FUSES & CIRCUIT BREAKERS
Fuses & Circuit Breakers 1990-95 Mazda
FUSES & CIRCUIT BREAKERS
FUSE PANEL LOCATION
Fuse box is located above driver's left knee, accessible through a removable cover. The main fuse block is
located at the right rear of the engine compartment.
The Trunk Mounted Fuse Panel is located on the right side of the trunk, near the trunk hinge. (1992-95 Models)
MAIN FUSE BLOCK IDENTIFICATION
Fig. 1: Main Fuse Block Identification

Courtesy of MAZDA MOTOR OF AMERICA, INC.
Fuse & Circuit Breaker Identification
WARNING:Always disconnect battery ground cable before servicing "high-current"
fuses. It is recommended that "high-current" fuses be replaced by a
qualified technician.

1991 Mazda MX-5 Miata
FUSES & CIRCUIT BREAKERS Fuses & Circuit Breakers 1990-95 Mazda

1991 Mazda MX-5 Miata
FUSES & CIRCUIT BREAKERS Fuses & Circuit Breakers 1990-95 Mazda
Microsoft
Sunday, July 05, 2009 2:15:54 PMPage 1 © 2005 Mitchell Repair Information Company, LLC.
Microsoft
Sunday, July 05, 2009 2:15:57 PMPage 1 © 2005 Mitchell Repair Information Company, LLC.

1 - 30 Amp (Pink) Headlights
2 - 30 Amp (Pink) Fuel Injection, Alternator
3 - 80 Amp (Black) Protection Of All Circuits
4 - 40 Amp (Green) Taillights, Shift Lock, Cruise Control, Horn, Stoplights, Hazard Warning Lights,
Interior Lights, Warning Buzzers, Radio/Cassette, Compact Disc Player, Clock
5 - Empty (1990); 60 Amp (Yellow) (1991-94) Anti-Lock Brake System
6 - 30 Amp (Pink) Cooling Fan
7 - 10 Amp (Red) Air Bag
8 - 20 Amp (Yellow) A/C Additional Fan
9 - 10 Amp (Red) Fuel Injection
10 - 30 Amp (Pink) Headlight Retractor
TRUNK MOUNTED FUSE PANEL IDENTIFICATION

1991 Mazda MX-5 Miata
FUSES & CIRCUIT BREAKERS Fuses & Circuit Breakers 1990-95 Mazda
Microsoft
Sunday, July 05, 2009 2:15:54 PMPage 2 © 2005 Mitchell Repair Information Company, LLC.

Fig. 2: Trunk Mounted Fuse Panel Identification (1992-94)
Courtesy of MAZDA MOTOR OF AMERICA, INC.
Fuse & Circuit Breaker Identification
1 - 10 Amp (Red) (1992-94) Rear Defroster
2 - 10 Amp (Red) (1992-94) Power Antenna
INTERIOR FUSE PANEL IDENTIFICATION

1991 Mazda MX-5 Miata
FUSES & CIRCUIT BREAKERS Fuses & Circuit Breakers 1990-95 Mazda
Microsoft
Sunday, July 05, 2009 2:15:54 PMPage 3 © 2005 Mitchell Repair Information Company, LLC.

Fig. 3: Interior Fuse Panel Identification
Courtesy of MAZDA MOTOR OF AMERICA, INC.
Fuse & Circuit Breaker Identification
11 - 15 Amp (Blue) Engine Cooling Fan
12 - 10 Amp (Red) Gauges, Warning Lights, Turn Signal Lights, Cruise Control
13 - 15 Amp (Blue) Air Bag
14 - 30 Amp Heater
15 - Empty
16 - 30 Amp (Green) Power Windows
17 - 20 Amp (Yellow) Wipers, Washers
18 - Empty
19 - 15 Amp (Blue) Taillights
20 - Empty
21 - 15 Amp (Blue) Shift Lock, Cruise Control, Horn, Stoplights
22 - 15 Amp (Blue) Hazard Warning Lights

1991 Mazda MX-5 Miata
FUSES & CIRCUIT BREAKERS Fuses & Circuit Breakers 1990-95 Mazda
Microsoft
Sunday, July 05, 2009 2:15:54 PMPage 4 © 2005 Mitchell Repair Information Company, LLC.

