2021 TOYOTA C-HR Owners Manual (in English)

3295-3. Using the storage features
5
Interior features
C-HR_OM_USA_OM10684U
Cup holders
The rear cup holder can have the partition
turned over, removed, and the depth
changed.
WARNING
●Do not place anything other than cups or aluminum cans in the cup hold-
ers.
Other items may be thrown out of the holders in the event of an accident or
sudden braking, causing injury.
● Observe the following precautions.
Failure to do so may result in serious injury such as burns.
• Close the lid on drinks that are hot.
• Check that the item can be sustained by the internal support.
• Take care to not let the cup height exceed armrest height.
• Do not use the partition in the front cup holder as it is only for use with
the rear cup holder.

3305-3. Using the storage features
C-HR_OM_USA_OM10684U
Luggage compartment features
Cargo hooks are provided for
securing loose items.
Cargo hooks
WARNING
To avoid injury, always return the cargo hooks to their positio ns when they
are not in use.
Grocery bag hooks
NOTICE
Do not hang any object heavier than 4.4 lb. (2 kg) on the groce ry bag hook.

3315-3. Using the storage features
5
Interior features
C-HR_OM_USA_OM10684U
Lift the deck mat tab and pull it
toward you to remove it.
Auxiliary boxes
Side auxiliary boxes

3325-3. Using the storage features
C-HR_OM_USA_OM10684U
Hard type
Unhook the cords and return
the luggage cover to horizontal
position.
Ty p e A
Pull it toward you and then lift
the luggage cover to remove
it.
Installation position
Confirm that the cover has
been securely installed to the
original position when install-
ing.
Removal position
Ty p e B
Lift the luggage cover and
pull it toward you to remove
it.
Confirm that the cover has been
securely installed to the original
position when installing.
Luggage cover
1
2
2

3335-3. Using the storage features
5
Interior features
C-HR_OM_USA_OM10684U
Soft type
■Removing the luggage cover
Unhook the cords.
Unhook the hook to the hook
brackets.
■Stowing the luggage cover
Hold the luggage cover with
both hands. Point your
thumbs in opposite direc-
tions.
1
2
1

3345-3. Using the storage features
C-HR_OM_USA_OM10684U
Bend one side of the cover
towards you.
Twist the other side in the
opposite direction, as shown
in the illustration.
Make a small circle, then fold
it inward.
Make sure the three circles
are side by side.2
3
4
5

3355-3. Using the storage features
5
Interior features
C-HR_OM_USA_OM10684U
Make sure the luggage cover
is properly folded.6
WARNING
Observe the following precautions.
Failure to do so may result in death or serious injury.
●Do not place anything on the luggage cover. In the event of sudden brak-
ing or turning, the item may go flying and strike an occupant.
● Do not allow children to climb on the luggage cover. Climbing o n the lug-
gage cover could result in damage to the luggage cover.
● Soft type luggage cover only: Be sure to properly fold the luggage cover.
Otherwise it could unexpectedly unfold.
● Soft type luggage cover only: Be sure to attach the cords correctly to pre-
vent the cover from flying off.
NOTICE
Soft type luggage cover only: Do not apply too much force when folding the
luggage cover. Doing so may damage the luggage cover.

3365-4. Using the other interior features
C-HR_OM_USA_OM10684U
Other interior features
To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.
To use the side extender, place
the visor in the side position,
then slide it backward. (if
equipped)
Slide the cover to open.
The light turns on when the cover
is opened. (if equipped)
Sun visors
Vanity mirrors
