2021 TOYOTA AVALON HYBRID Owners Manual (in English)

337
5Interior features
5-1. Using the
air conditioning system
and defogger
Automatic air conditioning
system............................. 338
Heated steering wheel/
seat heaters/
seat ventilators ................ 349
5-2. Using the interior lights
Interior lights list ................ 352
• Interior light ................... 353
• Personal lights .............. 353
• Ambient lights ............... 3545-3. Using the storage
features
List of storage features ..... 355
• Glove box...................... 356
• Console box .................. 356
• Bottle holders ................ 357
• Cup holders .................. 358
• Auxiliary boxes.............. 359
• Open tray ...................... 360
Trunk features ................... 361
5-4. Other interior features
Other interior features ....... 362
• Sun visors ..................... 362
• Vanity mirrors................ 362
• Power outlet .................. 363
• USB charging ports....... 364
• Wireless charger ........... 366
• Armrest ......................... 375
• Assist grips ................... 375
• Coat hooks.................... 376
Garage door opener.......... 377

3385-1. Using the air conditioning system and defogger
■Adjusting the temperature setting
To adjust the temperature setting, press “ ” on (driver’s
side) to increase the temperature and press “ ” on
(driver’s side) to decrease the temperature.
If is not pressed, the system will blow ambient temperature air or
heated air.
The air conditioning system switches between individual and synchro-
nized modes each time is pressed or is selected on the
air conditioning control screen.
Synchronized mode (indicator on):
The driver’s side can be used to adjust the temperature for the
driver’s and front passenger’s side. To enter individual mode, operate
the front passenger’s side .
Automatic air conditioning system
Air outlets and fan speed are automatically adjusted according
to the temperature setting.
Press the “MENU” button on the Audio Plus or Premium Audio,
then select “Climate” to display the air conditioning control
screen.
Control panel

3395-1. Using the air conditioning system and defogger
5
Interior features
Individual mode (indicator off):
The temperature for the driver’s and front passenger’s side can be
adjusted separately.
■
Fan speed setting
To adjust the fan speed, press to increase the fan speed
and to decrease the fan speed.
Press to turn the fan off.
■
Change the airflow mode
To change the airflow mode,
press .
The air outlets used are
switched each time the button is
pressed.
Air flows to the upper body.
Air flows to the upper body
and feet.
Air flows to the feet.
Air flows to the feet and the
windshield defogger oper-
ates.
■Other functions
●Switching between outside air and recirculated air modes
(P. 343)
●Defogging the windshield (P. 3 4 3 )
●Defogging the rear window and outside rear view mirrors
(P. 343)
1
2
3
4

3405-1. Using the air conditioning system and defogger
Adjust the driver’s side tem-
perature setting
Adjust the fan speed setting
Select the air flow mode
*
Adjust the front passenger’s
side temperature setting
Display the option control
screen (P. 341)
Turn automatic mode on/off
Turn the fan off
Turn cooling and dehumidification function on/off
If the indicator is turned off, the system will blow ambient tem-
perature air or heated air.
Change the temperature setting between individual/synchronized
mode. (P. 338)
Enable/Disable S-FLOW mode (P. 341)
*: — Air flows to the upper body
— Air flows to the upper body and feet
— Air flows to the feet
— Air flows to the feet and the windshield defogger operates
Control screen
1
2
3
4
5
6
7
8
9
10

3415-1. Using the air conditioning system and defogger
5
Interior features
■Option control screen
Select on the air conditioning control screen to display the
option control screen. The functions can be switched on and off.
When the function is on, the indicator illuminates on the screen.
Select to change the tem-
perature setting between
individual/synchronized
mode (P. 338)
Select to set cooling and
dehumidification function on/
off
Select the S-FLOW mode
(P. 341)
■Using the automatic mode
Press or select on the air conditioning control
screen.
The dehumidification function begins to operate. Air outlets and
fan speed are automatically adjusted according to the tempera-
ture setting.
Adjust the temperature setting.
To stop the operation, press or select on the air
conditioning control screen.
■Automatic mode indicator
If the fan speed setting or air flow modes are operated, the auto-
matic mode indicator goes off. However, automatic mode for func-
tions other than that operated is maintained.
■S-FLOW mode
When the air conditioning system is operating in S-FLOW mode, air
conditioner efficiency will be enhanced by concentrating the airflow
on occupied seats only.
1
2
3
Air conditioning controls
1
2
3

3425-1. Using the air conditioning system and defogger
●The following S-FLOW modes are available:
Automatic S-FLOW mode
When this mode is selected, if the rear seats are determined to
be unoccupied, the air conditioning system will operate in S-
FLOW mode.
When a rear passenger is detected, S-FLOW mode will be auto-
matically disabled.
The indicator on the air conditioning control screen will illumi-
nate when the air conditioning system is operating in S-FLOW mode.
To enter manual S-FLOW mode, select on the air conditioning
control screen.
Manual S-FLOW mode
When is selected, S-FLOW mode will be manually
enabled/disabled.
The indicator on the air conditioning control screen will illumi-
nate when the air conditioning system is operating in S-FLOW mode.
●Operation of the air conditioning system when S-FLOW mode is
enabled:
When the air conditioning system is operating in S-FLOW mode,
the airflow will be concentrated on the front seats, reducing the
airflow and air conditioning effect on the rear seats.
Additionally, if the front passenger seat is determined to be unoc-
cupied, the airflow will be concentrated on the driver’s seat only.
(Depending on the set temperature or ambient temperature, the
air conditioning system may not operate in S-FLOW mode as
described above.)
When certain conditions are met and priority is given to the
driver’s seat only, the temperature indicator for the front passen-
ger side will turn off.
How the system judges if a seat is occupied in S-FLOW mode:
P. 3 4 5

3435-1. Using the air conditioning system and defogger
5
Interior features
■Switching between outside air and recirculated air modes
Press .
The mode switches between outside air mode (indicator off) and recir-
culated air mode (indicator on) each time is pressed.
■
Defogging the windshield
Defoggers are used to defog the windshield and front side win-
dows.
Press .
The dehumidification function operates and fan speed increases.
Set the outside/recirculated air mode button to the outside air mode if
the recirculated air mode is used. (It may switch automatically.)
To defog the windshield and the side windows early, turn the air flow and
temperature up.
To return to the previous mode, press again when the windshield
is defogged.
■
Defogging the rear window and outside rear view mirrors
Defoggers are used to defog the rear window, and to remove rain-
drops, dew and frost from the outside rear view mirrors.
Press .
The defoggers will automatically turn off after a period of time.
Other functions

3445-1. Using the air conditioning system and defogger
■Location of air outlets
The air outlets and air volume
change according to the
selected airflow mode.
■Adjusting the position of and opening and closing the air out-
lets
Direct air flow to the left or right, up or down.
Turn the knob to open or close the vent.
Air outlets
FrontRear
1
2
