1993 VOLKSWAGEN GOLF Owners Manual

Downloaded from www.Manualslib.com manuals search engine CONTROLS AND EaUIPMENT ------------------------------~---
Pedals
- _ movement of the peda ls must never be ~S ncted .
::-thIs reason, do not put articles in the '00 well which cou ld roll or slide under­
- 3ath th e pedals.
- • In t
he case of defects on the brake sys­
'em, a greater pedal travel may be necess­a , t should always be possib le to depress
- "'e clut ch and acce le rator pedals fully.
All peda ls must be able to return , unh in-Jere d, to their rest positions. .
= o r these reasons, the only foot mats which e 'Y'\ay be used are those which leave the
ed al area compl ete ly free and which are pre ve nted from slipping .
'11
Hand brake
To apply the handbrake pull lever up firmly . On hills th e 1 st gear, or with automatic gear­
box the parking lock, sho uld also be en­
gaged. The handbrake should a lways be ap­plied so firmly that it is not possible to drive inadve rtentl y with the handbrake on.
W h
en handbrake is applied with the ignition on, the brake warning lam p* comes on.
To release handbrake, pu ll lev er up slightly ,
press locking knob in and push lever right
do w n.
Manual gearbox
• Only engage reverse gear when vehicle is st ationary With the engin e is running, de­
press clutch fully and wait a fe w seconds before mo ving gear lever. ThiS prevents
g rating noises .
When
rev erse gear is engaged with ignition on , the reversing lights come on.
Note
When driving you shou ld not rest your hand
on th e gear lever . The pressure of your hand is transmitted to the selector forks In the
gearb ox and can cause premature wear on the forks .
31

Downloaded from www.Manualslib.com manuals search engine Automatic gearbox*
Driving programmes
The gearbox control unit is equipped with two driving programmes:
• Sport programme
• Economy programme
The programme is selected automati­cally depending on operation of the accel­
erator pedal.
The sport programme is selected if the
accelerator pedal is operated rapidly. In this
case the accelerator pedal need not be de­
pressed to the point of kick-down (see
Page 33). In the sport programme, full use is made of the engine's power reserves
through delayed change to higher gear
The
economy programme is selected
when the acce lerator, pedal is operated
s lowly or normally. Fuel consumption is re­duced by changing early into higher gear and later into lower.
Selector lever lock
In positions "P" and " N" with the ignition
s wi tc h on the selector lever is locked . To move the selector lever out of these posi­
t ions the brake pedal must be depressed and the selector lever button pushed in .
This prevents a gear being engaged inadver­
tently
and the vehicle unintentional ly mov­
ing off .
A de l
ay circuit prevents the selector lever
f rom locking when it is moved quickly past the" N" position (for Instan ce from" R" to "
D " ) This enables for examp
le the vehicle
to be " rocked" out of a "bogged down "
position The shift lock only locks the selec­
tor
leve r if it is left in the " N" position for
more than about 1 second without the
brake pedal being depressed.
At speeds above 5 km/h the selector lever
is automatically switched-off in position "N".
Selector lever positions
P -Parking lock
The driving wheels are lock ed mechanically
The parking lock may only be engaged
when the vehicle is stationary. Before mov­
ing the lever in or out of the" P" position the
lock button in the selector lever handle
must be pressed. Before moving the selec­
tor lever out of
the" P" pOSition, the brake
pedal must also be depressed w hen the
ignition is switched on .
R -Reverse gear
The reverse gear should only be engaged
when the vehicle is station ary and with the
eng ine id ling. Before engaging the position
"R " from the positions "P" or "N " the

brake pedal must be d epr essed and the lock

b u tton in the selecto r lever handle must

also be p re ssed .

The
reversing lights come on then the se­

l e cto r leve r is in the "R" position with the

ignition switched on.

N -Neutral (idling position)

To move the leve r out of neutral when sta­

tionary or at speeds below 5 km/h and with
ignit ion switc hed on depress the brake
ped al and press the lock button in the selec ­

t or lever handle .

