1997 FORD EXPLORER Owners Manual

Fuel economy
Press once to display your vehicle's
average fuel economy in
kilometers/liters (miles/gallons).
Press again to display the fuel
economy that your vehicle is
getting at that particular time. Your
vehicle must be moving in order
for this display to function
properly.
Reset
Press the reset control to reset the
current feature being displayed.
Warnings, distance driven, average
fuel economy, fuel used and
personalized oil reset percentage
are the only features that respond
to reset.
System check
Press the system check control to
display the status of the following
systems:
²engine oil life left
²engine oil level
²voltage level
²engine coolant temperature
²washer fluid level
²head lamps
²tail lamps
²brake lamps
ENGLISH
METRICRANGESTATUS
ECONRESETSYSTEM
CHECKOIL CHANGE
RESET
FUEL
ENGLISH
METRICRANGESTATUS
ECONRESETSYSTEM
CHECKOIL CHANGE
RESET
FUEL
ENGLISH
METRICRANGESTATUS
ECONRESETSYSTEM
CHECKOIL CHANGE
RESET
FUEL
uno_reset_system
uno_system_check
Instrumentation
18

²automatic ride control (if
equipped)
²fuel level
The engine oil life left has two
phases. The first display will
indicate the oil change status (OK,
SOON, REQUIRED). The second
display will indicate the percentage
of oil life remaining. The display
OIL TEMP SIGNAL ERROR
indicates a problem with the
system. Following this display,
contact your dealer or qualified
service technician for system
maintenance.
Operating the message center
during system check
The message center controls will
operate as follows during the
system check sequence:
1. Press the system check controls
to advance to the next display.
2. Press the reset control to
immediately conclude the system
check.
3. Press the range, fuel status or
fuel economy control to conclude
the system check and display the
requested feature.
4. Press the metric/English control
to conclude the system check and
change the previous display to the
new mode.
5. Press the oil change reset
control to conclude the system
check and begin the oil change
reset procedure.
uno_operating_system
uno_oil_life_left
Instrumentation
19

Engine oil life left
The engine oil left has two phases.
The first display will indicate the
percentage the oil change status
(OK, SOON, REQUIRED). The
second display will indicate the
percentage of oil life remaining.
The display OIL TEMP SIGNAL
ERROR indicates a problem with
the system. Following this display,
contact your dealer or qualified
service technician for system
maintenance.
Message center warnings
Check air ride system
This warning message is displayed
when an air suspension system
fault has been detected. If this
warning message is displayed while
driving, safety pull off the road. If
the vehicle is loaded beyond the
recommended payload, the CHECK
AIR RIDE SYSTEM message will be
displayed. This is a normal
condition if the vehicle is
overloaded. To correct this
condition:
1. Remove or redistribute the load
according to the recommended
maximum requirements.
2. Turn the ignition from On to Off
and back On again.
3. If the warning message
reappears, turn the airsuspension
ENGLISH
METRICRANGESTATUS
ECONRESETSYSTEM
CHECKOIL CHANGE
RESET
FUEL
uno_warnings_title
uno_check_air_ride
Instrumentation
20

switch Off and have your vehicle
serviced as soon as possible.
Air ride switch off
The air ride suspension switch is
off. Refer toAir suspension
systemin theControls and
featureschapter for more
information.
Change oil soon
The engine oil life remaining is 5%
or less. After you have the oil
changed, you must reset the M/C
Oil Life Left feature as follows:
1. Turn the ignition to the On or
Acc position.
2. Press and hold the OIL
CHANGE RESET control for five
seconds. After a successful reset,
the message center will display
ªOIL LIFE RESET TO 100%.º
You may also set a Personalized Oil
Reset Procedure using the
following:
1. Turn the ignition to the ON or
ACC position.
2. Press and hold the OIL
CHANGE RESET control and press
the RESET control while the
display is counting down the five
seconds to reset. The display will
ENGLISH
METRICRANGESTATUS
ECONRESETSYSTEM
CHECKOIL CHANGE
RESET
FUEL
uno_air_ride
uno_change_oil
Instrumentation
21

change to ªSTART OIL LIFE AT
XXX%.º
3. Press the OIL CHANGE RESET
control until the displayed
percentage is the Personalized Oil
Reset Percentage you desire.
Check charging system
The electrical system is not
maintaining a proper voltage. Have
the electrical system checked as
soon as safely possible.
Check engine temp
The engine coolant is overheating.
Refer toEngine coolant
temperature gaugein the
Instrumentationchapter for more
information regarding the engine
coolant system.
Check exterior lamps
At least one brake lamp, rear side
marker or low beam headlamp is
burned out. To determine which
lamp is burned out:
1. Turn ignition switch to OFF to
reset M/C.
- +H
L
H
C
uno_check_charging_system uno_check_engine_temp
uno_check_exterior_lamps
Instrumentation
22

2. With the brake lamps, parking
lamps and headlamps off, turn the
ignition switch to ON or ACC.
3. After M/C briefly illuminates
(about two seconds), press the
brake pedal. If ªCHECK
EXTERIOR LAMPSº is displayed,
then a brake lamp is burned out. If
this message is not displayed,
proceed to the next step.
4. Turn the light switch to the
parking lamp positions. If ªCHECK
EXTERIOR LAMPSº is displayed,
then a rear side marker is burned
out. If this message is not
displayed, proceed to the next
step.
5. Turn the light switch to the
headlamp position. If ªCHECK
EXTERIOR LAMPSº is displayed,
then a low beam headlamp is
burned out.
If you use additional lights, such as
trailer lights, or replace bulbs with
equipment that is not equal to the
original Ford equipment, you may
0P RND21
UNLEADED
FUEL ONLY
RPM x 100012345
6H
C
F
E
RSM
SET
ACC
COAST OFF ONOFF
SRS
OFF
DIM
020
1030405060
70
80
90
110
120000000oooo
km/h10020406080100
120
140
160
180
Instrumentation
23

get a false warning or no warning
at all.
Door ajar
The ignition switch is in the On or
Start position and a door is open.
Low fuel level
The fuel level is low.
Low oil level
The oil level is low. Refer to
Checking and adding engine oil
in theMaintenance and
carechapter for more information.
Low washer fluid
The washer fluid reservoir is less
than one quarter full.
F
E
H
L
uno_door_ajar
uno_low_fuel uno_low_oil
uno_low_washer
Instrumentation
24

HEADLAMP CONTROL
Rotate the headlamp control to the
desired position:
OFF Ð Lamps off
Parking lamps, side marker
lamps, instrument panel lamps,
license plate lamps and tail lamps
on
Headlamps on
0P RND21RPM x 100012345
6H
C
F
E
RSM
SET
ACC
COAST OFF ONOFF
SRS
OFF
DIM
020
1030405060
70
80
90
110
120000000oooo
km/h10020406080100
120
140
160
180
uno_headlamp_switch uno_dimmer_control
