Page 49 of 122
Exterior Rear View Mirrors
The switch is located on the center console.
Turn electronic key in steering lock to position 2.
First select the mirror to be adjusted - press button:
Left mirror
Right mirror
To adjust, toggle the switch forward, backward or to eit her side. Vehicles with automatic brightness response
of inside rear view mirror: With the electronic key in st eering lock position 2, the driver's side mirror reflection
brightness responds to changes in light sensitivity. With gear selector lever in position "R", or with the interior
lamp switched on, the driver's side mirror brightne ss does not respond to changes in light sensitivity.
Notes:
The exterior mirrors have electrically heated glass. The heater switches on automatically, depending on outside
temperature. If an exterior mirror housing is forcibly pivot ed from its normal position, it must be repositioned by
applying firm pressure until it snaps into place.
Warning !
Exercise care when using the passenger-side mirror. The passenger-side exterior mirror is convex
(outwardly curved surface for a wider field of view). Objects in mirror are closer than they appear.
Check your inside rear view mirror or glance over your shoulder before changing lanes.
ProCarManuals.com
Page 50 of 122
Ashtrays
Center Console, Front
To remove ashtray:
Push sliding knob (1) toward the right to eject the insert.
To install ashtray:
Install insert into ashtray frame and push down to engage.
By touching the top of the cover light ly, the ashtray opens automatically.
Prior to removing the ashtray insert, move the gear selector lever to position "N".
Warning!
Remove front ashtray only with vehicle standing still. Wi th the gear selector lever in position "N", turn
off the engine and set the parking brake. Otherwise the vehicle might move as a result of unintended
contact with the gear selector lever.
Center Console, Rear
To remove ashtray:
Push center bar down and pull out the ashtray.
To install ashtray:
Install bottom of ashtray, push center bar down, and close ashtray.
ProCarManuals.com
Page 51 of 122
Lighter
Turn electronic key in steering lock to position 1 or 2.
Push in lighter (1); it will pop out automatically when hot.
Warning !
Never touch the heating element or sides of the lighter, they are extremely hot, hold at knob only.
Note:
The lighter socket can be used to accommodate electrical accessories up to maximum 85 W
Sun Visors
Swing sun visors down to protect against sun glare.
If sunlight enters through a side window, disengage visor from inner mounting and pivot to the side.
Illuminated Vanity Mirrors
With the visor engaged in its inner mounting, the lamp can be switched on by opening the cover.
Warning !
Do not use the vanity mirror while driving.
The lamp goes out automatically after approximately 5 minutes.
ProCarManuals.com
Page 52 of 122
Interior Lighting
1. Door contact switch:
Press once and interior lamps are switched on when opening a door. Interior lamps are switched on,
and off (soft fade) delayed, when unlocking or locking the vehicle, or when opening or closing a door.
However, there will be no (soft fade) delay when the electronic key is in steering lock position 2
Press again and interior lamps remain switc hed off, even when centrally unlocking or opening a door.
2. Press to switch interior and reading lamps on or off.
3. Press to switch rear passenger compartment lamp on or off.
4. Press to switch reading lamp on or off.
ProCarManuals.com
Page 53 of 122
Storage Compartments and Cupholder
Glove Box
1. Unlocking: Turn mechanical key to vertical position and remove.
2. Locking: Turn mechanical key to the right and remove.
3. Opening: Pull on handle.
Caution!
Keep compartment lids closed. This will prevent stored objects from being thrown about and
injuring vehicle occupants during an accident.
Storage Compartments in Center Console
To open compartment in armrest: Lift lid with handle (4).
To open compartment under armrest: Lift lid with handle (5).
To close: Lower lid until it engages in lock.
Cupholder in Center Console
To open cover:
Touch top of cover (6) slightly. The cover opens automatically.
To open cup holder:
Briefly press button (7). The cup holder opens automatically.
To store cup holder:
Push button (7) down until cup holder engages. Close cover (6).
Caution !
