1996 FORD F250 Owners Manual

167
*
[AS36500(BEF )01/95]
Automatic gain control circuitry for both AM
and FM bands has been incorporated into this
system to reduce strong signal capture and
overload.
%
*
[AS36600(BEF )08/89]
All About Radio Frequencies
*
[AS36700(BEF )05/95]
The Federal Communications Commission (FCC)
and the Canadian Radio Telecommunications
Commission (CRTC) establish the frequencies
AM and FM radio stations may use for their
broadcasts. The allowable frequencies are, AM:
530, 540...1600, 1610 kHz in 10 kHz steps; FM:
87.9, 88.1...107.7, 107.9 MHz in 0.2 MHz steps.
*
[AS36800(BEF )01/95]
Not all frequencies will be assigned to a given
area. This radio will tune to each of these
frequencies using MANUAL TUNE and no fine
tuning is necessary as radio stations may not use
other frequencies.
*
[AS36900(BEF )02/95]
Some FM radio stations advertise a
ªrounded-offº frequency which is not the
frequency they actually broadcast on. For
example, a radio station that is assigned a
frequency of 98.7 MHz may call itself ªRadio 99º
even though 99.0 MHz is not an allowable FM
broadcast frequency.
File:ltasf.ex
Update:Thu May 9 15:15:21 1996
ProCarManuals.com

168
*
[AS37000(BEF )01/95]
Important Warranty and Service
Information
*
[AS37050(BEF )07/90]
Warranty
*
[AS37100(BEF )03/95]
Your sound system is warranted for three years
or 36,000 miles (60,000 kilometers), whichever
comes first. Consult your vehicle warranty
booklet for further information. Ask your dealer
for a copy of this limited warranty.
*
[AS37300(BEF )10/92]
Service
*
[AS37400(BEF )01/95]
At Ford Electronics, we stand behind our audio
systems with a comprehensive service and repair
program. If anything should go wrong with
your Ford audio system, return to your dealer
for service. There is a nationwide network of
qualified Ford authorized repair centers to assist
you.
File:ltasf.ex
Update:Thu May 9 15:15:21 1996
ProCarManuals.com

169
Driving Your F-Series
*
[DR00350(BEF )03/95]
Procedures for driving your vehicle will vary
depending on which type of transmission your
vehicle has.
*
[DR00400( EF )06/92]
q
an Automatic Transmission (C-6)
*
[DR00550(BEF )04/95]
q
an Electronic 4-speed Automatic Transmission
(E4OD)
*
[DR00575(BEF )03/93]
q
an Electronic 4-speed Automatic Transmission
(4R7OW)
*
[DR00600(B F )03/95]
q
a manual transmission
*
[DR00650(BEF )04/95]
Your vehicle is equipped with an Electronic
Powertrain Control Module that limits engine
and/or vehicle speeds with a cut-out mode to
promote durability.
*
[DR00700( EF )12/91]
Automatic Transmission
Operation (C-6)
*
[DR00800( EF )01/95]
Putting Your Vehicle in Gear
*
[DR00900( EF )12/91]
Your vehicle's gearshift is on the steering
column. You can put the gearshift in any of
several positions.
*
[DR00950( EF )02/95]
NOTE: Do not rest your hand on the gearshift
lever while driving your vehicle
because you could cause the gearshift
lever to move out of position.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996
ProCarManuals.com

170
*
[DR01000( EF )06/93]
one third page art:0020129-C
The positions of the column-mounted gearshift
*
[DR01100( EF )01/93]
RWARNING
Hold the brake pedal down while you
move the gearshift lever from position to
position. If you do not hold the brake
pedal down, your vehicle may move
unexpectedly and injure someone.
*
[DR01200( EF )01/95]
Once you place the gearshift securely into
position, gradually release the brake pedal and
use the accelerator as necessary.
*
[DR01210( EF )01/95]
NOTE: Your vehicle is equipped with a
brake-shift interlock feature. This
feature prevents you from shifting
from P (Park) unless you have the
brake pedal depressed. (The ignition
must be in the ON position.) If you
cannot shift from P (Park) with the
brake pedal depressed:
*
[DR01220( EF )01/95]
1. Apply the parking brake.
*
[DR01230( EF )01/95]
2. Remove the key.
*
[DR01240( EF )01/95]
3. Insert the key and rotate one position
clockwise (ignition in the OFF position).
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996
ProCarManuals.com

171
*
[DR01250( EF )01/95]
4. Apply the brake pedal and shift to N
(Neutral). (If the vehicle is shifted to P
(Park), you must repeat the previous steps.)
*
[DR01260( EF )01/95]
5. Start the vehicle.
*
[DR01265( EF )05/95]
If you need to shift out of P (Park) by using the
alternate procedure described above, it is
possible that a fuse has blown and that your
brakelamps may also not be functional. Please
refer to the chapter titledServicing Your F-Series
in this Owner Guide for instructions on checking
and replacing fuses.
*
[DR01270( EF )05/95]
RWARNING
DO NOT DRIVE YOUR VEHICLE UNTIL
YOU VERIFY THAT THE BRAKELAMPS
ARE WORKING.
%*
[DR01300( EF )01/95]
R (Reverse)
*
[DR01400( EF )02/95]
With the gearshift in the R (Reverse) position,
the vehicle will move backward. You should
always come to a complete stop before shifting
into or out of R (Reverse).
%*
[DR01500( EF )01/95]
Driving
*
[DR01600( EF )03/93]
When to use D (Drive)
*
[DR01700( EF )12/91]
This is the normal driving position. As the
vehicle picks up speed, automatic upshifts from
First gear to Second and Second to Third will
occur. The transmission automatically downshifts
as speed decreases.
*
[DR01800( EF )01/95]
When to use 2 (Second)
*
[DR01900( EF )12/91]
Use 2 (Second) to drive up moderately steep
grades, to start-up on slippery roads or to
provide engine braking on downgrades.
*
[DR02000( EF )12/91]
Do not go faster than 55 mph (88 km/h) in this
gear.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996
ProCarManuals.com

