2021 TOYOTA AVALON HYBRID Owners Manual (in English)

3455-1. Using the air conditioning system and defogger
5
Interior features
■Using automatic mode
Fan speed is adjusted automatically according to the temperature setting and
the ambient conditions.
Therefore, the fan may stop for a while until warm or cool air is ready to flow
immediately after is pressed or is selected.
■How the system judges if a seat is occupied in S-FLOW mode
The system judges if a passenger is in the vehicle as follows:
• Front passenger seat:
The front passenger seat is judged to be occupied when the system detects
an object on the front passenger seat, fastening of the front passenger seat
belt, changing of the set temperature for the front passenger seat, or the
opening and closing of the front passenger door. (However, when only
opening and closing of the front passenger door is detected, the system will
judge that the passenger seat is unoccupied after the vehicle speed
reaches approximately 12 mph (20 km/h) or more.)
• Rear seats (automatic S-FLOW mode only):
The rear seats are judged to be occupied when the system detects the
opening and closing of a rear door.
If a seat is judged to be occupied, the system will retain that judgement for 60
minutes after the power switch is turned off.
■Changing from automatic S-FLOW mode to manual S-FLOW mode
When the system is operating in automatic S-FLOW mode, if a rear door is
opened and then closed, S-FLOW mode will be disabled. To enable S-FLOW
mode, select on the air conditioning control screen. (In this case, the
system will operate in manual S-FLOW mode.)
■Changing from manual S-FLOW mode to automatic S-FLOW mode
Select on the air conditioning control screen to disable S-FLOW
mode (check that indicator is not illuminated).
Turn the power switch off.
Wait for 60 minutes or more and change the power switch to ON mode.
■Fogging up of the windows
●The windows will easily fog up when the humidity in the vehicle is high.
Turning or on will dehumidify the air from the outlets and
defog the windshield effectively.
●If you turn or off, the windows may fog up more easily.
●The windows may fog up if the recirculated air mode is used.
1
2
3

3465-1. Using the air conditioning system and defogger
■When driving on dusty roads
Close all windows. If dust thrown up by the vehicle is still drawn into the vehi-
cle after closing the windows, it is recommended that the air intake mode be
set to outside air mode and the fan speed to any setting except off.
■Outside/recirculated air mode
●Setting to the recirculated air mode temporarily is recommended in prevent-
ing dirty air from entering the vehicle interior and helping to cool the vehicle
when the outside air temperature is high.
●Outside/recirculated air mode may automatically switch depending on the
temperature setting or the inside temperature.
■When the outside temperature exceeds 75°F (24°C) and the air condition-
ing system is on
●In order to reduce the air conditioning power consumption, the air condition-
ing system may switch to recirculated air mode automatically. This may also
reduce fuel consumption.
●Recirculated air mode is selected as a default mode when the power switch
is turned to ON mode.
●It is possible to switch to outside air mode at any time by pressing .
■When the outside temperature is low
The dehumidification function may not operate even when is pressed
or is selected.
■Operation of the air conditioning system in Eco drive mode
●In the Eco drive mode, “ECO” is displayed on the air conditioning screen
and the air conditioning system is controlled as follows to prioritize fuel effi-
ciency:
• Engine speed and compressor operation controlled to restrict heating/
cooling capacity
• Fan speed restricted when automatic mode is selected
●To improve air conditioning performance, perform the following operations:
• Adjust the fan speed
• Turn off Eco drive mode

3475-1. Using the air conditioning system and defogger
5
Interior features
■Ventilation and air conditioning odors
●To let fresh air in, set the air conditioning system to the outside air mode.
●During use, various odors from inside and outside the vehicle may enter into
and accumulate in the air conditioning system. This may then cause odor to
be emitted from the vents.
●To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air
mode prior to turning the vehicle off.
• The start timing of the blower may be delayed for a short period of time
immediately after the air conditioning system is started in automatic
mode.
■Air conditioning filter
P. 432
■Air conditioning system refrigerant
●The meaning of each symbol on the label are as follows:
■Customization
Some functions can be customized. (P. 533) ●A label regarding the refrigerant of the
air conditioning system is attached to the
hood at the location shown in the follow-
ing illustration.
Caution
Air conditioning system
Air conditioning system lubricant type
Requires registered technician to service air conditioning
system
Flammable refrigerant

