1996 FORD F SERIES MOTORHOME AND COMMERCIAL CHASSIS Owners Manual

173
General Information
*
[BK00050( ALL)05/95]
thirty-two pica chart:0060629-D
File:ltbkm.ex
Update:Tue Jun 20 16:42:47 1995

174Table of ContentsMaintenance Schedule and Record.......... 175
General Maintenance Information........... 175
Severe Duty Schedule................................. 178
Owner Maintenance Checks...................... 205
*
[BK00110( ALL)05/95]
twenty-two pica chart:0060691-A
File:ltbkm.ex
Update:Tue Jun 20 16:42:47 1995

175
Maintenance Schedule and
Record
[BK00140( M)05/93]
quarter page art:0020742-C*
[BK00200( ALL)01/95]
General Maintenance Information
*
[BK00300( ALL)01/95]
The required Scheduled Maintenance Services
listed in this booklet are considered essential to
the proper operation, safety and performance of
your Ford Motor Company vehicle. We
recommend that you also perform the Owner
Maintenance Checks listed. These services are
matters of day-to-day care that are also
important to the proper operation of your
vehicle. The recommended lubricants, fluids and
service parts conforming to Ford Specifications
are available from your dealer.
*
[BK00350( ALL)01/95]
This booklet gives you a place to record the
services that are performed on your vehicle so
that you can keep a record of when parts should
be checked or replaced. Give yourMaintenance
Schedule and Recordbooklet to the dealer service
manager.
*
[BK00400( ALL)01/95]
Maintenance: An investment
*
[BK00500( ALL)01/95]
An investment which will pay dividends in the
form of improved reliability, durability, and
resale value.
File:ltbkm.ex
Update:Tue Jun 20 16:42:47 1995

176
*
[BK01300( ALL)01/95]
To assure the durability of your vehicle and its
emission control systems, it is necessary that
scheduled maintenance be performed at the
designated intervals.
*
[BK01400( ALL)05/95]
Ford strongly recommends the use of genuine
Ford replacement parts. If other than Ford or
Motorcraft parts or Ford authorized
remanufactured parts are used for maintenance
replacements or for the service of components
affecting emission control, such non-Ford parts
should be equivalent to genuine Ford Motor
Company parts in performance and durability. It
is the owner's responsibility to determine the
equivalency of such parts. Please consult your
warranty booklet for complete warranty
information.
*
[BK01410( ALL)05/95]
No Cost PCV Valve Replacement
[BK01425( M)02/93]
THE PCV VALVE ON LIGHT TRUCKS IS A
CRITICAL EMISSION COMPONENT. YOUR
DEALER WILL REPLACE THE VALVE AT NO
COST AT 60,000 MILES/96,000 KILOMETERS
(EXCEPT CANADA VEHICLES).
*
[BK01435( ALL)06/94]
Wheel Lug Nuts
*
[BK01455( ALL)06/94]
Wheel lug nuts must be retightened to proper
torque specifications at 500 miles/800 km of
new vehicle operation (100 miles/160 km for
vehicles equipped for snowplowing). Proper
torque specifications are provided in your
Owner Guide. Also retighten to proper torque
specification at 500 miles/800 km after (1) any
wheel change or (2) any other time the wheel
lug nuts have been loosened.
File:ltbkm.ex
Update:Tue Jun 20 16:42:47 1995

177
*
[BK01462( ALL)01/95]
PRE-DELIVERY CHECK
*
[BK01464( ALL)01/95]
q
Pre-Delivery Service Inspection Completed
*
[BK01466( ALL)08/93]
four pica chart:0060627-A
File:ltbkm.ex
Update:Tue Jun 20 16:42:47 1995

178 Severe Duty ScheduleSevere Duty Schedule
*
[BK49700( ALL)01/95]
NOTE: Items for Emission Control Service are
shown in this type and style.
*
[BK49800( ALL)01/95]
For items marked with a number in parentheses
such as (1), see footnote at the end of this
section.
*
[BK49900( ALL)05/93]
NOTE: The Severe Duty Schedule provides
maintenance intervals for replacing
your air cleaner filter if you drive in
severe dust conditions. However, the
conditions you drive in may require
even more frequent air cleaner
replacement intervals than those
shown. Check with your dealer.
*
[BK50050( ALL)01/95]
Maintenance
Intervals
for Severe
Duty Schedule
*
[BK50100( ALL)01/95]
3,000 MILES (5,000 Kilometers)
*
[BK50200( ALL)01/95]
q
Change engine oil and replace oil filter.
*
[BK50450( ALL)04/93]
four pica chart:0060627-A
File:ltbkm.ex
Update:Tue Jun 20 16:42:47 1995

Severe Duty Schedule 179
*
[BK50501( ALL)01/95]
6,000 MILES (10,000 Kilometers)
*
[BK50601( ALL)01/95]
q
Change engine oil and replace oil filter.
*
[BK50650( ALL)94/93]
q
Rotate tires and adjust air pressure. (3)(5)(6)
*
[BK50801( ALL)04/93]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK50901( ALL)05/93]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK50910( ALL)05/94]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
*
[BK51001( ALL)08/94]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK51150( ALL)04/93]
four pica chart:0060627-A
*
[BK51201( ALL)01/95]
9,000 MILES (15,000 Kilometers)
*
[BK51301( ALL)01/95]
q
Change engine oil and replace oil filter.
*
[BK51350( ALL)04/93]
four pica chart:0060627-A
File:ltbkm.ex
Update:Tue Jun 20 16:42:47 1995

180 Severe Duty Schedule
*
[BK51401( ALL)01/95]
12,000 MILES (20,000 Kilometers)
*
[BK51501( ALL)01/95]
q
Change engine oil and replace oil filter.
*
[BK52001( ALL)04/93]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK52101( ALL)05/93]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK52110( ALL)05/94]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
*
[BK52201( FM)08/94]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK52350( ALL)04/93]
four pica chart:0060627-A
*
[BK52401( ALL)01/95]
15,000 MILES (25,000 Kilometers)
*
[BK52501( ALL)01/95]
q
Change engine oil and replace oil filter.
*
[BK52550( ALL)05/95]
q
Inspect engine cooling system, hoses, and clamps;
and check coolant strength every 15,000 miles
(25,000 km) or 12 months.
*
[BK52601( ALL)94/93]
q
Rotate tires and adjust air pressure. (3)(5)(6)
*
[BK52801( ALL)05/93]
q
Inspect disc brake system and lubricate
caliper slide rails. (2)
*
[BK52901( ALL)04/94]
q
Inspect drum brake systems, hoses and lines.
File:ltbkm.ex
Update:Tue Jun 20 16:42:47 1995
