1996 FORD WINDSTAR audio

Electronic Sound Systems
199
*
[AS03800(ALL)05/95]
With Auto Memory Store, you can continually set strong
stations into your memory buttons without losing your
existing memory presets, which is especially handy while
traveling. Your radio will automatically set your memory
buttons to the strong local stations so you don't have to
continually manually tune to existing stations.
[AS03900(ALL)10/94]
Activate Auto Memory Store by pushing the ªAUTO
PRESETº button once. Your radio will set the first five
strong stations of the band you are in (AM, FM1 or FM2)
into the memory buttons. The display will show ªAUTOº,
then run through the frequencies, stopping momentarily on
the stations being set into the memory buttons. The radio is
now in the ªAUTOº mode and this display will show
ªAUTOº each time a preset is activated.
*
[AS04000(ALL)05/95]
NOTE: If there are fewer than five strong stations in the
frequency band, the remaining unfilled buttons will
store the last strong station detected on the band.
*
[AS04100(ALL)05/95]
After all stations have been filled, the radio will begin
playing the station stored on memory button 1.
[AS04200(ALL)04/95]
To deactivate the Auto Memory Store mode and return to
the manually-set memory button stations (or those stations
set using Auto Memory Load), simply push the ªAUTO
PRESETº button. Display will show ªAUTOº then ªOFFº.
The next time Auto Memory Store is activated on that band,
the radio will store the next set of five strong stations.
*
[AS04400(ALL)04/95]
Using the ªAUDIOº button to adjust the tone balance
and speaker output
*
[AS04500(ALL)04/95]
n
Increasing or decreasing bass response
*
[AS04600(ALL)04/95]
Push the ªAUDIOº button repeatedly until the display reads
ªBASS.º Push the ª+º side of the ªVOLº button to increase
bass (more ªlowsº), and push the ª-º side to decrease bass
(less ªlowsº).
File:wnass.ex
Update:Tue Mar 19 08:19:39 1996

200
*
[AS04700(ALL)04/95]
n
Increasing or decreasing treble response
*
[AS04800(ALL)04/95]
Push the ªAUDIOº button repeatedly until the display reads
ªTREB.º Push the ª+º side of the ªVOLº button to increase
treble (more ªhighsº), and push the ª-º side to decrease
treble (less ªhighsº).
*
[AS05100(ALL)04/95]
n
Adjusting speaker balance
*
[AS05200(ALL)04/95]
Balance control allows you to adjust the sound distribution
between the right and left speakers. Push the ªAUDIOº
button repeatedly until the display reads ªBAL.º Push the
ª+º side of the ªVOLº button to shift the sound to the right
speakers, and push the ª-º side to shift the sound to the left
speakers.
*
[AS05300(ALL)04/95]
n
Adjusting speaker fader
*
[AS05400(ALL)04/95]
Fade control allows you to adjust the sound distribution
between the front and rear speakers. Push the ªAUDIOº
button repeatedly until the display reads ªFADE.º Push the
ª+º side of the ªVOLº button to shift the sound to the front
speakers, and push the ª-º side to shift the sound to the rear
speakers.
[AS05500(ALL)11/93]
NOTE: Illuminated bars in the display show relative levels of
bass and treble and positions of speaker balance and
fader functions for five seconds after adjustments are
made, then revert to volume level set.
%*
[AS05600(ALL)04/95]
Clock operation
*
[AS05700(ALL)04/95]
When in the radio mode, push the ªCLOCKº button to switch
from radio frequency to clock. Only the clock numerals will be
displayed in the clock mode Ð there is no A.M./P.M.
indication. When in the clock mode, the time will be displayed
until the button is pushed again. However, if you retune the
radio while it is in the clock mode, the new radio frequency
will be displayed for approximately ten seconds and then
change back to clock.
File:wnass.ex
Update:Tue Mar 19 08:19:39 1996

