4255-3. Owner Maintenance
5
Maintenance and Care
Turn the socket and bulb
assembly to remove it. Care-
fully remove the bulb from its
socket in the reflector by
gently pulling it straight back-
ward out of the socket.
Install the new bulb in the reverse order of the removal proce-
dure.5
6

4265-3. Owner Maintenance
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
■Rear turn signal lights, Brake lights/Taillights/Rear side-marker
lights
4-Door
Make sure the ignition is swit ched off, and the headlight switc h is
off.
Remove the cover.
Turn the socket and bulb assembly counterclockwise and
remove it.
Disconnect the bulb from the socket.
1
2
3
4
Rear turn signal lights: Brake lights/Taillights/Rear side-
marker lights:

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
4275-3. Owner Maintenance
5
Maintenance and Care
Install the new bulb in the reverse order of the removal proce-
dure.
Insert the cover tabs and install the cover.
Verify that the cover is securely installed.
5-Door
Make sure the ignition is swit ched off, and the headlight switc h is
off.
Turn the bolts counterclock-
wise and remove them.
Pull the unit rearward to
remove it.
Turn the socket and bulb assembly counterclockwise and
remove it.
Disconnect the bulb from the socket.
5
6
1
2
3
4
5
Rear turn signal lights: Brake lights/Taillights:

4285-3. Owner Maintenance
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
Install the new bulb in the reverse order of the removal proce-
dure.
■Reverse lights
4-Door
Make sure the ignition is switched off, and the headlight switc h is
off.
Pull the center of each plastic
retainers and remove them.
Removal
Installation
Remove the trunk lid trim.
Disconnect the electrical
connector from the bulb by
pressing the tab on the con-
nector with your finger and
pulling the connector.
Rear side-marker lights:
6
1
2
1
2
3
4

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
4295-3. Owner Maintenance
5
Maintenance and Care
Turn the socket and bulb
assembly counterclockwise
and remove it.
Disconnect the bulb from the
socket.
Install the new bulb in the reverse order of the removal proce-
dure.
5-Door
Make sure the ignition is switched off, and the headlight switc h is
off.
Pull the center of each plastic
retainer and remove the
retainers.
Removal
Installation
Remove the trunk lid trim.
Disconnect the connector
from the socket.
5
6
7
1
2
1
2
3
4

4305-3. Owner Maintenance
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
Turn the socket and bulb
assembly counterclockwise
and remove it.
Disconnect the bulb from the
socket.
Install the new bulb in the reverse order of the removal proce-
dure.5
6
7

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
4315-3. Owner Maintenance
5
Maintenance and Care
■License plate lights
4-Door
Make sure the ignition is switched off, and the headlight switc h is
off.
Pull the center of each plastic
retainers and remove them.
Removal
Installation
Peel back the trunk lid trim.
Turn the socket and bulb
assembly counterclockwise
and remove it.
Disconnect the bulb from the
socket.
Install the new bulb in the reverse order of the removal proce-
dure.
5-Door
Make sure the ignition is swit ched off, and the headlight switc h is
off.
Wrap a flathead screwdriver with a soft cloth to prevent damage
to the light unit.
Insert a flathead screwdriver
into the position shown in the
figure and pull the light unit
outward.
1
2
1
2
3
4
5
6
1
2
3

4325-3. Owner Maintenance
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
Disconnect the connector
from the bulb by pressing the
tab on the connector with
your finger and pulling the
connector.
Turn the socket and bulb
assembly counterclockwise
and remove it.
Disconnect the bulb from the
socket.
Install the new bulb in the reverse order of the removal proce-
dure.
■Headlights/Daytime running lights (With LED headlights), Side
turn signal lights (if equipped), High-mount brake light
The LED bulb cannot be replaced as a single unit because it is an
integrated unit. The LED bulb has to be replaced with the unit. We
recommend your Toyota dealer when the replacement is necessary.
■ Headlights/Daytime running lights
●To replace the bulb, contact your Toyota dealer.
● If the halogen bulb is accidentally touched, it should be clean ed with rubbing
alcohol before being used.
● Use the protective cover and carton of the replacement bulb to dispose of
the old bulb promptly out of the reach of children.
● When reinstalling the sealing cover, make sure it is fitted cor rectly.
4
5
6
7
