− AUTOMATIC TRANSAXLE (A540H)PARK/NEUTRAL POSITION (PNP) SWITCH
1996 RAV4 (RM447U)
PARK/NEUTRAL POSITION (PNP)
SWITCH
ON−VEHICLE REPAIR
1. REMOVE NO.2 ENGINE UNDER COVER
2. DISCONNECT PARK/NEUTRAL POSITION SWITCH
CONNECTOR
3. REMOVE PARK/NEUTRAL POSITION SWITCH
(a) Remove the nut and disconnect the shift control cable.
(b) Remove the nut and shift control lever.
(c) Using a screwdriver, pry off the lock plate.
(d) Remove the nut and lock plate.
(e) Remove the 2 bolts and pull out the park/neutral position
switch.
4. INSTALL AND ADJUST PARK/NEUTRAL POSITION
SWITCH
(a) Install the park/neutral position switch to the manual valve
shaft with the 2 bolts and nut.
(b) Install a new lock plate and tighten the nut.
Torque: 6.9 N·m (70 kgf·cm, 61 in.·lbf)
(c) Stake the nut with the lock plate.
(d) Temporarily install the manual valve lever shaft.
(e) Turn the lever counterclockwise until it stops, then turn it
clockwise 2 notches.
(f) Remove the shaft control lever.

Q06078
Neutral
Basic
Line
Groove
Q08738
− AUTOMATIC TRANSAXLE (A540H)PARK/NEUTRAL POSITION (PNP) SWITCH
AX−7
1996 RAV4 (RM447U)
(g) Adjust the park/neutral position switch
(See page AX−6).
HINT:
Align the groove and park/neutral basic line
(h) Tighten the 2 bolts.
Torque: 5.4 N·m (55 kgf·cm, 48 in.·lbf)
(i) Install the shaft control lever with the nut.
Torque: 12.7 N·m (130 kgf·cm, 9 ft·lbf)
(j) Connect the control cable with the nut.
5. CONNECT PARK/NEUTRAL POSITION SWITCH CON-
NECTOR
6. INSTALL NO.2 ENGINE UNDER COVER

Q06064
AX129−01
AT0103
D00691
D00692
AX−8
− AUTOMATIC TRANSAXLE (A540H)VALVE BODY ASSEMBLY
1996 RAV4 (RM447U)
VALVE BODY ASSEMBLY
ON−VEHICLE REPAIR
1. REMOVE NO.2 ENGINE UNDER COVER
2. DRAIN ATF
Using a 10 mm hexagon wrench, remove the drain plug, and
drain the ATF into a suitable container.
3. REMOVE OIL PAN AND GASKET
(a) Remove the 17 bolts.
(b) Remove the oil pan by lifting transaxle case.
NOTICE:
Some fluid remain in the oil pan.
4. EXHAUST PARTICLES IN PAN
Remove the magnet and use it to collect any steel chips.
Lock carefully at the chips and particles in the oil pan and on the
magnet to anticipate when type of wear you will find in the trans-
axle.
Steel (magnetic): bearing, gear and plate wear
Brass (non−magnetic): bushing wear
5. REMOVE OIL PIPE BRACKET AND STRAINER
(a) Remove the 2 bolts and oil pipe bracket.
(b) Remove the 3 bolts and strainer.
(c) Remove the gasket from the strainer.
6. REMOVE MANUAL VALVE BODY
(a) Remove the 2 bolts and detent spring.

Z13390A B
Z13391
A
BA
B
Q06019
Q06064
AX−12
− AUTOMATIC TRANSAXLE (A540H)VALVE BODY ASSEMBLY
1996 RAV4 (RM447U)
(d) Place the detent springs on the manual valve body and
hand−tighten the 2 bolts first.
Then, tighten them with a torque wrench.
Torque: 11 N·m (110 kgf·cm, 8 ft·lbf)
HINT:
Each bolt length is indicated below.
Bolt length:
Bolt A: 14 mm (0.55 in.)
Bolt B: 37 mm (1.46 in.)
(e) Check that the manual valve lever is touching the center
of the detent spring tip roller.
18. INSTALL PIPE BRACKET AND OIL STRAINER
Torque: 11 N·m (110 kgf·cm, 8 ft·lbf)
HINT:
Each bolt length is indicated below.
Bolt length:
Bolt A: 22 mm (0.87 in.)
Bolt B: 53 mm (2.09 in.)
19. INSTALL MAGNETS IN PLACE
NOTICE:
Make sure that the magnets do not interfere with the oil
pipes.
20. INSTALL OIL PAN WITH NEW GASKET
(a) Install a new gasket and oil pan.
(b) Install and tighten 17 bolts.
Torque: 7.9 N·m (80 kgf·cm, 70 in.·lbf)
21. FILL ATF AND CHECK FLUID LEVEL
(a) Using a 10 mm hexagon wrench, install a new gasket and
the drain plug.
Torque: 49 N·m (500 kgf·cm, 36 ft·lbf)
(b) Fill the ATF and check the fluid level (See page DI−173).
22. INSTALL NO.2 ENGINE UNDER COVER

