Fig. 7 Engine Compartment Wiring YJ
JWIRING AND COMPONENT IDENTIFICATION 8W - 19

Fig. 10 Engine Wiring 2.5L YJ
JWIRING AND COMPONENT IDENTIFICATION 8W - 21

Fig. 11 Engine Wiring 4.0L YJ
8W - 22 WIRING AND COMPONENT IDENTIFICATIONJ

XJ
Caption Fig.
Anti-Lock Brake System Wiring XJ..................3
Body Wiring XJ............................7,8
Door Wiring (Front) XJ.........................11
Engine Compartment Wiring 2.5L XJ................17
Engine Compartment Wiring 4.0L XJ.............18, 19
Engine Wiring 2.5L XJ.........................21
Engine Wiring 4.0L XJ.........................22
Front Cross-body Wiring XJ......................4
Front End Wiring XJ..........................16
Instrument Panel to Body Wiring XJ................14Caption Fig.
Instrument Panel Wiring XJ...................12, 13
Liftgate Wiring XJ.............................1
Power Seat Wiring XJ.........................15
Rear Door Wiring XJ...........................6
Roof Wiring (Rear) XJ..........................9
Roof Wiring XJ..............................5
Steering Column Wiring XJ......................10
Trailer Tow Wiring XJ..........................2
Transmission Wiring XJ........................20
JWIRING AND COMPONENT IDENTIFICATION 8W - 25

Fig. 17 Engine Compartment Wiring 2.5L XJ
JWIRING AND COMPONENT IDENTIFICATION 8W - 37

Fig. 18 Engine Compartment Wiring 4.0L XJ
8W - 38 WIRING AND COMPONENT IDENTIFICATIONJ

Fig. 19 Engine Compartment Wiring 4.0L XJ
JWIRING AND COMPONENT IDENTIFICATION 8W - 39

Fig. 21 Engine Wiring 2.5L XJ
JWIRING AND COMPONENT IDENTIFICATION 8W - 41
