Driveline Universal Joint and
Slip Yoke
[SV36050( M)06/93]
The universal joints that come standard with
your vehicle do require lubrication. Lubrication
will be necessary at the intervals shown in the
Maintenance Schedule and Recordbooklet.
%
*
[SV36300( ALL)03/95]
Brake Fluid
*
[SV36350( ALL)05/90]
Your vehicle is equipped with a brake fluid level
indicator in the master cylinder which lights the
BRAKE warning light on the instrument panel
when the brake fluid level is low.
*
[SV36400( ALL)04/95]
Under normal circumstances, your vehicle
should not use up brake fluid rapidly. However,
expect the level of the brake fluid to slowly fall
as you put more mileage on your vehicle and
the brake lining wears.
*
[SV36500( ALL)10/89]
Check the brake fluid at least once a year. You
can do this by looking at the fluid level in the
plastic reservoir on the master cylinder. The
fluid level should be at or near the MAX mark.
*
[SV36550( ALL)05/95]
RWARNING
Brake fluid is toxic.
*
[SV36560( ALL)06/95]
If brake fluid contacts eyes, flush eyes with
running water for 15 minutes. Get medical
attention if irritation persists. If taken internally,
drink water and induce vomiting. Get medical
attention immediately.
%*
[SV36600( ALL)02/95]
If the fluid is low, carefully clean and remove
the filler cap from the reservoir. Fill the
reservoir to the MAX line with Ford High
Performance DOT 3 Brake Fluid C6AZ-19542-AA
or DOT 3 equivalent fluid meeting Ford
specification ESA-M6C25-A.
File:ltsvm.ex
Update:Tue Jun 20 16:44:35 1995

142
*
[SV36850( ALL)12/91]
NOTE: If brake fluid is spilled on painted
surfaces, it must be flushed and wiped
away immediately. Brake fluid may
dissolve the paint finish on your
vehicle.
*
[SV36900( ALL)01/95]
RWARNING
If you use a brake fluid that is not DOT
3, you will cause permanent damage to
your brakes.
*
[SV37000( ALL)01/95]
Do not fill the reservoir above the MAX line.
*
[SV37100( ALL)01/95]
If you find that the fluid level is excessively low
Ð below the seam or ridge on the outside of the
plastic reservoir Ð have the brake system
inspected.
*
[SV37200( ALL)01/95]
RWARNING
Do not let the reservoir for the master
cylinder run dry. This may cause the
brakes to fail.
[SV37450( M)05/91]
one third page art:0020867-A
Brake master cylinder
File:ltsvm.ex
Update:Tue Jun 20 16:44:35 1995

143 [SV37525( M)07/92]
Parking Brake Reservoir
[SV37550( M)03/93]
To inspect the parking brake fluid, refer to the
1996 Ford Service Manualor a qualified service
technician.
%
*
[SV37600( ALL)03/95]
Power Steering Fluid
*
[SV37700( ALL)01/95]
Check the level of the power steering fluid at
least twice a year (i.e., every Spring and Fall).
*
[SV37800( ALL)03/95]
To check the level of your power steering fluid:
*
[SV37900( ALL)02/95]
1. Start the engine and let it run until the
power steering fluid reaches normal
operating temperature. The power steering
fluid will be at the right temperature when
the engine coolant temperature gauge in the
instrument cluster is near the center of the
NORMAL operating temperature range.
*
[SV38000( ALL)01/95]
2. While the engine idles, turn the steering
wheel back and forth several times. Make
sure that the cap assembly is installed at this
time.
[SV38150( M)05/94]
3. Then turn the engine off and do not press
the brake pedal.
%*
[SV38200( ALL)03/94]
4. Check the fluid level on the dipstick (which
is highlighted in yellow in your vehicle). The
fluid level should be between the arrows in
the FULL HOT range, which is marked on
the side of the dipstick, opposite the side
marked FULL COLD. Do not add fluid if the
level is within the FULL HOT range.
File:ltsvm.ex
Update:Tue Jun 20 16:44:35 1995