32

Downloaded from www.Manualslib.com manuals search engine ___________C~NTROLS AND EQUIPMENT"----O_
D -Normal driving position

-e four forward gears are shifted up and
~own automatically depending upon engine

:lad and road speed.

J n d er certain driving condit ions it
is advan­
--"geous to engage one of the following de­

s "ribed selector lever positions.

3 -Position for hilly regions

ne 1st, 2nd and 3rd gears are shifted up
a'1d down automatically depending upon
~ngine load, road speed and selected pro­
gramme (E or S) The 4th gear IS not en­
;}aged. This increases the engine braking ef­
-e el w hen the accelerator pedal is released.

-
his selector position is recommended in
5. uations where the gearbox alternates fre­quently between 3rd and 4th gears in the D" position .
2 -Position for steep hills
-h is selector lever position is sUitable for
n g climbs and descents. The
1 st
and 2nd gears are shifted up and
down automatically depending on engine

load and road speed . The 3rd and 4th gears

are not engaged in order to avoid unnecess­
ary gear changes. This further increases the

engine braking effect on deceleration .

1 -Position for very steep hills

This selector lever position is recom­

mended for very steep climbs and de­

scents.

To engage this gear, the lock button in the

selector leve r handle must be pressed in.
The vehicle only moves in 1st gear. The 2nd,

3rd and 4th gears are not engaged. Maxi­

mum possible engine braking effect is now
available.

The cruise control
* cannot be used in posi­

t ion "1".

Note
When changing down manually the select or
lever can be moved into the lower gear posi­
tion, but the automatic will not change
down until it is n o longe r possible to over­
rev the engine.
Kick-down device
The kick-down device gives maximum ac­celeration. When the accelerator pedal is pressed righ t down past the fu ll throttle
position, depending on road speed and en­
gine speed, the box changes down into a
lower gear. The shift up into the next higher
gear then takes place as soon as the maxi­
mum specified engine speed is reached.
Notes on driving
Starting
The engine can only be started when selec­
tor lev er is at "N" or "P". See also " Starting
engine" on page 36 .
Selecting a driving range
When the vehicle is stationary and the engine is running always de­press the foot brake when selecting a gear.
When the vehicle is stationary do not depress the accelerator when selecting a gear.
If the lever is moved accidentally into "Nu when driving, release ac­celerator and let the engine speed drop to idling before selecting a for­ward gear again.
33

Downloaded from www.Manualslib.com manuals search engine CONTROLS AND EQUIPMENT

• Attention • When the engine is running it is necessary to hold the vehicle with the foot brake in all gears. Because with an automatic gear­box the transfer of power is not fully interrupted even at idling speed -and the vehicle tends to "creep". If a driving range is selected while the vehicle is stationary, the throttle must on no account be opened (e.g. by hand from in­side the engine compartment). The vehicle can then start mov­ing, possibly even when the hand brake is applied.
Before working on a running en­gine, ensure that selector lever is
in position "p" and thatthe hand­brake is applied.
Moving off
Select driving range (R, 0, 3, 2, 1) Wait until the gearbox has shifted and the power flow is made to the driving
wheels (light selection jerk perceptible). Then one can accelerate.
Stopping
To stop vehicle temporarily such as at traffic
lights, it is only necessary to apply the
brakes. It is not necessary to move selector
lever to "N". The engine should however on ly be running at idling speed.
Parking
On level ground all you need do is engage
the parking lock. On a gradient the hand­
brake should be applied firmly first and then
the parking lock engaged. This will ensure
that the locking mechanism
is not too heav­
ily loaded and makes the lock easier to dis­
engage .
Tow starting
On vehicles w ith automatic gearbox the en­
gine cannot be started by towing or pushing
the vehicle. See page130 .
When the battery
is flat. the engine can be started from the battery of another vehicle
by using jumper cables See" Emergency starting", page 128.
Towing
If the vehicle has to be towed at any time ,
you must read the instructions in the sec­
tion "Towing/tow starting on page 129.
Emergency programme
If functional defects occur in the electronic system the gearbox can, amongst other
things, carry on operating in two emergency
programmes: •
The gearbox continues to change up
and
down automatically as before but hard shift

jerks are however noticeable. The vehicle

should
be taken to a Volkswagen dealer.

