1997 FORD CONTOUR Owners Manual

48
[CF01200(ALL)12/95]
Your vehicle also has small demister openings on each front
door near the window. This allows a small amount of air flow
to be directed onto the door glass to reduce fogging whenever
the heater system is operating.
[CF01300(ALL)05/96]
The temperature control is located at the right side of the
control with a broken RED and BLUE band around the top and
sides. The all RED part of the band (full right) is the heat or
warmer area. The all BLUE area (full left) is the cool or
unheated temperature area. Any position selected between full
right and full left will give a temperature between the two
extreme temperatures. The cool temperature you select will not
be cooler than the outside temperature if your vehicle is not
equipped with an air conditioner.
*
[CF01400(ALL)03/96]
HFan speed adjustment
[CF01500(ALL)05/96]
The
H(left) control is the fan speed control which controls the
volume of air flow. Rotate the
Hcontrol to HI to increase fan
speed and increase the amount of air entering the vehicle. Four
fan speed positions are available and are indicated by LO, two
single dots and HI beside the
Hcontrol.
[CF01600(ALL)04/96]
Air flow selections
[CF01700(ALL)12/95]
PANEL
[CF01800(ALL)05/96]
Use PANEL to bring outside air through the instrument panel
registers. You can heat the air in this position by rotating the
temperature control into the RED area. The air CANNOT be
cooled below the outside temperature regardless of the
temperature control setting.
[CF01900(ALL)12/95]
PNL/FLR
[CF02000(ALL)12/95]
Select PNL/FLR to get air flow to the floor and through the
instrument panel registers at the same time. This selection can
be used to either heat or ventilate your vehicle.
*
[CF02100(ALL)03/96]
FLOOR
[CF02200(ALL)12/95]
Air flow will be to the floor when FLOOR is selected. The air
cannot be cooled in the FLOOR position but can be heated by
rotating the temperature control knob into the RED area.
File:05cdcfo.ex
Update:Fri Sep 13 08:48:17 1996

Controls and Features
49
[CF02300(ALL)12/95]
FLR/DEF
[CF02400(ALL)12/95]
Select FLR/DEF to get air to the floor and windshield defrosters
at the same time.
*
[CF02500(ALL)03/96]
VDEF
[CF02600(ALL)05/96]
SelectVDEF to obtain maximum air flow to the windshield.
Rotate the temperature control into the RED area for the air
temperature required to defrost. Rotate the
Hcontrol to
increase the air flow.
*
[CF02700(ALL)01/96]
Heating and Air Conditioning System
[CF02800(ALL)12/95]
Heating, ventilation, defrosting and defogging are accomplished
in the same way as with the heating only system. See ªHeating
Only System.º
[CF02900(ALL)12/95]
With the heating and air conditioning system, if the outside
temperature is about50ÊF (10ÊC) orwarmer, the air will be
dehumidified to remove moisture if you select FLR/DEF orV
DEF.
[CF03000(O )05/96]
10-1/2 pica
art:0001192-C
The control for the heating and air conditioning system
File:05cdcfo.ex
Update:Fri Sep 13 08:48:17 1996

50
[CF03200(ALL)12/95]
Air conditioning
*
[CF03300(ALL)01/96]
A/C
[CF03400(ALL)12/95]
Select A/C to get refrigerated outside air through the
instrument panel registers. The A/C position is used for cooling
except when extremely hot or fast cooling of the vehicle is
needed. Then, select MAX A/C for fast cooling and return to
A/C when you are comfortable.
*
[CF03500(ALL)03/96]
MAX A/C
[CF03600(ALL)03/96]
The MAX A/C position produces cool air more rapidly to
provide faster cooling of your vehicle. This is possible because
cooler air is drawn from inside the passenger area and
refrigerated again instead of using warmer outside air. Using
inside air will also make the fan sound louder, which is normal
when using MAX A/C. The air flow will be from the
instrument panel registers.
[CF03700(ALL)12/95]
Comfort tips
[CF03800(ALL)04/96]
The following tips will help you to get the most satisfaction
from your climate control system.
[CF03900(ALL)12/95]
n
In humid weather, selectVDEF before starting your
engine. This will help to prevent windshield fogging. After a
few minutes of operation, you may select another function.
[CF04000(ALL)12/95]
n
To prevent humidity buildup inside your vehicle, always
drive with the climate control system turned on.
*
[CF04100(ALL)01/96]
n
Do not put objects under the front seats that interfere with
the flow of air to the back seat area.
[CF04200(ALL)12/95]
n
Remove any snow, ice, or leaves from the air intake area of
your heater and air conditioner system which could block
the air intake. The intake area is located at the bottom of the
windshield.
File:05cdcfo.ex
Update:Fri Sep 13 08:48:17 1996

Controls and Features
51
[CF04300(ALL)12/95]
Passenger Compartment Air Filter (if equipped)
[CF04400(ALL)04/96]
Your vehicle may have an air filter that removes pollen and
road dust from outside air before it is directed to the interior of
the vehicle. For maintenance of this filter, see theMaintenance
and Carechapter.
% [CF04500(ALL)03/96]
Rear Window Defroster (If equipped)
[CF04600(ALL)04/96]
The defroster for the rear window clears frost, fog, or thin ice
from both the inside and outside of the rear window.
[CF04700(ALL)12/95]
The button for the rear window defroster is on the instrument
panel, to the right of the steering wheel.
[CF04800(ALL)12/95]
6 pica art:0001180-C
The rear window defroster and heated side view mirrors
[CF04900(ALL)12/95]
Clear away any snow that is on the rear window before using
the defroster. With the engine running, push the defroster
button.
*
[CF05000(ALL)01/96]
After approximately 10 minutes, the defroster will turn off. If
the window is still not clear, turn the defroster on again.
*
[CF05100(ALL)01/96]
The defroster will turn off when the ignition key is turned to
the OFF or START position.
File:05cdcfo.ex
Update:Fri Sep 13 08:48:17 1996

