35-130 SERVICE BRAKES - Wheel Speed Sensor
Left side viewRight side
U 14AOO45
Left side view Left side
lo. INSTALLATION OF REAR SPEED SENSOR
(1) Temporarily install the speed sensor to the rear axle
spindle.
Caution Be careful when handling the pole piece at the tip of
the speed sensor and the toothed edge of the rotor so as not to damage them by striking against metal
objects.
(2) Note the following points when connecting the speed
sensor cable, and secure the cable by the clip.
0 Secure the clip so that the white-painted part
(shaded in the illustration) of the speed sensor
cable is not twisted.
0 Be sure that there is space (where shown in the illustration) so that the trailing arm and speed
sensor cable do not contact, and then secure by
the clip.
Caution
Because there is the
possibiliti of damage to the
cable during driving if the speed sensor cable and
the trailing arm come into contact, or if the speed sensor cable is twisted, care must be taken regard-
ing this point.
(3)
Inset-t a feeler gauge into the space between the
speed sensor’s pole piece and the rotor’s toothed
surface, and then tighten the speed sensors at the position where the clearance is the standard value.
Standard value:
0.3-0.9 mm (.012--035 in.)
NOTE
Check to be sure that there is no contact of the speed
sensor’s pole piece and the rotor’s toothed surface
when the rear hub assemlby is slowly rotated one
time.
If there is contact, it is probable that the rotor or the
rear hub is installed incorrectly, recheck installation.
10. INSTALLATION OF REAR SPEED SENSOR
Install the rear speed sensors as shown in the illustration.
Cross-section A-A
TSB Revision
Parkingcable
’ 2Rear speed
sensor1240076
Cross-section B-B Cross-section C-C
Rear speedsensor

SERVICE BRAKES - Wheel Speed Sensor 35-131
0% 8
0 00
PT
00
6A
5. INSTALLATION OF FRONT SPEED SENSOR BRACKET
Assemble the speed sensor and the speed sensor brack-
et.
NOTE
(1) The shape is different for the left and right speed sensor brackets. Each bracket has an identification
symbol, so be sure to note these symbols and install
correctly.
FR: Indicates that the bracket is for the front speed sensor.
R: Indicates that the bracket is for the right wheel.
L: Indicates that the bracket is for the left wheel.
(2) Check to be sure, when installing the speed sensor to the bracket, that the letters “FR” are visible.
4. INSTALLATION OF FRONT SPEED SENSOR (1) Temporarily install the speed sensor to the knuckle.
Caution
Be careful when handling the pole piece at the tip of
the speed sensor and the toothed edge of the rotor so as not to damage them by striking against other
parts.
Cross-section A-A
(2) Note the following points when connecting the speed sensor cable, and secure the cable by the clip.
0Secure the cable by the clip so that the whitepaint-
ed parts of the blackened parts (in the illustration)
of the speed sensor cable are within the range of
the angles indicated by cross-section A-A and cross-section B-B in the illustration.
0 Check to be sure that the white-painted part
(shaded in the illustration) of the speed sensor
cable is not twisted.
I14L0079Caution
Because there is the possibilii~of damage to the
cable during driving if the speed sensor cable is
twisted, care must be taken regarding this point.Cross-section B-B 14Ro157
(3)
Insert
a feeler gauge into the space between the
speed sensor’s pole piece and the rotor’s toothed
surface, and then tighten the speed sensor at the
position where the clearance is the standard value all
around.
Standard value:
0.3-0.9 mm (.012-.035
in.)
NOTE
If the clearance between the speed sensor’s pole piece
ant\
the rotor’s toothed surtace
is not within the standard
value
range, it is probable

that the rotor
is
incorrect\Y
.insta\\ed,
recheck insta\iation-

SERVICE BRAKES - G-Sensor
G-SENSOR
REMOVAL AND INSTALLATION
Pre-removal and Post-installation Op
*Removal and Installation of Floor
Con-
(Refer to GROUP
52-Floor Console.)l Removal and Installation of Trunk
<1991,1992 models>
g-14 Nm
M35OVAA

9-14 Nm
G-sensor (front) removal steps
1. Wiring harness connector
2. G-sensor (front)
3. G-sensor bracket
G-sensor (rear) removal steps
4. Wiring harness connector
5. G-sensor cover
6. G-sensor (rear)
7. G-sensor bracket
NOTEThe * symbol indicates with automatic transaxle.
INSPECTION
(1) Place the sensor on a level surface, then check that there
is conductance between the terminals.
1 TSB Revision

