1999 MERCEDES-BENZ C-280 Owners Manual

Replacing Wiper Blade Insert

For safety reasons, remove electronic key from steering lock before replacing the wiper blade, otherwise
the motor can suddenly turn on and cause injury.

Notes:
Do not open engine hood with wiper arm folded forward.
Do not allow the wiper arm to contact the windshield gl ass without a wiper blade inserted. The glass may be
scratched or broken. Make certain that the wiper blade is pr operly installed. An improperly installed blade may cause
windshield damage.






Removal:
Fold wiper arm forward. Press
safety tab down (1), push wiper
blade downward (2) and remove.
Place wiper blade on firm support.
Slide (direction of arrow) the wiper
blade insert out of the retainer
claws.





Installation:
Slide (direction of arrow) wiper
blade insert into retainer claws until
tabs are engaged.
Insert wiper blade between tabs (3)
on the wiper arm, and slide into
end of wiper arm. Press safety tab
upward until it locks in place.


Headlamp Wiper Blades


Removal:
Fold wiper arm forward. Push pin
(1) and remove wiper blade.

Installation:
Place wiper blade on wiper arm
and press in pin (1).


ProCarManuals.com

Manual Release of Fuel Filler Flap

The manual release knob is located behind the right side trunk panel and felt pad.
In case the central locking system does not release the fuel filler flap, pull the manual
release knob while simultaneously opening the fuel filler flap.


Roof Rack






Use only those roof racks appr oved by Mercedes-Benz to avoid damage to the vehicle.
Follow manufacturer's installation instructions.
Mount supports only between markings on border of roof which
are visible when doors are opened.


ProCarManuals.com

C230

C 280, C 43 AMG



Layout of Poly-V-belt Drive

1. Automatic belt tensioner
2. Crankshaft
3. Air conditioning compressor
4. Generator (alternator)

5. Idler pulley
6. Power steering pump
7. Coolant pump, fan

For dimensions of the poly-V-belt, see Technical Data in Index.

Spare Parts Service

All authorized Mercedes-Benz dealers maintain a stock of original spare parts required for maintenance and repair
work.
In addition, strategically located parts distributi on centers provide quick and reliable parts service.
More than 300,000 different spare parts, for other Mercedes-Benz models, are available.
Mercedes-Benz original spare parts are subjecte d to the most stringent quality inspections.
Each part has been specifically developed, manufactured or selected for and adapted to Mercedes-Benz vehicles.
Therefore, Mercedes-Benz original spare parts should be installed.

Important !

The use of non-genuine parts and accessories not authorized by Mercedes-Benz could damage the vehicle or
compromise its durability or safety.


ProCarManuals.com

Identification Labels

When ordering spare parts, please specify vehicle
identification and engine numbers.
1 Certification Label
2 Vehicle Identification No.
3 Identification Label lower edge of windshield)
4 Engine No.
C 230, rear left,
C 280, rear right,
C 43 AMG, rear right
5 Body No. and Paintwork No.
6 Emission Control Label
7 Information Label California version Vacuum line
routing for
emission control system


ProCarManuals.com

Warranty Coverage

Your car is covered under the terms of the "warranties" printed in the Owner's Service and
Warranty Information booklet and your authoriz ed Mercedes-Benz dealer will exchange or
repair any defective parts in accordance wi th the terms of the following warranties:

1 . New vehicle limited warranty
2 . Emission systems warranty
3 . Emission performance warranty
4 . California emission control systems warranty.

Loss of Owner's Service and Warranty Information Booklet
Should you lose your Owner's Service and Warr anty Information booklet, have your authorized
Mercedes-Benz dealer arrange for a replacement. It will be mailed to you.


ProCarManuals.com

Technical Data C 230
Model C 230 (202 023)1 Rims - Tires
Engine 111 Rims (light alloy rims) 7J x 15 H 2
Mode of operation 4-stroke engine,
gasoline injection

Wheel offset 1.46 in (37 mm)
No. of cylinders
4 All season;Radial-ply tires 205/60 R 15 91 H
Bore 3.58 in (90.90 mm) Winter tires;Radial-ply tires 205/60 R 15 91 T M+S
Stroke 3.48 in (88.40 mm) Model C 230- Canada only
Total piston displacement 140.1 cu.in. (2295 cm3) Rims (steel rims) 61/2J x 15 H 2
Compression ratio 10,4:1 Wheel offset 1.46 in (37 mm)
Output acc. to SAE J 1349 148 hp/5500 rpm
(110 kW/5500 rpm)

All season;Radial-ply tires 195/65 R 15 91 H
Maximum torque acc. to SAE
J 1349

162 ft.lb./4000 rpm
(220 Nm/40OOrpm)