172
*
[DR02100( EF )01/95]
When to use 1 (Low)
*
[DR02200( EF )06/92]
Use 1 (Low) to drive up steep grades and to
provide maximum engine braking on hilly roads.
Upshifts from 1 (Low) can be made by manually
shifting to 2 (Second) or D (Drive). Selection of 1
(Low) gear provides only First gear operation at
start-up. When driving, manually shifting to 1
(Low) will result in downshifts to Second gear
or First gear depending on vehicle speed.
*
[DR02250( EF )12/91]
NOTE: Do not drive faster than 30 mph
(48 km/h) in this gear.
*
[DR02300( EF )01/95]
P (Park)
*
[DR02400( EF )03/94]
Always come to a complete stop before you shift
into P (Park). This position locks the
transmission and prevents the rear wheels from
turning. To securely latch the gearshift in the P
(Park) position, pull it toward you, push it
completely counterclockwise against the stop,
and then push it toward the instrument panel.
*
[DR02450( EF )03/94]
The gearshift is securely latched in P (Park) if
you cannot rotate it in a clockwise direction
without lifting it toward you.
*
[DR02500( EF )05/95]
RWARNING
Always set the parking brake fully and
make sure that the gearshift is securely
latched in P (Park).
*
[DR02600( EF )05/95]
RWARNING
Never leave your vehicle unattended
while it is running.
[DR02625( F )05/95]
When the transfer case is in the N (Neutral)
position, the engine and transmission are
disconnected from the rest of the driveline.
Therefore, the vehicle is free to roll even if the
automatic transmission is in P (Park) or the
manual transmission is in gear.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996
ProCarManuals.com

173
*
[DR02650( F )05/95]
RWARNING
Do not leave the vehicle unattended with
the transfer case in the N (Neutral)
position. Always set the parking brake
fully and turn off the ignition when
leaving the vehicle.
*
[DR02900( EF )06/94]
Forced Downshifts
*
[DR03000( EF )06/92]
To gain added acceleration in D (Drive) (when
passing another vehicle) push the accelerator to
the floor. The transmission will downshift to
Second gear at speeds from about 35 to 55 mph
(56 to 88 km/h) or to either First or Second gear
at speeds under 35 mph (56 km/h).
*
[DR03040( EF )03/94]
Power Braking
*
[DR03075( EF )03/93]
Increasing the engine speed above idle without
vehicle movement (such as holding the brake) in
a forward or reverse gear causes transmission
stall.Continued operation in the stall condition
can result in transmission overheat, malfunction
or fluid expulsion.
*
[DR08650(BEF )03/93]
Automatic Transmission
Operation (E4OD and 4R70W)
*
[DR08710(BEF )03/94]
The E4OD and 4R70W transmissions are
electronically controlled four speed automatic
transmissions with overdrive. Transmission
operation is controlled by the Powertrain Control
Module (PCM).
*
[DR08720( ALL)08/94]
The PCM will automatically adjust transmission
operation to make up for varying conditions.
Several sensors located on the engine and
transmission such as Throttle Position, Engine
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996
ProCarManuals.com

174Speed, Vehicle Speed and Transmission
Temperature are used by the PCM to shift the
transmission into a higher or lower gear when
required for the best performance and fuel
economy. For example, you may notice that the
transmission will upshift to a higher gear more
quickly when the vehicle is first driven and has
not reached normal operating temperature.
*
[DR08730( ALL)07/94]
The PCM also controls the transmission's Torque
Converter Clutch to further raise vehicle
performance and fuel economy. The Torque
Converter Clutch will engage when the
transmission operating temperature and other
conditions determined by the PCM have been
met. Engagement of the clutch may be noted as
a decrease in engine speed after an upshift has
completed or when the driver has depressed the
throttle while driving at a steady road speed.
[DR08740( ALL)04/95]
To help in troubleshooting, the PCM continually
performs self-tests on the electronic control
system and if any faults are detected, will store
them in memory. The Transmission Control
Indicator Light (TCIL), which is located on the
gearshift lever, may flash steadily if a
malfunction has been detected. If the TCIL is
flashing, contact your Ford dealer as soon as
possible. If this condition persists, damage to the
transmission could occur.
[DR08745( ALL)04/95]
NOTE: The word ªOFFº located on the end of
the gearshift lever is the transmission
control indicator light (TCIL).
*
[DR08750( ALL)01/95]
Putting Your Vehicle in Gear
*
[DR08800( ALL)03/94]
Your vehicle's gearshift is on the steering
column. The Transmission Control Switch and
indicator light are located on the end of the
gearshift lever. You can put the gearshift in any
of the several positions.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996
ProCarManuals.com