204
*
[AS08900(ALL)04/95]
Special features of your CD player
*
[AS09000(ALL)04/95]
n
Compression
*
[AS09100(ALL)04/95]
The compression feature will bring soft and loud passages
closer together for a more consistent listening level.
[AS09200(ALL)02/95]
To turn the compression on, press the ªCOMPº button.
When on, the compression indicator (ªCº) will appear in the
display. Press the button again to turn off.
*
[AS09300(ALL)04/95]
n
Automatic Disc Storage
*
[AS09400(ALL)04/95]
If the disc is ejected from the CD player but is not removed
from the disc opening within approximately 10 seconds, the
player will automatically reload the disc for storage, unless
the disc is automatically ejected due to a ªfocus errorº (disc
inserted upside down). In this case, the disc will not be
automatically reloaded.
*
[AS09500(ALL)04/95]
How to eject the disc
*
[AS09600(ALL)04/95]
Push the ªEJECTº button to stop play, eject the disc and resume
radio operation of your audio system.
[AS09700(ALL)11/93]
NOTE: You can eject the disc while the radio power and/or
ignition is on or off.
%*
[AS09710(ALL)04/95]
How To Take Care of and Clean Your CD Player and
Discs
*
[AS09720(ALL)04/95]
To ensure the continued performance of your Ford Compact
Disc Player, carefully read the following precautions:
*
[AS09730(ALL)04/95]
n
Always handle the disc by its edge. Never touch the playing
surface.
*
[AS09740(ALL)04/95]
n
Before playing, inspect the disc for any contamination. If
needed, clean the disc with an approved disc cleaner, such as
the DiscwasherHCompact Disc Cleaner or the Allsop 3H
Compact Disc Cleaner, by wiping from the center out to the
edges.Do not use a circular motion to clean.
File:wnass.ex
Update:Tue Mar 19 08:19:39 1996

Electronic Sound Systems
207
[AS09925(ALL)04/95]
33-1/2 pica
art:0060675-B
High-Level Audio System
File:wnass.ex
Update:Tue Mar 19 08:19:39 1996

208
%*
[AS09930(ALL)03/95]
High-Level Audio System
[AS09940(ALL)07/91]
Ford's High-Level Audio System delivers quality performance
for maximum listening enjoyment.
*
[AS09950(ALL)02/95]
Using the Controls on Your New Radio
*
[AS09960(ALL)04/95]
How to turn the radio on and off
*
[AS09970(ALL)04/95]
Press the ªPOWERº button to turn the radio on. Press it again
to turn it off.
*
[AS09990(ALL)04/95]
How to adjust the volume
*
[AS10000(ALL)05/95]
Press the (+/±) side of the ªVOLº button to increase/decrease
the volume. Bars illuminate in the display to show the relative
volume level.
*
[AS10010(ALL)04/95]
NOTE: If the volume level is set above a certain listening
level when the ignition switch is turned off, when the
ignition switch is turned back on, the volume will
come back to a ªnominalº listening level. However, if
the radio power is turned off (with the ªPOWERº
button), the volume will remain in the position it was
set at when radio power is switched back on.
*
[AS10020(ALL)04/95]
Selecting the AM or FM frequency band
*
[AS10030(ALL)07/92]
Push the ªAM/FMº button to select the desired frequency band.
When in the radio mode, pushing the button more than once
will alternate between AM, FM1 and FM2. These functions are
used with the station memory buttons described underHow to
Tune Radio Stations.
File:wnass.ex
Update:Tue Mar 19 08:19:39 1996