SERV,CE BRAKES _ G-Sensor- models>35433
14AOlss
14AOlBB
(2) Slowly inclining the G-sensor in the direction of forward
vehicle travel, check that there is no conductance above a
sensor angle of 30 degrees.
(3) Slowly inclining the G-sensor in the direction of reverse
vehicle travel, check that there is no conductance above a sensor angle of 30 degrees.
BRAKE FLUID PRESSURE SWITCH 4WD-A,.B.S.: Up to 1991 models>
REMOVAL AND INSTALLATION
Pre-removal Operationl Draining of Brake Fluid
(Refer
to P.35-57.)
Removal steps
1. W
iring harness connector
2. Brake tubes connection
3. Brake fluid pressure switch TSB
Revision I

ALPHABETICAL INDEX1
A
ABS
Checking by the ABS Warnrng Light................
. 35-68-l
Troubleshooting ...........................
35-l 5-l
ABS POWER RELAY, Chec
k 35-74-l
ACCELERATOR CABLE
Inspection and Adjustment
13-398-l
Inspection and Adjustment ........ 13-329-l
ACCELERATOR SWITCH, Inspection and Adjustment 13-329-I
A/C COMPRESSOR CLUTCH RELAY
On-vehicle Inspection
.............
. 13-285-l
On-vehrcle
Inspection
.........
. 13-83-t
On-vehicle Inspection
......
. 13-176-l
ACTIVE-ECS ON-BOARD DIAGNOSTIC, Check......

. 338-88-I
ACTIVE-ECS RELAY.......................

. 338-141
-I
ACTIVE-ECS SENSOR....

.
...... ............ 338-138-I
ACTIVE-ECS SYSTEM
Checking by Using Alarm Light
.................
. 338-87-I
Operation Check ........................... 338-90-I
AERO PARTS..

.
........................... 51-18-l
AIR CLEANER...............................

. 15-9-I
AIR CLEANER ELEMENT
Inspection and Replacement
....................
. 15-6-l
Maintenance .......................... 00-39-l
AIR COMPRESSOR..........................

. 338-125-I
AIR CONDITIONING SWITCH
Emission control
...........................
.
17-21 -I
Heater, Air
Conditionrng
and Ventilation .............. 55-29-l
On-vehicle Inspection ................. 13-285-l
On-vehicle Inspection
...........
. 13-83-l
On-vehicle Inspection

..........
. 13-176-l
AIR TUBE..............

.
....................... 338-133-I
ALARM LIGHT, Check. ......................... 338-87-I
ALARM SYSTEM, Theft ..........................
54-165-11
ALIGNMENT
Front Wheel, Adjustment .......................
. 33A-5-l
Rear
Wheel, inspection ..................
. 34-23-l
Rear Wheel, Inspection
....................
. 34-5-l
ANTENNA ......................................
54-153-11
ANTI-LOCK BRAKING SYSTEM, Troubleshooting .........
.
35-15-1
ARM
Lower
......................
. 338-103-I
Lower Suspension>......................
.
33A-10-I
Lower
................... 34-28-l
Torsion
................
.
338-l 19-l
Torsion Suspension-FWD>
...................34-l 5-lTrailing
................. 34-31-l
Upper
.................. 34-28-l
AUDIO
SYSTEM................

.
.................
54-l 12-11
AUTO-CRUISE CONTROL. ..........................
. 13-408-I
AUTO-CRUISE CONTROL INDIVIDUAL PARTS, inspection..

. 13-401-I
AUTO-CRUISE CONTROL SYSTEM...................

. 13-332-l
AUTO-CRUISE CONTROL SYSTEM, Inspection..........

. 13-397-l
AUTOMATIC TRANSAXLE, Maintenance ................. 00-43-I
AXLE
Rear, Maintenance
...............................
. 00-45-I
Torsion
........................
.
338-l 19-l
Torsion .....

.
......................... 34-15-l
AXLE HUB
Rear
Disc Brakes> ...................... 27-8-l
Rear CFWD-Rear
Drum Brakes> ................... 27-6-l
AXLE SHAFT ..............................