Q06113
AX04U−02
Q05857
Z19463
Q05858
− AUTOMATIC TRANSAXLE (A540H)AUTOMATIC TRANSAXLE UNIT
AX−19
1996 RAV4 (RM447U)
REMOVAL
1. REMOVE TRANSAXLE WITH ENGINE (See page
EM−68)
2. REMOVE STARTER
Torque: 39 N·m (400 kgf·cm, 29 ft·lbf)
3. REMOVE STIFFENER PLATE
Remove the 3 bolts and stiffener plate.
Torque: 37 N·m (380 kgf·cm, 27 ft·lbf)
4. REMOVE REAR END PLATE
Remove the 4 bolts and rear end plate.
Torque:
Bolt A: 9.3 N·m (95 kgf·cm, 82 in.·lbf)
Bolt B: 25 N·m (250 kgf·cm, 18 ft·lbf)
5. REMOVE TORQUE CONVERTER CLUTCH MOUNT-
ING BOLTS
Turn the crankshaft to gain access and remove the 6 bolts with
holding the crankshaft pulley nut by a wrench.
Torque: 27 N·m (280 kgf·cm, 20 ft·lbf)
HINT:
At the time of installation, please refer to the following item.
Coat the threads of the bolts with sealant.
Sealant: Part No. 08833 − 00070, THREE BONDS 1324
or equivalent
Tighten the bolts evenly.
First install dark green colored bolt and then the 5
bolts.
6. DISCONNECT CONNECTORS AND WIRE HARNESS
FROM TRANSAXLE

BE277−01
BE−68
− BODY ELECTRICALAUDIO SYSTEM
1996 RAV4 (RM447U)
TROUBLESHOOTING
NOTICE:
When replacing the internal mechanism (computer part) of the audio system, be careful that no part
of your body or clothing comes in contact with the terminals of the leads from the IC etc. of the re-
placement part (spare part).
HINT:
This inspection procedure is a simple troubleshooting which should be carried out on the vehicle during sys-
tem operation and was prepared on the assumption of system component troubles (except for the wires and
connectors, etc.).
Always inspect the trouble taking the following items into consideration.
Open or short circuit of the wire harness
Connector or terminal connection fault
ProblemNo.
RadioNo power coming in.1
Power coming in, but radio not operating.2
Noise present, but AM − FM not operating.3
Either speaker does not work.4
Either AM or FM does not work.5
Reception poor (Volume faint).5
Few preset tuning bands.5
Sound quality poor.6
Cannot set station select button.6
Preset memory disappears.7
Tape PlayerCassette tape cannot be inserted.8
Cassette tape inserted, but no power.9
Power coming in, but tape player not operating.10
Either speaker does not work.11
Sound quality poor (Volume faint).12
Tape jammed, malfunction with tape speed or auto−reverse.13
APS, SKIP, RPT buttons not operating.14
Cassette tape will not ejected.15
AntennaAntenna−related.16
NoiseNoise produced by vibration or shock while driving.17
Noise produced when engine starts.18

V08467
18
Noise NOISE PRODUCED WHEN ENGINE STARTS
Whistling noise which becomes high−pitched
when accelerator strongly depressed, disappears
shortly after engine stops.Ye s
Generator noise.
No
Whining noise occurs when A/C is operating.Ye s
A/C noise.
Scratching noise occurs during sudden
acceleration, driving on rough roads or when
ignition switch is turned on.No
Ye s
Fuel gauge noise.
No
Clicking sound heard when horn button is
pressed, then released. Whirring/grating sound
when pushed continuously.Ye s
Horn noise.
No
Murmuring sound stops when engine stops.
NoYe s
Ignition noise.
Tick−tock noise, occurs in co−ordination with
blinking of flasher.Ye s
Turn signal noise.
No
Noise occurs during window washer operation.Ye s
Washer noise.
No
Scratching noise occurs while engine is running,
continues a while even after engine stops.
NoEngine coolant temperature gauge noise. Ye s
Scraping noise in time with wiper beat.
NoYe s
Wiper noise.
Other type of noise.
− BODY ELECTRICALAUDIO SYSTEM
BE−79
1996 RAV4 (RM447U)

R10851
Pedal Height Push RodStop Light
Switch
BR1DV−01
BR4980
R00935
Pedal Freeplay BR−6
− BRAKEBRAKE PEDAL
1996 RAV4 (RM447U)
BRAKE PEDAL
ON−VEHICLE INSPECTION
1. CHECK PEDAL HEIGHT
Pedal height from asphalt sheet:
157.1 − 167.1 mm (6.185 − 6.579 in.)
If the pedal height is incorrect, adjust it.
2. IF NECESSARY, ADJUST PEDAL HEIGHT
(a) Disconnect the connector from the stop light switch.
(b) Loosen the stop light switch lock nut and remove the stop
light switch.
(c) Loosen the push rod lock nut.
(d) Adjust the pedal height by turning the pedal push rod.
(e) Tighten the push rod lock nut.
Torque: 25 N·m (260 kgf·cm, 19 ft·lbf)
(f) Install the stop light switch and turn it until it lightly con-
tacts with the pedal stopper.
(g) Turn the stop light switch back one turn.
(h) Check the clearance (A) between stop light switch and
pedal.
Clearance: 0.5 − 2.4 mm (0.020 − 0.094 in.)
(i) Tighten the stop light switch lock nut.
(j) Connect the connector to the stop light switch.
(k) Check that the stop lights come on when the brake pedal
is depressed, and go off when the brake pedal is re-
leased.
(l) After adjusting the pedal height, check the pedal freeplay.
HINT:
If clearance (A) between the stop light switch and the brake
pedal stopper has been adjusted correctly, the pedal freeplay
will meet the specifications.
3. CHECK PEDAL FREEPLAY
(a) Stop the engine and depress the brake pedal several
times until there is no more vacuum left in the booster.
(b) Push in the pedal by hand until the resistance begins to
be felt, then measure the distance, as shown.
Pedal freeplay: 1 − 6 mm (0.04 − 0.24 in.)
