1996 FORD F SERIES MOTORHOME AND COMMERCIAL CHASSIS Owners Manual

29
*
[LG08900( ALL)01/95]
High Beam Light
*
[LG09001( ALL)03/95]
This light comes on when the headlamps are
turned on high beam or when you flash the
lights.
*
[LG09025( ALL)11/89]
one inch art:0020537-B
High beam indicator light
*
[LG09500( ALL)01/95]
Fuel Gauge
*
[LG09700( ALL)06/93]
The fuel gauge displays approximately how
much fuel is in the fuel tank only when the
ignition switch is ON.
*
[LG09850( M)01/95]
For a proper fuel gauge indication after adding
fuel, the ignition switch should be in the OFF
position while the vehicle is being refueled.
*
[LG09860( ALL)06/93]
The fuel gauge indicator may vary slightly when
the vehicle is in motion.
*
[LG09875( ALL)08/93]
With ignition switch OFF, the fuel gauge
indicator may drift from the ignition switch ON
position.
[LG10130( E M)10/92]
one inch art:0020064-C
Fuel gauge
File:ltlgm.ex
Update:Tue Jun 20 16:47:10 1995

30 %
*
[LG11100( ALL)01/95]
Engine Coolant Temperature Gauge
*
[LG11201( ALL)03/95]
This gauge tells you the temperature of the
engine coolant, not the coolant level. If the
coolant is not at its proper level or mixture, the
gauge indicator will not be accurate.
*
[LG11301( ALL)02/95]
The pointer moves from the C (cold) mark into
the Normal band as the engine coolant warms
up. It is acceptable for the pointer to fluctuate
within the Normal band under normal driving
conditions. Under certain driving conditions,
such as heavy stop and go traffic or driving up
hills in hot weather, the pointer may indicate at
the top of the Normal band.
*
[LG11401( ALL)05/95]
If, under any circumstances, the pointer moves
above the NORMAL band, the engine coolant is
overheating and continued operation may cause
engine damage.
*
[LG11501( ALL)01/95]
If your engine coolant overheats:
*
[LG11601( ALL)03/95]
1. Pull off the road as soon as it is safely
possible.
*
[LG11701( ALL)03/95]
2. Turn off the engine. If you do not stop the
engine as soon as safely possible, severe
engine damage could result.
*
[LG11801( ALL)05/95]
3. Let the engine cool.DO NOT REMOVE
COOLANT SYSTEM FILL CAP UNTIL
THE ENGINE IS COOL.
*
[LG11901( ALL)04/95]
4. Check the coolant level following the
instructions on checking and adding coolant
to your engine, seeEngine Coolantin the
Index. If you do not follow these
instructions, you or others could be injured.
*
[LG12200( ALL)03/95]
For instructions on checking and adding coolant
to your engine, seeEngine coolantin the Index. If
you do not follow these instructions, you or
others could be injured.
File:ltlgm.ex
Update:Tue Jun 20 16:47:10 1995

31 [LG12375( E M)03/93]
quarter page art:0020687-C
Engine coolant temperature gauge
*
[LG12601( ALL)01/95]
Speedometer
*
[LG12700( ALL)01/95]
The speedometer tells you how many miles
(kilometers) per hour your vehicle is moving.
[LG12751( M)05/95]
Your vehicle contains a speedometer which
receives its input from a speed sensor. The
speedometer is also used to provide a speed
signal for correct operation of the vehicle's
Electronic Engine Control (EEC) module,
electronic transmission, and speed control
(if so equipped).
File:ltlgm.ex
Update:Tue Jun 20 16:47:10 1995

32 [LG12780( E M)10/92]
one third page art:0020872-BSpeedometer
%*
[LG13130( ALL)10/92]
Odometer/Trip Odometer
*
[LG13160( ALL)05/95]
The Liquid Crystal Display (LCD) odometer is a
combination trip odometer and total odometer.
The total odometer is normally displayed. To see
the trip odometer, press and release the SELECT
BUTTON on the upper right side of the
speedometer. To zero out the trip odometer,
press and release the RESET button on the
upper left side of the speedometer while the trip
odometer is displayed. If the trip odometer is
displayed, press and release the ªSelectº button
to return the display to the total odometer value.
File:ltlgm.ex
Update:Tue Jun 20 16:47:10 1995