.
27-17-1
B
BACKLASH. Total, Rear Axle, Check ............
. 27-15-l
BALL JOINT
Rotation Starting Torque Check ...................... 378-8-I
Tie Rod End, Staning Torque Check .................. 37A-15-l
Tie Rod End, Variation Check ....................... 37A-15-l
BALL JOINT SEALS, Maintenance ..................... 00-45-I
BAR
Stabilizer ....................

. 338-106-I
Stabilizer
...................
. 33A-13-l
Stabilizer Suspension-AWD>...............
. 34-37-l
BAROMETRIC PRESSURE SENSOR
On-vehicle Inspection
................
. 13-266-l
On-vehicle Inspection
13-53-l
On-vehicle Inspection
..........
. 13-154-l
BASIC IDLE SPEED
Adjustment
...........................
. 13-245-l
Adjustment
..................... 13-33-l
Adjustment
...................
. 13-133-l
BATTERY.........................................

.
54-2-11
BATTERY, Flat Remedy.
.............................
. 35-75-l
BEARING
Wheel, Adjustment ................

. 338-87-I
Wheel, Adjustment ............. 33A-5-l
BELT
Drive, Compressor, Adjustment
....................
. 55-17-l
Drive (For Water Pump and Generator), Maintenance ..... 00-41-I
Drive, Tension Adjustment ................. 11-61-I
Drive, Tension Adjustment ................. 11-12-l
Seat..........................................

. 52-39-l
Timing ...................... ......... 11-80-I
Timing................................

. 11-34-l
Timing, Maintenance ............................... 00-40-I
Timing, Tension Adjustment ................ 11-10-I
BLEEDING
Clutch
..........................................
. 21-6-l
4ws...........................................

. 370-4-I
Service Brakes. .................................. 35-57-l
Steering ........................................ 37A-22-l
BLOWER..........................................

. 55-32-l
BOOSTER
Brake
.........................................
. 35-85-l
Brake, Operating Inspection ......................... 35-54-l
BOOST METER, On-vehicle Inspection ... 13-311-l
BOOTS, Drive Shaft, Maintenance ....................... 00-45-I
BRAKE
Disc, Front
......................................
. 35-94-l
Disc, Rear.....................................

.
35-l 14-l
BRAKE BOOSTER
...................................
. 35-85-l
BRAKE BOOSTER, Operating Inspection .................. 35-54-l
BRAKE DISC
Front, Run-out Check.
.............................
. 35-63-l
Front, Run-out Correction ........................... 35-64-l
Front, Thickness Check ............................. 35-65-l
Rear, Run-out Check ............................... 35-66-l
Rear, Run-out Correction. ........................... 35-66-l
Rear, Thickness Check............................

. 35-66-l
BRAKE DRUM, tnside
Diameter, Check ................... 35-67-l
BRAKE FLUID LEVEL SENSOR, Check...................

. 35-54-l
BRAKE FLUID PRESSURE SWITCH
AWD-ABS (Up to 1991 Models)
....................
.
35-133-l
AWD-ABS
(Up to 1991 models), Check ...............
. 35-75-l
BRAKE HOSES, Maintenance ........................... 06-45-t
BRAKELINE
........................................
35-87-l

2ALPHABETICAL INDEX
BRAKE LINING ThicknessCheck

.., ..,............
Drum, Rear, Maintenanc
e
BRAKE LINING AND BRAKE DRUM, Connection Check..
BRAKE PAD
Drsc, Front, Check and Replacemen
t
Disc, Rear, Check and Replacement BRAKEPEDAL..
BRAKE PEDAL, Inspection and Adjustment
BUMPER..... 35-67-l
00-44-l
35-67-l
35-59-l
35-65-l
35-76-l
35-53-l
51-7-I
C
CABLEAccelerator, Inspection and Adjustment
13-398-l
Accelerator, Inspection and Adjustment Control> 13-329-I
High
Tensron, Spark Test ........
.
16-42-11Parking Brake................................

.
36-5-l
Spark
Plug, Tes
t
........................
16-42-11Speedometer, Replacement ...............
.
23-93-l
Speedometer, Replacement
.........
.
22-19-I
Speedometer, Replacement
............
.
22-5-l
CAMSHAFTDOH

C
...................
1 l-68-lSOHC.................................

.
11-19-I
CAMSHAFT OIL SEALS
DOHC
...................................
.
11-68-I
SOHC........................................