52
%*
[CF05200(ALL)03/96]
NOTE: Never use sharp instruments or window cleaners with
abrasives to clean the inside of your rear window. If
you do, you may damage the heating elements that
are bonded to the inside of the rear window and
cause damage to the rear window defroster.
%*
[CF05300(ALL)03/96]
The Interior and Exterior Lights
%*
[CF05400(ALL)03/96]
Turning On the Exterior Lights
[CF05500(ALL)12/95]
To turn on your headlamps, parking lamps, and tail lamps, use
the knob that is on the instrument panel, to the left of the
steering wheel.
[CF05600(O )04/96]
10-1/2 pica art:0001178-E
The knob for the exterior lights
[CF05800(ALL)04/96]
To turn on the parking lamps, tail lamps, license plate lamps
and side marker lamps, turn the knob clockwise to the first
position.
[CF05900(ALL)04/96]
To turn on the headlamps, parking lamps, tail lamps, license
plate lamps and side marker lamps, turn the knob clockwise to
the second position.
File:05cdcfo.ex
Update:Fri Sep 13 08:48:17 1996

Controls and Features
53
%*
[CF06000(ALL)08/95]
Fog Lamps (If equipped)
[CF06100(ALL)12/95]
The fog lamps act as a supplement to the low beam headlamps
under limited visibility conditions such as rain, snow, dust or
fog.
[CF06200(ALL)12/95]
The fog lamps operate only when the low beam headlamps are
on. To operate the fog lamps, turn the headlamp control knob
to the second position (headlamps on) and pull the knob out.
An indicator lamp will glow when the fog lamps are on.
[CF06300(ALL)12/95]
To turn off, push the headlamp control knob in.
*
[CF06400(ALL)03/96]
To maximize fog lamp bulb life, it is recommended that the fog
lamp switch be turned off after each use prior to turning off the
headlamps.
%*
[CF06500(ALL)03/96]
Daytime Running Light System
*
[CF06600(ALL)03/96]
(Canadian vehicles only)
*
[CF06700(ALL)01/96]
The Daytime Running Light (DRL) system is designed to turn
the high beam headlamps on, with a reduced light output and
without illuminating the high beam indicator lamp in the
instrument panel. The DRL system operates when all of the
following conditions are met:
[CF06750(ALL)04/96]
n
The vehicle's parking brake is fully released.
[CF06800(ALL)04/96]
n
The vehicle is ªrunning.º
[CF06900(ALL)04/96]
n
The headlamp system is in the OFF position.
*
[CF07000(ALL)03/96]
The high beam indicator light on the instrument cluster will not
be on.
[CF07100(ALL)12/95]
A flashing high beam light in the instrument cluster indicates a
failure in the DRL system circuit, like a burnt bulb or fuse.
File:05cdcfo.ex
Update:Fri Sep 13 08:48:17 1996

54
*
[CF07200(ALL)03/96]
RWARNING
The Daytime Running Light (DRL) system will not
illuminate the tail lamps and parking lamps. Turn on
your headlamps at dusk. Failure to do so may result in a
collision.
%*
[CF07300(ALL)01/96]
Lighting Up the Interior and Instrument Panel
[CF07400(ALL)12/95]
When either front door is opened, the footwell lights and the
door courtesy lights come on.
[CF07500(ALL)12/95]
The instrument panel lights, window control lights and door
handle lights come on whenever the headlamp switch is turned
from the OFF position. To dim the instrument panel lights, use
the thumbwheel on the instrument panel to the right of the
steering wheel.
[CF07600(ALL)12/95]
6 pica art:0001177-B
Dimming the instrument panel lights
% [CF07700(ALL)12/95]
Traction Control System (If equipped)
[CF07800(ALL)02/96]
This button turns the traction control system off and on. See the
Driving Chapterfor more information.
[CF07900(ALL)12/95]
6 pica art:0001179-C
The button for the traction control system
File:05cdcfo.ex
Update:Fri Sep 13 08:48:17 1996

Controls and Features
55
%*
[CF08000(ALL)03/96]
Clock
[CF08100(O )12/95]
7-1/2 pica art:0001220-B
The digital clock
*
[CF08300(ALL)12/95]1.
To set the hour, press and hold the hour button. When the
desired hour appears, release the button.
*
[CF08400(ALL)12/95]2.
To set the minutes, press and hold the minute button. When
the desired minute appears, release the button.
[CF08500(ALL)12/95]3.
To switch between a 12-hour clock and a 24-hour clock,
press both the hour and minute buttons at the same time.
Reset the time as above.
%*
[CF08600(ALL)05/96]
Storage Compartments
[CF08700(ALL)12/95]
Your vehicle may have several storage compartments:
[CF08800(ALL)12/95]
n
a coin holder on the instrument panel
*
[CF09000(ALL)05/96]
The controls on the steering column and wheel are designed to
give you easy access to the controls while you are driving.