144
*
[SV38250( ALL)03/94]
one third page art:0021016-B
Power steering dipstick
[SV38650( M)03/93]
one third page art:0020729-B
Power steering reservoir
*
[SV38800( ALL)07/94]
5. If the power steering fluid is low, add fluid
in small amounts, continuously checking the
level, until you reach the FULL HOT range.
Do not overfill.
% [SV39100( M)05/91]
q
Use only Motorcraft MERCONHAutomatic
Transmission Fluid or an equivalent
MERCONHapproved fluid.
*
[SV39200( ALL)01/95]
If the power steering fluid is low, do not drive
your vehicle for a long period of time before
adding fluid. This can damage the power
steering pump.
*
[SV39300( ALL)03/95]
6. When you are finished, put the dipstick back
in and make sure that it fits snugly.
File:ltsvm.ex
Update:Tue Jun 20 16:44:35 1995

145
*
[SV39400( ALL)02/95]
If you check the power steering fluid when it is
cold, make sure that the fluid reaches the FULL
COLD range on the dipstick. The reading will
only be accurate if the fluid temperature is
approximately 50 to85ÊF (10 to 30ÊC).
*
[SV39405( ALL)06/93]
NOTE: Do not turn the steering wheel of your
vehicle with the engine off. It could
force power steering fluid out from the
reservoir cap or in extreme cases, it
could unseat the cap.
[SV39410( M)06/90]
Suspension and Steering
[SV39420( M)06/90]
Modifications
[SV39430( M)06/90]
The suspension and steering systems on your
vehicle have been designed and tested to
provide both safe, predictable performance
whether loaded or empty as well as durable
load carrying capability. Any modifications to
the suspension or steering systems can reduce
your vehicle's performance capability and
adversely affect driver and passenger safety.
Ford recommends that you do not make
modifications such as adding or removing parts
(like lift kits or stabilizer bars) or by using
replacement parts not equivalent to the original
factory equipment.
[SV39440( M)08/90]
RWARNING
The low pressure gas shock absorbers are
charged with nitrogen gas to 90 psi (620
kPa). Do not attempt to heat, puncture or
open.
File:ltsvm.ex
Update:Tue Jun 20 16:44:35 1995

146 [SV39450( M)06/90]Inspecting for Road Damage
[SV39460( M)06/90]
The suspension and steering linkage in your
vehicle should be inspected periodically for
abnormal looseness and damaged seals. Also be
alert for changes in steering action. Hard
steering, excessive free play or unusual sounds
when turning or parking indicate a need for
inspection or servicing.
[SV39470( M)06/90]
NOTE: After any severe impact such as
striking large potholes, inadvertent
sliding into curbs on icy roads, or a
collision involving the front end,
observe the steering wheel alignment.
If the steering wheel spokes seem to
be in a different position while going
down the road, have the front
suspension and steering checked for
possible damage.
File:ltsvm.ex
Update:Tue Jun 20 16:44:35 1995

147
%*
[SV39500( ALL)04/95]
Fuses, Fuse Links and Circuit
Breakers
*
[SV39650(B FM)12/91]
Fuses, circuit breakers and fuse links protect
your vehicle's electrical system from overloading.
If electrical parts in your vehicle are not
working, the system may have been overloaded
and blown a fuse or tripped a circuit breaker.
Before you replace or repair any electrical parts,
check the appropriate fuses or circuit breakers.
*
[SV39700( ALL)10/89]
The following charts tell you which fuses or
circuit breakers protect each electrical part of
your vehicle. If a fuse blows or a circuit breaker
opens a circuit, all the parts of your vehicle that
use that circuit will not work.
[SV39750( M)10/92]
Selected circuits, such as headlamps and
windshield wipers, are protected with circuit
breakers. A circuit breaker is designed to stop
current flow in case of a short-circuit or
overload. It will automatically restore current
flow after a few seconds, but will again interrupt
current if the overload or short-circuit continues.
This on-off cycle will continue as long as the
overload or short-circuit exists.
*
[SV39800( ALL)06/95]
Once you have determined which fuses or circuit
breakers to check, follow the procedures under
Checking and replacing fusesorChecking and
replacing circuit breakerslater in this chapter.
File:ltsvm.ex
Update:Tue Jun 20 16:44:35 1995

148 % [SV40200( M)05/94]
full page art:0020730-DFuses/circuit breakers and their locations