.
11-19-I
CAMSHAFT POSITION SENSOR
On-vehrcle Inspection
..................
.
13-277-l
On-vehicle Inspection
............
.
13-69-l
On-vehicle Inspection
........
.
13-165-I
CANISTER,
Evaporatjve Emission.................

.
17-21-l
CATALYTIC CONVERTER............................

.
17-24-l
CENTERMEMBER...................

.
....... 32-8-l
CENTRAL DOOR LOCKING SYSTEM..................

.
42-101-I
CHARGE AIR COOLER...............................

.
15-l

2-l
CHARGING..................
.
..... 55-17-I
CHARGING SYSTEM....................

.
...........
16-2-11CHARGING SYSTEM, Inspection.......................
.
16-5-11CHECK VALVE, Operation Check......................

.
35-54-l
CIGARETTE LIGHTER..........................

.
54-106-11
CLOCK........................................
.
54-109-11CLOSED THROTTLE POSITION SWITCHAdjustment GVALVE>
.................. 13-136-I
Frxed SAS, Adjustment
..................
.
13-250-I
On-vehicle inspection .................. 13-274-l
On-vehicle Inspection
............
.
13-61-I
On-vehicle Inspection

.........
. 13-160-I
CLUTCH CONTROL.................................

.
21-10-I
CLUTCH MASTER CYLINDER.........................

.
21-12-l
CLUTCH PEDAL.....................................

.
21-7-l
CLUTCH PEDAL, Inspection and Adjustment ................
21-5-1CLUTCH RELAY, A/C Compressor, On-vehicle Inspection
>
....................................... 13-285-l
CLUTCH RELEASE CYLINDER.........................
21-13-lCOIL
Ignition, On-vehicle
Inspectron 13-302-I
Ignition, On-vehicle
InspectIon
......
. 13-96-l
Ignition. On-vehicle Inspection
13-186-l
COLUMN SWITCH............................

.
54-100-11COMBINATION LIGHT, Rear.
.........................
.
54-95-11COMPRESSION PRESSURE
Check
...............................
.
1
i-59-1Check
..................................
11-8-l
COMPRESSOR...................................
.
55-38-l
COMPRESSOR, Air.......

.
........................ 338-125-I
COMPRESSOR DRIVE BELT, Adjustment, ................. 55-17-l
COMPRESSOR NOISE, Adjustment ...................... 55-23-l
CONDENSER, ............ .......................... 55-48-l
CONDENSER FAN MOTOR...........................

.
55-48-l
CONSOLE, Floor....................................

.
52-29-l
CONTROL
Engine
........................................
.
13-328-l
Transaxle ............................... 23-94-l
Transaxle
..........................
.
22-19-I
Transaxle
...........................
.
22-6-l
CONTROL SYSTEM
Evaporative Emission
.............................
.
17-15-l
Intake Charge Pressure, Inspection.
....................
15-7-lMixture (MFI
)
.............................. 17-29-l
Purge, Inspection .................... 17-17-l
Purge, Inspection ....................... 17-18-l
CONTROL UNIT
ABS
........................................
.
35-134-l
Active-ECS ................................... 338-140-I
EPS.....................................

.
...37A-59-lCONTROL VALVE <4WS>..........................

.
378-12-I
COOLANT
Engine, Concentration Test ..........................
14-8-lEngine, Leak Check ................................
.
14-8-l
Engine, Maintenance. ............................ 00-44-I
Engine, Replacement ...........
................... 14-8-lCRANKCASE VENTILATION SYSTEM, inspection..........

.
17-14-l
CRANKSHAFT POSITION SENSOR
On-vehicle Inspection
..................
.
13-280-I
On-vehicle Inspection
............
.
13-73-l
On-vehicle Inspection
13-167-l
CROSSMEMBER....................................

.
32-8-l
CURB IDLE SPEED
Inspection
.......
.
.................... 13-245-l
Inspection
13-32-l
Inspection
....................
.
13-133-l
CYLINDER
Master
.........................................
.
35-81 -IPower
.........................................
.
378-9-I
Wheel,RearBrake...............................

