Low Windshield Washer Fluid Level Warning
(Optional Chime with Light)
[LG06640(ALL)11/93]
This light indicates that the level of your washer fluid is low,
and you have to add more fluid. This light comes on briefly
after you turn your ignition key from the START to the ON
position. If the washer fluid is low, a one second chime will
sound and the light will remain on for 60 seconds. If the washer
fluid is not low, the light should turn off a few seconds after
the engine has started. The light and chime also come on if the
washer fluid is low when you use your windshield washers.
[LG06660(ALL)03/94]
The washer fluid is only checked when the engine is started or
the windshield washers are in operation. The light will not
come on if the fluid level becomes low while you are driving
unless you turn on the windshield washers.
[LG06680(ALL)12/93]
6 pica art:0050062-B
The low windshield washer indicator light
% [LG06685(ALL)03/94]
Low Fuel Indicator Light
[LG06690(ALL)04/95]
This light comes on when your fuel gauge indicates
approximately 1/16 of a tank. The ignition must be turned to
ON in order for this light to come on.
[LG06695(ALL)11/93]
6 pica art:0050189-A
The low fuel indicator light
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

Warning Lights and Gauges
79
[LG07401(ALL)11/93]
The pointer moves from the C (cold) mark into the NORMAL
band as the engine coolant warms up. It is acceptable for the
pointer to fluctuate within the normal band under normal
driving conditions. Under certain driving conditions such as
heavy stop and go traffic, or driving up hills in hot weather, the
pointer may indicate at the top of the NORMAL band. This is
also acceptable.
*
[LG07501(ALL)05/95]
If, under any circumstances, the pointer moves above the
NORMAL band, the engine coolant is overheating and
continued operation may cause engine damage.
*
[LG07601(ALL)01/95]
If your engine coolant overheats:
*
[LG07701(ALL)03/95]1.
Pull off the road as soon as it is safely possible.
*
[LG07801(ALL)03/95]2.
Turn off the engine. If you do not stop the engine as soon as
safely possible, severe engine damage could result.
*
[LG07901(ALL)05/95]3.
Let the engine cool.DO NOT REMOVE COOLANT
SYSTEM FILL CAP UNTIL THE ENGINE IS COOL.
[LG08001(ALL)11/93]4.
Check the coolant level following the instructions on
checking and adding coolant to your engine in this Owner
Guide. Seeengine coolantin the index. If you do not follow
these instructions, you or others could be injured.
*
[LG08025(ALL)01/95]
If the coolant continues to overheat, have the coolant system
serviced.
%*
[LG08400(ALL)01/95]
Speedometer
*
[LG08500(ALL)01/95]
The speedometer tells you how many miles (kilometers) per
hour your vehicle is moving.
%*
[LG08600(ALL)01/95]
Odometer
*
[LG08700(ALL)01/93]
The odometer records the total distance the vehicle has been
driven.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

84
[LG10835(ALL)11/93]
6 pica art:0050148-B
The safety belt warning light
%*
[LG10845(ALL)03/95]
Brake System Light
[LG10848(ALL)11/93]
The warning light for the brakes indicates two things Ð that
either the parking brake is on or not fully released, or that the
brake fluid level is low in the master cylinder reservoir. If the
fluid level is low, the brake system should be checked by a
qualified service technician.
[LG10850(ALL)11/93]
6 pica art:0050144-B
The brake system light
[LG10855(ALL)12/93]
The BRAKE light normally comes on when you turn the
ignition key to the ON or START position to verify that the
indicator bulb is working. If the light stays on or comes on
when the engine is running and after you have released the
parking brake fully, have the hydraulic brake system serviced.
*
[LG10858(ALL)05/95]
RWARNING
The BRAKE light indicates that the brakes may not be
working properly. Have the brakes checked immediately.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

Warning Lights and Gauges
85
%*
[LG10861(ALL)01/95]
Air Bag Readiness Light
[LG10871(ALL)11/93]
This light indicates that the Air Bag system is not functional
and needs to be serviced. The light illuminates for
approximately six seconds when the ignition is turned to the
ON position to verify that the indicator bulb is working. If the
light fails to illuminate, flashes continuously, or remains on,
have the air bag system serviced as soon as possible.
[LG10881(ALL)11/93]
6 pica art:0050153-B
The air bag readiness light
%*
[LG10901(ALL)01/95]
Charging System Light
[LG10911(ALL)11/93]
This light indicates that your battery is not being charged. The
light comes on briefly during the display self-test every time
you turn your ignition key to the ON position. The light will go
off when the key is turned to the START position. The light
should stay off when the self-test is done if the engine is
running and the alternator is charging.
*
[LG10913(ALL)01/95]
If the light stays on or comes on when the engine is running,
have the electrical system checked as soon as possible.
[LG10915(ALL)11/93]
6 pica art:0050149-B
The charging system light
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