212
[AS10300(ALL)04/95]
To deactivate the Auto Memory Store mode and return to
the manually-set memory button stations (or those stations
set using Auto Memory Load), simply push the ªAUTO
PRESETº button. Display will show ªAUTOº then ªOFFº.
The next time Auto Memory Store is activated on that band,
the radio will store the next set of five strong stations.
*
[AS10310(ALL)02/95]
Adjusting the tone balance and speaker output of your
radio
*
[AS10320(ALL)04/95]
n
Increasing or decreasing bass response
*
[AS10330(ALL)04/95]
Push the ªAUDIOº button repeatedly until the display reads
ªBASS.º Push the ª+º side of the ªVOLº button to increase
bass (more ªlowsº), and push the ª-º side to decrease bass
(less ªlowsº).
*
[AS10340(ALL)04/95]
n
Increasing or decreasing treble response
*
[AS10350(ALL)04/95]
Push the ªAUDIOº button repeatedly until the display reads
ªTREB.º Push the ª+º side of the ªVOLº button to increase
treble (more ªhighsº), and push the ª-º side to decrease
treble (less ªhighsº).
*
[AS10360(ALL)04/95]
n
Adjusting speaker balance
*
[AS10370(ALL)04/95]
Balance control allows you to adjust the sound distribution
between the right and left speakers. Push the ªAUDIOº
button repeatedly until the display reads ªBAL.º Push the
ª+º side of the ªVOLº button to shift the sound to the right
speakers, and push the ª-º side to shift the sound to the left
speakers.
*
[AS10380(ALL)04/95]
n
Adjusting speaker fader
*
[AS10390(ALL)04/95]
Fade control allows you to adjust the sound distribution
between the front and rear speakers. Push the ªAUDIOº
button repeatedly until the display reads ªFADE.º Push the
ª+º side of the ªVOLº button to shift the sound to the front
speakers, and push the ª-º side to shift the sound to the rear
speakers.
File:wnass.ex
Update:Tue Mar 19 08:19:39 1996

216
*
[AS11010(ALL)01/95]
Tape error messages
*
[AS11020(ALL)01/95]
Your cassette tape player is equipped to diagnose certain
problems you may experience. Error codes are as follows:
*
[AS11030(ALL)02/95]
Error 0Ð Communication error between the radio controller
and the tape controller. The cassette player will eject the tape.
Insert the tape again. If the same error code appears, turn the
ignition off, then back on again and insert the tape.
*
[AS11040(ALL)02/95]
Error 1Ð Possible problem cartridge. The cassette tape player
will eject the tape. Insert the tape again. If the same error code
appears in the display, try a different cartridge.
*
[AS11050(ALL)02/95]
Error 2Ð Tape eject or load failure. Your cassette tape player
will go into the pause mode. Push ªEJCTº to eject the tape. If
the tape doesn't eject, refer the problem to qualified personnel
for service.
%*
[AS11060(ALL)03/95]
Clock Operation
*
[AS11080(ALL)07/90]
How to view the clock mode
*
[AS11090(ALL)07/93]
Press the ªCLOCKº button to alternate the frequency and time
in the display. In the clock mode, pressing any radio function
will automatically display the radio frequency for approximately
ten seconds before changing back to the clock mode.
*
[AS11100(ALL)07/90]
How to set the clock
[AS11120(ALL)12/93]
Press and hold in the ªCLOCKº button, press the ªSEEKº
button left (
b) to advance the hours and right (
a) to advance
the minutes.
*
[AS11130(ALL)11/93]
NOTE: The clock displays 12-hour time with no AM/PM
indications.
[AS11135(ALL)11/93]
NOTE: On the High-Level Audio System, the clock can be set
with the radio power on or off.
File:wnass.ex
Update:Tue Mar 19 08:19:39 1996

Electronic Sound Systems
217
[AS12000(ALL)03/94]
NOTE: In order to maintain the performance of your cassette
stereo system, refer to ªTips on Caring for the
Cassette Player and Tapesº later in this chapter.
[AS12003(ALL)04/95]
The Ford 10-CD Changer System
[AS12006(ALL)05/95]
The Ford 10-CD Changer is mounted in your center floor
console and holds 10 CDs, all controlled by using the buttons
on your High-Level Audio System.
[AS12012(ALL)05/95]
Center Floor Console Loading Instructions
[AS12015(ALL)05/95]1.
Open Compact Disc Changer center floor console unit by
sliding door to the right (Figure 1).
[AS12018(ALL)05/95]
7-1/2 pica art:0050265-A[AS12021(ALL)04/95]2.
Push ªEJECTº button to eject the disc ªmagazineº (holds 10
discs) (Figure 2).
[AS12024(ALL)05/95]
7-1/2 pica art:0050266-AFile:wnass.ex
Update:Tue Mar 19 08:19:39 1996