. 35-111-l
Wheel, Rear, Maintenance .......................... 00-44-I
CYLINDER HEAD GASKET
DOHC
.......................................
.
11-73-l
SOHC.................: ......................... 11-25-l
D
DASH POT, Inspection and Adjustment
1 l-58-lDEFOGGER, Rear Window 64-156-11
DEFOGGER RELA
Y
.54-163-11DEFOGGER SWITCH, Rear Window. 54-163-11
DEFOGGER TIMER 54-164-11
DELAY VALVE, Check
35-74-l
DIAPHRAGM, Rolling, Check 33B-89-l
DIFFERENTIAL CARRIER
27-26-l
DISC
Brake, Front, Run-out Check
35-63-l
Brake, Front, Run-out Correction 35-64-l
Brake, Front.
Thichness Check 35-65-l
Brake, Rear, Run-out Check 35-66-l
Brake, Rear, Run-out Correction 35-66-l
Brake, Rear,
Thichness Chec
k
35-66-l

ALPHABETICAL INDEX3
DISC BRAKEFront
......................................
.
35-94-I
Rear......................................

.
35-114-l
DlSC BRAKE PADS. Marntenance.......................

.
00-44-j
DWHARGlNG
SYSTEM ......................... 55-26-l
DISJRIBUTOR..............................

.
16-55-11
DOoR
........................................
42-74-lDOOR. Fit Adjustment
..............................
. 42-51-l
DOOR DRIP LINE WEATHERSTRIP
Front.......

.
........................... 42-112-j
Rear.....................................

.
42-114-IDOOR GLASS
Adjustment
...............................
42-52-f
Front..................................
.
42-80-l
Rear ........... 42-83-I
DOOR HANDLE
Front
...........
.
........ ............ 42-96-l
Rear.
.................. ................. 42-99-l
DOOR INSIDE HANDLE, Play Check.....................

.
42-52-l
DOOR LATCH
Front
.........
.
............... ........ 42-96-l
Rear.................................

. 42-99-l
DOOR MIRROR...............................

.
51-33-1
DOOR
MOULDING
Front
....................................
.
42-112-l
Rear......................................

.
42-114-l
DOOR REGULATOR
Front
......................................
.
42-80-I
Rear...............

.
.................... 42-83-l
DOOR RUNCHANNEL..........................

.
42-l 10-l
DOOR TRIM
Front
......................................
.
42-76-l
Rear.......................................

.
42-78-i
DOOR WATERPROOF FILM
Fron

t
.................................... 42-76-l
Rear........................................

.
42-78-l
DRIVE BELT
Compressor, Adjustment
....................
.
55-17-l
Tension Adjustment ..................... 11-61-l
Tension Adjustment ...................... 11-12-I
Water Pump and Generator, Maintenance ..............
00-41 -IDRIVE SHAFTFront Axle
.....................................
. 26-12-l
Rear
Axle

............................
. 27-20-I
DRIVE SHAFT BOOTS, Maintenance....................

.
00-45-j
DRIVE SHAFT OIL SEALSReplacement
...........................
.
23-92-I
Replacement
.......................
.
22-18-l
Replacement
........................
.
22-4-l
DRUMBrake, inside Diameter, Check
......................
.
35-67-j
Brake,
Rear..............................
.
..... 35-108-l
DRUM BRAKE, Rear
................................
.
35-108-1
DRUM BRAKE LININGS, Rear, Maintenance
..............
.
06-44-j
DRYER........................................

.
33B-127-l
E
EGR SOLENOID Emission Control
.................................
.
17-28-j
On-vehicle
Inspection ................. 13-307-j
On-vehicle
Inspection

..I........
.
13-101-t
On-vehicle
Inspection

..........
.
13-191-l
EGR SYSTEM

speccon
..........................
.
17-25-j inspection

...........................
.
17-25-1
EGR TEMPERATURE SENSOR
Emission Control
................................
.
17-28-l
On-vehicle Inspection .................. 13-288-l
On-vehicle Inspection

13-85-l
On-vehicle
Inspection
..........
.
13-177-l
EGRVALVE........................................

.
17-27-f
EGR VALVE CONTROL VACUUM
.......................
.
17-26-l
ELECTRONIC CONTROL UNIT
35-134-jELEMENT
Air Cleaner. Inspection
and Replacement ................ 15-6-l
Air Cleaner, Maintenance ........................... go-39-j
END PLAY
Hub.
Inspection
................
.
33B-86-l
Hub. Inspection
...................
.
26-5-l
Rear. Wheel Bearing, Adjustment
...........
.
27-3-l
Rear Wheel Bearing. Check
...............
.
27-15-i
ENGINE
DOHC
.......................................
.
11-63-l
SOHC.......................................

