1999 CADILLAC ELDORADO Owners Manual

yellowblue
2-81
If a no response is made after the DOORS LOCK IN
GEAR prompt is displayed, FEATURE OFF will appear.
The automatic door locking system has been disabled
and no other door lock messages will be displayed.
LGHTS FLSH AT UNLOCK, which is the next
available personalization feature to display, will appear
next. See ªLock/Unlock Confirmationº in the Index for
more information.
If a yes response is made after the DOORS LOCK IN
GEAR prompt is displayed, FEATURE ON appears.
The automatic door locking system is enabled and
allows the DRIVR UNLOCK IN PARK prompt to
appear. Choosing this prompt advances you to LGHTS
FLSH AT UNLOCK whereas a no response will display
the DRIVR UNLOCK KEY OFF prompt.
If DRIVR UNLOCK KEY OFF is chosen, FEATURE
ON appears. You will advance to the LGHTS FLSH AT
UNLOCK prompt. If you don't choose this prompt,
FEATURE OFF appears as well as the next
prompt
-- DOORS UNLOCK IN PARK. If this prompt
is chosen, FEATURE ON appears. If a no response was
made, DOORS UNLOCK KEY OFF will appear. At this
point, a yes or no response automatically brings up the
LGHTS FLSH AT UNLOCK feature.Lock/Unlock Confirmation
This personalization feature allows the driver to
program the parking lamps to blink when the lock or
unlock buttons on the remote keyless entry transmitter
are pressed, to program the horn to sound when the lock
button is pressed and/or to program the exterior lamps to
turn on when the unlock button is pressed. Press the
YES TRIP RESET button to answer yes, press the NO
INFO RESET button to indicate no or press the SKIP
INFO button to skip to the next personalization feature.
To begin programming, your vehicle's ignition must be
in RUN. Press and hold the SKIP INFO and NO INFO
RESET buttons at the same time to display the
following prompts. LOCK/UNLOCK confirmation is
the second feature to appear. To skip past the first
personalization feature, press the SKIP INFO button.
LGHTS FLSH AT UNLOCK: Parking lamps blink
twice when the unlock button on the remote keyless
entry transmitter is pressed.
LIGHTS FLASH AT LOCK: Parking lamps blink
once when the lock button on the remote keyless entry
transmitter is pressed.
HORN SOUNDS AT LOCK: Horn sounds when
the lock button on the remote keyless entry transmitter
is pressed.

yellowblue
2-82
EXT LIGHTS AT UNLOCK: Exterior lamps (parking
lamps, taillamps, sidemarker lamps, license plate lamps,
low
-beam headlamps, etc.) turn on when the unlock
button on the remote keyless entry transmitter is pressed
and it is dark outside. These lamps stay on for about 20
seconds or until the key is turned OFF.
The prompts listed here appear in the same order as
displayed on the DIC. FEATURE ON appears when a
yes response is made and FEATURE OFF appears with
a no response. To skip to the next personalization feature
(REMOTE RECALL MEMORY), press the
SKIP INFO button.
Remote Recall Memory (If Equipped with
Memory Personalization)
Memory settings that have been previously programmed
(climate control settings, radio preset settings, exterior
lighting choices, remote confirmation choices and
programmable automatic door lock choices) can be
recalled by using the remote keyless entry transmitter or
by placing the key in your vehicle's ignition.Before you begin programming, make sure that your
vehicle's ignition is in RUN. To begin programming,
press the SKIP INFO and NO INFO RESET buttons at
the same time for about two seconds. As mentioned,
remote recall memory is the third feature to appear. To
skip past the first two personalization features, press the
SKIP INFO button.
When REMOTE RECALL MEMORY appears, the
driver is able to recall memory settings when the unlock
button on the remote keyless entry transmitter is
pressed. Press the YES TRIP RESET button to select or
press the NO INFO RESET button to answer no and to
continue on to the next prompt. FEATURE ON displays
when a yes response is made.
If a no response was made, the KEY IN RECALL
MEMORY prompt will show next. This choice recalls
memory settings when the key is placed in your
vehicle's ignition. FEATURE ON displays for a yes
response, and FEATURE OFF for a no response. A yes
or no response is required.

yellowblue
2-83
Curb View Assist Mirror (If Equipped
with Memory)
If your vehicle has this personalization feature,
MIRROR TILT IN REV will be the fourth
personalization prompt to display on the DIC.
To program your vehicle, press the SKIP INFO and NO
INFO RESET buttons at the same time for about two
seconds. When MIRROR TILT IN REV appears, a yes
or no response is needed. Press the YES TRIP RESET
button to answer yes or the NO INFO RESET button to
answer no.
FEATURE ON displays when a yes response is made
and FEATURE OFF shows after a no response. If you
do not want this feature, press the SKIP INFO button to
skip to the next personalization feature which is
STORAGE MODE.Storage Mode Personalization
Before you begin programming, make sure that your
vehicle's ignition is in RUN. To begin programming,
press the SKIP INFO and NO INFO RESET buttons at
the same time for about two seconds. The first message
to appear is DOORS LOCK IN GEAR. Press the SKIP
INFO button after this prompt is displayed until
STORAGE MODE prompt appears on the Driver
Information Center (DIC). Press the YES TRIP RESET
button to answer yes or press the NO INFO RESET
button to indicate a no response.
FEATURE ON appears when a yes response is made
and FEATURE OFF shows when a no response is made.
Since this is the last personalization feature available, a
yes or no response will end out of the DIC display.
Once the battery guard has been programmed, your
vehicle will enter the storage mode about 20 minutes
after the ignition key has been turned off.

