1999 MERCEDES-BENZ C-280 Owners Manual

Checking Engine Oil Level
Example



1.
Oil dipstick
2. Oil filler cap

To check the engine oil level, park vehicle on level gro und, with engine at normal operational temperature. Check
engine
oil level approximately 5 minutes after stopping the engine, allowing for the oil to return to the oil pan.


Oil Dipstick:
Wipe oil dipstick clean prior to checking the engine oil level. Fully insert dipstick in tube, and remove after three
seconds to obtain accurate reading.


Oil level must be between the
lower (min) and upper (max)
mark of the dipstick.



Fill quantity between upper and lower dipstick markin
g level is approximately 2.1 US qt (2.0 I).
Do not overfill the engine.

Excessive oil must be drained or siphoned. It could cause damage to engine and catalytic converter not covered by
the Mercedes-Benz Limited Warranty.
For low engine oil level warning lamp, see Index.


ProCarManuals.com

Odometer Display Field
(Models C 280 and C 43 AMG)

Turn electronic key in steering lock to position 2 and wait until the symbols
and appears in the
odometer display field. Within 1 second press button 0 twice.


The following messages are available:
"OK"
"-1.0 Q" (Canada: -1.0 L)
"-1.5 Q" (Canada: -1.5L)
"-2.0 Q" (Canada: -2.0 L)
Add oil to upper (max) mark of the dipstick."HI"

Do not overfill the engine.
Excessive oil must be drained or siphoned. It could caus e damage to engine and catalytic converter not covered
by the Mercedes-Benz Limi ted Warranty. The symbol
flashes in the odometer field if a proper oil level check
cannot be performed. The oil level check
can be repeated after a short while. Perform the oil level check with the dipstick, if it cannot be completed via the
odometer display field. In this case we recommend that you have the system checked at a Mercedes-Benz dealer.


Automatic Transmission Fluid Level
The transmission has a permanent fill of automatic tran smission fluid. Regular automatic transmission fluid
level checks and changes are not required. For this reason the dipstick is omitted. If you notice fluid leaks or
gear shifting malfunctions, have your authorized Mercede s-Benz dealer check the transmission fluid level.


ProCarManuals.com

Trunk Lamp
If the trunk is to remain open for a long period of time, the
trunk lamp can be switched off by pulling out the plunger
in the switch (arrow). This prevents t he vehicle battery from being discharged. When the trunk lid is closed, the switch
will reset and turn on the lamp next time the lid is opened.


Stowing Things in the Vehicle

Warning !
To help avoid personal injury during a collision or sudden maneuver, exercise care when stowing things.
Put luggage or cargo in the trunk if possible. Do not pile luggage or cargo higher than the seat backs.
Do not place anything on the shelf below the rear window.


ProCarManuals.com

First Aid Kit

1. Opening lid
The first aid kit is stored in the shelf below the rear window.


Spare Wheel, Vehicle Tools, Storage Compartment

1. Trunk floor
2. Handle
3. Luggage bowl
4. Vehicle tools
5. Tab

Lift trunk floor and engage handle in upper edge of the trunk. To remove spare tire: Turn luggage bowl
counterclockwise and remove. To store spare tire: Place spare tire in wheel well and secure it with
luggage bowl. Turn luggage bowl clockwise to its stop . The tab must point toward front of vehicle.

Note:
Always lower trunk floor before closing trunk lid
.

ProCarManuals.com

Vehicle Jack



1. Jack arm
2. Jack base

See illustration for proper storage of jack. Before storing the jack on the felt in the spare wheel well, the jack arm
must be lowered almost to the base of the jack.

Warning !
The jack is designed exclusively for jacking up the vehicle at the jack tubes built into either side of the
vehicle. To help avoid personal injury, use the jack only to lift the vehicle during a wheel change. Never
get beneath the vehicle while it is supported by the jack. Keep hands and feet away from the area under the
lifted vehicle. Always firmly set parking brake and blo ck wheels before raising vehicle with jack. Do not
disengage parking brake while the vehicle is raised. Be certain that the jack is always vertical when in use,
especially on hills. Always try to use the jack on level surface. Be sure that the jack arm is fully inserted in
the jack tube. Always lower the vehicle onto sufficient capacity jackstands before working under the vehicle.


ProCarManuals.com

Wheels
Replace rims or tires with the same designation, manufacturer and type as shown on the original part. See your
authorized Mercedes-Benz dealer for further information. See your authorized Mercedes- Benz dealer for information
on tested and recommended rims and tires for summer and wi nter operation. They can also offer advice concerning
tire service and purchase.


Tire Replacement
Front tires should be replaced in sets. Furthermore - in the event of tire replacement - the spare wheel (except model
C 43 AMG), if possible, should be used on the rear axle. Ri ms and tires must be of the correct size and type. For
dimensions, see "Technical Data". We recommend that y ou break in new tires for approx. 60 miles (100 km) at
moderate speed. It is imperative that the wheel mounting bolts be fastened to a tightening torque of 80 ft.lb. (110 Nm)
whenever wheels are mounted. For rim and tire specifications, refer to "Technical Data".