.
11-14-1
ENGINE CONTROL................................

.
13-328-l
ENGINE CONTROL MODULE POWER GROUND
On-vehicle Inspectron
..................
.
13-257-l
On-vehicle Inspection
............
.
13-45-l
On-vehicle Inspection
..........
.
13-146-1
ENGINE CONTROL MODULE TERMINAL VOLTAGE
On-vehicle Inspection ..................
.
13-315-I
On-vehicle Inspection
........... 13-105-I
On-vehicle Inspection

..........
.
13-192-l
ENGINE COOLANT
Concentration Test
....
.
............................
14-8-l LeakCheck
....................................... 14-8-l
Maintenance ..................................... 00-44-I
Replacement ..............................
,......
.
14-8-I
ENGINE COOLANT TEMPERATURE GAUGE UNIT.........

. 14-31-l
ENGINE COOLANT TEMPERATURE SENSOR
Cooling
........................................
. 14-31-I
Emission Control .................................. 17-21-l
On-vehicle Inspection ................... 13-268-l
On-vehicle Inspection
............
.
13-55-j
On-vehicle Inspection
..........
.
13-155-l
ENGINE COOLANT TEMPERATURE SWITCH
Cooling........................................
. 14-31-I
Heater, Air Conditioning and Ventilation ......... 55-57-l
ENGINE MOUNTING..................................

.
32-4-l
ENGINE OILCheck
................................
.
11-57-j
Check.................................

. 11-7-l
Maintenance .....................................
00-41-1
ENGINE OIL FILTER, Maintenance ......................
.
60-41-j
ENGINE RPLL
STOPPER..............................
.
32-6-j
EPS CONTROL UNIT................................

.
37A-59-l
EPS MODE SELECTOR SWITCH.......................

.
37A-59-j
EpS SOLENOID, Check
..............................
.
37A-19-j
EVAPORATIVE EMISSION CANISTER...................

.
77-21-j
EVAPORATIVE EMISSION CONTROL SYSTEM............

.
17-15-l
EVAPORATIVE EMISSION PURGE SOLENOIDEmission Control
.................................
.
17-21-1
On-vehicle
Inspection ..................
, 13-307-I
On-vehicle
Inspection

............
.
13-99-1
On-v&i&
inspection

........... 13-189-j
EVAPORATOR....

.
................................ 55-34-f
EXHAUST GAS RECIRCULATION (EGR) SYSTEM..........

.
17-22-I
EXHAUST MANIFOLD
DOHC-Non-Turbo................................
.
15-30-1

4ALPHABETICAL INDEX
DOHC-Turbo.................................
. 15-31-f
SOHC-8VALVE..................................

.
15-27-t
SOHC-1 GVALVE............................

.
15-28-l
EXHAUST PIPEDOH

C
......................... 15-33-I
SOHC.....................................

.
15-32-l
EXHAUST SYSTEM, Maintenance ..................... 00-45-I
F
FAN MOTOR
Condenser
.............................
.
55-48-l
Radiator...................

.
......... 14-12-I
FEEDER CABLE ..........................
54-l 55-11FENDER................................
.
42-61-t
FILLER DOOR, Fuel Tank.........................

.
42-60-I
FILLER TUBE CAP, Fuel Tank, Inspection...............

.
17-21 -I
FILTER
Engine 011. Maintenance ....................
. 00-41-I
Fuel ........................... 13-327-l
Fuel
....
.
...................
13-I 15-lFuel ........................
.
13-195
FITTINGS, Handling................................
. 55-22-l
FIXED SAS
Adjustment
........................
.
13-250-I
Adjustment
...................
.
13-138-I
FLAT BATTERY, Remedy............................

.
35-75-l
FLOOR CONSOLE................................

.
52-29-l
FLUID
Power Steering, Level Check
...................
. 37A-21-l
Power Steering, Replacement ................. 37A-21-l
Transaxle, Replacement ..................... 23-82-l
FLUID LEVEL, Transaxle, Inspection .................. 23-82-l
FOG LIGHT................