23 - Empty
24 - 10 Amp (Red) Interior Lights, Warning Buzzers, Radio/Cassette, Compact Disc Player, Clock
25 - 15 Amp (Blue) Radio/Cassette, Compact Disc Player, Clock, Cigarette Lighter
26 - Empty
27 - Empty
BATTERY SPECIFICATIONS
Vehicle is equipped with a special 9 9/16" x 4 3/4" x 7 3/8" 12-volt battery that is vented to outside of vehicle.
CAUTIONS & WARNINGS
SUPPLEMENTAL RESTRAINT SYSTEM (AIR BAG)
Modifications or improper maintenance, including incorrect removal and installation of the Supplemental
Restraint System (SRS), can adversely affect system performance. DO NOT cover, obstruct or change the
steering wheel horn pad in any way, as such action could cause improper function of the system. Use only plain
water when cleaning the horn pad. Solvents or cleaners could adversely affect the air bag cover and cause
improper deployment of the system.
AIR CONDITIONING SERVICING CAUTION: When battery is disconnected, vehicles equipped with computers may
lose memory data. When battery power is restored, driveability problems
may exist on some vehicles. These vehicles may require a relearn
procedure. See COMPUTER RELEARN PROCEDURES article in the
GENERAL INFORMATION Section.
NOTE: See the AIR BAGS article in the ACCESSORIES/SAFETY EQUIPMENT Section.
WARNING:To avoid injury from accidental air bag deployment, read and carefully
follow all warnings and service precautions. See appropriate AIR BAGS
article in ACCESSORIES/SAFETY EQUIPMENT.
CAUTION: Disconnect negative battery cable before servicing any air bag system,
steering column or passenger side dash component. After any repair, turn
ignition key to the ON position from passenger's side of vehicle in case of
accidental air bag inflation
CAUTION: Avoid breathing R-134a refrigerant and PAG lubricant vapors, exposure
may irritate eyes, nose and throat. To remove R-134a from system use R-
134a recycling equipment that meets SAE J2210 specifications. If
accidental system discharge occurs, ventilate work area before resuming

1991 Mazda MX-5 Miata
FUSES & CIRCUIT BREAKERS Fuses & Circuit Breakers 1990-95 Mazda
Microsoft
Sunday, July 05, 2009 2:15:54 PMPage 5 © 2005 Mitchell Repair Information Company, LLC.

ANTI-LOCK BRAKE SYSTEM
The anti-lock brake system contains electronic equipment that can be susceptible to interference caused by
improperly installed or high output radio transmitting equipment. Since this interference could cause the
possible loss of the anti-lock braking capability, such equipment should be installed by qualified professionals.
On models equipped with anti-lock brake systems, ALWAYS observe the following cautions:
DO NOT attempt to bleed hydraulic system without first referring to the appropriate ANTI-LOCK
BRAKE SYSTEM article in the BRAKES Section.
DO NOT mix tire sizes. As long as tires remain close to the original diameter, increasing the width is
acceptable. Rolling diameter must be identical for all 4 tires. Some manufacturers recommend tires of the
same brand, style and type. Failure to follow this precaution may cause inaccurate wheel speed readings.
Use ONLY recommended brake fluids. DO NOT use silicone brake fluids in an ABS-equipped vehicle.
BATTERY WARNING
REPLACING BLOWN FUSES
Before replacing a blown fuse, remove ignition key, turn off all lights and accessories to avoid damaging the
electrical system. Be sure to use fuse with the correct indicated amperage rating. The use of an incorrect
amperage rating fuse may result in a dangerous electrical system overload.
BRAKE PAD WEAR INDICATOR
Indicator will cause a squealing or scraping noise, warning that brake pads need replacement.
CATALYTIC CONVERTER
Continued operation of vehicle with a severe malfunction could cause converter to overheat, resulting in
possible damage to converter and vehicle. service.
WARNING:R-134a service equipment or vehicle A/C systems SHOULD NOT be
pressure tested or leak tested with compressed air. Some mixtures of
air/R134a have shown to be combustible at elevated pressures. These
mixtures are dangerous and may cause fire and/or explosions. See AIR
CONDITIONING SERVICE article in GENERAL INFORMATION section.
WARNING:When battery is disconnected, vehicles equipped with computers may
lose memory data. When battery power is restored, driveability problems
may exist on some vehicles. These vehicles may require a relearn
procedure. See COMPUTER RELEARN PROCEDURES article in GENERAL
INFORMATION section.
