1998 FORD WINDSTAR Owners Manual

Instrumentation
23
*
[IS12200(ALL)08/96]3.
Let the engine cool.DO NOT REMOVE COOLANT
SYSTEM FILL CAP UNTIL THE ENGINE IS COOL.
[IS12300(ALL)08/96]4.
Check the coolant level following the instructions on
checking and adding coolant to your engine in this Owner
Guide. Seeengine coolantin the index. If you do not follow
these instructions, you or others could be injured.
*
[IS12400(ALL)08/96]
If the coolant continues to overheat, have the coolant system
serviced as soon as possible.
%*
[IS13600(ALL)08/96]
Speedometer
*
[IS13700(ALL)03/96]
The speedometer tells you how many miles (kilometers) per
hour your vehicle is moving.
%*
[IS14200(ALL)08/96]
Odometer
*
[IS14300(ALL)01/96]
The odometer records the total distance the vehicle has been
driven.
%*
[IS14700(ALL)01/96]
Trip Odometer
%*
[IS14800(ALL)05/96]
The trip odometer records the distance of individual trips.
Before each trip, set the trip odometer to zero by pushing the
reset control.
[IS14900(ALL)01/96]
10-1/2 pica
art:0050155-C
The speedometer, odometer and trip odometer
File:03wniss.ex
Update:Fri Oct 11 10:45:38 1996

24
% [IS15000(ALL)04/96]
Tachometer (If equipped)
*
[IS15100(ALL)03/96]
The tachometer will show you the engine's speed measured in
revolutions per minute (RPM).
*
[IS15200(ALL)03/96]
The tachometer may move slightly when the key is placed in
the ACC or ON position, with the engine off. This is normal
and does not affect the performance of the tachometer when the
engine is running.
[IS15300(ALL)01/96]
Some vehicles are equipped with an engine speed (RPM)
limiting device that is contained within the Electronic Engine
Control Module. The purpose of this device is to maintain peak
engine speed (RPM) below a specified limit. (Engine speed
limits may vary based on engine size.)
*
[IS15400(ALL)03/96]
If you are experiencing an ªengine cut-outº condition at high
speeds, it may be the result of this limiting device. It is a
normal condition and can be avoided by reducing
vehicle/engine speed.
[IS15500(ALL)01/96]
10-1/2 pica
art:0050168-B
The tachometer
File:03wniss.ex
Update:Fri Oct 11 10:45:38 1996

Instrumentation
25
% [IS19200(ALL)01/96]
Auxiliary Warning Module (If equipped)
[IS19300(ALL)01/96]
An additional bank of indicator and warning lights is located
above the driver's side vent, just to the right of the steering
wheel. The light(s) located in this module are described and
illustrated below.
[IS19400(ALL)08/96]
13-1/2 pica
art:0050122-H
The auxiliary warning module
% [IS19500(ALL)01/96]
Traction Control Active Light
[IS19600(ALL)01/96]
This light comes on when the Traction Control system begins
applying and releasing the brakes and adjusting the engine
characteristics to limit a wheelspin condition. You may feel
some steering changes and hear some noise, but this is normal.
[IS19700(ALL)01/96]
one inch art:0050274-AFile:03wniss.ex
Update:Fri Oct 11 10:45:38 1996

26
[IS19800(ALL)01/96]
The Traction Control light will stay on for a minimum of four
seconds.
[IS19900(ALL)07/96]
Traction Control Off Light
[IS20000(ALL)01/96]
This light comes on when the Traction Control system is not
operating. In some conditions, you may want to turn Traction
Control off, such as when rocking your vehicle out of deep
snow or mud.
[IS20100(ALL)07/96]
one inch art:0050275-B[IS20200(ALL)01/96]
Traction Control will automatically turn off to prevent the
brakes from overheating. The system will turn back on once the
brakes have cooled down.
[IS20300(ALL)01/96]
NOTE: If the TRAC OFF light is flashing repeatedly, it means
that there is a Traction Control system malfunction
and the system is inoperative. Contact your dealer for
service as soon as possible.
File:03wniss.ex
Update:Fri Oct 11 10:45:38 1996

