Page 1373 of 4087
Crankshaft Thrust clearance STD 0.020±0.220 mm (0.0008±0.0087 in.)
Limit 0.30 mm (0.0118 in.)
Thrust washer thickness 2.440±2.490 mm (0.0961±0.0980 in.)
Main journal bore diameter on cylinder block 67.026±67.033 mm (2.8388±2.6391 in.)
(with main bearing)
Main journal oil clearance
STD
0.026±0.045 mm (0.0010±0.0018 in.) Limit 0.055 mm (0.0022 in.) Main journal diameter 66.988±67.000 mm (2.6373±2.6378 in.) \
\
Main bearing center wall thickness (Reference)
Mark 1 2.486±2.489 mm (0.0979±0.0980 in.) Mark 2 2.489±2.492 mm (0.0980±0.0981 in.) Mark 3 2.492±2.495 mm (0.0981±0.0982 in.) Mark 4 2.495±2.498 mm (0.0982±0.0983 in.)
Mark 5 2.498±2.501 mm (0.0983±0.0985 in.)
Crank pin diameter 51.982±52.000 mm (2.0465±2.0472 in.)
Circle runout Limit 0.08mm (0.0031 in.)
Main journal taper and out±of±round Limit 0.02mm (0.0008 in.)
Crank pin taper and out±of±round Limit 0.02mm (0.0008.in)
EGOC6±0C
TORQUE SPECIFICATION
Part tightened NVm kgf Vcm ft Vlbf
No.1 idler pulley x Cylinder Block 34 350 25
No.2 idler pulley x Cylinder block3435025
Hydraulic pump x Cylinder block for 12 mm head 16 160 12
yy
for 14 mm head3031022 Crankshaft pulley x Crankshaft 245 2,500 181 Camshaft timing pulley x Camshaft 108 1,100 80 Timing belt tensioner x Oil pump 26 270 20 Spark plug x Cylinder head 18 180 13
Drive belt tensioner x Cylinder block 16 160 12
Generator x Generator bracket 37 380 27
Generator x Cylinder block3738027
Distributor housing x Cylinder head1818513
Distributor rotor x Camshaft timing pulley3.83934 in. lbf
Distributor cap x Distributor housing3.83934 in. lbf
RH No.2 timing belt cover x Cylinder blockfor 12 mm head1818513
Drive belt idler pulley x Fan bracket3738027
A/C compressor x Cylinder block4950036 A/C compressor x Fan bracket 49 500 36 A/C compressor stay x Oil filter bracket 29 300 22 Upper radiator support x Body 12 120 9 Exhaust manifold x Cylinder head 44 450 33
Cylinder head x Cylinder block 1st 39 400 29
2nd Turn 90 5
Camshaft bearing cap x Cylinder head 16 160 12
Cylinder head cover x Cylinder head 5.9 60 52 in.Vlbf
Engine hanger x Cylinder head3738027 EGR pipe x RH exhaust pipe 18 185 13 Rear water bypass joint x Cylinder head 18 185 13
±
1UZ ± FE ENGINE ENGINE MECHANICALEG±209
WhereEverybodyKnowsYourName
Page 1385 of 4087
TUNE±UP
EG10Z±05
ENGINE COOLANT INSPECTION
1. CHECK ENGINE COOLANT LEVEL AT RESERVOIR TANK
The coolant level should be above the ªCOLD LEVELº at nor-
mal temperature (20 5C (68 5F)).
If low, check for leaks and add coolant up to the ªCOLD LEV-
ELº
2. CHECK ENGINE COOLANT QUALITY
(a) Remove the radiator cap from the reservoir tank.
CAUTION: To avoid the danger of being burned, do not remove
it while the engine and radiator are still hot as fluid and steam
can be blown out under pressure
(b) There should not be any excessive deposits of rust or scale around the radiator cap or reservoir tank filler hole, and the
coolant should be free from oil.
If excessively dirty, clean the coolant passages and replace
the coolant.
Capacity (w/ Heater):
10.8 liters (11.4 US qts, 9.5 lmp. qts)
HINT:
wUse a good brand of ethylene±glycol base coolant and
mix it according to the manufacturer's directions.
w Using coolant which includes more than 50%
ethylene±glycol(but not more than 70%) is
recommended.
NOTICE:
w Do not use a alcohol type coolant.
w The coolant should be mixed with demineralized water or
distilled water.
(c) Reinstall the radiator cap.
±
1UZ±FE ENGINE ENGINE MECHANICALEG±9
WhereEverybodyKnowsYourName
Page 1422 of 4087
EG21P±02
TIMING BELT REMOVAL
(See Components for Removal and Installation)
1. REMOVE BATTERY CAUTION: Work must be started after 90 seconds from
the time the ignition switch is turned to the ªLOCKº posi-
tion and the negative (±) terminal cable is disconnected
from the battery.
2. REMOVE ENGINE UNDER COVER
3. DRAIN ENGINE COOLANT
4. REMOVE DRIVE BELT
Loosen the drive belt tension by turning the drive belt tension-
er counterclockwise, and remove the drive belt.
HINT: The pulley bolt for the drive belt tensioner has a left±
hand thread.
