1996 FORD F SERIES MOTORHOME AND COMMERCIAL CHASSIS Owners Manual

Severe Duty Schedule 181
*
[BK53001( ALL)04/94]
q
Change fuel filter (Recommended but not
required for California Certified Vehicles).
*
[BK53030( FM)02/95]
q
Check spring U-bolt torque (F-Super Duty).
*
[BK53035( FM)02/95]
q
Inspect parking brake fluid (F-Super Duty).
*
[BK53050( ALL)04/93]
four pica chart:0060627-A
*
[BK53101( ALL)01/95]
18,000 MILES (30,000 Kilometers)
*
[BK53201( ALL)01/95]
q
Change engine oil and replace oil filter.
*
[BK53501( ALL)04/93]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK53601( ALL)05/93]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK53610( ALL)05/94]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
*
[BK53801( ALL)08/94]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK54050( ALL)04/93]
four pica chart:0060627-A
File:ltbkm.ex
Update:Tue Jun 20 16:42:47 1995

182 Severe Duty Schedule
*
[BK54101( ALL)01/95]
21,000 MILES (35,000 Kilometers)
*
[BK54201( ALL)01/95]
q
Change engine oil and replace oil filter.
*
[BK54225( ALL)01/95]
q
Change automatic transmission fluid.
*
[BK54250( ALL)04/93]
four pica chart:0060627-A
*
[BK54301( ALL)01/95]
24,000 MILES (40,000 Kilometers)
*
[BK54401( ALL)01/95]
q
Change engine oil and replace oil filter.
*
[BK54501( ALL)94/93]
q
Rotate tires and adjust air pressure. (3)(5)(6)
*
[BK54801( ALL)04/93]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK54901( ALL)05/93]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK54910( ALL)05/94]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
*
[BK55101( ALL)08/94]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK55301( ALL)05/93]
q
Lubricate throttle kickdown or TV lever ball
studs.
*
[BK55350( ALL)04/93]
four pica chart:0060627-A
File:ltbkm.ex
Update:Tue Jun 20 16:42:47 1995

Severe Duty Schedule 183
*
[BK55401( ALL)01/95]
27,000 MILES (45,000 Kilometers)
*
[BK55501( ALL)01/95]
q
Change engine oil and replace oil filter.
*
[BK55550( ALL)04/93]
four pica chart:0060627-A
*
[BK55601( ALL)01/95]
30,000 MILES (50,000 Kilometers)
*
[BK55701( ALL)01/95]
q
Change engine oil and replace oil filter.
*
[BK55800( ALL)05/94]
q
Replace air cleaner filter every 30,000 miles
(50,000 km) or 30 months. If operating in dusty
conditions consult your dealer and/or follow severe
duty maintenance schedule. (1)
*
[BK55950( ALL)05/95]
q
Inspect engine cooling system, hoses, and clamps;
and check coolant strength every 15,000 miles
(25,000 km) or 12 months.
*
[BK55985( ALL)04/93]
q
Replace crankcase emission air filter. If operating
in dusty conditions consult your dealer and/or
follow severe duty maintenance schedule. (4.9L,
5.0L man. trans., and 7.5L only.) (1)
*
[BK56200( ALL)04/93]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK56300( ALL)05/93]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK56350( ALL)05/94]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
File:ltbkm.ex
Update:Tue Jun 20 16:42:47 1995

184 Severe Duty Schedule
*
[BK56400( ALL)08/94]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK56700( ALL)05/93]
q
Inspect disc brake system and lubricate
caliper slide rails. (2)
*
[BK56800( ALL)04/94]
q
Inspect drum brake systems, hoses and lines.
*
[BK56900( ALL)04/94]
q
Change fuel filter (Recommended but not
required for California Certified Vehicles).
*
[BK57000( ALL)05/93]
q
Inspect and lubricate front wheel bearings. (2)
*
[BK57100( ALL)04/93]
q
Inspect parking brake system for damage and
operation.
q
Inspect parking brake fluid (F-Super Duty
only).
*
[BK57450( FM)06/94]
q
Change rear axle lube (F-Super Duty only).
(4)
*
[BK57520( FM)02/95]
q
Check spring U-bolt torque (F-Super Duty).
*
[BK57550( ALL)04/93]
four pica chart:0060627-A
*
[BK57600( ALL)01/95]
33,000 MILES (55,000 Kilometers)
*
[BK57700( ALL)01/95]
q
Change engine oil and replace oil filter.
*
[BK57750( ALL)94/93]
q
Rotate tires and adjust air pressure. (3)(5)(6)
*
[BK58050( ALL)04/93]
four pica chart:0060627-A
File:ltbkm.ex
Update:Tue Jun 20 16:42:47 1995

