2020 TOYOTA YARIS HATCHBACK Owners Manual (in English)

177
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
3-3. Transaxle
3
When Driving
Manual Transaxle Operation
The shift pattern of the transaxle
is conventional, as shown.
Depress the clutch pedal all the
way down while shifting; then
release it slowly.
Your vehicle is equipped with a
device to prevent shifting to R
(reverse) by mistake. Push the
shift lever downward and shift to
R.
If shifting to R is difficult, shift back into neutral, release the clutch pedal, and
try again.
Manual Transaxle Shift Pattern
Neutral position
WARNING
■Do not use sudden engine braking on slippery road surfaces or at high
speeds
Shifting down while driving on wet, snowy, or frozen roads, or while driving
at high speeds causes sudden engine braking, which is dangerous . The
sudden change in tire speed could cause the tires to skid. This could lead to
loss of vehicle control and an accident.
■ Always leave the shift lever in 1 or R position and set the par king brake
when leaving the vehicle unattended
Otherwise the vehicle could move and cause an accident.

178
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
3-3. Transaxle
The gear shift indicator supports you to obtain optimum fuel economy
and smooth driving. It displays the selected gear position in t he com-
bination meter as well as notifies the driver to change to the most suit-
able gear position corresponding to the actual driving condition.
Selected gear position
Suitable gear position
The gear shift indicator turns off when the following operations are performed.
● The vehicle is stopped.
● The vehicle is put in neutral.
● The vehicle is driven in reverse.
● The clutch is not fully engaged when accelerating from a stop.
● The clutch pedal remains depressed for 2 seconds or longer whil e driving.
NOTICE
●Keep your foot off the clutch pedal except when shifting gears. Also, do
not use the clutch to hold the vehicle on an upgrade. Riding th e clutch will
cause needless clutch wear and damage.
● Do not apply any excessive lateral force to the shift lever when changing
from 5th to 4th gear. This could lead to the accidental selecti on of 2nd
gear, which could result in damage to the transaxle.
● Make sure the vehicle comes to a complete stop before shifting to R. Shift-
ing to R while the vehicle is still moving may damage the trans axle.
Gear Shift Indicator
1
2
IndicationCondition
NumeralThe selected gear position is displayed.
and numeralShift up or down to the indicated gear position is rec-
ommended.

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
1793-3. Transaxle
3
When Driving
■Upshifting
For normal acceleration, Toyota recommends these shift points:
For cruising, Toyota recom mends these shift points:
WARNING
Do not rely solely on the shift-up/shift-down recommendations by indica-
tions. The actual driving situation might require shift operations different
from indication. To avoid the risk of accidents, the road and t raffic conditions
have to be judged correctly by the driver before shifting.
Recommendations for Shifting
GearVehicle speed
1 to 217 mph (27 km/h)
2 to 327 mph (43 km/h)
3 to 437 mph (60 km/h)
4 to 547 mph (76 km/h)
5 to 655 mph (89 km/h)
GearVehicle speed
1 to 211 mph (18 km/h)
2 to 319 mph (30 km/h)
3 to 430 mph (48 km/h)
4 to 539 mph (63 km/h)
5 to 651 mph (82 km/h)

180
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
3-3. Transaxle
■Downshifting
When you must slow down in heavy traffic or on a steep upgrade,
downshift before the engine starts to overwork. This reduces the
chance of stalling and gives bet ter acceleration when you need
more speed.
On a steep downgrade, downshifting helps maintain safe speed
and prolongs brake life.

181
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
3-3. Transaxle
3
When Driving
Automatic Transaxle Controls
Various Lockouts:
The Sport AT has an option that is not included in the traditional automatic
transaxle that gives the driver the option of selecting each ge ar instead of
leaving it to the transaxle to shift gears. Even if you intend to use the auto-
matic transaxle functions as a traditional automatic, you shoul d also be aware
that you can inadvertently shift into manual shift mode and an inappropriate
gear may be retained as the vehicle speed increases. If you not ice the engine
speed going higher or hear the engine racing, confirm you have not acciden-
tally slipped into manual shift mode ( P. 185).
Lock-release button
Indicates that you must depress the brake pedal and hold in
the lock-release button to shift (The ignition must be
switched ON).
Indicates the selector lever can be shifted freely into any
position.
Indicates that you must hold in the lock-release button to
shift.

182
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
3-3. Transaxle
The selector position is indicated
when the ignition is switched ON.
■Gear position indication
In manual shift mode, the “M” of the shift position indication illumi-
nates and the numeral for the selected gear is displayed.
The warning light turns on when the system has a malfunction.
Refer to Warning Lights on P. 173.
• The shift position indicator light in the combination meter il lumi-
nates. Refer to Warning/I ndicator Lights on P. 173.
• The selector lever must be in P or N to operate the starter.
■P (Park)
P locks the transaxle and prevent s the front wheels from rotating.
■R (Reverse)
In position R, the vehicle moves only backward. You must be at a
complete stop before shifting to or from R, except under rare c ir-
cumstances as explained i n Rocking the Vehicle (P. 145).
■N (Neutral)
In N, the wheels and transaxle a re not locked. The vehicle will roll
freely even on the slightest inc line unless the parking brake o r
brakes are on.
Apply the parking brake or depress the brake pedal before moving the
selector lever from N to prevent the vehicle from moving unexpe ctedly.
■
D (Drive)
D is the normal driving position. From a stop, the transaxle wi ll
automatically shift through a 6-gearsequence.
Shift Position Indication
Warning Light
Transaxle Ranges

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
1833-3. Transaxle
3
When Driving
■M (Manual)
M is the manual shift mode position. Gears can be shifted up or
down by operating the selector lever. Refer to Manual Shift Mode
on P. 185.
WARNING
■ Always set the selector lever to P and set the parking brake wh en park-
ing
Only setting the selector lever to the P position without using the parking
brake to hold the vehicle is dangerous. If P fails to hold, the vehicle could
move and cause an accident.
■ If the engine is running faster than idle, do not shift from N or P into a
driving gear
It’s dangerous to shift from N or P into a driving gear when th e engine is run-
ning faster than idle. If this is done, the vehicle could move suddenly, caus-
ing an accident or serious injury.
■ Do not shift into N when driving the vehicle
Shifting into N while driving is dangerous. Engine braking cann ot be applied
when decelerating which could lead to an accident or serious in jury.
NOTICE
●Shifting into P, N or R while the vehicle is moving can damage your tran-
saxle.
● Shifting into a driving gear or reverse when the engine is runn ing faster
than idle can damage the transaxle.
● Do not shift into N when driving the vehicle. Doing so can cause transaxle
damage.

184
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
3-3. Transaxle
Active Adaptive Shift (AAS) automatically controls the transaxle shift
points to best suit the road conditions and driver input. This improves
driving feel. The transaxle may switch to AAS mode when driving up
and down slopes, cornering, driving at high elevations, or depressing
the accelerator pedal quickly while the selector lever is in th e D posi-
tion. Depending on the road and driving conditions/vehicle oper ations,
gear shifting could be delayed or not occur, however, this does not
indicate a problem because the AAS mode will maintain the optim um
gear position.
The shift-lock system prevents s hifting out of P unless the brake pedal
is depressed.
To shift from P:
Depress and hold the brake pedal.
Start the engine.
Press and hold the lock-release button.
Move the selector lever.
● When the ignition is switched to ACC or the ignition is switche d off, the
selector lever cannot be shifted from P.
● The ignition cannot be switched to OFF if the selector lever is not in P.
Active Adaptive Shift (AAS)
Shift-Lock System
1
2
3
4