33
Instrument Panel Controls
[IP00475( M)11/92]
NOTE: The following section does not apply
to Stripped Chassis vehicles. See your
Body Builder's instructions for location
and operation of controls for climate
control systems, lamps and radio.
%*
[IP16900( ALL)01/95]
Turning On the Exterior Lights
*
[IP17000( ALL)02/95]
To turn on your headlamps, parking lamps,
marker lamps, and tail lamps, use the headlamp
switch to the left of the steering column.
*
[IP17100( ALL)06/94]
1. Pull the headlamp control knob toward you
to the first position. Parking lamps, tail
lamps and marker lamps are now on.
*
[IP17200( ALL)06/94]
2. Pull the headlamp control knob toward you
to the outer position. Headlamps are now on
in addition to the above.
File:ltipm.ex
Update:Tue Jun 20 16:46:41 1995

34
*
[IP17260(B FM)10/92]
half page art:0020122-F
Headlamp switch
*
[IP17815( ALL)01/95]
Daytime Running Light System
*
[IP17820( ALL)03/95]
(Canadian vehicles only)
*
[IP17830( ALL)03/95]
The Daytime Running Light (DRL) system turns
the high beam headlamps on, with a reduced
light output, when:
*
[IP17835( ALL)03/95]
q
The headlamp system is in the OFF position,
and
*
[IP17840( ALL)03/95]
q
The vehicle is running, and
*
[IP17850( ALL)01/95]
q
The vehicle has a fully released parking
brake.
*
[IP17875( ALL)01/95]
NOTE: You may notice that the lights flicker
when the vehicle is turned on or off.
This is a normal condition.
File:ltipm.ex
Update:Tue Jun 20 16:46:41 1995

35
Steering Column Controls
*
[SC00400( ALL)01/95]
The controls on the steering column and wheel
are designed to give you easy access to the
controls while you are driving.
*
[SC00500( ALL)01/95]
The Turn Signal Lever
*
[SC00600( ALL)01/95]
You can use the turn signal lever on the left side
of the steering column to:
*
[SC00700( ALL)03/95]
q
operate the turn signals and cornering lamps
*
[SC01100( ALL)01/95]
Turn Signals
*
[SC01200( ALL)03/95]
Move the lever up to signal a right turn. Move
it down to signal a left turn. The corresponding
indicator light in the instrument cluster will
flash.
*
[SC01400( ALL)03/95]
If the turn signal stays on after you turn, move
the lever back to the center (off) position.
*
[SC01700( ALL)05/95]
one third page art:0020081-C
Turn signal lever and functions
File:ltscm.ex
Update:Tue Jun 20 16:46:36 1995

36
*
[SC01800( ALL)11/89]
If the turn indicator light in the instrument
panel does not illuminate or remains on (doesn't
flash) when you signal a turn, the turn signaling
system is malfunctioning. Have this condition
corrected as soon as possible, but make sure that
you use the accepted hand signals in the
meantime.
*
[SC03200( ALL)05/95]
High Beams
*
[SC03300( ALL)05/95]
To turn on the high beams, turn the headlamp
control knob to the headlamp ON position and
push the turn signal lever away from you until
it latches. When the high beams are ON, the
high beam indicator light on the instrument
panel comes on.
*
[SC03400( ALL)05/95]
To turn off the high beams, pull the lever
toward you until it latches. The high beam
indicator light turns off.
*
[SC03800( ALL)05/95]
one third page art:0020074-B
Headlamp high beam switch and turn signal lever
*
[SC04200( ALL)05/95]
Flashing the Lights
*
[SC04300( ALL)06/95]
To flash the headlamps, pull the lever toward
you for a moment and then release it. The
headlamps will flash whether the headlamp
knob is in the on or off position.
File:ltscm.ex
Update:Tue Jun 20 16:46:36 1995