• The gearbox no longer changes up and
down automatically.

The gearbox can then be shifted manually

but in the selector leve r positions "0", "3"
and "2" only the 3rd gear is available.

I n se lector lever positions " 1 " and " R", the
1 st and reverse gears
are available as nor­
mal .
However, the converter must. due to the
absence of 2nd gear work harder ,
and under
certain circumstances this causes the con­
verte r to overheat.
In a case such as this the
vehicle should be taken, as soon as poss­
ible, to a Volkswagen dealer.
34

Downloaded from www.Manualslib.com manuals search engine CONTROLS AND EQUIPMENT

Height adjustable
steering wheel*
-n e steering wheel height can be adjusted as r equired . To do this pull the lever on the :::1 of th e stee ring co lumn down and move -~e w hee l to the desir ed position
Attention
For safety reasons, the lever
must then be pressed fully up again, so that the steering wheel position cannot move while ve­
hicle is moving.
Ignition lock
Petrol engines
1 -Ignition off -Steering can be locked
2 -Ignition on
3 -Starting engine
Diesel engines
1 -Fuel supply cut off! engine stopped, steering can be locked
2 -Glow and drive position
No other current co nsumer s should be sw itc hed on together w ith the glow plugs ­
this aVOi d s dra ining the batte ry unn ecessa r­ily.
3 -Starting engine
For all vehicles:
Position 1:
To lock the steering wheel withdraw key and turn wheel unti l you hear the lock­
ing pin engage
Attention Do not withdraw key from lock until vehicle is stationary! The steering lock could be uninten­tionally engaged.
Position 2:
If the key is difficult to turn in the lock or can­
not be turned to this position at all, the steer­
ing wheel must be rocked to and fro slightly
to release the locking pin .
Position 3:
In this pos ition the headlights and other
h eavy cu rre nt consume rs are switched off.
Before the start er
can be operated again the key must be turned back to position 1. The
non-repeat mechanism in the ignition lock
prevents th e starter from being operated
w hen engine
is ru nning, as this could dam­
age the starter.
35

Downloaded from www.Manualslib.com manuals search engine CONTROLS AND EQUIPMEN-=-T-=------___
Starting the engine
General hints
Attention When starting the engine in con­fined spaces there is a danger of poisoning.
• Before starting, move gear lever to neu·
tral (with automatic gearbox: Selector lever in "P" or"N" position) and apply handbrake fi rmly
•
On vehicles with a manual gearbox de­
press the clutch pedal when operating
starter
so that starter only has to turn en­
gine .
• As soon
as engine starts, release the
ignition key so that starter can dise ngage .
• After starting a co
ld engine It may sound
noisy for a moment or two because the 011 pressure has to build up in the hydraulic
tappets first. This is normal and no cause for
alarm .
~Do not warm engine up by run­~ning it with vehicle stationary. Drive off straight away.
Do not overrev or use full throttle until the
engine has reached the normal operating
temperature .
• On vehicles with a catalytic con­verter the engine must not be started by towing the vehicle in ex· cess of 50 m. Otherwise unburnt fuel can pass into the converter and lead to damage.
• Before trying to start engine by towing, the battery from another ve· hicle should be used for starting if possible -see page 128.
Petrol engines
These engines are equipped with a petrol in­
jection system that automat ically supp lies
the correct fuel/air mixture at all ambient
temperatures.
When engine
is cold or at operating temperature do not accelerate before or
during the starting procedure.
I f the engin e does not start at once, stop
us ing th e starter after 10 secs. wait about
half a m in ute and then try again.
If the engine sti
ll does not start, the electric
fuel pump fuse may have blown -see page
119 .
When the engine
is very hot it may be
neces sary to accelerate slightl y after the
engine has start
ed.
/
36