5. REMOVE RADIATOR RESERVOIR TANK
(a) Disconnect the coolant level sensor connector.
(b) Disconnect the following hoses: (1) Reservoir hose from water inlet housing
(2) Reservoir hose from radiator
(c) Remove the 2 bolts and reservoir tank bracket.
(d) Remove the bolt holding the reservoir tank to the radiator.
(e) Disconnect the reservoir tank from the reservoir tank bracket,
and remove the reservoir tank.
6. REMOVE RADIATOR ASSEMBLY
(a) Disconnect the ECT sensor connector (for cooling fan).
(b) Disconnect the ECT sensor wire clamp from the radiator fan shroud.
EG±46
±
1UZ±FE ENGINE ENGINE MECHANICAL
WhereEverybodyKnowsYourName
Page 1423 of 4087
(c) Disconnect the following hoses:(1) 2 oil cooler hoses (for cooling fan) from pipes
(2) 2 radiator hoses
(3) 2 oil cooler hoses (for transmission) from radiator
HINT: Plug the hose ends.
(4) Suction hose from hydraulic pump
(5) Pressure hose from hydraulic pump
(d) Remove the 2 bolts, screw and upper radiator support. Remove the 2 upper radiator supports.
±
1UZ±FE ENGINE ENGINE MECHANICALEG±47
WhereEverybodyKnowsYourName
Page 1424 of 4087
(e) Slightly lift the radiator, and disconnect the 2 oil cooler hoses(for cooling fan) from the hose clamp on the radiator fan
shroud.
(f) Remove the radiator assembly.
(g) Remove the 2 lower radiator supports from the radiator.
7. DISCONNECT AIR CONDITIONING (A/C) COMPRESSOR
FROM ENGINE
(a) Disconnect the A/C compressor connector.
(b) Remove the nut, and disconnect the ground cable from the
A/C compressor stay.
(c) Remove the bolt and A/C compressor stay.
(d) Remove the 2 bolts, and disconnect the A/C compressor from the engine.
HINT: Put aside the A/C compressor, and suspend it.
8. REMOVE INTAKE AIR CONNECTOR
(a) Disconnect the following hoses: (1) Air hose from IAC valve
(2) Air hose (from air control valve on PS pump) from intake
air connector
(b) Remove the bolt holding the intake air connector to the cylinder head cover.
(c) Loosen the 2 hose clamps.
(d) Disconnect the intake air connector from the throttle body
and air cleaner hose, and remove the intake air connector.
EG±48
±
1UZ±FE ENGINE ENGINE MECHANICAL
WhereEverybodyKnowsYourName
Page 1446 of 4087
37. INSTALL AIR CONDITIONING (A/C) COMPRESSOR
(a) Install the A/C compressor, compressor stay and groundcable with the nut and 3 bolts.
Torque:
49 NVm (500 kgf Vcm, 36 ft Vlbf) for bolt
29 N Vm (300 kgf Vcm, 22 ft Vlbf) for nut
(b) Connect the A/C compressor connector.
38. INSTALL RADIATOR ASSEMBLY
(a) Install the 2 lower radiator supports to the radiator.
(b) Place the radiator assembly on the body bracket.
(c) Slightly lift the radiator, and connect the 2 oil cooler hoses (for
cooling fan) to the hose clamp on the radiator fan shroud.
(d) Install the upper radiator support with the 2 bolts and screw. Install the 2 upper radiator supports.
Torque: 12 N Vm (120 kgf Vcm, 9 ft Vlbf)
EG±70±
1UZ±FE ENGINE ENGINE MECHANICAL
WhereEverybodyKnowsYourName
Page 1447 of 4087
(e) Connect the following hoses:(1) 2 oil cooler hoses (for cooling fan) to pipes
(2) 2 radiator hoses
(3) 2 oil cooler hoses (for transmission) to radiator
(4) Suction hose to hydraulic pump
(5) Pressure hose to hydraulic pump
(f) Connect the ECT sensor connector (for cooling fan).
(g) Install the ECT sensor wire clamp to the radiator fan shroud.
±
1UZ±FE ENGINE ENGINE MECHANICALEG±71
WhereEverybodyKnowsYourName
Page 1448 of 4087
39. INSTALL RADIATOR RESERVOIR TANK
(a) Install the reservoir tank to the reservoir tank bracket.
(b) Install the reservoir tank with the bracket and 3 bolts.
Torque: 4.9 NVm (50 kgf Vcm, 43 in. Vlbf)
(c) Connect the following hoses:
(1) Reservoir hose to water inlet housing
(2) Reservoir hose to radiator
(d) Connect the coolant level sensor connector.
40. INSTALL DRIVE BELT Install the drive belt by turning the drive belt tensioner coun-
terclockwise.
HINT: The pulley bolt for the dive belt tensioner has a left
hand thread.
41. INSTALL BATTERY
42. FILL WITH ENGINE COOLANT
43. START ENGINE AND CHECK FOR LEAKS
44. CHECK TRANSMISSION FLUID LEVEL
45. INSTALL ENGINE UNDER COVER
EG±72
±
1UZ±FE ENGINE ENGINE MECHANICAL