Keep cup holder closed while travelling. Place only containers that fit into the cup holder to
prevent spills. Do not fill contai ners to a height where the conten ts could spill during vehicle
maneuvers, especially hot liquids.
ProCarManuals.com
Page 54 of 122
Sliding/Pop-Up Roof (optional)
1. to slide roof open
2. to slide roof closed
3. to raise roof at rear
4. to lower roof at rear
Turn electronic key in steering lock to position 1 or 2. The switch is illuminated when the exterior lamps are
switched on (except standing lamps). With the roof clos ed or tilted open, a screen can be slid into the roof
opening to guard against sun rays. When sliding the roof open, the screen will also retract.
Warning !
When closing the sliding/ pop-up roof, be sure that there is no danger of anyone being harmed by
the closing procedure.
Notes:
The sliding/pop-up roof can be opened or closed manually should an electrical malfunction occur, refer to
Emergency Operation in Index. The sliding/pop-up roof can also be closed with the mechanical key or
infrared remote control while locking the vehicle door s or trunk (see Central Locking System in Index).
ProCarManuals.com
Page 55 of 122
Power Windows
on center console, front
Switches for:
1.
left, front
2. left, rear
3. right, front
4. right, rear
5. Switch for rear door window override
6. individual switches (rear doors)
in rear doors
in rear doors
Turn electronic key in steering lock to position 1 or 2.
Press switch in to resistance point:
to open
to close
Release switch when window is in desired position.
Express Opening and Closing
Press switch or past resistance point and release - window opens or closes completely. To interrupt
procedure, briefly press
or If the upward movement of the window is blocked during the closing procedure,
the window will stop during the last few inches before closure and open slightly. When pressing and holding the
switch
to close the window, and upward movement of the wi ndow is blocked during the last few inches before
closure, it will stop but not
open slightly.
Blocking of Rear Door Window Operation
If no operation of the rear windows by switch (6) (for instance by children) is desired, slide override switch (5) to right,
symbol
becomes visible.
Warning !
When closing the windows, be sure that there is no danger of anyone being harmed by the closing
procedure. In case of obstruction, the automatic rever sal will not operate if a window is being closed
by pressing the switch to its resistance point and holdi ng it there, or when using a mechanical key or
the remote control. The closing procedure can be immediately reversed by either pressing the switch
,
turning the mechanical key to the unlocking position, or pressing button
on the remote control,
and holding it.
Note:
The power windows can also be closed with the mechanical ke y or infrared remote control while locking the vehicle
doors or trunk (see Central Locking System in Index).
Warning !
When leaving the vehicle, always remove the el ectronic key from the steering lock, and lock the
vehicle. Do not leave children unattended in the vehicle, or with access to an unlocked vehicle.
Unsupervised use of vehicle equipment can cause serious personal injury.
Synchronizing Power Windows
If the power supply was interrupted (battery disconnected or empty), the wi ndows cannot be opened or closed by
the Express feature. To resynchronize the Ex press feature, press
side of power window switch until the
window is completely closed and hold for additional 2 seconds. Repeat procedure for each window.
The automatic full opening and closing procedure of the windows should now be restored.
ProCarManuals.com
Page 56 of 122
Instrument Lamps
Press + or - button to vary intensity of instrument lamps.
Display illumination
The display for temperature, odometer, oil level indicator, FSS indicator and clock is illuminated briefly when
opening the driver door. The display illumination brightness responds automatically according to changes in the
surrounding light sensitivity. To briefly illuminate the display (with electronic key
removed or in steering lock position 0 or 1), press button O, +,- , h or m.
Trip Odometer
• To reset:
• Press button O once and hold (with display illuminated).
• Press button O twice and hold (with display not illuminated).
Clock
Adjusting clock (display illuminated): Press button m or h briefly. The disp lay flashes to indicate that the clock
can be adjusted.
Minute: Press button m briefly.
Minutes: Press and hold button m.
Hour: Press button h briefly.
Hours: Press and hold button h .
ProCarManuals.com
