1997 FORD CONTOUR Owners Manual

80
[CF28100(ALL)05/96]
When you use the remote entry UNLOCK, TRUNK or PANIC
controls, the illuminated entry system turns on the interior
lights for 12 seconds. You can turn these lights off by turning
the ignition to the ON position. The interior lights will not turn
off if you have turned them on manually or if a door is open.
[CF28200(ALL)12/95]
NOTE: The illuminated entry system will only work when
the dome light switch is in the ª12º position.
*
[CF28300(ALL)04/96]
Locking the doors
*
[CF28400(ALL)04/96]
To lock all the doors, press the LOCK control.
*
[CF28500(ALL)04/96]
If you would like a signal that the doors are being locked, press
the LOCK control again within five seconds. The doors will lock
again and the horn will beep.
%*
[CF28600(ALL)03/96]
Activating the remote personal alarm
[CF28700(ALL)05/96]
If you wish to activate the remote personal alarm, press the
PANIC control. This will honk the horn and flash the low beam
headlamps and tail lamps for approximately two minutes
forty-five seconds. You can turn it off by pressing the PANIC
control again on the same transmitter or by turning the ignition
key to the ON position.
%*
[CF28800(ALL)03/96]
Replacing the Batteries
*
[CF28900(ALL)01/96]
The remote entry transmitter is powered by two coin type
three-volt lithium 2016 batteries (included) that should last for
several years of normal use. If you notice a significant decrease
in operating range, the batteries should be replaced.
Replacement batteries can be purchased at most pharmacies,
watch stores or at your Ford or Lincoln-Mercury dealer.
File:05cdcfo.ex
Update:Fri Sep 13 08:48:17 1996

Controls and Features
81
*
[CF29000(ALL)01/96]
NOTE: The operating range of the remote entry system can
also be affected by weather conditions (such as very
cold temperatures) or structures around the vehicle
(buildings, other vehicles, radio towers, etc.). Typical
operating range will allow you to be up to 33 feet (10
meters) away from your vehicle.
[CF29100(ALL)12/95]
7-1/2 pica art:0001315-A
Replacing the batteries
*
[CF29200(ALL)01/96]
The transmitter can be snapped apart to replace the batteries by
twisting a thin coin between the two halves of the transmitter.
DO NOT TAKE THE FRONT PART OF THE TRANSMITTER
APART. When installing the new batteries, be sure to place the
positive (+) side down as marked. Snap the two halves back
together.
%*
[CF29300(ALL)02/96]
Replacement/additional transmitters
*
[CF29400(ALL)01/96]
In the event a transmitter is lost, return the remaining
transmitters to your dealer for reprogramming of your remote
entry system. This is necessary to prevent further unauthorized
use of the lost transmitter.
*
[CF29500(ALL)01/96]
Additional transmitters may be purchased from your dealer
(remote entry system will work with up to four transmitters).
Return your existing transmitters to your dealer so the remote
entry system can be reprogrammed with your new and existing
transmitters.
File:05cdcfo.ex
Update:Fri Sep 13 08:48:17 1996

82
*
[CF29600(ALL)01/96]
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC
RULES. OPERATION IS SUBJECT TO THE FOLLOWING
TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE
HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST
ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATION.
File:05cdcfo.ex
Update:Fri Sep 13 08:48:17 1996

83
Seating and Safety Restraints
%*
[SS00200(ALL)01/96]
Seats
%*
[SS00300(ALL)02/96]
Head Restraints
*
[SS00400(ALL)01/96]
If you use them properly, head restraints will help protect your
head and neck in a collision.
*
[SS00500(ALL)01/96]
A head restraint helps protect you best if you position it behind
your head and not behind your neck.
[SS00600(ALL)12/95]
If your vehicle has the four-way head restraint, you can adjust it
in four directions. You can raise it two (2) inches (50 mm) from
its normal position, or you can move it forward up to 60Ê until
you reach the desired position.
[SS00700(ALL)12/95]
10-1/2 pica
art:0001216-A
The four-way head restraint
File:06cdsso.ex
Update:Thu Sep 12 11:03:20 1996

84
%*
[SS00800(ALL)12/95]
Manual Seats
[SS00900(ALL)12/95]
10-1/2 pica
art:0001217-C
Manual seat adjustment
*
[SS01000(ALL)01/96]
RWARNING
Never adjust the driver's seat or seatback when the
vehicle is moving.
*
[SS01100(ALL)02/96]
RWARNING
Always drive and ride with your seatback upright and
the lap belt snug and low across the hips.
File:06cdsso.ex
Update:Thu Sep 12 11:03:20 1996

Seating and Safety Restraints
85
%*
[SS01600(ALL)12/95]
Power Seats (If equipped)
[SS01700(ALL)12/95]
If your vehicle has power seats, you can raise or lower the
whole front seat, move the seat forward or backward and tilt
the front or back of the seat up or down.
[SS01800(ALL)12/95]
13-1/2 pica
art:0001297-B
The seat base controls on the driver's seat
File:06cdsso.ex
Update:Thu Sep 12 11:03:20 1996

86
[SS01900(ALL)12/95]
To move the seat forward or back, slide the seat base control
button forward or back. To raise or lower the height of the seat
base, slide the button up or down. To raise or lower the front of
the seat base, slide the front of the button up or down. To raise
or lower the rear of the seat base, slide the back of the button
up or down.
[SS02000(O )12/95]
Power seatback (if equipped)
[SS02200(ALL)12/95]
13-1/2 pica art:0000462-E
The seatback controls on the driver's seat
[SS02300(ALL)12/95]
To tilt the seatback forward or back, slide the top part of the
top button forward or back. To inflate or deflate the lumbar
support pads, slide the bottom of the button forward or back.
[SS02400(ALL)12/95]
Folding Rear Seats (If equipped)
% [SS02500(ALL)12/95]
The release knobs for the split rear folding seatbacks are in the
trunk. Pull the knob to fold down the seat.
[SS02600(ALL)12/95]
To raise the rear seatback, push the seatback upward until it
locks in place. Make sure it is firmly latched by pushing
forward and back on it.
File:06cdsso.ex
Update:Thu Sep 12 11:03:20 1996

Seating and Safety Restraints
87
*
[SS02700(ALL)02/96]
RWARNING
Check to see that the seat and seatback are latched
securely in position. Keep floor area free of objects that
would prevent proper seat engagement. Never attempt to
adjust the seat while the vehicle is in motion.
[SS02800(ALL)12/95]
10-1/2 pica
art:0001248-B
Folding rear seatback release knob
[SS02810(ALL)01/96]
n
a small storage pocket on the outside of the front seat base
%*
[SS02900(ALL)02/96]
Important Safety Belt Information
*
[SS03000(ALL)02/96]
The use of safety belts helps to restrain you and your
passengers in case of a collision. In most states and in Canada
the law requires their use.
*
[SS03100(ALL)02/96]
Safety belts provide best restraint when:
*
[SS03200(ALL)02/96]
n
the seatback is upright
*
[SS03300(ALL)02/96]
n
the occupant is sitting upright (not slouched)
*
[SS03400(ALL)02/96]
n
the lap belt is snug and low on the hips
*
[SS03500(ALL)02/96]
n
the shoulder belt is snug against the chest
*
[SS03600(ALL)02/96]
n
the knees are straight forward
File:06cdsso.ex
Update:Thu Sep 12 11:03:20 1996
