TORQUE SPECIFICATIONS
Part tightenedNVmkgf Vcmft Vlbf
Engine drain plug X Cylinder block1818013
Coolant filler plug X Water inlet housing44450 33
Water pump X Cylinder block18185 13
Water inlet housing X Water pump18185 13
Water inlet X Water inlet housing18185 13
Radiator fan shroud X Radiator4.950 43 in. Vlbf
Radiator X Body12120 9
Cooling fan reservoir tank X Radiator fan shroud4.950 43 in. Vlbf
Cooling fan inlet pipe X Radiator fan shroud4.950 43 in. Vlbf
Cooling fan pressure hose X Hydraulic motor64650 47
Radiator reservoir tank X Upper radiator support4.950 43 in. Vlbf
Radiator reservoir tank X Radiator reservoir tank support4.950 43 in. Vlbf
Hydraulic pump rear housing X End plug (for spool valve)19200 14
Hydraulic pump front housing X Rear housing21210 15
Hydraulic pump pulley X Drive shaft59600 43
Solenoid valve X Hydraulic pump rear housing39400 28
Hydraulic pump suction port union X Rear housing13135 10
Hydraulic pump X Cylinder block 12 mm head 16 160 12
14 mm head 20 310 22
\
\
Cooling fan pressure hose X Hydraulic pump 64 650 47
\
\
RH No.2 timing belt cover X Cylinder block 16 160 12
\
\
Drive belt idler pulley X Hydraulic pump 37 380 27
\
\
A/C compressor X Hydraulic pump 49 500 36
\
\
A/C compressor X Cylinder block 49 500 36\
\
A/C compressor stay X Oil filter bracket 29 300 22\
\
Hydraulic motor cover X Motor housing 28 290 21\
\
\
Hydraulic motor X Radiator fan shroud
4.9
50
43 in.
Vlbf
\
\
Cooling fan X Hydraulic motor 15 150 11
\
\
Cooling fan oil cooler X Body 18 180 13
\
\
Water temperature sensor X Radiator 7.4 75 65 in. Vlbf
±
COOLIING SYSTEM Service SpecificationsCO±65