.
......................
54-94-11FOG LIGHT SWITCH................................
.
54-99-114WS, Function Check
..........................
. 37B-6-l
FRONT BRAKE DISC
Run-out Check
...................................
. 35-63-I
Run-out Correction ........................... 35-64-l
Thickness Check .............................. 35-65-l
FRONT DISC BRAKE.................................

. 35-94-l
FRONT DISC BRAKE PAD, Check and Replacement ......... 35-59-l
FRONT DOOR DRIP LINE WEATHERSTRIP 42-112-I
FRONT DOOR GLASS...............................

. 42-80-l
FRONT DOOR HANDLE.........................

. 42-96-l
FRONT DOOR LATCH...

.
......... .......... 42-96-l
FRONT DOOR
MOULDING
........................... 42-112-I
FRONT DOOR REGULATOR........................

. 42-80-I
FRONT DOOR TRIM.................................

. 42-76-l
FRONT DOOR WATERPROOF FILM....................

. 42-76-l
FRONT GRILLE..................................

. 51-12-l
FRONT SEAT,...................................

. 52-35-l
FRONT WHEEL ALIGNMENT Adjustment
.....................
. 338-86-I
Adjustment .................... 33A-5-l
FUEL FILTER
DOHC
.......................................
. 13-327-I
SOHC-8VALVE
.................................
13-l 15-l SOHC-IGVALVE
................................ 13-195-I
FUEL HOSES, Maintenance ............................
00-39-1
FUEL LINE
DOHC-AWD ..................................
.
13-326-l
DOHC-FWD....................................

.
13-324-l
SOHC-8VALVE
................................. 13-113-l
SOHC-1 ~VALVE............................

.
13-l 95-IFUEL PRESSURE
On-vehicle Inspection
On-vehicle Inspection

On-vehicle Inspection
FUEL PRESSURE SOLENOID ,
On-vehicle Inspection >
FUEL PUMP
On-vehicle Inspection
On-vehicle Inspection

On-vehicle Inspection
FUEL SYSTEM, Maintenanc

e
FUEL TANK
DOHC-AWD .,.......
DOHC-FW

D
SOHC-8VALVE
SOHC-16VALVE
FUEL TANK FILLER DOO

R
FUEL TANK FILLER TUBE CAP, Inspection
FUEL TANK PRESSURE CONTROL VALVE. 13-312-l
13-102-I
,.....13-I
92-l
13-307-I
......
13-258-l
....... 13-46-l
...... 13-147-l
....... 00-39-l
......
13-322-l
...... 13-318-l
..... 13-109-I
...... 13-195-I
....... 42-60-I
....... 17-21-I
....... 17-21-l
G
GARNISHES
51-13-l
GASKET
Cylinder Head 1 l-73-l
Cylinder Head 1 l-25-l
GAUGE UNIT, Engine Coolant Temperature
14-31-l
GEAR BOX, Power Steering 37A-32-l
GEAR OIL, Level Check
27-15-l
GENERATOR
16-g-11
GLASS
Door, Adjustmen
t
42-52-l
Door, Front 42-80-I
Door, Rear 42-83-l
Quarter Window 42-70-I
Window.............
.._......_...... 42-63-i
Window,Rear
42-72-i
GRILLE,Front
_. _. _.
51-12-l
G-SENSOR
Service Brakes
35-132-l
Output Voltage, Check 336-96-l
H
HANDLE
Door, Front
..........................
.
Door,Rear
...........................
Door Inside, Play Check. ..................
HAZARD SWITCH.........................
.
HEADLIGHTS............................

.
HEADLINING.............................

.
HEATED OXYGEN SENSOR, On-vehicle Inspection
>
...............................
HEATER CONTROL.......................
.
HEATER UNIT............................

.
HEIGHT SENSOR.........................

.
HIGH MOUNTED STOP LIGHT...............

.
42-96-1 42-99-l
42-52-l
54-98-11
54-92-11
52-31-l
13-290-I
55-25-l
55-30-I
338-l
35-l
54-96-11HIGH PRESSURE SWITCH (HIGH-PRESSURE TANK SIDE),Actuation Pressure Check. 338-94-I
16-42-11
42-55-l
42-50-I
54-l 03-11
54-105-11
HIGH TENSION CABLE, Spark Test
HOOD .__...._..._......__._...................
HOOD, Alignment Adjustment .
HOR

N
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . HORNRELAY

._.._._....___.........__.._._..___
HOSE
Brake, Maintenance
.
00-45-I