Instrumentation
27
% [IS20400(ALL)01/96]
Anti-Theft Active Indicator Light
[IS20500(ALL)07/96]
This indicator is used in the optional Anti-Theft System. See
ªAnti-Theft Systemº in theControls and Featureschapter of this
Owner Guide.
[IS20600(ALL)01/96]
6 pica art:0050123-B
The anti-theft active indicator light
[IS20700(ALL)01/96]
Air Suspension Warning Light
[IS20800(ALL)01/96]
6 pica art:0050227-A
The air suspension warning light
[IS20900(ALL)01/96]
The warning light for the Air Suspension indicates one of two
things:
[IS21000(ALL)01/96]1.
The service switch (located in the jack storage area) is in the
ªoffº position.
[IS21100(ALL)01/96]2.
A system malfunction has occurred electronically disabling
Air Suspension function.
[IS21200(ALL)01/96]
NOTE: If the switch is returned to or in the ªONº position
and the light does not go out after recycling the
ignition switch OFF/ON, the Air Suspension should
be checked by a qualified service technician.
File:03wniss.ex
Update:Fri Oct 11 10:45:38 1996

29
Electronic Sound Systems
[AS01100(ALL)04/95]
33-1/2 pica
art:0060674-B
The Compact Disc Radio
File:04wnass.ex
Update:Fri Sep 27 13:16:38 1996

30
%*
[AS01175(ALL)10/95]
Compact Disc Radio
*
[AS01250(ALL)10/95]
The Compact Disc Radio combines the Electronic Stereo Radio
with the Ford Compact Disc Player.
*
[AS01300(ALL)08/95]
Using the Controls on Your New Radio/CD Player
*
[AS01400(ALL)04/92]
Most of the features of this unit work for both radio and CD
operation, depending on which mode the unit is in. Also, some
of the buttons control several different functions, so be sure to
read all of the operating instructions carefully.
*
[AS01500(ALL)03/96]
How to turn the radio on and off
*
[AS01600(ALL)10/95]
Press the ªPOWERº button to turn the radio on. Press it again
to turn it off.
*
[AS01625(ALL)03/96]
How to adjust the volume
*
[AS01650(ALL)03/96]
Press the (R/S) side of the ªVOLº button to increase/decrease
the volume. Bars illuminate in the display to show the relative
volume level.
*
[AS01675(ALL)02/96]
NOTE: If the volume level is set above a certain listening
level when the ignition switch is turned off, when the
ignition switch is turned back on, the volume will
come back to a ªnominalº listening level. However, if
the radio power is turned off, the volume will remain
in the position it was set at when radio power was
switched off.
*
[AS01700(ALL)03/96]
Selecting the AM or FM frequency band
*
[AS01800(ALL)10/95]
Push the ªAM/FMº button to select the desired frequency band.
When in the radio mode, pushing the button more than once
will alternate between AM, FM1 and FM2. These functions are
used with the station memory buttons described underHow to
tune radio stations.
File:04wnass.ex
Update:Fri Sep 27 13:16:38 1996

Electronic Sound Systems
31
%*
[AS01900(ALL)03/96]
How to tune radio stations
*
[AS02000(ALL)10/95]
There are four ways for you to tune in a particular station. You
can manually locate the station using the ªSCAN/TUNEº
button, ªSEEKº the station, ªSCANº to the station or select the
station by using the memory buttons, which you can set to any
desired frequency. These four methods are described below.
*
[AS02100(ALL)10/95]
n
Using the ªSCAN/TUNEº button to manually tune
*
[AS02200(ALL)04/96]
You can change the frequency up or down one increment at
a time (FM changes in increments of 200kHz; AM changes in
increments of 10kHz) by first pressing the ªSCAN/TUNEº
button twice (display shows ªTUNEº), then Ðwithin
approximately five secondsÐpressing and releasing either
the top
aor bottom
bhalf of the ªSEEKº button. To
change frequencies quickly, press andhold downeither the
top or bottom half of the ªSEEKº button. While you are
manually tuning, the display will show a blinking ªMº.
*
[AS02300(ALL)03/96]
Manual tuning adjusts your radio to any allowable broadcast
frequency, whether or not a station is present on that
frequency. (SeeAll About Radio Frequenciesin this section.)
*
[AS02400(ALL)04/96]
n
Using the ªSEEKº function
*
[AS02500(ALL)04/96]
This feature on your radio allows you to automatically select
listenable stations up or down the frequency band. Press the
top
ahalf of the ªSEEKº button to select the next listenable
station up the frequency band. Press the bottom
bhalf of
the button to select the next listenable station down the
frequency band. By pressing and holding the button,
listenable stations can be passed over to reach the desired
station.
