AN91.12-P-0002-01A
Replacing rear seat bearing
Model 163.113/136/154/172 from

A145273 up to A152440 with Code
(847) 3
rd

seat row

Spring compressor

163 589 02 31 00

P91.12-2192-06

1
Remove pin (1) at bottom of seat

adjustment strut (2)

2

Remove gas pressure struts (3)


Danger of breaking retaining clips! Do not

completely remove clips, otherwise

installation tension is released.

3
Remove pins (4) at bottom of seat

hinges (5)

4
Remove seat bearing (6) and install

updated bearing at bottom of seat

hinges (5)


Replace retaining rings.

5
Install pins (1) at seat adjustment strut
(2)


Replace retaining ring.

6

Install gas pressure struts (3)

Copyright DaimlerChrysler AG 12.06.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1

Fig. 224: Checking Headlamp Adjustment
Check
1Drive vehicle to level
surfaceThe vehicle level must
not change when the
brakes are applied.
Vehicle must be in ready-
for-the-road condition
(unladen weight, fuel tank
full or proper additional
weight).
Correctly adjust tire
pressure.
Load driver's seat with 75
kg or a person (except
USA)
2Align headlamp
adjustment tester to
vehicle and adjust height
according to marking in
lens
Follow the operating
instructions for headlamp
beam setting equipment
exactly*WE58.40-Z-1006-19A
Risk of accident from
vehicle starting off by
itself when engine
running. Risk of injury
suffered in the form of
bruises or burns to the
hands when reaching in
while the engine cranks
or runsSecure vehicle to prevent
it from moving off by
itself.
Wear closed and close-
fitting work clothes.
Do not touch hot or
rotating parts.AS00.00-Z-0005-01A