Downloaded from www.Manualslib.com manuals search engine ___CONTROLS AND EQUIPMENT

Diesel engines
Glow plug system
Ith the 47 and 66 kW Diesel engines. ~fter sw itching to the driving position (igni­on on ), the required glow plug warm-up
• m e is Indicated by a lamp which is con­
:r oll ed by the coolant temperature -see
p ag e 47 .
On he
55 kW Diesel engine the glow pl ug sys tem is automaticall y activated after ~'osing the driver's door. If the engine is not subsequentl y sta rted, the glow plug syst em .111 not be activated by each further opening an closing of the driver's door.
Cold starting aid/idling speed
boost (47 and 55 kW engines only)
-0 facilitate starting from cold, there is a
c old starting device (cold sta rting aid) in the nJec tion pump.
he cold starting device is actuated when "'1e knob on h e left of the steerinq column
s pulle d out fully. ­
fl addition , the idling speed can be in­~reased with the knob to reduce any vehicle
• br ation which may occur .
47 and 55 kW engines
Starting a cold engine
• At ambient temperatures down to -155C, pull the cold start knob out fully before operating the sta rter .
At lower t em pe rature s, the knob should not
be pulle d out until engine is firing reg­ularly -the engine wi ll then start more
readily .
•
Turn the key in the igniti on lock to posi­
tion 2 (see page 35) -the glow plug wa rning
lamp comes on. It goes out when the igni­
t ion tempera ture is reached (see page 47) While the glow plugs are working do not switch on any other heavy cur­rent consumers because this would place an unnecessary load on the battery.
• When the w arning lam p goes out, start
the engine immediatel y
D o not depress the acce lerator while star
t­ing
If the
engine only fire s irregul arly, continue to ope rate the starter a few seconds longer (30 seconds at maximum) until the engine
runs under its own power. If
the eng ine does not start , switch the g
low plugs on again and try starting it again as de­
scr ibed . If th e eng ine still doe s not start the
fuse for the glow plugs may have blown ­
page 120 .
• Push the cold start aid knob
in fully as soon as the engin e has rea ched its norma l
operating te mper ature.
If ve hicle vibrati on then
occurs whe n i dling,
the knob can be pul led out again until the en­
gine runs free of vibration at the lowest
pos sible idling speed
Starting a warm engine
The glow plug lamp does not come on -the engin e can be started straight away. D o not pull the cold s tart aid knob and do not press
the accelerator pedal.
37

Downloaded from www.Manualslib.com manuals search engine CONTROLS AND EQUIPMENT

Stopping engine
66 kW engine
Starting a cold engine
Ambient temperature above +5 0C:

The engine can be started without pre­
glow Do not depress throttle during the

starting procedure.

Ambient temperature below +5 0C:

• Turn the key in the ignition lock to posi­
tion 2 (see page 35) -the glow plug warning
lamp comes on It goes out when the igni­
tion temperature is reached (see page 47). While the glow plugs are working do not switch on any other heavy cur­rent consumers because this would place an unnecessary load on the battery.
• When the warning lamp goes out, start
the engine immediately
If the engine does not start, repeat
preglow and try starting it again as described. If the
engine still does not start the fuse for the glow plugs may have blown -see page 120.
Starting a warm engine
The glow plug lamp does not come on -the
engine can be started straight away
When engine has been running fast for a long time, let it idle for about 2 minutes so that it can cool down slightly before being switched off.
Attention After the engine has been stopped the fan can continue running for a while (up to about 10 minutes) with the ignition switched off. It can also start to run again suddenly after a short time if -the coolant temperature in­creases due to heat build-up
-when engine is hot and the en­gine compartment is heated additionally by strong sun­light.
Special care must therefore be taken when working in the en­gine compartment.
On vehicles with a catalytic con­verter, the ignition must not be switched off as long as the vehicle is rolling with a gear engaged, other­wise, unburnt fuel can pass into the catalytic converter and cause dam­age.
38
