2022 TOYOTA AVALON HYBRID Owners Manual

3615-1. Using the air conditioning system and defogger
5
Interior features
Individual mode (indicator off):
The temperature for the driver’s and front passenger’s side can be
adjusted separately.
■
Fan speed setting
To adjust the fan speed, press to increase the fan speed
and to decrease the fan speed.
Press to turn the fan off.
■
Change the airflow mode
To change the airflow mode,
press .
The air outlets used are
switched each time the button is
pressed.
Air flows to the upper body.
Air flows to the upper body
and feet.
Air flows to the feet.
Air flows to the feet and the
windshield defogger oper-
ates.
■Other functions
● Switching between outside air and recirculated air modes
(  P. 365)
● Defogging the windshield ( P. 3 6 5 )
● Defogging the rear window and outside rear view mirrors
(  P. 365)
1
2
3
4

3625-1. Using the air conditioning system and defogger
Adjust the driver’s side tem-
perature setting
Adjust the fan speed setting
Select the air flow mode
*
Adjust the front passenger’s
side temperature setting
Display the option control
screen (P. 363)
Turn automatic mode on/off
Turn the fan off
Turn cooling and dehumidifi cation function on/off
If the indicator is turned off, the system will blow ambient t em-
perature air or heated air.
Change the temperature setting between individual/synchronized
mode. ( P. 360)
Enable/Disable S-FLOW mode ( P. 363)
*: — Air flows to the upper body
— Air flows to the upper body and feet
— Air flows to the feet
— Air flows to the feet and the windshield defogger operates
Control screen
1
2
3
4
5
6
7
8
9
10

3635-1. Using the air conditioning system and defogger
5
Interior features
■Option control screen
Select on the air conditioning control screen to display the
option control screen. The funct ions can be switched on and off.
When the function is on, the indicator illuminates on the scree n.
Select to change the tem-
perature setting between
individual/synchronized
mode (P. 360)
Select to set cooling and
dehumidification function on/
off
Select the S-FLOW mode
(  P. 363)
■Using the automatic mode
Press or select on the air conditioning control
screen.
The dehumidification function begins to operate. Air outlets an d
fan speed are automatically adjusted according to the tempera-
ture setting.
Adjust the temperature setting.
To stop the operation, press or select on the air
conditioning control screen.
■Automatic mode indicator
If the fan speed setting or air flow modes are operated, the au to-
matic mode indicator goes off. However, automatic mode for func -
tions other than that o perated is maintained.
■S-FLOW mode
When the air conditioning system is operating in S-FLOW mode, a ir
conditioner efficiency will be enhanced by concentrating the ai rflow
on occupied seats only.
1
2
3
Air conditioning controls
1
2
3

3645-1. Using the air conditioning system and defogger
●The following S-FLOW modes are available:
Automatic S-FLOW mode
When this mode is selected, if the rear seats are determined to
be unoccupied, the air conditioning system will operate in S-
FLOW mode.
When a rear passenger is dete cted, S-FLOW mode will be auto-
matically disabled.
The indicator on the air conditioning control screen will illu mi-
nate when the air conditioning system is operating in S-FLOW mo de.
To enter manual S-FLOW mode, select on the air conditioning
control screen.
Manual S-FLOW mode
When is selected, S-FLOW mode will be manually
enabled/disabled.
The indicator on the air conditioning control screen will illu mi-
nate when the air conditioning system is operating in S-FLOW mo de.
●Operation of the air condition ing system when S-FLOW mode is
enabled:
When the air conditioning system is operating in S-FLOW mode,
the airflow will be concentrat ed on the front seats, reducing t he
airflow and air conditioning effect on the rear seats.
Additionally, if the front pass enger seat is determined to be u noc-
cupied, the airflow will be con centrated on the driver’s seat o nly.
(Depending on the set temperature or ambient temperature, the
air conditioning system may not operate in S-FLOW mode as
described above.)
When certain conditions are met and priority is given to the
driver’s seat only, the temperature indicator for the front pas sen-
ger side will turn off.
How the system judges if a seat is occupied in S-FLOW mode:
 P. 3 6 7