Winter tires;Radial-ply tires
195/65 R 15 91 T M+S
Maximum engine speed 6000 rpm Electrical System
Firing order 1-3-4-2 Generator (alternator) 14 V/90 A
Poly-V-belt 2155 mm Starter motor 12 V/1.4KW
Main Dimensions Battery 12 V/100 Ah
Overall vehicle length 177.4 in (4507 mm) Spark plugs Bosch F 9 DCO
Overall vehicle width 67.7 in (1720mm) Beru 14 F-9 DUO
Overall height 56.1 in (1424 mm)
Champion C 12 YCC
Wheel base 105.9 in (2690 mm) Electrode gap 0.032 in (0,8 mm)
Track, front 59.0 in (1499 mm) Tightening torque 15-22ft.lb. (20-30 Mm)
Track, rear 57.6 in (1464mm)

Weights See certification tag
Roof load max. 220 lb(100 kg)

Trunk load max 220 lb(100 kg)
1 The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz
dealer for the correspon-ding data of ali special bodies and special equipment,

ProCarManuals.com

Technical Data C 280
Model C 280 (202 029)1 Rims - Tires
Engine 112 Rims (light
alloy rims)
7J x 15 H 2
Mode of operation 4-stroke engine,
gasoline injection
Wheel
offset

1.46 in (37 mm)
No. of cylinders 6
Summer
tires;
Radial-ply
tires

205/60R 15 91 H
Bore 3.54 in (89.90 mm)

Winter
tires;
Radial-ply
tires


205/60 R 15 91 T M+S

Stroke 2.89 in (73.50 mm)
Rims and All season Tires ( Sport Package)
Rims (light alloy rims) 7J x 16 H 2
Wheel offset 1.46 in (37 mm)
Summer tires;
Radial-ply tires

205/55 R 16 91 H
Electrical System
Total piston displacement 170.8 cu.in. (2799 cm3) Generator
(alternator) 14 V/90 A
Compression ratio 10:1
Starter
motor
12 V/1.7KW
Output acc. to SAE J
1349
195 hp/5800 rpm
(145 kW/5800 rpm)
Battery 12 V/100 Ah
Maximum torque acc.
to SAE J 1349


195 ft.lb./3000 rpm
(265 Nm/3000rpm)

Spark
plugs
Electrode
gap
Tightening
torque
Bosch F 9 DPER
0.032 in (0,8 mm)
15-22ft.lb. (20-30 Mm)
Maximum engine speed 6000 rpm Main Dimensions
Firing order 1-4-3-6-2-5 Overall
vehicle
length
177.4 in (4507 mm)
Poly-V-belt 2390 mm

Overall
vehicle
width

67.7 in (1720mm)
Weights: See certification tag
Overall
height
56.1 in (1424 mm)
Roof load max. 220 lb(100 kg) Wheel
base

105.9 in (2690 mm)
Trunk load max. 220 lb(100 kg) Track,
front
59.0 in (1499 mm)
Track, rear57.6 in (1464mm)


1 The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz dealer
for the correspon-ding data of ali special bodies and special equipment,

ProCarManuals.com

Technical Data C 43 AMG
Model C 43 AMG (202 033)1 Rims and All season Tires
Engine 113 Rims2
Front axle
AMG light
alloy rims
Wheel
offset


71/2J x 17 H 2
1.38 in (35 mm)
Mode of operation 4-stroke engine,
gasoline injection

Rear axle
AMG light
alloy rims
Wheel
offset

8
1/2J x 17 H 2
1.18 in (30 mm)

No. of cylinders 8
Radial-ply
tires
Front axle
Rear axe

225/45 ZR 173
245/40 ZR 173
Bore 3.54 in 89.90 mm)

Rims and
Winter
Tires

Stroke
3.31 in (84.00 mm)
Rims2
AMG light alloy rims 71/2J x 17 H 2
Wheel offset 1.38 in (35 mm)
Radial-ply tires
or
215/45 R 17 H M + S
225/45 R 17 H M + S 3
Spare Wheel
Rims2
AMG light alloy rims 71/2J x 17 H 2
Wheel offset 1.38 in (35 mm)
All season tire:
Radial-ply tire

225/45 ZR 173
Electrical System
Total piston displacement 260.0 cu.in. (4265 cm3) Generator
(alternator)14 V/150 A
Compression ratio 10:1
Starter
motor
12 V/1.7KW
Output acc. to SAE J
1349
302 hp/5850 rpm
(225 kW/5850 rpm)
Battery 12 V/100 Ah
Maximum torque acc.
to SAE J 1349

302ft.lb./3250 rpm
(410 Nm/3250rpm)


Spark
plugs
Electrode
gap
Tightening
torque
Bosch F 8 DEPER
0.032 in (0,8 mm)
15-22ft.lb. (20-30 Mm)
Maximum engine speed 6300 rpm
Main Dimensions
Firing order 1-5-4-2-6-3-7-8

Overall
vehicle
length
177.4 in (4507 mm)
Poly-V-belt 2390 mm
Overall
vehicle
width 67.7 in (1720mm)

Overall
height
56.1 in (1424 mm)
Wheel
base 105.9 in (2690 mm)

Track,
front
59.2 in (1503 mm)
Weights See certification tag Tra ck, rear 58.2 in (1478mm)