yellowblue
2-84
Your vehicle will stay in the storage mode until the
ignition key is turned out of LOCK. The system will
ªwake
-upº when the door key is inserted into the door,
however, your vehicle will remain in the storage mode.
The ignition must be out of LOCK before the battery
guard is disabled.
Comfort Controls and Radio System Personalization
These features allow both drivers to personalize their
own climate control settings as well as their radio
settings. For more information, see ªClimate Control
Personalizationº and ªRadio Personalizationº in
the Index.
Continuous Variable Road Sensing
Suspension (CVRSS) (ETC Only)
The CVRSS automatically adjusts the ride of your
vehicle. Automatic ride control is achieved through a
computer used to control and monitor the suspension
system. The controller receives input from various
sensors to determine the proper system response. If the
controller detects a problem within the system, the
Driver Information Center (DIC) will display a
SERVICE RIDE CONTROL message. If this message
appears, have your vehicle serviced at your dealership.
Oil Life Indicator
This feature lets you know when to change the engine
oil. It's based on the engine oil temperatures and your
driving patterns. To see the display, press the SKIP
INFO button several times until XX OIL LIFE LEFT
appears. If you see 99% OIL LIFE LEFT, 99 percent of
your current oil life remains.

yellowblue
2-85
The Driver Information Center (DIC) may display a
CHANGE ENGINE OIL message. Always keep a
written record of the mileage and date when you
changed your oil. For more information, see the
Maintenance Schedule booklet. If you see CHANGE
ENGINE OIL, it means that you have no oil life left and
you should change your engine oil right away.
The system should indicate changing the oil between
3,000 miles (5 000 km) and 7,500 miles (12 500 km).
It may indicate changing the oil before 3,000 miles
(5 000 km) depending on your driving habits. If the
vehicle has been driven 7,500 miles (12 500 km), it willindicate to change the oil. If you drive in a dusty area,
you should change your oil every 3,000 miles
(5 000 km) or three months (whichever comes first)
unless the display indicates changing it sooner. See
ªEngine Oil, When to Changeº in the Index. The
system doesn't check how much oil you have, so you'll
still have to check for that. To see how, see ªEngine Oilº
in the Index.
When the oil is changed, you'll need to reset the system.
See ªOil Life Indicator, How to Resetº in the Index.

yellowblue
2-86
-NOTES

3-
yellowblue
3-1
Section 3 Comfort Controls and Audio Systems
In this section, you'll find out how to operate the comfort control and audio systems offered with your vehicle. Be
sure to read about the particular systems supplied with your vehicle.
3
-2 Comfort Controls
3
-2 Climate Control Panel
3
-6 Electronic Solar Sensor
3
-6 Air Conditioning
3
-6 Heating
3
-7 Defrosting
3
-7 Rear Window Defogger
3
-8 Ventilation System
3
-9 HVAC Steering Wheel Controls
3
-9 Climate Control Personalization (If Equipped)
3
-9 Audio Systems
3
-9 Setting the Clock
3
-10 AM-FM Stereo with Cassette Tape Player
3
-13 AM-FM Stereo with Cassette Tape and
Compact Disc Player with Radio Data
Systems (RDS) and Digital Signal Processing
(DPS) (If Equipped)3
-22 Radio Data Systems (RDS) Program Type
(PTY) Selections
3
-23 CD Adapter Kits
3
-23 Trunk-Mounted CD Changer (If Equipped)
3
-27 Radio Personalization with Home and Away
Feature (If Equipped)
3
-28 Theft-Deterrent Feature
3
-28 Audio Steering Wheel Controls
3
-29 Understanding Radio Reception
3
-29 Tips About Your Audio System
3
-30 Care of Your Cassette Tape Player
3
-31 Care of Your Compact Discs
3
-31 Care of Your Compact Disc Player
3
-32 Power Antenna Mast Care

yellowblue
3-2
Comfort Controls
This section tells you how to make your air system work
for you. Your Electronic Climate Control (ECC) system
uses ozone
-friendly R-134a refrigerant.
With the ECC system, you can control the heating,
cooling and ventilation in your vehicle. Your vehicle
also has a flow
-through ventilation system described
later in this section.
Climate Control Panel
Fan Button
The button with the fan symbol adjusts the fan speed.
Press the up arrow to increase fan speed and the down
arrow to decrease fan speed.Driver's Side Temperature Knob
The TEMP/AUTO knob adjusts the air temperature coming
through the system. Turn the TEMP/AUTO knob clockwise
to increase the temperature and counterclockwise to decrease
the temperature. Press the TEMP/AUTO knob to put the
system in the automatic mode.
Passenger's Side Temperature Button
With this dual
-zone feature, the right front passenger
can control the temperature of air for his/her own zone.
The passenger can select a four degree warmer or cooler
temperature from the driver's setting. To turn the system
on, press the PASS/TEMP button. Press the up arrow to
increase the temperature and press the down arrow to
decrease the climate setting. Pressing the OFF button
will turn off the dual
-zone function.
Outside Temperature Display
The outside temperature is always displayed when your
vehicle is running. You can change it from Fahrenheit to
Celsius by pressing the SKIP INFO button (above the
radio) until ENGLISH/METRIC RESET displays. Once
displayed, press the NO INFO RESET button to select.
