2021 TOYOTA PRIUS Accessories, Audio & Navigation (in English)

105
PRIUS_Navi_OM47E22U_(U)
20.03.26 18:17
AUDIO SYSTEM
3
3. MEDIA OPERATION
1. USB MEMORY
*: This function is not made available in some countries or areas.
OVERVIEW
The USB memory operation screen can be reached by the following methods:
Connect a USB memory. ( P.85)
 Select “USB” on the “Select Audio Source” screen. ( P.84)
When an Apple CarPlay connection is established, this function will be unavail-
able.*
 USB audio
USB video

106
3. MEDIA OPERATION
PRIUS_Navi_OM47E22U_(U)
20.03.26 18:17
No.Function
AudioVideo
Select to select a folder/album.
Select to select a file/track.
 Select and hold to fast rewind.Select to select a file.
 Select and hold to fast rewind.
Select to play/pause.Select to play/pause.
 Select to select a file/track.
 Select and hold to fast forward.Select to select a file.
 Select and hold to fast forward.
Select to set repeat playback. ( P.108)
Select to set random playback. ( P.108)
Select to display the play mode selection
screen.
To return to the top screen, select “Now
playing” on the list screen. Select to display the play mode selection
screen.
To return to the top screen, select “Now
playing” on the list screen.
Displays cover art
 Select to display a file/track list.
To return to the top screen, select “Now
playing” on the list screen.

Select to display expanded screen video.

107
3. MEDIA OPERATION
PRIUS_Navi_OM47E22U_(U)
20.03.26 18:17
AUDIO SYSTEM
3
Select to display the option screen.
( P.108)
Select to stop the video screen.
Select to display the file information.
WA R N I N G
● Do not operate the player’s contr ols or connect the USB memory while driving.
NOTICE
●Do not leave your portable player in the car. In particular, hi gh temperatures inside the
vehicle may damage the portable player.
● Do not push down on or apply unnecessary pressure to the portable player while it is con-
nected as this may damage the portable player or its terminal.
● Do not insert foreign objects into the port as this may damage the portable player or its
terminal.
INFORMATION
● The system can only output the sound while driving.
No.Function
AudioVideo

108
3. MEDIA OPERATION
PRIUS_Navi_OM47E22U_(U)
20.03.26 18:17
1Select the repeat button to change on/
off.
1Select the shuffle button to change on/
off.
1Select “Options” .
2Select the desired setting to change.
USB AUDIO
REPEATING
The file/track currently being listened
to can be repeated.
RANDOM ORDER
Files/tracks can be automatically and
randomly selected.
USB VIDEO
To change to USB video mode, select
“Browse” on the USB audio screen,
then select the “Video” tab and select
the desired video file.
USB VIDEO OPTIONS
No.FunctionPage
Select to change the screen
size. 87
Select to display the image
quality adjustment screen.88

109
3. MEDIA OPERATION
PRIUS_Navi_OM47E22U_(U)
20.03.26 18:17
AUDIO SYSTEM
3
2. iPod
*: When an Apple CarPlay connection is established, this switch will not be displayed.
OVERVIEW
The iPod operation screen can be reached by the following metho ds:
Connect an iPod. ( P.85)
 Select “iPod (DEVICE NAME)” on the “Select Audi o Source” screen. (P.84)
No.Function
Displays cover art
 Select to display a track list.
To return to the top screen, sel ect “Now Playing” on the list screen.
*Select to display the play mode selection screen.
To return to the top screen, select “Now Playing” on the list screen.
Select to set random playback.
Select to set repeat playback.
Press to select a track.
 Press and hold to fast forward.
Select to play/pause.
Press to select a track.
 Press and hold to fast rewind.

110
3. MEDIA OPERATION
PRIUS_Navi_OM47E22U_(U)
20.03.26 18:17
WA R N I N G
●Do not operate the player’s controls or connect the iPod while driving.
NOTICE
●Do not leave your portable player in the car. In particular, hi gh temperatures inside the
vehicle may damage the portable player.
● Do not push down on or apply unnecessary pressure to the portab le player while it is con-
nected as this may damage the portable player or its terminal.
● Do not insert foreign objects into the port as this may damage the portable player or its
terminal.

111
3. MEDIA OPERATION
PRIUS_Navi_OM47E22U_(U)
20.03.26 18:17
AUDIO SYSTEM
3
INFORMATION
●When an iPod is connected using a genuine iPod cable, the iPod starts charging its bat-
tery.
● Depending on the iPod and the songs in the iPod, iPod cover art may be displayed. This
function can be changed to on/off. ( P.121) It may take time to display iPod cover art,
and the iPod may not be operated while the cover art display is in process.
● When an iPod is connected and the audio source is changed to iP od mode, the iPod will
resume playing from the same point it was last used.
● Depending on the iPod that is connected to the system, certain functions may not be
available.
● Files/tracks selected by operating a connected iPod may not be recognized or displayed
properly.
● If an iPhone is connected via Bluetooth
® and USB at the same time, system operation
may become unstable.
For known phone compatibility information, refer to https://www .toyota.com/audio-
multimedia/.

112
3. MEDIA OPERATION
PRIUS_Navi_OM47E22U_(U)
20.03.26 18:17
1Select the repeat button to change on/
off.
1Select the shuffle button to change on/
off.
iPod AUDIO
REPEATING
The track currently being listened to
can be repeated.
RANDOM ORDER
Tracks can be automatically and ran-
domly selected.
