2022 TOYOTA AVALON HYBRID Owners Manual

891-4. Theft deterrent system
1
For safety and security
■System maintenance
The vehicle has a maintenance-free type alarm system.
■ Items to check before locking the vehicle
To prevent unexpected triggering of the alarm and vehicle theft , make sure of
the following:
● Nobody is in the vehicle.
● The windows and moon roof (if equipped) are closed before the a larm is set.
● No valuables or other personal items are left in the vehicle.
■ Triggering of the alarm
The alarm may be triggered in the following situations:
(Stopping the alarm deactivates the alarm system.)
●The trunk is opened using the mechani-
cal key.
● A person inside the vehicle opens a door
or the trunk or hood, or unlocks the vehi-
cle.
● The 12-volt battery is recharged or
replaced when the vehicle is locked.
(P. 513)

901-4. Theft deterrent system
■Alarm-operated door lock
In the following cases, depending on the situation, the door ma y automatically
lock to prevent improper entry into the vehicle:
● When a person remaining in the vehicle unlocks the door and the alarm is
activated.
● While the alarm is activated, a person remaining in the vehicle unlocks the
door.
● When recharging or replacing the 12-volt battery
NOTICE
■To ensure the system operates correctly
Do not modify or remove the system. If modified or removed, the proper
operation of the system cannot be guaranteed.

91
Instrument cluster2
2. Instrument clusterWarning lights and indicators .......................... 92
Gauges and meters ............ 98
Multi-information display............................. 102
Head-up display ................ 123
Energy monitor/ consumption screen ........ 130

922. Instrument cluster
Warning lights and indicators
The warning lights and indicators on the instrument cluster, cen-
ter panel and outside rear view mirrors inform the driver of the
status of the vehicle’s various systems.
For the purpose of explanation, t he following illustrations dis-
play all warning lights a nd indicators illuminated.

932. Instrument cluster
2
Instrument cluster
Warning lights inform the driver of malfunctions in any of the vehicle’s
systems.
Warning lights
*1
(Red)
Brake system warning
light ( P. 478) Parking brake indicator
(
P. 480)
*1
(Yellow)
Brake system warning
light ( P. 478)*1, 3
Brake hold operated
indicator ( P. 480)
*2High coolant tempera-
ture warning light
(P. 478)*1
(Red/yellow)
Electric power steering
system warning light
(P. 480)
*2
Charging system
warning light ( P. 478)
*1
(Flashes or
illuminates)
PCS warning light
( P. 480)
*2
Low engine oil pressure
warning light ( P. 478)*1, 3
(if equipped)
ICS OFF indicator
(P. 481)
*1
Malfunction indicator
lamp ( P. 479)*2
(Amber)
LTA indicator ( P. 480)
*1SRS warning light
(P. 479)*1
Slip indicator ( P. 481)
*1ABS warning light
(P. 479)Low fuel level warning
light ( P. 481)
*2Inappropriate pedal
operation warning light
(P. 479)Driver’s and front
passenger’s seat belt
reminder light
(P. 481)

942. Instrument cluster
*1: These lights turn on when the power switch is turned to ON mode to indi-
cate that a system check is being performed. They will turn off after the
hybrid system is on, or after a few seconds. There may be a malfunction in
a system if a light does not come on, or turn off. Have the veh icle
inspected by your Toyota dealer.
*2: This light illuminates on the multi-information display.
*3: This light flashes to indicate a malfunction.
*4: This light illuminates on the center panel.
*4Rear passengers’ seat
belt reminder lights
( P. 481)*1Tire pressure warning
light ( P. 482)
*1Master warning light
(P. 481)

952. Instrument cluster
2
Instrument cluster
The indicators inform the driver of the operating state of the vehicle’s
various systems.
Indicators
Turn signal indicator
( P. 215)*2Dynamic radar cruise
control indicator
(P. 281)
Headlight indicator
( P. 222)
*2Cruise control “SET”
indicator
(P. 281)
Headlight high beam
indicator ( P. 222)
*1, 3PCS warning light
(P. 251)
*2Automatic High Beam
indicator ( P. 226)*1, 3
(if equipped)
ICS OFF indicator
(P. 324)
*2AGC (Auto Glide Con-
trol) indicator ( P. 343)*2, 4LTA indicator
(P. 247, 261)
Parking brake indicator
( P. 216)
*1, 5
Slip indicator ( P. 345)
*1Brake hold operated
indicator (P. 220)*1, 3VSC OFF indicator
(P. 346)
*1Brake hold standby
indicator ( P. 220)*2“BSM” indicator
(P. 297)
*2Cruise control indicator
(P. 281)*2“RCTA” indicator
(P. 297)

962. Instrument cluster
*6, 7BSM (Blind Spot Moni-
tor) outside rear view
mirror indicators
(P. 297)*2“ECO MODE” indicator
(P. 342)
*1, 8“AIR BAG
ON/OFF”
indicator
(P. 48)*2
EV drive mode indicator
(P. 206)
*8Security indicator
(P. 86, 88)*2
EV indicator ( P. 77)
*2
(if equipped)
Intuitive parking assist
indicator ( P. 313) “READY” indicator
(
P. 200)
*2
Smart key system indi-
cator (P. 200)*2, 9
Low outside tempera-
ture indicator ( P. 98)
*2“SPORT” indicator
(P. 342)
