.

Note:
If additional lighting equipment is installed (e.g. auxiliary headl amps etc.) be certain to connect into the fuse before
the failure indicator monitoring unit in order to avoid damaging the system.


Brake Pad Wear Indicator Lamp
With the electronic key in steering lock position 2, the brake pad wear indicator lamp comes on for approximately 30
seconds. It goes out when the engine is running.
If the indicator lamp lights up during braking, this indica tes that the brake pads are worn down. Have the brake
system checked at your authorized Mercedes- Benz dealer as soon as possible.


Brake Warning Lamp
With the electronic key in steering lock position 2, the brake warning lamp will come on. It should go out when the
engine is running. The brake warning lamp will come on:

• when there is insufficient brake fluid in the rese rvoir (engine running and parking brake released), or
• when the parking brake is set (engine running).

Warning !
Driving with the brake warning lamp on can result in an accident. Have your brake system checked
immediately if the brake warning lamp stays on. Don't add brake fluid before checking the brake system.
Overfilling the brake fluid reservoir can result in spilling brake fluid on hot engine parts and the brake fluid
catching fire. You can be seriously burned.

If you find that the minimum mark on the brake fluid reserv oir is reached, have the brake system checked for brake
pad thickness and leaks. To test the brake warning lamp, turn electronic key in steering lock to position 2. The brake
warning lamp comes on, and should go out when the engine is running.


ProCarManuals.com

Flexible Service System (FSS)




The FSS permits a flexible service schedule that is dire
ctly related to the operating conditions of the vehicle.
The symbol
or appears in the main odometer field prior to the next suggested service. Depending on operating
conditions throughout the year, the nex t service is calculated and displayed in days or distance remaining. The
message is displayed for approx. 10 seconds when turning the electronic key in steering lock to position 2, or it can
be canceled manually by pressing button 0. Once the suggested term has passed, the message plus symbol
or
, preceded by a - (minus symbol) blinks, when turning t he electronic key to position 2. The FSS display can also
be called up for approx.10 seconds with display illuminated by pressing button 0 twice. Following a completed service
the Mercedes-Benz dealer sets the counter to 10 000 miles (Canada: 15 000 km) and 365 days.

The counter can also be set by any individual. To do so:
1 . Turn electronic key in steering lock to position 2.
2 . Within 4 seconds press button 0 twice.
3 . The present status for days or distance is displayed. Within 10 seconds turn electronic key in steering lock to
position 0.
4 . Press and hold button 0, while turning electronic key in steering lock to position 2 again. The present status for
days or distance is displayed once more. Continue to hold button 0 After approx. 10 seconds a signal sounds, and the
display shows 10 000 miles (Canada: 15000 km).
5 . Release button 0. If the FSS counter was inadvertently reset, have a Mercedes -Benz dealer correct it.

Notes:
When disconnecting vehicle battery for one or more days at a time, such days will not be counted. Any such days not
counted by the FSS can be added by your Mercedes-Benz de aler. The interval between services is determined by
the kind of vehicle operation. Driving at extreme speeds, and cold starts combined with short distance driving in which
the engine does not reach normal operating temperat ure, reduce the interval between services.

Model C 230:
The FSS allows for distances between 10 000 miles (Canada: 15 000 km) and 15 000 miles (Canada: 22 500 km),
or from 365 to 730 days between services.

Models C 280 and C 43 AMG:
The FSS allows for distances between 10 000 miles (Canada: 15 000 km) and 20 000 miles (Canada: 30 000 km),
or from 365 to 730 days between services. However you choose to set your reference numbers, the scheduled
services as posted in the Service Booklet must be followed to properly care for your vehicle.


ProCarManuals.com