3485-1. Using the air conditioning system and defogger
WARNING
■To prevent the windshield from fogging up
●Do not use during cool air operation in extremely humid weather.
The difference between the temperature of the outside air and that of the
windshield can cause the outer surface of the windshield to fog up, block-
ing your vision.
■To prevent burns
Do not touch the rear view mirror surfaces when the outside rear view mirror
defoggers are on.
NOTICE
■To prevent 12-volt battery discharge
Do not leave the air conditioning system on longer than necessary when the
hybrid system is stopped.
■When repairing/replacing parts of the air conditioning system
Have repair/replacement performed by your Toyota dealer.
When a part of the air conditioning system, such as the evaporator, is to be
replaced, it must be replaced with a new one.
●Do not place anything on the instrument
panel which may cover the air outlets.
Otherwise, air flow may be obstructed,
preventing the windshield defoggers
from defogging.

3495-1. Using the air conditioning system and defogger
5
Interior features
: If equipped
Heated steering wheel/seat heaters/seat
ventilator s

Heated steering wheel and seat heaters heat the side grips of the
steering wheel and seats, respectively. Seat ventilators maintain
good ventilation by pulling air through the seat upholstery.
WARNING
●Care should be taken to prevent injury if anyone in the following categories
<004600520050004800560003004c0051000300460052005100570044004600570003005a004c0057004b00030057004b0048000300560057004800480055004c0051004a0003005a004b00480048004f000300440051004700030056004800440057005600
03005a004b0048005100030057004b00480003004b00480044[ter is on:
• Babies, small children, the elderly, the sick and the physically chal-
lenged
• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sleeping
drugs, cold remedies, etc.)
●<003200450056004800550059004800030057004b0048000300490052004f004f0052005a004c0051004a00030053005500480046004400580057004c0052005100560003005700520003005300550048005900480051005700030050004c00510052005500
03004500580055005100560003005200550003005200590048[rheating:
• Do not cover the seat with a blanket or cushion when using the seat
heater.
• Do not use seat heater more than necessary.
NOTICE
●Do not put heavy objects that have an uneven surface on the seat and do
not stick sharp objects (needles, nails, etc.) into the seat.
●To prevent 12-volt battery discharge, do not use the functions when the
hybrid system is off.

3505-1. Using the air conditioning system and defogger
Turns the heated steering wheel
on/off
The indicator light comes on when
the heated steering wheel is oper-
ating.
The heated steering wheel can be used when the power switch is in ON
mode.
■
Front
Each time the switch is pressed, the operation condition changes as
follows.
Hi (3 segments lit)  Mid (2 segments lit)  Lo (1 segment lit)  Off
The level indicator lights up during operation.
Heated steering wheel
Seat heaters
Without seat ventilatorsWith seat ventilators

3515-1. Using the air conditioning system and defogger
5
Interior features
■Rear (if equipped)
Turns the heated rear seat on/off
The indicator light will illuminate
when the rear seat heater is oper-
ating.
The seat heaters can be used when the power switch is in ON mode.
Each time the switch is pressed,
the operation condition changes
as follows.
Hi (3 segments lit)  Mid (2 seg-
ments lit)  Lo (1 segment lit) 
Off
The level indicator lights up during
operation.
■The seat ventilators can be used when
The power switch is in ON mode.
■Air conditioning system-linked control mode
When a seat ventilator is set to Hi, the fan speed of the seat ventilator may
increase according to the fan speed of the air conditioning system
Seat ventilators

3525-2. Using the interior lights
Front interior/personal lights (P. 353)
Shift lever light
Ambient lights (if equipped) (P. 3 5 4 )
Door courtesy lights
Rear personal lights (P. 3 5 3 )
Footwell lights
Front center console light
Interior lights list
1
2
3
4
5
6
7