Severe Duty Schedule 185
*
[BK58100( ALL)01/95]
36,000 MILES (60,000 Kilometers)
*
[BK58200( ALL)01/95]
q
Change engine oil and replace oil filter.
*
[BK58700( ALL)04/93]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK58800( ALL)05/93]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK58850( ALL)05/94]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
*
[BK58900( ALL)08/94]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK59050( ALL)04/93]
four pica chart:0060627-A
*
[BK59100( ALL)01/95]
39,000 MILES (65,000 Kilometers)
*
[BK59200( ALL)01/95]
q
Change engine oil and replace oil filter.
*
[BK59250( ALL)04/93]
four pica chart:0060627-A
File:ltbkm.ex
Update:Tue Jun 20 16:42:47 1995

186 Severe Duty Schedule
*
[BK59300( ALL)01/95]
42,000 MILES (70,000 Kilometers)
*
[BK59400( ALL)01/95]
q
Change engine oil and replace oil filter.
*
[BK59425( ALL)01/95]
q
Change automatic transmission fluid.
*
[BK59450( ALL)94/93]
q
Rotate tires and adjust air pressure. (3)(5)(6)
*
[BK59600( ALL)04/93]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK59700( ALL)05/93]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK59750( ALL)05/94]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
*
[BK59800( ALL)08/94]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK59950( ALL)04/93]
four pica chart:0060627-A
*
[BK60000( ALL)01/95]
45,000 MILES (75,000 Kilometers)
*
[BK60100( ALL)01/95]
q
Change engine oil and replace oil filter.
*
[BK60150( ALL)05/95]
q
Inspect engine cooling system, hoses, and clamps;
and check coolant strength every 15,000 miles
(25,000 km) or 12 months.
*
[BK60400( ALL)05/93]
q
Inspect disc brake system and lubricate
caliper slide rails. (2)
*
[BK60500( ALL)04/94]
q
Inspect drum brake systems, hoses and lines.
File:ltbkm.ex
Update:Tue Jun 20 16:42:47 1995

Severe Duty Schedule 187
*
[BK60600( ALL)04/94]
q
Change fuel filter (Recommended but not
required for California Certified Vehicles).
*
[BK60630( FM)02/95]
q
Inspect parking brake fluid (F-Super Duty).
*
[BK60635( FM)02/95]
q
Check spring U-bolt torque (F-Super Duty).
*
[BK60650( ALL)04/93]
four pica chart:0060627-A
*
[BK60700( ALL)01/95]
48,000 MILES (80,000 Kilometers)
*
[BK60800( ALL)01/95]
q
Change engine oil and replace oil filter.
*
[BK60900( ALL)01/95]
q
Change engine coolant initially at 48,000 miles
(80,000 km) or 48 months. Thereafter, change
engine coolant every 30,000 miles (50,000 km) or
36 months.
*
[BK61300( ALL)04/93]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK61400( ALL)05/93]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK61450( ALL)05/94]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
File:ltbkm.ex
Update:Tue Jun 20 16:42:47 1995

188 Severe Duty Schedule
*
[BK61500( ALL)08/94]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK61800( ALL)05/93]
q
Lubricate throttle kickdown or TV lever ball
studs.
*
[BK62150( ALL)04/93]
four pica chart:0060627-A
*
[BK62200( ALL)01/95]
51,000 MILES (85,000 Kilometers)
*
[BK62300( ALL)01/95]
q
Change engine oil and replace oil filter.
*
[BK62340( ALL)94/93]
q
Rotate tires and adjust air pressure. (3)(5)(6)
*
[BK62350( ALL)04/93]
four pica chart:0060627-A
*
[BK62400( ALL)01/95]
54,000 MILES (90,000 Kilometers)
*
[BK62500( ALL)01/95]
q
Change engine oil and replace oil filter.
*
[BK62700( ALL)04/93]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK62800( ALL)05/93]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK62850( ALL)05/94]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
File:ltbkm.ex
Update:Tue Jun 20 16:42:47 1995