3655-1. Using the air conditioning system and defogger
5
Interior features
■Switching between outside air and recirculated air modes
Press .
The mode switches between outside air mode (indicator off) and recir-
culated air mode (indicator on) each time is pressed.
■
Defogging the windshield
Defoggers are used to defog the windshield and front side win-
dows.
Press .
The dehumidification function operates and fan speed increases.
Set the outside/recirculated air mode button to the outside air mode if
the recirculated air mode is used. (It may switch automatically .)
To defog the windshield and the side windows early, turn the ai r flow and
temperature up.
To return to the previous mode, press again when the windshiel d
is defogged.
■
Defogging the rear window and outside rear view mirrors
Defoggers are used to defog the rear window, and to remove rain -
drops, dew and frost from the outside rear view mirrors.
Press .
The defoggers will automatically turn off after a period of tim e.
Other functions

3665-1. Using the air conditioning system and defogger
■Location of air outlets
The air outlets and air volume
change according to the
selected airflow mode.
■Adjusting the position of and opening and closing the air out-
lets
Direct air flow to the le ft or right, up or down.
Turn the knob to open o r close the vent.
Air outlets
FrontRear
1
2

3675-1. Using the air conditioning system and defogger
5
Interior features
■Using automatic mode
Fan speed is adjusted automatically according to the temperatur e setting and
the ambient conditions.
Therefore, the fan may stop for a while until warm or cool air is ready to flow
immediately after is pressed or is selected.
■ How the system judges if a seat is occupied in S-FLOW mode
The system judges if a passenger is in the vehicle as follows:
• Front passenger seat: The front passenger seat is judged to be occupied when the syst em detects
an object on the front passenger seat, fastening of the front p assenger seat
belt, changing of the set temperature for the front passenger s eat, or the
opening and closing of the front passenger door. (However, when only
opening and closing of the front passenger door is detected, th e system will
judge that the passenger seat is unoccupied after the vehicle s peed
reaches approximately 12 mph (20 km/h) or more.)
• Rear seats (automatic S-FLOW mode only): The rear seats are judged to be occupied when the system detect s the
opening and closing of a rear door.
If a seat is judged to be occupied, the system will retain that judgement for 60
minutes after the power switch is turned off.
■ Changing from automatic S-FLOW mode to manual S-FLOW mode
When the system is operating in automatic S-FLOW mode, if a rea r door is
opened and then closed, S-FLOW mode will be disabled. To enable S-FLOW
mode, select on the air conditioning control screen. (In this case, the
system will operate in manual S-FLOW mode.)
■ Changing from manual S-FLOW mode to automatic S-FLOW mode
Select on the air conditioning control screen to disable S-FLO W
mode (check that indicator is not illuminated).
Turn the power switch off.
Wait for 60 minutes or more and change the power switch to ON m ode.
■ Fogging up of the windows
●The windows will easily fog up when the humidity in the vehicle is high.
Turning or on will dehumidify the air from the outlets and
defog the windshield effectively.
● If you turn or off, the windows may fog up more easily.
● The windows may fog up if the recirculated air mode is used.
1
2
3

3685-1. Using the air conditioning system and defogger
■When driving on dusty roads
Close all windows. If dust thrown up by the vehicle is still drawn into the vehi-
cle after closing the windows, it is recommended that the air i ntake mode be
set to outside air mode and the fan speed to any setting except off.
■ Outside/recirculated air mode
●Setting to the recirculated air mode temporarily is recommended in prevent-
ing dirty air from entering the vehicle interior and helping to cool the vehicle
when the outside air temperature is high.
● Outside/recirculated air mode may automatically switch dependin g on the
temperature setting or the inside temperature.
■ When the outside temperature exceeds 75°F (24°C) and the air co ndition-
ing system is on
● In order to reduce the air conditioning power consumption, the air condition-
ing system may switch to recirculated air mode automatically. This may also
reduce fuel consumption.
● Recirculated air mode is selected as a default mode when the power switch
is turned to ON mode.
● It is possible to switch to outside air mode at any time by pre ssing .
■ When the outside t emperature is low
The dehumidification function may not operate even when is pre ssed
or is selected.
■ Operation of the air conditioning system in Eco drive mode
●In the Eco drive mode, “ECO” is displayed on the air conditioni ng screen
and the air conditioning system is controlled as follows to pri oritize fuel effi-
ciency:
• Engine speed and compressor operation controlled to restrict h eating/
cooling capacity
• Fan speed restricted when automatic mode is selected
● To improve air conditioning performance, perform the following operations:
• Adjust the fan speed
• Turn off Eco drive mode