86
%*
[LG10921(ALL)03/95]
Check Engine Warning Light
[LG10932(ALL)02/95]
The Powertrain On-Board Diagnostic II (OBD II) system consists
of the hardware and software necessary to monitor the
operation of the powetrain. The OBD II system is designed to
check the function of the vehicle's powertrain control system
during normal operation. If an emission problem is detected, the
Check Engine Warning Light (in the cluster) is turned on.
[LG10941(ALL)11/93]
6 pica art:0050065-B
The check engine warning light
*
[LG10949(ALL)05/95]
Modification or additions to the vehicle may cause incorrect
operation of the OBD II system. Additions such as burglar
alarms, cellular phones, and CB radios must be carefully
installed. Do not install these devices by tapping into or running
wires close to powertrain control system wires or components.
[LG10955(ALL)02/95]
The light comes on briefly when you turn the ignition key to
ON, but it should turn off when the engine starts. If the light
does not come on when you turn the ignition to ON or if it
comes on and stays on when you are driving, have your vehicle
serviced as soon as possible. This indicates a possible problem
with one of the vehicle's emission control systems. You do not
need to have your vehicle towed in.
*
[LG10960(ALL)05/95]
If the light turns on and off at one (1) second intervals while
you are driving the vehicle, it means that the engine is
misfiring. If this condition persists, damage could occur to the
engine or catalytic convertor. Have your vehicle serviced at the
first opportunity. You do not need to have your vehicle towed
in.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

Warning Lights and Gauges
87
*
[LG10962(ALL)05/95]
If the light turns on and off on rare occasions while you are
driving, it means that a malfunction occurred and the condition
corrected itself.
*
[LG10965(ALL)05/95]
An example of a condition which corrects itself occurs when an
engine running out of fuel begins to misfire. In this case, the
Check Engine Warning Light may turn on and will then set a
Diagnostic Trouble Code indicating that the engine was
misfiring while the last of the fuel was being consumed. After
refueling, the Check Engine Warning Light will turn off after
the vehicle has completed three consecutive warm up cycles
without a misfire condition occurring. A warm up cycle consists
of engine start from a cold condition (engine at ambient
temperature) and running until the engine reaches normal
operating temperature.
*
[LG10968(ALL)05/95]
On the fourth engine start up, the Check Engine Warning Light
will turn off as soon as the engine begins to crank. It is not
necessary to have the engine serviced.
[LG10969(ALL)02/95]
Under certain conditions, the Check Engine Warning Light may
come on if the fuel cap is not properly installed. If the Check
Engine Warning Light comes on and you suspect that the fuel
cap is not properly installed, pull off the road as soon as it is
safely possible and turn off the engine. Remove and replace the
fuel cap, making sure it is properly seated.
[LG10970(ALL)02/95]
After completing three (3) consecutive warm up cycles and on
the fourth engine start up, the Check Engine Warning Light
should turn off. If the light does not go off after the fourth
engine re-start, have your vehicle serviced by your dealer or a
qualified technician.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

Warning Lights and Gauges
89
% [LG11001(ALL)02/95]
Oil Pressure Light
[LG11005(ALL)06/94]
6 pica art:0050150-B
The oil pressure light
[LG11010(ALL)11/93]
This light indicates the engine's oil pressure, not the oil level.
However, if your engine's oil level is low, it could affect the oil
pressure. The light will come on briefly during the display
self-test every time you turn your key to the ON position. The
light will go off when the key is turned to the START position.
The light should stay off when the self-test is done if the engine
is running with normal oil pressure. If the light comes on while
the engine is running, you have lost oil pressure and continued
operation will cause severe engine damage.
*
[LG11020(ALL)03/95]
If you lose engine oil pressure:
*
[LG11030(ALL)03/95]1.
Pull off the road as soon as safely possible.
*
[LG11040(ALL)11/94]2.
Shut off the engine immediately. If you do not stop the
engine as soon as safely possible, severe engine damage
could result.
[LG11050(ALL)06/94]3.
Check the engine's oil level. (See ªChecking and Adding
Engine Oilº in theServicing Your Vehiclechapter of this
Owner Guide.) If you do not follow these instructions, you
or others could be injured. To ensure an accurate reading,
your vehicle should be on level ground.
[LG11060(ALL)10/93]4.
If the level is low, add only as much oil as necessary before
you start the engine again. Do not overfill. Do not operate
the engine if the light is on regardless of the oil level.
Contact your nearest dealer for further service.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

Warning Lights and Gauges
91
% [LG11255(ALL)03/94]
Low Windshield Washer Fluid Level Warning Light
[LG11257(ALL)11/93]
This light indicates that the level of your washer fluid is low,
and you have to add more fluid. This light comes on briefly
after you turn your ignition key from the START to the ON
position. If the washer fluid is low, a one second chime will
sound and the light will remain on for 60 seconds. If the washer
fluid is not low, the light should turn off a few seconds after
the engine has started. The light and chime also come on if the
washer fluid is low when you use your windshield washers.
[LG11258(ALL)03/94]
The washer fluid is only checked when the engine is started or
the windshield washers are in operation. The light will not
come on if the fluid level becomes low while you are driving
unless you turn on the windshield washers.
[LG11260(ALL)12/93]
6 pica art:0050062-B
The low windshield washer indicator light
*
[LG11265(ALL)06/95]
Speed Control Indicator
[LG11270(ALL)05/95]
A SPEED CONTROL light is displayed in the optional electronic
instrument cluster when the speed control system is engaged.
The display will turn off when the brake pedal is pressed or if
speed control is shut off.
*
[LG11275(ALL)05/95]
This display does not indicate any problems with the speed
control, but is simply a convenient way of knowing when it is
active.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996