Warning !
Worn, old tires can cause accidents. If the tire tread is badly worn, or if the tires have sustained damage,
replace them. When replacing rims, use only genuine Mercedes-Benz wheel bolts specified for the particular
rim type. Failure to do so can result in the bolts loosening and possibly an accident.


Rotating Wheels
Rotation of wheels with summer tires does not apply to m odel C 43 AMG. The wheels can be rotated according to the
degree of tire wear while retaining the same direction of travel. Rotating, however, should be carried out at the
scheduled service intervals, before the characteristic tire wear pattern (shoulder wear on front wheels and tread
center wear on rear wheels) becomes visible, as otherwise the driving properties

Important !
Unidirectional tires must always be mounted with arrow on tire sidewall pointing in direction of vehicle forward
movement. Notes: Thoroughly clean the inner side of the w heels any time you rotate the wheels or wash the vehicle
underside. The use of retread tires is not recommended. Retread tires may adversely affect the handling
characteristics and safety of the vehicle. Dented or bent rims can cause tire pressure loss and damage to the tire
beads. For this reason, check rims for damage at regular in tervals. The rim flanges must be checked for wear before
a tire is mounted. Remove burrs, if any. Check and correct ti re inflation pressure after rotating the wheels. For Tire
Inflation Pressure refer to Index.


ProCarManuals.com

Spare Wheel for Model C 43 AMG

The spare wheel rim size is 71/2Jx17H2 In the case of a flat tire or break- down, you may temporarily use a 71/2Jx17
H 2 instead of the 81/2J x 17 H 2 wheel rim on the rear axle, when observing the following restrictions:
• Do not exceed vehicle speed of 50 mph (80 km/h).
• Drive to the nearest repair facility to have the fl at tire repaired or replaced as appropriate.
For additional information, refer to "Technical Data".


1. Wheel bolt for model C 43 AMG
2. Wheel bolt for model 230 und C 28


Replace rims or tires with the same designation, manufa cturer and type as shown on the original part. See your
authorized Mercedes-Benz dealer for further information.

Warning !
The jack is designed exclusively for jacking up the vehicle at the jack tubes built into either side of the
vehicle. To help avoid personal injury, use the jack only to lift the vehicle during a wheel change. Never get
beneath the vehicle while it is supported by the jack. Keep hands and feet away from the area under the lifted
vehicle. Always firmly set parking brake and block whee ls before raising vehicle with jack. Do not disengage
parking brake while the vehicle is raised. Be certain that the jack is always vertical when in use, especially on
hills. Always try to use the jack on level surface. Be sure that the jack arm is fully inserted in the jack tube.
Always lower the vehicle onto sufficient capacity jackstands before working under the vehicle.


ProCarManuals.com

Changing Wheels

Move vehicle to a level area which is a safe distance from the road way.
1 . Set parking brake and turn on hazard warning flasher.
2 . Move selector lever to position "P" and turn off engine.
3 . Prevent vehicle from rolling away by blocking wheels with wheel chocks
(not supplied with vehicle) or sizable wood block or stone. When changing a wheel
on a hill, place chocks on the downhill side blocking both wheels of the other axle.
On a level road, place one chock in front of and one behind the wheel that is
diagonally opposite to the wheel being changed.
4 . Using the wrench, loosen but do not yet remove the wheel bolts.




5
. Remove the protective cover from the jack support tube opening by inserting the
screwdriver (supplied in the tool kit) in the opening and prying it out. The tube
openings are located directly behind the front wheel housings and in front of the
rear wheel housings.


6
. Insert jack arm fully into the tube hole up to the stop.
Place jack on firm ground. Position the jack so that it is always vertical (plumb-line)
as seen from the side (see arrow), even if the vehicle is parked on an incline.

7. Jack up the vehicle until the wheel is clear of the ground.
Never start engine while vehicle is raised.

8 . Unscrew upper-most wheel bolt and install alignment bolt (1) supplied in the
tool kit. Remove the remaining bolts. Keep bolt threads protected from dirt and
sand.



9. Remove wheel. Grip wheel from the sides. Keep hands from beneath the wheels.
10. Clean contact surfaces of wheel and wheel hub. Install spare wheel on wheel
hub.
Insert wheel bolts and tighten them slightly. To avoid paint damage, place wheel
flat
against hub and hold it there while installing first wheel bolt.


Unscrew the alignment bolt (1) to install the last wheel bolt.
11. Lower car. Remove jack and insert jack tube cover. Before storing the jack,
the jack arm must be lowered almost to the base of the jack.



Warning !
Always replace wheel bolts that are damaged or rusted.
Never apply oil or grease to wheel bolts. Damaged wheel hub threads should
be repaired immediately.
Incorrect mounting bolts or improperly tightened mounting bolts can cause the
wheel to come off. This could cause an accident. Be sure to use the correct
mounting bolts.


12.
Using the wrench, tighten the five bolts evenly, following the sequence illustrated
above, until all bolts are tight. Obse rve a tightening torque of 80 ft.lb. (110 Nm).
13. Ensure proper tire pressure.
