1998 TOYOTA 4RUNNER Owners Manual

4RUNNER (1998)
The vehicle identification number
(VIN) is the legal identifier for your
vehicle. This number is on the left
top of the instrument panel, and
can be seen through the windshield
from outside.
This is the primary identification num-
ber for your Toyota. It is used in reg-
istering the ownership of your vehicle.

4RUNNER (1998)
The vehicle identification number (VIN)
is also on the Certification Label. ÐEngine number
3RZ-FE
engine
3RZ- FE engine

4RUNNER (1998)
5VZ-FE engine
5VZ- FE engine The engine number is stamped on
the engine block as shown. Your new vehicle carries theft pre-
vention labels which are approxi-
mately 56 mm (2.20 in.) by 16 mm
(0.63 in.).
The purpose of these labels is to re-
duce the incidence of vehicle thefts by
facilitating the tracing and recovery of
parts from stolen vehicles. The label
is designed so that once it is applied
to a surface, any attempt to remove
it will result in destroying the integrity
of the label. Transferring these labels
intact from one part to another, will be
impossible.Theft prevention labels
(except for Canada)

4RUNNER (1998)
NOTICE
You should not attempt to remove
the theft prevention labels as itmay violate certain state or feder-al laws.
Suspension and chassis
CAUTION
Do not modify the suspension/
chassis with lift kits, spacers,
springs, etc. It can cause danger-
ous handling characteristics re-
sulting in loss of control.
Types of tires
Determine what kind of tires your
vehicle is originally equipped with.
1. Summer tires
Summer tires are high- speed capabili-
ty tires best suited to highway driving
under dry conditions.
Since summer tires do not have the
same traction performance as snow
tires, summer tires are inadequate for
driving on snow- covered or icy roads.
For driving on snow- covered or icy
roads, we recommend using snow
tires. If installing snow tires, be sure
to replace all four tires. 2. All season tires
All season tires are designed to pro-
vide better traction in snow and to be
adequate for driving in most winter
conditions, as well as for use all year
round.
All season tires, however, do not have
adequate traction performance
compared with snow tires in heavy or
loose snow. Also, all season tires fall
short in acceleration and handling per-
formance compared with summer tires
in highway driving.

4RUNNER (1998)
CAUTION
Do not mix summer and all sea-
son tires on your vehicle as
this can cause dangerous han-
dling characteristics, resulting
in loss of control.
Do not use tire other than the
manufacturer 's designated tires,
and never mix tires or wheels
of the sizes different from the
originals.

4RUNNER (1998)

4RUNNER (1998)
Part 3
STARTING AND
DRIVING
Before starting the engine
How to start the engine
Tips for driving in various
conditions
Off- road driving precautions
Winter driving tips
Tr ailer towing
How to save fuel and make
your
vehicle last longer, too
Before starting the engine
1. Check the area around the vehicle before entering it.
2. Adjust seat position, seatback angle, seat cushion angle, head re-
straint height and steering wheel
angle.
3. Adjust inside and outside rear view mirrors.
4. Lock all doors.
5. Fasten seat belts. 1. Apply the parking brake firmly.
2. Turn off unnecessary lights and ac-
cessories.
3. Manual transmission: Press the
clutch pedal to the floor and shift
the transmission into neutral. Hold
the clutch pedal to the floor until
the engine is started. A starter
safety device will prevent the start-
er from operating if the clutch ped-
al is not fully depressed.
Automatic transmission: Put the
selector lever in ºPº. If you need to
restart the engine while the vehicle
is moving, put the selector lever in
ºNº. A starter safety device will pre-
vent the starter from operating if the
selector lever is in any drive position.
4. Automatic transmission only: De-
press the brake pedal and hold it
to the floor until driving off.
How to start the engineÐ
(a) Before cranking

4RUNNER (1998)
(b) Starting the engine
Before starting the engine, be sure to
follow the instructions in º(a) Before
crankingº.
Normal starting procedure
The multiport fuel injection system/se-
quential multiport fuel injection system
in your engine automatically controls
the proper air- fuel mixture for starting.
You can start a cold or hot engine as
follows:
1. With your foot off the accelerator
pedal, crank the engine by turning the
key to ºSTARTº. Release it when the
engine starts.
2. After the engine runs for about 10
seconds, you are ready to drive.
If the weather is below freezing, let
the engine warm up for a few minutes
before driving.
If the engine stalls...
Simply restart it, using the correct
procedure given in normal starting.
If the engine will not startÐ
See ºIf your vehicle will not startº in
Part 4.
NOTICE
Do not crank for more than 30 seconds at a time. This mayoverheat the starter and wiringsystems.
Do not race a cold engine.
If the engine becomes difficult
to start or stalls frequently,have the engine checked im-mediately.
Always slow down in gusty cross-
winds. This will allow you much
better control.
Drive slowly onto curbs and, if
possible, at a right angle. Avoid
driving onto high, sharp- edged ob-
jects and other road hazards. Fail-
ure to do so can lead to severe
tire damage resulting in tire bursts.
When parking on a hill, turn the
front wheels until they touch the
curb so that the vehicle will not
roll. Apply the parking brake, and
place the transmission in ºPº (auto-
matic) or in first or reverse (manu-
al). If necessary, block the wheels.
Washing your vehicle or driving
through deep water may get the
brakes wet. To see whether they
are wet, check that there is no
traffic near you, and then press the
pedal lightly. If you do not feel a
normal braking force, the brakes
are probably wet. To dry them,
drive the vehicle cautiously while
lightly pressing the brake pedal
with the parking brake pulled. If
they still do not work safely, pull to
the side of the road and call a
Toyota dealer for assistance.
Tips for driving in various
conditions
